SUBARU IMPREZA 2002 2.G Owners Manual

Audio
5-24
press any of the other mode buttons “FM” (2), “AM”
(1) and “TAPE” (12), the player will enter standby
mode. Press the “CD” button to start playback.
n Loading all the magazine (Full disc loading mode)
1. If you continue to press the “LOAD” button for
more than 1.5 seconds, the player will produce beep sound and will enter the full disc loading mode.
2. A “DISC” indicator will blink, and the “IN” will be
on display for a period of 15 seconds. If a disc issuccessfully loaded during this period, the “DISC”
indicator will stop blinking and will steadily light.
3. When the loading of a disc is complete, the next
“DISC” indicator will blink. Then repeat Step 2.
4. When the magazine is filled with discs by repeat-
ing Steps 2 and 3, the player will start playback of
the discs, beginning with the one inserted first.
If you fail to insert any disc during each 15-second interval, the full disc loading mode will be canceled,
and the player will start playback of the disc in-
serted first.
How to play back a CD or make a pause
n When there is no CD inserted:
Insert a CD by referring to “How to Insert a CD(s) ”.When a CD is loaded, the player will start playback
of the CD, beginning with the first number.
n When there are CDs loaded:
Press a desired one of the “DISC SELECT ” buttons
(26) the “DISC” indicator of which steadily lights up.
The player will then start playback of the selected
CD, beginning with the first number.
Selecting a desired track (TRACK)
HS5005BA
❚: Skipping forward
❚ : Skipping backward
: Fast forwarding
: Fast reversing

Audio
5-25
– CONTINUED –
nSkipping forward
Turn the “TRACK” knob (24) clockwise and release it
immediately to skip to the beginning of the next
track. Each time the knob is turned and released,
the indicated track number will increase.
n Skipping backward
Turn the “TRACK” knob (24) counterclockwise and
release it immediately to skip to the beginning of the
current track. If you continue to turn and release the
knob, the indicated truck number will decrease.
n Fast forwarding
Turn the “TRACK” knob (24) clockwise and hold it
continuously for more than 2 seconds to fast forwardthe disc.
Release the knob to stop fast forwarding.
n Fast reversing
Turn the “TRACK” knob (24)
counterclockwise and
hold it continuously for more than 2 seconds to fast
reverse the disc.
Release the knob to stop fast reverse.
Repeat playback
Press the “RPT” button (25) while a song is playing
to play the song repeatedly. The “RPT” indicator will
come on and the song will be played continuously. To cancel the repeat mode, press the button again.
Then the
“RPT” indicator goes out, and normal play-
back mode is restored.
Random playback
Press the “RDM” button (23) while a disc is being
played back to play all songs on the disc in a ran-
dom order. The “RDM” indicator will come on and all
songs on the disc will be played in a random order.
To cancel the random mode, press the button again.
Then the “RDM” indicator goes out, and normal
playback mode is restored.
Scan
When the “SCAN” button (19) is pressed while the
disc is being played back, you can hear the first 10
seconds of each track to search for the desired pro-
gram. To continue listening to the program, pressthe “SCAN” button again. After all tracks on the disc
have been scanned, normal playback mode is re-
stored.
How to unload CDs from the player
n Ejecting a CD from the player
Of the discs loaded, you can select and removeonly one disc.
1. Press the “DISC SELECT ” button (26) of the disc

Audio
5-26
whose “DISC” indicator is ON.
2. Press the “EJECT” button (22). Then the “DISC”
indicator associated with the disc you have selected will blink, and the disc will be ejected.
To remove more discs in succession, repeat Steps 1and 2.
n Ejecting all discs from the player (All discejection mode)
1. If you continue to press the “EJECT” button (22),
the player will produce beep sound and will enterthe all disc ejection mode.
2. Remove the disc that has been ejected. The oth- er discs loaded will then be ejected one after anoth-
er. If you do not remove the disc that has been
ejected, the “All disc ejection mode ” will be can-
celed.
NOTE
Avoid driving the vehicle with a CD sticking out,
because vibration might make it fall out. Precautions to observe when han- dling a compact disc (CD)
To remove a disc from the case, press the center
of the case and hold both edges of the disc. If the
disc surface is touched directly, contamination
could cause poor tone quality. Do not touch the disc
surface. Use a clean disc whenever possible. If there are
deposits, wipe the disc surface from the center out-
ward with a dry, soft cloth. Be sure not to use a hard
cloth, thinner, benzene, alcohol, etc. Never use a badly damaged, deformed or
cracked disc. Malfunctions or problems might result. A disc is vulnerable to heat. Never keep it either in
places exposed to direct sunlight, near heaters or in vehicles parked in the sun or hot days.

Audio
5-27
– CONTINUED –
HG5009BA

6
6-1
– CONTINUED –
Interior light 6-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome light 6-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage area light (if equipped) 6-2 . . . . . . . . . . . . . . . .
Spotlight (if equipped) 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sun visors 6-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center visor 6-4
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vanity mirror (if equipped) 6-4 . . . . . . . . . . . . . . . . . . . . . . .
Storage compartment 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove compartment 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center console 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holder 6-6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In instrument panel 6-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In center console (if equipped) 6-6 . . . . . . . . . . . . . . . . . .
Accessory power socket 6-7 . . . . . . . . . . . . . . . . . . . . . . . . .
In the luggage compartment (if equipped) 6-7 . . . .
Electrical power socket located
on the lower part of the instrument panel 6-8 . . .
Cigarette lighter socket (if equipped) 6-9 . . . . . . . .
Cigarette lighter (if equipped) 6-9 . . . . . . . . . . . . . . . . . . .
Ashtray 6-10
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat (if equipped) 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luggage cover (if equipped) 6-12 . . . . . . . . . . . . . . . . . . . .
Using the cover 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To remove the cover 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
To install the cover housing 6-13 . . . . . . . . . . . . . . . . . . . . .
Cargo anchorage eyelets (if equipped) 6-14 . . . . . .
Storage tray (if equipped) 6-15 . . . . . . . . . . . . . . . . . . . . . . . .
Interior equipment

Interior equipment
6-2
Interior light
When leaving your vehicle, make sure the light is
turned off to avoid battery discharge.
The interior light switch has three positions: Dome light
HS6003BB
ON: The light stays on continuously.
DOOR: The light comes on when any door is opened
and stays on for several seconds after all doors are closed. OFF: The light stays off.
Luggage area light (if equipped)
HG0157
DOOR: The light comes on only when the rear gate
is opened. OFF: The light stays off.

Interior equipment
6-3
– CONTINUED –
Spotlight (if equipped)
HB6006CA
To turn on the spotlight, push the switch. To turn it
off, push the switch again.
When leaving the vehicle, make sure the light is
turned off to avoid battery discharge. Sun visors
HB7001BA
To block out glare, swing down the visors. To use the
sun visor at a side window, swing it down and moveit sideways.

Interior equipment
6-4
Center visor
HG6002BA
To block out glare, swing down the visor.
Vanity mirror (if equipped)
HB0137
To use the vanity mirror, swing down the sun visor
and open the vanity mirror cover.

Interior equipment
6-5
– CONTINUED –
Storage compartment
CAUTION
Always keep the storage compartment
closed while driving to reduce the risk of inju- ry in the event of sudden stops or an accident. Do not store spray cans, containers with
flammable or corrosive liquids or any otherdangerous items in the storage compartment.
Glove compartment
HS0090
1) Lock 2) Unlock To open the glove compartment, pull the handle. To
close it, push the lid firmly upward.
To lock the glove compartment, insert the key and
turn it clockwise.
Center console
HG6003BA
To open the lid, push the release button.
