SUBARU IMPREZA WRX 2003 2.G Owners Manual

Keys and doors
2-20
3. Open the doors and get out of the vehicle.
4. Before closing the doors, lock all doors with theinside door lock levers.
5. Close the doors. The system will automatically
arm after one minute.
In the passive mode, the system can also be armed
with the remote transmitter or with the power door
locking switches. If the remote transmitter or power
door lock switch is used to lock the vehicle, arming
will take place immediately regardless of whether ornot the passive mode has been selected.
CAUTION
In passive mode, the system will automatically
activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you
must either lock them as indicated in step 4
above or with the key once they have been
closed. Failure to lock the doors manually willresult in a higher security risk.
Disarming the system
To disarm the system, briefly press the “UNLOCK/
DISARM” button on the transmitter.
n Tripped sensor identification
If the horn sounds four times and the parking lights
flash four times when you disarm the system, this in-
dicates that the alarm was triggered. The number oftimes the indicator light flashes indicates what sen-
sor caused the alarm condition.
To enter identification mode:
1. Open the driver ’s door and leave it open.
2. Turn the ignition switch to the “ON” position two
times. ( “LOCK” “ON” “LOCK” “ON”
“LOCK”)
3. The indicator light will start flashing.

Keys and doors
2-21
– CONTINUED –
The indicator light provides the following indications. Flashing one time: Any door, the rear gate or the
trunk lid has been opened.Flashing three times: The impact sensor in the sys-
tem’ s unit has been activated. This may indicate that
your vehicle has been shocked or tampered with by
some outside force and/or unauthorized person. Flashing four times: The ignition switch has been
turned on or the battery has been disconnected.
NOTE The battery must be reconnected before the indi- cator light will flash.
To exit this mode, close the door and turn the igni-
tion switch to the “ON” position. Child safety locks
1) Lock 2) Unlock
Each rear door has a child safety lock that prevents
the doors from being opened even if the inside door
handle is pulled.
When the child safety lock lever is in the lock posi-
tion, the door cannot be opened from inside regard- less of the position of the inner door handle lock
lever. The door can only be opened from the out-side.

Keys and doors
2-22
WARNING
Always use the child safety lock whenever a child rides in the rear seat. Serious injurycould result if a child accidentally opened thedoor and fell out.Windows
Power windows
WARNING
To avoid serious personal injury, you must observe the following warnings: When operating the power windows, be ex-
tremely careful to prevent anyone ’s fingers,
arms or head from being caught in the win-
dow. Always lock the passengers ’ windows using
the lock switch when children are riding in thevehicle. Before leaving the vehicle, always remove
the key from the ignition switch for safety andnever allow an unattended child to remain inthe vehicle. Failure to follow this procedure could result in injury to a child operating the
power window.
The power windows operate only when the ignitionswitch is in the “ON” position.

Keys and doors
2-23
– CONTINUED –
Driver’ s side switches
1) Lock switch
2) For driver ’s window (with one-touch auto down fea-
ture)
3) For front passenger ’s window
4) For rear left window
5) For rear right window
All door windows can be controlled by the power
window switch cluster at the driver side door. n
Operating the driver ’s window1) Open
2) Automatically open
3) Close
To open: Push the switch down lightly and hold it. The win- dow will open as long as the switch is held.
This switch also has a one-touch auto down featurethat allows the window to be opened fully without
holding the switch.
Push the switch down until it clicks and release it,
and the window will fully open. To stop the window
halfway, pull the switch up lightly.

Keys and doors
2-24
To close: Pull the switch up lightly and hold it. The window willclose as long as the switch is held.n Operating the passengers ’ windows
To open the passengers ’ windows, push the ap-
propriate switch down and hold it until the window
reaches the desired position.
To close the window, pull the switch up and hold it
until it reaches the desired position. n
Locking the passengers ’ windows
1) Lock 2) Unlock
To lock the passengers ’ windows, push the lock
switch. When the lock switch is in the “LOCK” posi-
tion, the passengers ’ windows cannot be opened or
closed.
Passengers’ side switches
To open the window, push the switch down and hold
it until the window reaches the desired position.
To close the window, pull the switch up and hold it
until the window reaches the desired position.
When the lock switch on the power window switch

Keys and doors
2-25
– CONTINUED –
cluster, located on the driver ’s side door, is in the
“LOCK” position, the passengers ’ windows cannot
be operated with the passengers ’ switches. Trunk lid (Sedan)
WARNING

To prevent dangerous exhaust gas from en-
tering the vehicle, always keep the trunk lid
closed while driving. Help prevent young children from locking
themselves in the trunk. When leaving the ve-
hicle, either close all windows and lock all doors or cancel the inside trunk lid release. Also make certain that the trunk is closed.
On hot or sunny days, the temperature in thetrunk could quickly become high enough to
cause death or serious heat-related injuries
including brain damage, particularly for small children.

Keys and doors
2-26
To open and close the trunk lid from outside
To open the trunk lid from outside, insert the key and
turn it clockwise.
To close the trunk lid, lightly press the trunk lid down
until the latch engages.
To open the trunk lid from inside
1) Open
Pull the trunk lid release lever upward.

Keys and doors
2-27
– CONTINUED –
To cancel the trunk lid release
The inside trunk lid release can be cancelled to help
prevent unauthorized entry into the trunk. To cancel
the trunk lid release, set the lid release cancel lever
(located on the inside of the trunk lid, mounted tothe trunk lid latch) to the “CANCEL” position. When
this lock is in the “CANCEL” position, the trunk can
be opened only with the key.
Internal trunk lid release handle
The internal trunk lid release handle is a device de-
signed to open the trunk lid from inside the trunk. In
the event children or adults become locked inside
the trunk, the handle allows them to open the lid.The handle is located on the inside of the trunk lid.
To open the trunk lid from inside the trunk, press the
yellow handle downward as indicated by the arrow on the handle.This operation unlocks the trunk lid. Then, push upthe lid.
The handle is made of material that remains lumi-
nescent for approximately an hour in the dark trunk

Keys and doors
2-28
space after it is exposed to ambient light even for a
short time.
WARNING
Never allow any child to get in the trunk and
play with the release handle. If the driverstarts the vehicle without knowing that a child
is inside the trunk and the child opens the lidusing the release handle, the child could fallout and be killed or seriously injured.
CAUTION
Do not close the lid while gripping the re-
lease handle. The handle may be damaged. Do not use the handle as a hook to fasten
straps or ropes to secure your cargo in thetrunk. Such use may result in damage of thehandle. Load the trunk so that cargo can not strike
the release handle. If the cargo hits the handlewhile the vehicle is being driven, the handle may be pushed down and the trunk lid may open. That may cause cargo to fall out of thetrunk, which could create a traffic safety haz-ard.
Inspection
Perform the following steps at least twice a year to
check the release handle for correct operation.
1. Open the trunk lid.
2. Use a screwdriver with a thin blade. Slide the
screwdriver blade from the slit aperture of the lock
assembly fully to the end until you hear a click.

Keys and doors
2-29
– CONTINUED –
This places the latch in the locked position.
3. Move the release handle, from outside the ve-
hicle, in the direction of the arrow to check if the
latch is released.
If the latch is not released, contact your SUBARU
dealer.
In that case, use the key to release the latch, then close the trunk lid.
Also, if the movements of the release handle feel re-
stricted or not entirely smooth during operation, orthe handle and/or handle base is cracked, contact
your SUBARU dealer.
