Appearance care
10-4
Corrosion protection
Your SUBARU has been designed and built to resist
corrosion. Special materials and protective finishes
have been used on most parts of the vehicle to help
maintain fine appearance, strength, and reliable op- eration. Most common causes of corrosion
The most common causes of corrosion are:
1. The accumulation of moisture retaining dirt and
debris in body panel sections, cavities, and other
areas.
2. Damage to paint and other protective coatings caused by gravel and stone chips or minor acci- dents.
Corrosion is accelerated on the vehicle when:
1. It is exposed to road salt or dust control chemi-
cals, or used in coastal areas where there is more
salt in the air, or in areas where there is considerable industrial pollution.
2. It is driven in areas of high humidity, especially
when temperatures range just above freezing.
3. Dampness in certain parts of the vehicle remains
for a long time, even though other parts of the ve-
hicle may be dry. 4. High temperatures will cause corrosion to parts
of the vehicle which cannot dry quickly due to lack
of proper ventilation.
To help prevent corrosion
Wash the vehicle frequently. If you drive on salted
roads in the winter or if you live in a coastal area,
you should flush the underbody with fresh water fre-
quently.
After the winter has ended, it is recommended that
the underbody be given a very thorough washing.
Before the beginning of winter, check the condition of underbody components, such as the exhaust sys- tem, fuel and brake lines, brake cables, suspension, steering system, floor pan, and fenders. If any of
them are found to be rusted, they should be given
an appropriate rust prevention treatment or should
be replaced. Contact your SUBARU dealer to per-
form this kind of maintenance and treatment if you need assistance. Repair chips and scratches in the paint as soon as you find them.
Check the interior of the vehicle for water and dirt
accumulation under the floor mats because that
could cause corrosion. Occasionally check under

Appearance care
10-5
– CONTINUED –
the mats to make sure the area is dry.
Keep your garage dry. Do not park your vehicle in adamp, poorly ventilated garage. In such a garage,
corrosion can be caused by dampness. If you washthe vehicle in the garage or put the vehicle into the
garage when wet or covered with snow, that can cause dampness.
If your vehicle is operated in cold weather and/or in
areas where road salts and other corrosive materials
are used, the door hinges and locks, trunk lid lock,
and hood latch should be inspected and lubricated
periodically. Cleaning the interior
Use a vacuum cleaner to get rid of the dust and dirt.
Wipe the vinyl areas with a clean, damp cloth.
Seat fabric
Remove loose dirt, dust or debris with a vacuum
cleaner. If the dirt is caked on the fabric or hard to
remove with a vacuum cleaner, use a soft blush then vacuum it.
Wipe the fabric surface with a tightly wrung cloth
and dry the seat fabric thoroughly. If the fabric is still
dirty, wipe using a solution of mild soap and luke-
warm water then dry thoroughly.
If the stain does not come out, try a commercially-
available fabric cleaner. Use the cleaner on a hid-
den place and make sure it does not affect the fab-
ric adversely. Use the cleaner according to itsinstructions. Leather seat materials
The leather used by SUBARU is a high quality natu-
ral product which will retain its distinctive appear-
ance and feel for many years with proper care.
Allowing dust or road dirt to build up on the surfacecan cause the material to become brittle and to

Appearance care
10-6
wear prematurely. Regular cleaning with a soft,
moist, natural fiber cloth should be performed
monthly, taking care not to soak the leather or allowwater to penetrate the stitched seams.A mild detergent suitable for cleaning woolen fab-
rics may be used to remove difficult dirt spots, rub-
bing with a soft, dry cloth afterwards to restore the
luster. If your SUBARU is to be parked for a long
time in bright sunlight, it is recommended that the
seats and headrests be covered, or the windows
shaded, to prevent fading or shrinkage.
Minor surface blemishes or bald patches may be
treated with a commercial leather spray lacquer. You will discover that each leather seat section will de-
velop soft folds or wrinkles, which is characteristic of
genuine leather. Synthetic leather upholstery
The synthetic leather material used on the SUBARU may be cleaned using mild soap or detergent and
water, after first vacuuming or brushing away loose
dirt. Allow the soap to soak in for a few minutes and
wipe off with a clean, damp cloth. Commercial foam-type cleaners suitable for synthetic leather materials
may be used when necessary. NOTE Strong cleaning agents such as solvents, paint
thinners, window cleaner or gasoline must neverbe used on leather or synthetic interior materials.

11
11-1
– CONTINUED –
Maintenance schedule 11-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance precautions 11-3 . . . . . . . . . . . . . . . . . . . . . . . .
Engine hood 11-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine compartment overview 11-8 . . . . . . . . . . . . . . . . .
2.5 liter model 11-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.0 liter (Turbo) model 11-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine oil 11-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing the oil and oil filter 11-11 . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-13 . . . . . . . . . . .
Recommended grade and viscosity under
severe driving conditions 11-15 . . . . . . . . . . . . . . . . . . . . . .
Synthetic oil 11-15
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling system 11-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling fan, hose and connections 11-16 . . . . . . . . . . . .
Engine coolant 11-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air cleaner element 11-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing the air cleaner element 11-20 . . . . . . . . . . . . . .
Spark plugs 11-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended spark plugs 11-24 . . . . . . . . . . . . . . . . . . . . .
Drive belts 11-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual transmission oil 11-25 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the oil level 11-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-26 . . . . . . . . . . .
Automatic transmission fluid 11-27 . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Front differential gear oil (AT vehicles) 11-29
. . . . .
Checking the oil level 11-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-30 . . . . . . . . . . .
Rear differential gear oil 11-31 . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the gear oil level 11-31 . . . . . . . . . . . . . . . . . . . . . . .
Recommended grade and viscosity 11-32 . . . . . . . . . . .
Power steering fluid 11-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-32 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended fluid 11-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake fluid 11-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-34 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended brake fluid 11-34 . . . . . . . . . . . . . . . . . . . . . . .
Clutch fluid (MT vehicles) 11-35 . . . . . . . . . . . . . . . . . . . . . . . .
Checking the fluid level 11-35 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended clutch fluid 11-36 . . . . . . . . . . . . . . . . . . . . . .
Brake booster 11-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake pedal 11-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the brake pedal free play 11-37 . . . . . . . . . . . .
Checking the brake pedal reserve distance 11-37 . .
Clutch pedal (MT vehicles) 11-38 . . . . . . . . . . . . . . . . . . . . . .
Checking the clutch function 11-38 . . . . . . . . . . . . . . . . . . . .
Checking the clutch pedal free play 11-38 . . . . . . . . . . .
Replacement of brake pad and lining 11-39 . . . . . . . .
Breaking-in of new brake pads and linings 11-39 . . .
Parking brake stroke 11-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires and wheels 11-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Types of tires 11-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and service

Maintenance and service
11-2
Tire inspection 11-41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire pressures and wear 11-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel balance 11-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wear indicators 11-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire rotation 11-46
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tire replacement 11-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel replacement 11-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel covers 11-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Aluminum wheels (If equipped) 11-50 . . . . . . . . . . . . . . . .
Windshield washer fluid 11-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement of windshield wiper blades 11-51 . .
Battery 11-54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 11-56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Main fuse 11-59
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 11-60 . . . . . . . . . . . . . . . . . . . . . . .
Replacing bulbs 11-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 11-62
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front turn signal light and parking light 11-64 . . . . . .
Front fog light (if equipped) 11-68 . . . . . . . . . . . . . . . . . . . . .
Front side marker light 11-69 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear combination lights 11-70 . . . . . . . . . . . . . . . . . . . . . . . . . .
License plate light 11-72 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome light, map light and cargo area light 11-73 . . .
Trunk light 11-74
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High mount stop light 11-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Maintenance and service
11-3
– CONTINUED –
Maintenance schedule
The scheduled maintenance items required to be
serviced at regular intervals are shown in the “War-
ranty and Maintenance Booklet ”.
For details of your maintenance schedule, read theseparate “Warranty and Maintenance Booklet ”.Maintenance precautions
When maintenance and service are required, it is
recommended that all work be done by an autho-
rized SUBARU dealer.
If you perform maintenance and service by yourself,
you should familiarize yourself with the information
provided in this section on general maintenance andservice for your SUBARU.
Incorrect or incomplete service could cause
improper or unsafe vehicle operation. Any problems
caused by improper maintenance and service per-
formed by you are not eligible for warranty cover-age.
WARNING

Testing of an All-Wheel Drive vehicle must
NEVER be performed on a single two-wheel
dynamometer or similar apparatus. Attempt-ing to do so will result in transmission dam-age and in uncontrolled vehicle movement and may cause an accident or injuries to per-
sons nearby. Always select a safe area when performing
maintenance on your vehicle.

Maintenance and service
11-4
Always be very careful to avoid injury when
working on the vehicle. Remember that some of the materials in the vehicle may be hazard-
ous if improperly used or handled, for exam-ple, battery acid. Your vehicle should only be serviced by per-
sons fully competent to do so. Serious per-sonal injury may result to persons not experi-enced in servicing vehicles. Always use the proper tools and make cer-
tain that they are well maintained. Never get under the vehicle supported only
by a jack. Always use a safety stands to sup-port the vehicle. Never keep the engine running in a poorly
ventilated area, such as a garage or other
closed areas. Do not smoke or allow open flames around
the fuel or battery. This will cause a fire. Because the fuel system is under pressure,
replacement of the fuel filter should be per-
formed only by your SUBARU dealer. Wear adequate eye protection to guard
against getting oil or fluids in your eyes. If something does get in your eyes, thoroughly
wash them out with clean water. Do not tamper with the wiring of the SRS airbag system or seatbelt pretensioner sys-tem, or attempt to take its connectors apart,as that may activate the system or it can ren-der it inoperative. The wiring and connectorsof these systems are yellow for easy identifi-cation. NEVER use a circuit tester for these wiring. If your SRS airbag or seatbelt pretensionerneeds service, consult your nearest SUBARU
dealer.
Before checking or servicing in the
engine compartment
Always stop the engine and set the parking
brake firmly to prevent the vehicle from mov- ing. Always let the engine cool down. Engine
parts become very hot when the engine is run-
ning and remain hot for some time after theengine is stopped. Do not spill engine oil, engine coolant, brake
fluid or any other fluid on hot engine compo-nents. This may cause a fire. Always remove the key from the ignition
switch. When the ignition switch is in the
“ON” position, the cooling fan may operate

Maintenance and service
11-5
– CONTINUED –
suddenly even when the engine is stopped. When you do checking or servicing in the engine compartment whilethe engine is running
A running engine can be dangerous. Keep your fingers, hands, clothing, hair and toolsaway from the cooling fan, belts and any other
moving engine parts. Removing rings,watches and ties is advisable. Engine hood
To open the hood:
1. Pull the hood release knob under the instrument panel.

Maintenance and service
11-6
2. Release the secondary hood release located
under the front grille by moving the lever toward theleft.Lift up the hood, release the hood prop from its
retainer and put the end of the hood prop into theslot in the hood.
To close the hood: All models except WRX:
1. Lift the hood slightly and remove the hood prop
from the slot in the hood and return the prop to its
retainer.
2. Lower the hood until it approaches about 6 in.
(15 cm) from the closed position and let it drop.

Maintenance and service
11-7
– CONTINUED –
WRX:
1. Lift the hood slightly and remove the hood prop
from the slot in the hood and return the prop to its
retainer.
2. Lower the hood until it approaches about 12 in.
(30 cm) from the closed position and let it drop.
After closing the hood, be sure the hood is securelylocked.
If this does not close the hood, release it from a
slightly higher position. Do not push the hood forci-
bly to close it. It could deform the metal.
WARNING
Always check that the hood is properly locked before you start driving. If it is not, it might fly open while the vehicle is moving and block
your view, which may cause an accident and
serious bodily injury.
