SUBARU LEGACY 2001 3.G Owners Manual

Climate control4-15
–
CONTINUED –
With the fan sp eed c ontrol switc h in the AUTO p osit
ion, the fan sp eed
c hang es automatic ally c orresp ond ing to various c ond itions: air tem-
p erature insid e and outsid e of the p asseng er c omp ar tment, intensity
of the sunlig ht, etc .
Use this switc h to selec t d esired fan sp eed . Fan sp eed inc reases with
eac h p ress of the switc h and returns to the AUTO p o sition.
n A/C — Air conditioner switch
NOTE The air conditioner compressor does not operate when the out- side air temperature is below 32 F (0 C).
If the wind shield starts to fog when the air c ond it ioner is op erated in
the AUTO mod e, p ush the air c ond itioner switc h “A/C ” to d efog and
d ehumid ify.
When this switc h is p ushed , the air c ond itioner c om p ressor turns on
and the ind ic ator lig ht “A/C ” on the c ontrol p anel c omes on. After
eliminating the fog g ing from the wind shield , set th e air c ond itioner
b ac k in the AUTO mod e b y p ushing the “AUTO ” switc h.
n MODE — Air flow control switch
(Ventilation) : Air flows throug h the instrument p an el outlets.
(Bi-level) : Air flows throug h the instrument p anel outlets
and the foot outlets.
(Heat) : Air flows throug h the foot outlets and some throug h the wind shield d efroster outlets.
(Heat-d ef) : Air flows throug h the wind shield d efros ter out-
lets and foot outlet.

4-16n
Air inlet selection switch
WARNING
Continued operation in the “
” position may fog up the win-
dows. Switch to the “
” position as soon as the outside
dusty condition clears.
HB5022BB
Selec t the air inlet b y p ushing the air inlet selec tion switc h.
: Interior air rec irc ulates insid e the p asseng er’s c omp artment.
Use this p osition when q uic kly warming up the p asse ng er
c omp artment or c ooling it d own or when p reventing o utsid e
air from entering the p asseng er c omp artment from th e out-
sid e air. The ind ic ator lig ht “
” on the c ontrol p anel
c omes on when this switc h is p ushed .
: Outsid e air is d rawn into the p asseng er c omp artmen t. When
the air c ond itioning system is op erated in the “AUTO ” mod e,
this p osition is selec ted automatic ally. The ind ic a tor lig ht
“
” on the c ontrol p anel c omes on when this switc h is
p ushed .

Climate control4-17
–
CONTINUED –
n
Temperature control dial
HB5023BB
NOTE A setting of about 77 F (25 C) throughout the year is recom-
mended. The temperature setting remains even after the ignition switch
is turned to the “OFF”. However, if the battery cables are discon-
nected, the temperature will be set to 77 F (25 C) automatically.
Set d esired temp erature b y turning the temp erature c ontrol d ial; turn
the d ial c loc kwise to raise the temp erature setting and turn it c ounter-
c loc kwise to lower it.
The temp erature c an b e set in inc rements of 1 F within a rang e of 65
– 85 F for US mod els and in inc rements of 0.5 C within a rang e of 18
– 32 C for Canad ian mod els.
Even when q uic k c ooling or warming is nec essary, yo u d o not have to
c hang e the temp erature setting . The Automatic Clima te Control sys-
tem op erates at maximum p erformanc e until the air i n the p asseng er
c omp artment reac hes to the sp ec ified temp erature.

4-18
Temperature sensors
This Automatic Climate Control system emp loys the s everal sensors.
These are very d elic ate p arts. Therefore, if these sensors are d am-
ag ed , it is p ossib le that the Automatic Climate Con trol system will not
p rop erly c ontrol the air temp erature in the p asseng er c omp artment.
To p revent p ossib le d amag e to the sensors, p lease o b serve the fol-
lowing :
–Do not allow anything to imp ac t the sensors.
– Be c areful not to let water c ontac t the sensors.
– Do not c over the sensors.
The sensors are found at the following loc ations: – Sun-load sensor (b esid e the wind shield d efroster g r ille)
– In-vehic le temp erature sensor (b esid e the temp eratu re c ontrol
d ial.)
– Amb ient sensor (at the b ac ksid e of the front g rille )
HB5025BB
HB5024BB

Climate control4-19
–
CONTINUED –
Operating tips for heater and air conditioner
Cleaning ventilator grille
HB5019BC
Always keep the front ventilator inlet g rille free of snow, leaves, or oth-
er ob struc tions to ensure effic ient heating and d ef rosting . Sinc e the
c ond enser is loc ated in front of the rad iator, this area should b e kep t
c lean b ec ause c ooling p erformanc e is imp aired b y an y ac c umulation
of insec ts and leaves on the c ond enser. Efficient cooling after parking in direct sunlight
After p arking in d irec t sunlig ht, d rive with the wi nd ows op en for a few
minutes to allow outsid e air to c irc ulate into the heated interior. This
results in q uic ker c ooling b y the air c ond itioner. Keep the wind ows
c losed d uring the op eration of the air c ond itioner for maximum c ool-
ing effic ienc y. Lubrication oil circulation in the refrigerant circuit
Op erate the air c ond itioner c omp ressor at a low eng ine sp eed (at id le
or low d riving sp eed s) a few minutes eac h month d ur ing the off-sea-
son to c irc ulate its oil. Checking air conditioning system before summer season
Chec k the air c ond itioner unit for refrig erant leak s, hose c ond itions,
and p rop er op eration eac h sp ring . This c hec k is b es t p erformed b y
your SUBARU d ealer.

4-20
Cooling and dehumidifying in high humidity and low tempera- ture weather condition
Und er c ertain weather c ond itions (hig h relative hum id ity, low temp era-
tures, etc .) a small amount of water vap or emission from the air outlets
may b e notic ed . This c ond ition is normal and d oes n ot ind ic ate any
p rob lem with the air c ond itioning system. Air conditioner compressor shut-off when engine is heavily loaded
To imp rove ac c eleration and g as mileag e, the air c o nd itioner c om-
p ressor is d esig ned to temp orarily shut off d uring air c ond itioner op -
eration whenever the ac c elerator is fully d ep ressed suc h as d uring
rap id ac c erelation or when d riving on a steep up g ra d e.
Refrigerant for your climate control system
Your air c ond itioner uses ozone friend ly refrig eran t HFC134a. There-
fore, the method of ad d ing , c hang ing or c hec king th e refrig erant is
d ifferent from the method for CFC12 (freon). Consul t your SUBARU
d ealer for servic e. Rep airs need ed as a result of u sing the wrong
refrig erant are not c overed und er warranty.
Air filtration system (if equipped)
If your vehic le ’s air c ond itioning system is eq uip p ed with a op tion al air
filtration system, rep lac e the filter element ac c or d ing to the rep lac ement
sc hed ule shown b elow. This sc hed ule should b e follo wed to maintain the
filter ’s d ust c ollec tion ab ility. Und er extremely d usty c o nd itions, the filter
should b e rep lac ed more freq uently. Sinc e the filte r element is a visc ous
typ e, it is unnec essary to c lean or wash the elemen t. Have your filter
c hec ked or rep lac ed b y your SUBARU d ealer.
Replacement schedule: Every 12 months or 7,500 miles (12,000 km) whichever comes first
NOTE The filter can influence the air conditioning, heating and defroster performance.

5
Audio Antenna system5-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation of accessories 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio set 5-3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type A and B audio set (if equipped) 5-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type C audio set (if equipped) 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Type D audio set (if equipped) 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
McIntosh audio set (if equipped) 5-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD player 1 (if equipped) 5-52
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD player 2 (if equipped) 5-54
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In-dash 6 CD auto changer (if equipped) 5-57 . . . . . . . . . . . . . . . . . . . . . . . . .
Precautions to observe when handling a compact disc (CD) 5-60
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-2
Antenna system
Printed antenna CAUTION
Do not use sharp instruments or window cleaner containing abra-
sives to clean the inner surface of the window on which theantenna is printed. Doing so may damage the antenna printed on
the window.
The antenna is p rinted on the insid e of the rear wi nd ow g lass (sed an)
or the left sid e rear q uarter wind ow g lass (station wag on).
HB5038AA
HBF013IA

Pillar mounted antenna
OM-H2376
Pull the antenna out to extend it to its full leng t h.

Audio5-3
–
CONTINUED –

FM reception
Althoug h FM is normally static free, rec ep tion c an b e affec ted b y the
surround ing area, atmosp heric c ond itions, station s treng th and trans-
mitter d istanc e. Build ing s or other ob struc tions ma y c ause momentary
static , flutter or station interferenc e. If rec ep ti on c ontinues to b e unsat-
isfac tory, switc h to a strong er station.
Installation of accessories
Always c onsult your SUBARU d ealer b efore installing a c itizen b and ra-
d io or other transmitting d evic e in your vehic le. S uc h d evic es may c ause
the elec tronic c ontrol system to malfunc tion if the y are inc orrec tly
installed or if they are not suited for the vehic le .
Audio set
Your SUBARU may b e eq uip p ed with one of the followi ng aud io sets.
See the p ag es ind ic ated in this sec tion for op erati ng d etails.
Type A and type B audio set
HB5041AA
Rad io op eration: refer to p ag e 5-7
Cassette p layer op eration: refer to p ag e 5-11
CD p layer c ontrol: refer to p ag e 5-13
CD c hang er c ontrol: refer to p ag e 5-16

5-4
Type C audio set
HB5042AA
Rad io op eration: refer to p ag e 5-19
Cassette p layer op eration: refer to p ag e 5-24
CD (c omp ac t d isc ) p layer op eration: refer to p ag e 5 -27
CD c hang er c ontrol: refer to p ag e 5-30
Type D audio set
HB5043AA
Rad io op eration: refer to p ag e 5-33
Cassette p layer op eration: refer to p ag e 5-37
CD p layer c ontrol: refer to p ag e 5-38
