Page 63 of 308
RADIO OPERATION
61
AUDIO
3
No. Function
Select to display the audio source selection screen.
Select to display the cache radio operation buttons.
: 3
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
Select to display a list of receivable stations/channels.
Select to scan for receivable stations/channels.
HD Radio only: Select to store information of the audio
F X U U H Q W O \ E H L Q J E U R D G F D V W R Q W K H U D G L R : 3
Select to tune to a preset station/channel.
Select to turn HD Radio mode on/off. When the HD
Radio indicator is off, the station list shows only analog
broadcasts.
Select to display the additional text information.
Analog FM only: Select to display RBDS text messages.
NOTE
OThe radio automatically changes to stereo reception when a
stereo broadcast is received.
OThe radio automatically blends to an HD Radio signal in AM or
FM where available.
PRESETTING A STATION
Radio mode has a mix preset function, which can store up
to 36 stations from any of the AM, FM or SiriusXM Satellite
Radio bands.
1. Tune in the desired station.
2. Select (add new) ((add new)).
”To change the preset station to a different one, select
and hold the preset station.
3. Select Yes < H V R Q W K H F R Q
Page 64 of 308
RADIO OPERATION
62
SELECTING A STATION FROM THE LIST
A station list can be displayed.
1. Select .
2. FM radio only: Select the desired program genre.
3. Select the desired station and then select OK (OK).
RADIO BROADCAST DATA SYSTEM
This audio system is equipped with Radio Broadcast Data
Systems (RBDS). RBDS mode allows text messages to be
received from radio stations that utilize RBDS transmitters.
When RBDS is on, the radio can
— only select stations of a particular program type,
— display messages from radio stations,
— search for a stronger signal station.
RBDS features are available only when listening to an FM
station that broadcasts RBDS information and the
FM Info
(FM Info) indicator is on.
Page 68 of 308
RADIO OPERATION
66
”FM stations can provide additional digital-only audio
programming on HD2/HD3 Channels.
PRESERVING A MUSIC INFORMATION
Tag information in the music broadcasting is preserved in
the system and transmits to an iPod.
1. Select Tag (Tag) to bookmark the music information.
2. & R Q Q H F W D Q L 3 R G : 3
”Turn on the power of the iPod if it is not turned on.
”Once an iPod is connected, the music tag moves
from the radio into the iPod.
”When the iPod is connected to iTunes, the “tagged”
information of the songs which were tagged while
listening to the radio can be viewed. Then a user may
decide to purchase the song or CD/Album which had
been listened to on their radio.
”Up to 50 items of tag information can be stored.
NOTE
OThe tag information can not be preserved while scanning or
caching the radio station.
OIf tagging the music information fails, “Saving the HD Radio
tag was unsuccessful. (Saving the HD Radio tag was
unsuccessful.)” will be displayed on the screen. If this occurs,
tag the information again.
OHD Radio™ stations can be preset.
OAn orange
HD) will be displayed on the screen when in digital.
The
HD) Z L O O
Page 72 of 308
RADIO OPERATION
70
No. Information/Function
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
6 H O H F W W R G L V S O D \ D O L V W R I F D W H J R U L H V : 3
Select to search subscribed channels by category.
By turning TuneScan Enable ON with channels
registered in Smart Favorites,
Tune Scan (Tune
6 F D Q L V G L V S O D \ H G : 3
6 H O H F W W R U H F H L Y H W D J L Q I R U P D W L R Q : 3
Select to tune to a preset channel.
is displayed for channels registered in Smart
Favorites.
6 H O H F W W R W X U Q W K H 6 ; 0 ) H D W X U H G R Q R I I : 3
Select to show information such as channel name, song
title, and artist name.
6 H O H F W W R W X U Q W K H 7 X Q H 6 F D Q R Q R I I : 3
Select to display the “Edit Favorites (Edit Favorites)”
V F U H H Q : 3
6 H O H F W W R W X U Q W K H 7 X Q H 6 W D U W R Q R I I : 3
NOTE
OIf the ignition switch is turned “OFF” and then set to the “ACC”
or “ON” position when listening to an XL channel, broadcasting
from the XL channel will not begin. If so, the SXM001 channel
will be broadcast.
OXL channels may include frequent explicit language or mature
programming.
HOW TO SUBSCRIBE TO SiriusXM® Satellite
Radio
To listen to a satellite radio broadcast in the vehicle, a
subscription to the SiriusXM® Satellite Radio service is
necessary.
A SiriusXM
® Satellite Radio is a tuner designed exclusively
to receive broadcasts provided under a separate
subscription. SiriusXM U.S. satellite and data services
are available only in the 48 contiguous USA and DC.
SiriusXM satellite service is also available in Canada; see
www.siriusxm.ca.
Page 75 of 308
RADIO OPERATION
73
AUDIO
3
NOTE
OSiriusXM® Satellite Radio Service is solely responsible for the
quality, availability and content of the satellite radio services
provided, which are subject to the terms and conditions of the
SiriusXM Satellite Radio customer service agreement.
OCustomers should have their radio ID ready; the radio ID can
be found by tuning to “Ch 000” on the radio. For details, see
“DISPLAYING THE RADIO ID” below.
OAll fees and programming are the responsibility of SiriusXM
®
Satellite Radio Services and are subject to change.
DISPLAYING THE RADIO ID
( D F K 6 L U L X V ; 0 W X Q H U L V L G H Q W L
Page 77 of 308
RADIO OPERATION
75
AUDIO
3
No. Function
Fast forwards continuously.
The fast forward speed increased the longer the button
is held down.
Select to access the desired program.
Skips forward through program.
Returns to the live radio broadcast.
Shows the current playback location relative to the
cached broadcast recording time with a bar scale.
NOTE
OThe time displayed on the bar scale may differ from the actual
time.
REGISTERING A SMART FAVORITE
CHANNEL
The TuneStart and TuneScan functions can be used by
registering preset channels as Smart Favorites. Up to 5
channels can be registered in Smart Favorites.
1. Select Smart Favs Setup (Smart Favs Setup) on the
option screen.
2. Select check boxes for preset channels to be
registered, and then select
OK (OK).
TuneStartTM FUNCTION
TuneStart begins playing the current program from the
beginning when tuning to a channel registered in Smart
Favorites, allowing you to enjoy the complete program.
TuneStart is applicable to channels registered in Smart
) D Y R U L W H V : 3
It is necessary to turn on TuneStart at the option screen to
X V H W K L V I X Q F W L R Q : 3
NOTE
OLive radio is broadcast immediately after switching from another
mode to SiriusXM mode even if the TuneStart setting is turned
ON. The TuneStart function starts if switching to a channel
registered in Smart Favorites within SiriusXM mode.
OThe TuneStart function is not applicable to programs for which
even a little has been listened to from the start.
Page 81 of 308
MEDIA OPERATION
79
AUDIO
3
XControl screen
Page 82 of 308
MEDIA OPERATION
80
No. Function
XAudio CDSelect to enable/disable random playback for the tracks
currently playing on the CD.
XMP3/WMA/AAC discThe random playback method changes as shown below
H D F K W L P H W K H V K X I À H E X W W R Q L V V H O H F W H G
: The files contained within the folder
currently playing will be played in
random order.
: The files contained on the disc
currently playing will be played in
random order.
: Random playback is disabled.
XAudio CDSelect to display a track list.
XMP3/WMA/AAC disc 6 H O H F W W R G L V S O D \ D I R O G H U ¿ O H O L V W
To return to the top screen, select Now Playing (Now
Playing) on the list screen.
Select to choose a folder.
NOTE
O , I D G L V F F R Q W D L Q V & ' ' $
Page 84 of 308
MEDIA OPERATION
82 XControl screen (Audio/Video)
No. Function
Displays cover art.
6 H O H F W W R G L V S O D \ ¿ O H W U D F N O L V W
Select to display the audio source selection screen.
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
Select to play/pause.
Shows progress.
No. Function
The repeat method changes as shown below each time
the repeat button is selected.
: Repeat playback is disabled.
: The file/track currently playing will be
repeated.
: The files/tracks contained within the
folder/album currently playing will be
repeated.
The random playback method changes as shown below
H D F K W L P H W K H V K X I À H E X W W R Q L V V H O H F W H G
: Random playback is disabled.
: The files/tracks contained on the USB
memory currently playing will be played
in random order.
: The files/tracks contained within the
folder/album currently playing will be
played in random order.
Page 85 of 308
MEDIA OPERATION
83
AUDIO
3
No. Function
Select to display the play mode selection screen.
‡ “Artists (Artists)”/“Albums (Albums)”/“Songs
(Songs)”/“Genres (Genres)”/“Composers
(Composers)”/“Folder (Folder)”/“Videos (Videos)” are
on the play mode selection screen.
‡ Switching between USB audio and USB video is
possible on the play mode selection screen. To
return to the top screen, select
Now Playing (Now
Playing) on the list screen.
Select to choose the folder.
Select to display the options screen.
The following can be done on the options screen.
