Page 153 of 308
MirrorLink™
151
APPS
5
XControl screen
*: The displayed screen will differ depending on the connected smartphone.
No. Function
Select to choose a MirrorLink™ device.
6 H O H F W W R F K D Q J H W K H V F U H H Q V L ] H : 3
Select to return the application list screen.
No. Function
Displays software buttons that function as the buttons
on the smartphone.
Select to change the other audio source (Radio, Disc
etc.).
NOTE
OThis function cannot be used while USB audio, video or photo is
in use.
OThe video displayed on the screen may differ from that displayed
on the smartphone.
OIt may not be possible to use certain applications while driving.
ABOUT THE SUPPORTED DEVICES
”Your smartphone must support the MirrorLinkTM
function.
”Available operations will differ depending on your
smartphone. Refer to your smartphone owner's
manual, or consult the manufacturer.
Page 155 of 308
APPS
5
ahaTM by HARMAN
153 XControl screen
No. Function
Select to display a list of preset stations.
A maximum of 35 entries can be displayed in this list.
Select to display a list of stations using the location
information.
A maximum of 10 entries can be displayed in this list.
No. Function
Select to display the audio source selection screen.
Station list
Select to display the station operation screen.
Displays station name.
Select to display the top screen.
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
6 W D W L R Q R S H U D W L R Q V F U H H Q E X W W R Q V : 3
Select to change the station operation screen buttons.
Select to display the content item list.
Displays cover art.
NOTE
OWhen you switch to other modes with the aha application
activated and then turn the system Off/On with the smartphone
device still connected, the aha mode will start instead of
the last mode used. If you do not want to start the aha mode
automatically, turn off the aha application on the smartphone.
Page 156 of 308
ahaTM by HARMAN
154
NOTE
OTop 35 entries in the preset station list on the smartphone are
displayed. When there are more than 35 entries in the preset
station list, change the order of the entries in the list on the
smartphone. You can change the priority of your preset stations
within the aha application (after disconnected from this system)
to modify the station list shown on the screen. Please see your
smartphone aha application “Edit Presets” to modify this list.
O , I W K H U H D U H P X O W L S O H D X G L R
Page 157 of 308
APPS
5
ahaTM by HARMAN
155
3. For Android devices: Select aha (aha) on the “APPS
(APPS)” screen.
”The “aha” top screen can also be displayed by
selecting
aha (aha) on the “Select Audio Source
(Select Audio Source)” screen.
4. Check that the top screen is displayed.
5. Select the desired station.
6. Check that the station operation screen is displayed.
”Main functions of the station operation screen button:
: 3
”For details on the services or the operations, check
the aha site (http://www.aharadio.com) on the
internet.
NOTE
OWhen iPhone and Android devices are connected at the same
time, select the smartphone which you want to use on the
Page 158 of 308
ahaTM by HARMAN
156
STATION OPERATION SCREEN BUTTONS
Button Function
Select to start playback.
Select to pause playback.
Select to stop playback.
Select to upload “Like” information to the
application server. To cancel “Like” information
that is being uploaded to the server, select this
button again.
Select to upload “Dislike” information to the
application server. To cancel “Dislike” information
that is being uploaded to the server, select this
button again.
*Select to display the POI information on the map
V F U H H Q D Q G V H W L W D V D G H V W L Q D W L R Q : 3
Select to call the registered number.
Select to upload your current location to your
social network.
Select to send your voice to the application
V H U Y H U : 3
Button Function
Select to refresh the content item information in
the current station.
Select to rewind the current content item for 15
seconds.
Select to fast forward the current content item for
30 seconds.
*: With navigation function
NOTE
OThe button display will vary depending on each station or content
item.
SHOUT FUNCTION
Your voice can be sent to the application server.
1. Select .
Page 159 of 308
APPS
5
ahaTM by HARMAN
157
2. Check that the countdown screen is displayed.
”Cancel (Cancel): Select to cancel shout function.
3. Record your voice and then select Save (Save).
”Cancel (Cancel): Select to cancel shout function.
”A maximum of 30 seconds can be recorded.
4. Select Send (Send).
”Confirmation & R Q
Page 162 of 308
Pandora®
160 XControl screen
No. Function
Select to display the audio source selection screen.
6 H O H F W W R G L V S O D \ W K H V R X Q G V H W W L Q J V F U H H Q : 3
Shows progress.
Select to rate the track currently playing as “Like” or
“Dislike”.
Select to bookmark the track currently playing.
No. Function
Select to skip to the next track.
Select to play/pause.
Select to display a station list.
Displays cover art.
ABOUT THE SUPPORTED DEVICES
This system supports the following devices.
”iPhone: iOS 5.0 or later
”Android: Differs with mobile device used
Page 165 of 308
USEFUL INFORMATION
163
INFORMATION
6
No. Function
Select to switch to an audio broadcast while information
during a game is being displayed.
<0037004b004800030056004600520055004800560003004400550048000300460052005000530044005500480047000f000300440051004700030057004b004800030044004900bf004f004c0044005700480003005a004c0057004b00030057004b004800
03>
highest score is displayed in yellow.
Select to set which sports information is displayed.
6 H O H F W W R V H W \ R X U I D Y R U L W H D I
Page 166 of 308
USEFUL INFORMATION
164 XWith navigation function
3. Check that weather information is displayed.
No. Function
Select to switch the timing of the displayed forecast.
Items such as the weather forecast, forecast
temperature or highest temperature (orange)/lowest
temperature (blue), and chance of precipitation are
displayed.
Select to display alert list.
Select to set the forecast region. Follow the steps in
“ XWithout navigation function” from “STEP 4”.
Select to update the forecast location.
Select to update with the latest information.
Weather forecast icons
Display Information
noneNo Data Available
Unknown Precip
Isolated Thunderstorms
Scattered Thunderstorms
Scattered Thunderstorms (night)
Severe Thunderstorms
Thunderstorms
Rain
Light Rain
Heavy Rain
Scattered Showers
Showers
Page 167 of 308
USEFUL INFORMATION
165
INFORMATION
6
Display Information
Scattered Showers (night)
Drizzle
Freezing Drizzle
Freezing Rain
Mixed Rain And Hail
Wintry Mix
Mixed Rain And Snow
Mixed Rain And Sleet
Hail
Ice Pellets
Sleet
Flurries
Light Snow
Scattered Snow Showers
Snow Showers
Display Information
Moderate Snow
Snow
Heavy Snow
Scattered Snow Showers (night)
Blowing Snow
Blizzard
Sandstorm
Blowing Dust
Dust
Foggy
Moderate Fog
