SUBARU TRIBECA 2011 1.G Navigation Manual

40
Setting Route
■“Coordinates” methodYou can set destinations or waypoints using their latitudes and longitudes as follows:1
Enter the latitude of the desired location.Use the numeric keys together with the [°] (degrees), [’] (minutes), and [“] (seconds)
keys.
2
Enter the longitude of the location.
:Use this key to switch over to the north latitude.
:Use this key to switch over to the south latitude.
:Use this key to switch over to the west longitude.
:Use this key to switch over to the east longitude.
:Use this key to delete the character last entered. Select it repeatedly if you
want to delete all the characters entered.
First, choose either of the two procedures below to follow the “coordinates” method.
• Press the button or select , select (destination entry), and then select (coordinates).
• Press the button and select (coordinates).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 40

41
3
Select .
4
Select (destination) or (waypoint).
Setting Route
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 41

42
Setting Route
■“Intersection” methodYou can use a intersection defined by two street names as a location for setting your destination or a waypoint.1
Enter the name of the first street and then select .
2
Select the street from the “Intersection” list.
: Use this key to display up to five previous suggestions.
: Use this key to display the previous suggestion.
: Use this key to display the next suggestion.
: Use this key to display up to five of the next suggestions.
First, choose either of the two procedures below to follow the “intersection” method.
• Press the button or select , select (destination entry), and then select (intersection).
• Press the button and select (intersection).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 42

43
3
Specify the second street using the same procedure as the first street.
4
Select (destination) or (waypoint).
NOTENo intersection is defined if
• the two streets do not cross each other,
• the two streets are a freeway and a highway,
• either street is for right or left turns only,
• both are one-way streets,
• either street is for U-turns,
• the two streets cross on the inside lane,
• either street is an on/off ramp,
• either street is a frontage street, and/or
Setting Route
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 43

44
Setting Route
■“Phone number” methodThis function allows buildings and the like to be located using their phone numbers.1
Enter the phone number starting with the area code.
2
Select .
First, choose either of the two procedures below to follow the “phone number” method.
• Press the button or select , select (destination entry), and then select (phone number).
• Press the button and select (phone number).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 44

45
3
Select (destination) or (waypoint).
NOTEIf a number of candidates exist as a result of, for example, different area codes, these will be displayed in a list. Your desired destination
can then be selected from the list.
Setting Route
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 45

46
■Using “Change Search Area” function This function designates a general geographical area where the destination or waypoint you want to set is located.
This function can be used in the methods marked with an asterisk (*) on Page 25.1
Select the desired area.The DESTINATION ENTRY menu screen will appear.
NOTE
• The SEARCH AREA screen shown above is a sample image. It may be slightly different from the actual screen image.
• The DVD-ROM disc containing map data is split into two discs, containing information regarding East and West U.S. respectively. Both
discs cover the Continental U.S. and the District of Columbia, but the POI (points of interest) are split depending on the disc, as follows:
WEST: US1 ~ US7 and southern Canada
EAST: US6 ~ US10 and southern Canada
US6, US7 and southern Canada (CAN) are included in both discs.
Please note that Alaska, Hawaii, Guam and the other Pacific islands are not covered.
Setting Route
First, choose either of the two procedures below to follow the “change” method.
• Press the button or select , select (destination entry), and then select (change).
• Press the button and select (change).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 46

47
Route GuidanceDuring route guidance, the system can indicate on a second screen the directions in which you must make
turns at the next and following intersections in either of two ways: “turn arrow” or “turn list”. Specify your
preferred method of indication as follows:
1
Select (screen configuration).
2
Select for turn arrow indication or for turn list indication.If you need not make any further selection, select . The relevant keys will
disappear.
Route Guidance Screen

Turn direction is indicated by an arrow.
Turn directions are indicated in a list.
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 47

48
Before you arrive at an intersection, the system will automatically show a zoom-in map of the intersection on a
second screen to make the guidance clearer.
As you approach an intersection during route guidance, a zoom-in map of the
intersection automatically appears on a second screen. After you drive past the
intersection, the zoom-in map disappears.
As you approach a fork on a freeway during route guidance, a zoom-in map of the
freeway automatically appears on a second screen, making the route guidance
clearer.
NOTEUse the following procedure to recall the most recently displayed zoom-in map of an
intersection or a freeway fork.
1. Select (screen configuration).
2. Select (re-display of intersection/range guidance).
If you need not make any further selection, select . The relevant keys will disappear.
Zoom-in Map at IntersectionRoute Guidance
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 48

49
Route Guidance
You can configure the screen for a dual map display.
1
Select (screen configuration).
2
Select (dual map).If you wish to return to the single map display, select (single map).
If you need not make any further selection, select . The relevant keys will
disappear.
NOTE
If you wish to modify the display selections that have been made for a second screen, touch the top of the screen. After completing the
modification, select .
• See Page 19 for details on scale changes.
• See Page 108 for details on setting with .
Dual Map Display
