A list of buildings and facilities along a freeway can be displayed on the screen.
1
Select (screen configuration).
2
Select (freeway information).If you need not make any further selection, select . The relevant keys will
disappear.
If you want to listen to the last voice guidance again during route guidance, use the following procedure:
1
Select . You can hear the voice guidance again.
Replaying Voice GuidanceFreeway InformationRoute Guidance
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 50
Page 52 of 126
51
Longitude and latitude of present location can be displayed on the screen.
1
Select (screen configuration).
2
Select (compass).
3
Longitude and latitude of present location are displayed at lower right
of the screen.
Compass Mode
Route Guidance
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 51
Page 53 of 126
52
Using the functions available from the Route Options screen, you can change the route options, stop the route
guidance or check the route. Use the following procedures:
1
Press the button or select .
2
Select (route options). The Route Options screen will appear. Select any of the following displayed functions
as necessary:
(search condition):
This function allows you to specify the way in which the system calculates the route
to the destination. (See Page 54.)
(detour):
This function allows you to prompt the system to calculate an alternative route from
your current position within a specified distance. (See Page 55.)
(route preferences):
This function allows you to prompt the system to alter the route search conditions
and recalculate the route accordingly. (See Page 56.)
Setting Route OptionsRoute Options
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 52
Page 54 of 126
53
Route Options
(destination and waypoint):
This function allows you to modify the destination and waypoints, and prompt the
system to recalculate the route accordingly. (See Page 57.)
(display route):
This function allows you to confirm the entire route and, if necessary, prompt the
system to recalculate the route according to your specification. (See Page 65.)
(route preview):
This function allows you to simulate a drive along the system-calculated route before
departure. (See Page 66.)
(calculate):
Selecting this key prompts the system to recalculate the route.
(cancel guidance):
Selecting this key prompts the system to stop route guidance. Note that this erases
the destination and waypoints. To prompt the system to start guidance again, select
(calculate).
NOTE
A recalculated route will sometimes be the same route as the one displayed before recalculation.
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 53
Page 55 of 126
54
Search conditionYou can specify the way in which the system calculates your route.
1
Select (Quick), (Alt.), or (Short) to specify the way of
calculating the route to reach the next waypoint or the destination from
the current point.
:The system will calculate a route with the shortest driving time required.
:The system will calculate an alternative route.
(You can select , or for the first waypoint. Only or
can be specified for the second and subsequent waypoints.)
:The system will calculate a route with the shortest driving distance.
2
Select (calculate).
3
Select (start).
Route Options
Press the button or select , then select (route options), and then select
(search condition).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 54
Page 56 of 126
55
Route Options
DetourYou can specify a detour distance from your current position. The system will calculate an alternative route
according to the distance specification, enabling you to take a detour.
1
Select a detour distance using , , , or
(whole route).The system will then calculate an alternative route that detours from the current
location within the specified distance.
2
Select (start).
NOTEIf you are driving off the route, it is not possible to calculate a detour route.Press the button or select , then select (route options), and then select
(detour).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 55
Page 57 of 126
56
Route preferencesUse this function to specify preferred route search conditions. The system will start recalculating the route
according to your specified conditions.
1
Specify conditions by selecting keys. Each time you select a key, it will toggle between “usage” and “non-usage” of the
corresponding roads or ferries.
2
Select (calculate).
NOTE• The (calculate) key can be selected during route guidance.
• The route calculation will not always be able to follow the specified conditions.
Route Options
Press the button or select , then select (route options), and then select
(route preferences).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 56
Page 58 of 126
57
Route Options
Destination and waypointsYou can change the destination or waypoints for the route calculation by using this function.
■Addition of waypoints Use the following procedure to add new waypoints to the current route for recalculation.1
Select (add).
2
Set a waypoint using any method available from the screen.
Press the button or select , then select (route options), and then select
(destination and
waypoints
).
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 57
Page 59 of 126
58
3
Specify the order in which all the set waypoints are to be visited.Choose the location of the waypoint to be added, and then select (add).
4
Select (calculate).
NOTE• When a new destination is set using (destination), it will replace the current destination and the route calculation will be carried
out again.
• Step 3 must be performed for the second and any subsequent waypoints.
• Repeat Steps 1 to 3 for each waypoint to be set.
Route Options
TribecaNavi_US_B3112BE.qxd 06.12.12 11:08 AM Page 58
Page 60 of 126
59
Route Options
■Modifying destination or waypoint positionsUse this procedure to modify the destination or waypoint positions. The screen will display the calculated route and
the positions of the destination or waypoints that you will be able to modify.1
Select (list).
2
Select (change location).
3
Select the key corresponding to the location that is to be modified.The map for the area around your current location will be displayed.
Press the button or select , then select (route options), and then select
(destination and
waypoints
).
