&Selecting audible signal op-
erationUsing an electronic chirp, the system will
give you an audible signal when the doors
lock and unlock. If desired, you may
change the volume of the audible signal
or turn it off. For details, refer to“Keyless
buzzer volume setting”F3-61.&Warning chimes and warning
indicatorThe warning chime and the access key
warning light serve the following purposes:
.To minimize improper operation of the
keyless access with push-button start
system
.To protect your vehicle from theft
For details, refer to“Warning chimes and
warning indicator of the keyless access
with push-button start system”F3-28.
&Disabling keyless access
function
WARNING
If you wear an implanted pacemaker
or an implanted defibrillator, operate
the driver’s door to disable the key-
less access function. Otherwise, the
operation of an implanted pace-
maker or implanted defibrillator
may be affected by the radio waves
from the transmitter antenna.
When the vehicle is not going to be used
for a long time, or when you choose not to
use the keyless access function, the key-
less access function can be disabled.NOTE.The locking and unlocking function
by the remote keyless entry system is
not disabled.
.The setting can also be changed at
SUBARU dealers. For more details,
contact a SUBARU dealer.
.To start the engine while the func-
tions are disabled, perform the proce-
dure described in“Starting engine”
F9-27.
.We recommend that you disable the
keyless access functions under thefollowing conditions.
–When the vehicle is not going to
be used for an extended period of
time
–When the keyless access func-
tions are not going to be used
!Disabling functions
!By operating the access key fob
If you have registered a PIN code for PIN
Code Access, you can disable the keyless
access function by operating the access
key fob. For details about registering a PIN
code, refer to“Registration for a PIN code”
F2-12.
1. Open the driver’s door.
2. Rotate the lock lever forward.
Keys and doors/Keyless access with push-button start system
2-14

(115,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
3. Press and hold the“
”button and“
”
button on the access key fob simulta-
neously for more than 5 seconds.
A chirp sound will be heard, and the
function will be disabled.!By operating the driver’s door
1. Sit in the driver’s seat, and close the
door.
2. Push the rear side (unlock side) of the
power door locking switch.
3. Within 5 seconds after step 2 is
performed, open the driver’s door.
4. Within 5 seconds after step 3 is
performed, push the rear side (unlock
side) of the power door locking switch
twice while the door is open.
5. Within 10 seconds after step 4 is
performed, close and open the driver’s
door twice.
6. Within 10 seconds after step 5 is
performed, push the rear side (unlock
side) of the power door locking switch
twice while the door is open.7. Within 10 seconds after step 6 is
performed, close and open the driver’s
door once.
8. Within 5 seconds after step 7 is
performed, close the door. A chirp sound
will be heard, and the functions will be
disabled.
NOTEIn steps 4 and 6, press the power door
locking switch slowly. If the switch is
pressed quickly, the functions may not
be disabled.
!Enabling functions
When the procedure to disable the func-
tions is performed again, the functions are
enabled.NOTE.The keyless access function will be
enabled only if you perform the proce-
dure in the same manner you disabled
the function (for example, when dis-
abling by operating the driver’s door,
the function will not be enabled even if
you operate the access key fob).
.Press the push-button ignition
switch if you do not know the proce-
dure in which the keyless access func-
tion was disabled.
–When disabling by operating the
–CONTINUED–
Keys and doors/Keyless access with push-button start system
2-15
2

(116,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
driver’s door: a chirp will not be
heard
–When disabling by operating the
access key fob: a chirp will be heard
&When access key fob does
not operate properlyRefer to“Access key fob–if access key
fob does not operate properly”F9-26.&Replacing battery of access
key fobRefer to“Replacing battery of access key
fob”F11-52.&Replacing access key fobAccess key fobs can be replaced at
SUBARU dealers. For more details, con-
tact a SUBARU dealer.
&Certification for keyless ac-
cess with push-button start
system!U.S.-spec. models
FCC ID: HYQ13CZZ
FCC ID: HYQ14AHC
FCC ID: Y8PSSPIMB02
FCC ID: Y8PSSPLF02
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.NOTEThis device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This devicemay not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
!Canada-spec. models
Keys and doors/Keyless access with push-button start system
2-16

(117,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Mexico-spec. modelsIFT
RLVDE1413-2269
14AHC
DENSO&Tips!Operating range tips
Regarding malfunction:
The keyless access function may not
operate properly due to the following
reasons.
.The access key fob is placed too close
to the vehicle body (in this case, repeat the
operation from further away).
.The access key fob is placed near the
ground or in an elevated location from theground, even if it is in the operating range.
.The status of the access key fob and
the radio wave conditions around the
vehicle (in this case, perform the proce-
dure described in“Locking and unlocking”
F9-26.)
Precautions:
.When the access key fob is within the
operating range, it is possible for anyone,
even someone who is not carrying the
access key fob, to operate the keyless
access function. Please note that the
keyless access function is only available
for the following items when the access
key fob is detected within operating range.
–Door handle
–Door lock sensor
–Trunk opener button
.It is not possible to lock the doors using
the keyless access function when the
access key fob is inside the vehicle.
However, depending on the status of the
access key fob and the environmental
conditions, the access key fob may be
locked inside the vehicle. Before locking,
make sure that you have the access key
fob.
.The operating ranges may be reduced,
or the keyless access function may not
operate in the following cases:
–When the battery of the access keyfob is discharged
–When the access key fob is in a
location with strong radio waves or
noise (e.g., near a radio tower, power
plant, broadcast station or an area
where wireless equipment is used)
–While talking on a cell phone
In such a case, perform the procedure
described in“Locking and unlocking”F9-
26
.When an access key fob is in the
operating range, if the door handle be-
comes wet due to exposure to a significant
amount of water when the vehicle is
washed or during heavy rain, the doors
may be locked or unlocked.
!Keyless access function tips
.Turn off the push-button ignition switch
before locking the doors using the keyless
access function. It is not possible to lock
the doors using the keyless access func-
tion when the push-button ignition switch is
on the“ACC”or“ON”position. For details
about turning off the push-button ignition
switch, refer to“Switching power status”
F3-7.
.If the door handle is gripped or the door
lock sensor is touched with a gloved hand,
the doors may not be locked or unlocked.
.If the door lock sensor is touched three
times or more repeatedly, the system will
–CONTINUED–
Keys and doors/Keyless access with push-button start system
2-17
2

(118,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
ignore the sensor operation.
.When performing the locking proce-
dure too quickly, doors may not be locked.
After the locking procedures, it is recom-
mended to pull the REAR door handles to
confirm that the doors have been locked.
.It is possible to lock the doors even
when one of the doors is open. After
performing the locking procedure, close
the opened door to lock it.
.Within 3 seconds after locking the
doors by touching the door lock sensor, it
is not possible to unlock doors by gripping
the door handle.
.When locking, be sure to carry the
access key fob to prevent locking the
access key fob in the vehicle.
.The settings of the hazard warning
flasher operation and the volume of the
audible signal can be changed by your
SUBARU dealer. Contact your SUBARU
dealer for details. You can also change the
setting of the hazard warning flasher
operation by operating the multi-function
display (color LCD). For details, refer to
“Hazard warning flasher setting”F3-61.
Remote keyless entry system
CAUTION
.Do not expose the remote trans-
mitter to severe shocks, such as
those experienced as a result of
dropping or throwing.
.Do not take the remote transmit-
ter apart except when replacing
the battery.
.Do not get the remote transmitter
wet. If it gets wet, wipe it dry with
a cloth immediately.
.When you carry the remote trans-
mitter on an airplane, do not
press the button of the remote
transmitter while in the airplane.
When any button of the remote
transmitter is pressed, radio
waves are sent and may affect
the operation of the airplane.
When you carry the remote trans-
mitter in a bag on an airplane,
take measures to prevent the
buttons of the remote transmitter
from being pressed.
For models with“keyless access with
push-button start system”, the access
key fob is used as the transmitter for theremote keyless entry system. For models
without“keyless access with push-button
start system”, the transmitter for the
remote keyless entry system is located
inside the key head.
The remote keyless entry system has the
following functions.
.Locking and unlocking the doors with-
out a key
.Opening the trunk without a key
.Sounding a panic alarm
.Arming and disarming the alarm sys-
tem. For detailed information, refer to
“Alarm system”F2-24.
The operable distance of the remote key-
less entry system is approximately 30 feet
(10 meters). However, this distance will
vary depending on environmental condi-
tions. The system’s operable distance will
be shorter in areas near a facility or
electronic equipment emitting strong radio
waves such as a power plant, broadcast
station, TV tower, or remote controller of
home electronic appliances.
NOTE.For models with“keyless access
with push-button start system”,the
remote keyless entry system will not
be activated when the push-button
ignition switch is in any position other
Keys and doors/Remote keyless entry system
2-18

(119,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
than the“OFF”position.
.For models without“keyless access
with push-button start system”,the
remote keyless entry system will not
be activated when the key is inserted in
the ignition switch.Access key fob
1) Lock/arm button
2) Unlock/disarm button
3) Trunk opener button
4) PANIC button
Transmitter
1) Lock/arm button
2) Unlock/disarm button
3) Trunk opener button
4) PANIC buttonNOTEThe hazard warning flashers will flash
once or twice when the transmitter
button is pressed in the following
cases.
–When locking the doors
–When unlocking the doors
–When unlocking the trunk lid
Operation of the hazard warning
flashers in the above cases can be set
to“On”or“Off”by a SUBARU dealer.
Consult your SUBARU dealer for de-tails. Also, you can change the setting
using the multi-function display (color
LCD).Fordetails,referto“Hazard
warning flasher setting”F3-61.
&Locking the doorsPress the lock/arm button to lock all doors.
An electronic chirp will sound once and the
hazard warning flashers will flash once.
If any of the doors or the trunk lid is not fully
closed, an electronic chirp will sound five
times and the hazard warning flashers will
flash five times to alert you that the doors
(or the trunk lid) are not properly closed.
When you close the door, it will automati-
cally lock and then an electronic chirp will
sound once and the hazard warning
flashers will flash once.&Unlocking the doorsPress the unlock/disarm button to unlock
the driver’s door. An electronic chirp will
sound twice and the hazard warning
flashers will flash twice. To unlock all
doors, briefly press the unlock/disarm
button a second time within 5 seconds.
–CONTINUED–
Keys and doors/Remote keyless entry system
2-19
2

(120,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
NOTEIf the interval between the first and
second presses of the unlock/disarm
button (for unlocking of all of the doors)
is extremely short, the system may not
respond.&Opening the trunk lidThe trunk lid opens when the“
”button
is pressed continuously for at least 2
seconds. An electronic chirp will sound
twice and the turn signal lights will flash
twice.
NOTEYou can disable the“
”button on the
access key fob/transmitter. Contact
your SUBARU dealer to change the
setting.
&Vehicle finder functionUse this function to find your vehicle
parked among many vehicles in a large
parking lot. Provided you are within 30 feet
(10 meters) of the vehicle, pressing the
lock/arm button three times in a 5-second
period will cause your vehicle’s horn to
sound once and its hazard warning
flashers to flash three times.
NOTEIf the interval between presses is too
short when you press the lock/arm
button three times, the system may
not respond to the signals from the
access key fob/remote transmitter.&Sounding a panic alarmTo activate the alarm, press the“PANIC”
button once.
The horn will sound and the hazard
warning flashers will flash.
To deactivate the panic alarm, press any
button on the access key fob/remote
transmitter. Unless a button on the access
key fob/remote transmitter is pressed, the
alarm will be deactivated after approxi-
mately 30 seconds.&Selecting audible signal op-
eration (models without
“keyless access with push-
button start system”)Using an electronic chirp, the system will
give you an audible signal when the doors
lock and unlock. If desired, you may turn
the audible signal off.
Perform the following steps to deactivate
the audible signal. You can also use thesame steps to restore the function.
1. Sit in the driver’s seat and shut all
doors and the trunk.
2. Hold down the REAR (UNLOCK) side
of the power door locking switch.
3. While holding down the REAR (UN-
LOCK) side of the power door locking
switch, pull the key out and re-insert it into
the ignition switch at least 6 times within 10
seconds after Step 2.
4. Open and close the driver’s door once
within 10 seconds after Step 3.
5. The hazard warning flashers flash 3
times to indicate completion of the setting.
You may have the above settings done by
your SUBARU dealer. Also, the setting can
be changed using the multi-function dis-
play (color LCD). For details, refer to
Keys and doors/Remote keyless entry system
2-20

(121,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
“Keyless buzzer volume setting”F3-61.
You may also change the volume of the
audible signal by operating the multi-
function display (color LCD).&Replacing the batteryRefer to“Replacing battery”F11-51.&Replacing lost transmittersIf you lose a transmitter or want to
purchase additional transmitters (up to
four can be programmed), your transmit-
ters should be reprogrammed for security
reasons. For details, contact your
SUBARU dealer and have the transmitters
programmed into the remote keyless entry
system.&Certification for Remote key-
less entry system!U.S.-spec. models
FCC ID: CWTWB1U811
FCC ID: CWTWD1U781
CAUTION
FCC CAUTION
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate theequipment.
NOTEThis device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This de-
vice may not cause harmful interfer-
ence, and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.!Canada-spec. models
–CONTINUED–
Keys and doors/Remote keyless entry system
2-21
2

(122,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Mexico-spec. modelsCOFETEL RCPSUTW13-2221
COFETEL RLVSU8813-2140
Anti-theft system&ImmobilizerThe immobilizer system is designed to
prevent an unauthorized person from
starting the engine. Only keys registered
with your vehicle’s immobilizer system can
be used to operate your vehicle. This
system, however, is not a 100% anti-theft
guaranty.
For models with“keyless access with
push-button start system”:
If you press the push-button ignition switch
when carrying an unregistered access key
fob, the switch will not turn to the“ON”
position and the engine will not start.
For models without“keyless access
with push-button start system”:
Even if an unregistered key fits into the
ignition switch and can be turned to the
“START”position, the engine will automa-
tically stop after several seconds.
If the engine does not start, perform either
of the following procedures.
.Perform the procedure described in
“Starting engine”F9-27 (models with
“keyless access with push-button start
system”).
.Pull out the key once before trying
again (models without“keyless accesswith push-button start system”). Refer to
“Ignition switch”F3-4.
CAUTION
.Do not place the key under direct
sunlight or anywhere it may be-
come hot.
.Do not get the key wet. If the key
gets wet, wipe it dry with a cloth
immediately.
.Do not modify or remove the
system. If modified or removed,
the proper operation of the sys-
tem cannot be guaranteed.NOTE.To protect your vehicle from theft,
please pay close attention to the follow-
ing security precautions:
–Never leave your vehicle unat-
tended with its keys inside.
–Before leaving your vehicle,
close all windows and the moon-
roof, and lock the doors.
–Do not leave spare keys or any
record of your key number in the
vehicle.
.The vehicle has a maintenance-free
type immobilizer system.
Keys and doors/Anti-theft system
2-22

(123,1)
北米Model "A1700BE-B" EDITED: 2017/ 10/ 11
!Security indicator light
Refer to“Security indicator light”F3-33.
!Key replacement
Your key number plate will be required if
you ever need a replacement key made.
Any new key must be registered for use
with your vehicle’s immobilizer system
before it can be used. The maximum
number of keys that can be registered for
use with one vehicle is as follows.
.Four (models without“keyless access
with push-button start system”)
.Seven (models with“keyless access
with push-button start system”)
One key that has already been registered
is required in order to register a new key.
If you lose a key, the lost key’s ID code still
remains in the memory of the vehicle’s
immobilizer system. For security reasons,
the lost key’s ID code should be erased
from the memory. To erase the lost key’sID
code, all keys that will be used are
required.
For details about new key registration and
erasing the lost key’s ID code, contact your
SUBARU dealer.!Certification for immobilizer system
For models with“keyless access with
push-button start system”:
Refer to“Certification for keyless access
with push-button start system”F2-16.
For models without“keyless access
with push-button start system”:
!U.S.-spec. models
FCC ID: MOZRI-38BFH
CAUTION
FCC WARNING
Changes or modifications not ex-
pressly approved by the party re-
sponsible for compliance could void
the user’s authority to operate the
equipment.
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.!Canada-spec. models
–CONTINUED–
Keys and doors/Anti-theft system
2-23
2
