TESLA MODEL X 2022 Owner´s Manual

ISOFIX* Installed Child Restraints
Monopost Seats:
Mass GroupSize ClassFixture
Front
Passenger *SecondRow
OutboardSecond Row
Center
Third Row
Group 0up to 10 kgER1XILXIL**
Group 0+up to 13kg
ER1XILXIL**DR2XILXIL**CR3XXXIL**
Group I9 - 18 kg
DR2XILXIL**CR3XXXIL**BF2XIUFXIUFB1F2XXIUFXIUFAF3XIUFXIUFIUF: Suitable for universal ISOFIX forward child restraint systems approved for use in this mass
group.
IL: Suitable for particular ISOFIX child restraint systems in the "specific vehicle", "restricted", or
"semi-universal" categories.
X: Seating position does not support ISOFIX child restraint systems in this mass group/size
class.
* It is the driver

Bench Seats:
Mass GroupSize
ClassFixtureFront
Passenger*Second Row
OutboardSecond
Row
CenterThird RowGroup 0up to 10 kgER1XILXIL**
Group 0+up to 13kg
ER1XILXIL**DR2XILXIL**CR3XILXIL**
Group I9 - 18kg
DR2XILXIL**CR3XILXIL**BF2XIUFXIUFB1F2XXIUFXIUFAF3XIUFXIUFIUF: Suitable for universal ISOFIX forward child restraint systems approved for use in this mass
group.
IL: Suitable for particular ISOFIX child restraint systems in the "specific vehicle", "restricted", or
"semi-universal" categories.
X: Seating position does not support ISOFIX child restraint systems in this mass group/size
class.
* It is the driver

Seating Larger Children
If a child is too large to fit into a child safety
seat, but too small to safely fit into the
standard seat belts, use a booster seat
appropriate for the child

Bench Seats:
In the second row, install ISOFIX child safety
seats in the outboard seating positions only.
Use only a seat belt retained seat in the center
position.
Note: If Model X is equipped with two seats in
the second row, both seats support the use of
ISOFIX child safety seats.
Monopost Seats:
Child Safety Seats
34Model X Owner

Bench Seats:
In the third row (if equipped), you can install
ISOFIX child safety seats in both seating
locations.
To install a ISOFIX child safety seat, slide the
safety seat latches onto the anchor bars until
they click into place. Carefully read and follow
the instructions provided by the child safety
seat manufacturer.
Monopost Seats:
Bench Seats:
Once installed, test the security of the installation before seating a child. Attempt to twist the child safety seat from side to side
and try to pull it away from the seat, then
check to ensure the anchors remain securely
in place.
Child Safety Seats
Seating and Safety Restraints35

Note: Lower LATCH anchors should not be
used with child seats or booster seats that
have an integrated safety belt in situations
where the combined weight of the child plus the child restraint is more than 65 lbs (29 kg).In these situations, use the safety belt instead.
Attaching Upper Tether Straps
If an upper tether strap is provided, attach its
hook to the anchor point located on the back of the second and third row seats.
Note: The location of anchor points may not
be readily visible but can be found by
identifying a slice in the seat

For single-strap tethers, position the strap in
the outboard seating positions over the outside-facing side of the head restraint (i.e.
same side of the head restraint as the seat belt
retraction mechanism). In the center seating
position (if equipped), center and position the
strap over the top of the head restraint.
Single Strap - Second Row Monopost Seats:
Single Strap - Second Row Bench Seats:
Child Safety Seats
Seating and Safety Restraints37

Single Strap - Third Row Seats
Note: If Model X is equipped with the optional
six seat interior, a center seating position is
not available in the second row.
Testing a Child Safety Seat
Before seating a child, always make sure the
child safety seat is not loose:
1. Hold the child safety seat by the belt path
and try to slide the safety seat from side
to side and front to back.
2. If the seat moves more than 2.5 cm, it is
too loose. Tighten the belt or reconnect
the ISOFIX retained child safety seat.
3. If you are unable to reduce slack, try a
different seat location or try another child
safety seat.
Child Safety Seat Warnings
Warning: Never seat a child in a child
safety seat or a booster seat on the front
passenger seat when the airbag is
activated. Doing so can cause serious injury or death.Warning: Never use a rearward facing
child restraint on a seat protected by an
active airbag. Doing so can cause serious
injury or death. Refer to the warning label
located on the sun visor.Warning: Child restraint systems are
designed to be secured in vehicle seats
by lap belts or the lap belt portion of a lap-shoulder belt. Children could be
endangered in a crash if their child restraints are not properly secured in the
vehicle.Warning: According to collision statistics,
children are safer when properlyrestrained in the rear seating positions
than in the front seating positions.Warning: Do not use a forward facing
child safety seat until your child weighs
over 9 kg and can sit independently. Up
to the age of two, a child

Airbags
Location of Airbags Airbags are located in the approximate areas shown here. Airbag warning information is printed
on the sun visors.
Model X is equipped with an airbag and lap/shoulder belt at both front outboard seating
positions. The airbag is a supplemental restraint at those seating positions. All occupants,
including the driver, should always wear their seat belts whether or not an airbag is also provided at their seating position to minimize the risk of severe injury or death in the event of a crash.
Note: On RHD (Right Hand Drive) vehicles, the locations of the passenger and driver airbags are
reversed.
1. Front airbags
2. Curtain airbags
3. Seat-mounted side airbags
4. Door-mounted airbags
Airbags
Seating and Safety Restraints39

How the Airbags Work
Airbags in
