TOYOTA 4RUNNER 2003 N210 / 4.G Navigation Manual

4Runner_Navi_U (L/O 0208)
32003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
Touching the “List” switch will change
the screen to a display of the database
items that match the name or address
that you have entered on the screen. The
number of matching items is shown to
the right side of the screen. If the match-
ing item is more than 9,999, the system
displays
“” on the screen.
To input numerals, touch the
“0–9”
switch and the display will change the
screen to number input display.
L00014
Touching the “A–Z” switch changes the
screen back to the previous name input
display.
L00015
When a list is displayed, you can scroll
or page through the list by using the
appropriate switch.
To shift to the next or previous
page.
To scroll up or down one item
at a time.
This expresses a displayed
screen position.
If appears to the right of the
item name, the complete name
is too long for the display.
To u c h , and the name will
scroll to the end of the name.
Touching will scroll the
name to the beginning of the
name.

4Runner_Navi_U (L/O 0208)
42003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
L00016
1. Touch the “Adjust” switch to move the cursor .
How to move the cursor

4Runner_Navi_U (L/O 0208)
52003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
L00017
Position locating screen on the map
2. When you touch an arrow facing your desired point, the map scrolls in that direction. When you release your finger,
scrolling stops.
3. If you touch the
“Enter” switch, the position of cursor is set.

4Runner_Navi_U (L/O 0208)
62003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
Touch the “DEST” tab on the screen
and the “Destination” screen appears.
L00018
The “Destination” screen allows you to
select the area to search for your des-
tination.
Touch the
“Change” switch on the
“Destination” screen to display a map
of the United States and Canada divid-
ed into 11 areas. See page 62 for map
database information and updates.
L00019
Touch one of the “US1” through
“CAN” switches to select a search
area. Touch the
“OK” switch and the
“Destination” screen returns.
Once you choose the area to search, you
can use one of 11 different methods to
enter your destination. USA
SwitchStates included in the search
area
US1Idaho
Oregon
Washington
US2California
Nevada
US3
Arizona
Colorado
Montana
New Mexico
Utah
Wyoming
US4
Iowa
Kansas
Minnesota
Missouri
Nebraska
North Dakota
South Dakota
US5Oklahoma
Te x a s
US6
Illinois
Indiana
Kentucky
Michigan
Ohio
Wisconsin
Destination input

4Runner_Navi_U (L/O 0208)
72003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
US7
Alabama
Arkansas
Louisiana
Mississippi
Tennessee
US8
Connecticut
Maine
Massachusetts
New Hampshire
New Jersey
New York
Rhode Island
Vermont
US9
Delaware
Maryland
New Jersey
Pennsylvania
Virginia
Washington, D.C.
West Virginia
US10
Florida
Georgia
North Carolina
South Carolina
Canada
SwitchProvinces and regions included
in the search area
CAN
Alberta
British Columbia
Manitoba
New Brunswick
Newfoundland and Labrac
Nova Scotia
Ontario
Prince Edward Island
Québec
Saskatchewan
You can find your destination using vari-
ous methods. See pages 10 through 24
for the detailed steps.
1. By Home (
switch on the “Destination” screen): You can select your own home without entering the address each time.
To use this function, it is necessary to register y our home beforehand. See page 10 for the detailed steps.
2. By Preset Destination (
— switches on the “Destination” screen): You can select one of 5 preset destinations
directly. To use this function, it is necessary to register the destinations beforehand. See page 11 for the detailed steps.

4Runner_Navi_U (L/O 0208)
82003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
3. By Address: You can input the house number and th e street address by using the input keys. See page 11 for the detailed
steps.
4. By POI: You can select one of the many points of interest that ha ve been already stored in the system’s database. There are
about 50 categories to choose from, including restaurants, banks and automotive locations. See page 14 for the detailed steps.

4Runner_Navi_U (L/O 0208)
92003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
5. By Marked Point: You can register your own favorite destinations as a “Marked Point”. The system allows you to store up 100
marked points. See page 19 for the detailed steps.
6. By Previous Destination: You can select a destination from any of the last 20 previously set destinations. See page 20 for
the detailed steps.
7. By Emergency: You can select one of the three points of emergency service points that have been already stored in the system’s
database. See page 21 for the detailed steps.
8. By Intersection: You can enter the names of two intersec ting streets. This is helpful if you do not know the specific street
address of your destination but know the general vicinity. See page 22 for the detailed steps.
9. By Freeway Entrance/Exit: You can enter the name of the freeway (interstate) entrance or exit. See page 23 for the detailed
steps.
10. By Previous Starting Point: You can enter a point where the system has started to guide last time. See page 24 for the detailed
steps.

4Runner_Navi_U (L/O 0208)
102003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
11. By Map Selection: You can select a destination simply by touching the location on the displayed map. See page 24 for the
detailed steps.
INFORMATION
 When inputting the destination, the
response to the switch may be
slow.
 “Points of Interest” registration is
made based on the NAVTECH
“Standard POI Inclusion List” and
infoUSA POI data.
 If there is no point registered,
switches such as “Marked Point”,
“Previous Destination” and “Pre-
vious Starting Point” are dimmed
and not available.
 The route for returning may not be
the same as that for going.
 The route guidance to the destina-
tion may not be the shortest route
or a route without traffic conges-
tion.
 Route guidance may not be avail-
able if there is no road data for the
specified location.When setting the destination, you
should use the map on a scale of
one half mile or smaller.
 To select an “Address”, “Point of
Interest”, “Freeway Entrance/Exit”
or “Intersection” in a different area,
it is necessary to change the
search area.
CAUTION
While you are driving, be sure to
follow traffic regulations and keep
the road condition in mind. If a traf-
fic sign on the road has been
changed, the route guidance may
provide wrong information.
Touch the switch on the Destina-
tion input screen.
The screen changes and displays the
map location of your home.
Guidance starts from your current posi-
tion to your home immediately after you
touch the
switch during driving.
For the steps to register your home, see
“Registering your home” on page 41.
Destination input by HOME

4Runner_Navi_U (L/O 0208)
112003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
Touch any of — (preset des-
tination) switches on the “Destination”
screen.
The screen changes and displays the
map location of the preset destination.
Guidance starts from your current posi-
tion to the preset destination immediately
after you touch the preset destination
switch.
For the steps to register a preset destina-
tion, see “Registering preset destination”
on page 45.
L00020
There are 2 ways to input a destina-
tion by address. Touch the
“Address” switch on the
destination screen. The “Address”
screen appears, and then you can in-
put a house number.
Touch letters directly on the screen to
input a house number.
L00021
After inputting a house number, touch the
“Enter” switch to display the screen
which you can input a street name.
It is possible to input a street name first.
Touch the
“Street” switch to display
the screen which you can input a street
name.
Destination input by PRESET
DESTINATION Destination input by
ADDRESS(a) Inputting a house number
and a street name

4Runner_Navi_U (L/O 0208)
122003 MY 4Runner Navigation from Aug. ’02 Prod. (OM35799U)
L00022
After each letter is input, the system
searches the database for street names
that match. Alphabet keys are dimmed if
the database does not have a match for
the next letter in the remaining list of
matching street names.
When you input numerals, touch the
“0–9” switch to display the screen
for numeral input.
Based on your input, the number of
matching sites appears at the top right of
the screen. After the number decreases
to some extent, touch the
“List” switch
to display the street selection list. If the
number of matches decreases to 4 or
less, the screen changes automatically to
the selection list.
L00015
When you find your desired street
name, touch
of the item. The
screen changes and displays the map
location of the selected destination
and the route preference. (See “(a) En-
tering destination” on page 25.)
If the same address exists in more than
one city, the current screen changes to
the “City Select” screen. Select or enter
your desired city.
L00023
If you input a street name first, the
screen changes. You can then input the
house number.
L00024
If the above screen appears, you can
select an address range on that screen.
