navigation system TOYOTA 4RUNNER 2004 N210 / 4.G Navigation Manual

4Runner_Navi_U (L/O 0308)
98
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
1. Touch the “MENU” tab on the screen to display the “Menu” screen, and touch the “Setup” switch.
L00059
L00133
2. Touch the “On” switch of “Auto reroute”. If you can not find the item on the list, touch or to scroll up or
down the list.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new
route may or may not take you back
to the previous route depending on
how far you are off the original guid-
ance route.When the “Estimated travel time” fea-
ture is turned on, the time required to
reach the destination is displayed on
the route guidance screen.
L00059
To turn the “Estimated travel time” on:
Estimated travel time

4Runner_Navi_U (L/O 0308)
11 0
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
The current street name appears on the
map screen.
L00148L00136
This system has a function which in-
forms you of the time to replace cer-
tain parts or components as well as
other information shown on the
screen. (See “INFORMATION ITEMS”
on page 112.) When the system begins
operating after reaching either the In-
formation Item’s date or driving dis-
tance, the “Information” screen will be
displayed.
To avoid seeing the “Information” screen
again, touch the
“Do not display
this message again”
switch.
NZN044
Maintenance information

4Runner_Navi_U (L/O 0308)
11 2
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
L00138
Date: Input the next maintenance date.
Distance: Input the driving distance until
the next maintenance check. You can in-
put up to five digits for the driving dis-
tance.
When you touch the
“!” switch on the
screen, the screen changes to display the
“Change name” screen. Touch the keys to
input your desired name and then input
the conditions.
After you input the information, touch the
“OK” switch. The screen returns to the
“Maintenance” screen. The icon color will
change to green after the date and driv-
ing distance are input. The icon color will
change to orange when your vehicle
needs to be serviced. The following
switches appear on the “Maintenance”
screen.Delete all: Cancel all conditions which
have been input.
Reset all: Reset all items which satisfy
either condition.
Touch the
“Off” switch on the “Mainte-
nance” screen, and the “Information”
screen will no longer be displayed.
INFORMATION
For scheduled maintenance infor-
mation, please refer to the “Sched-
uled Maintenance Guide” or “Own-
er’s Manual Supplement”.
Depending on your driving or the
road conditions, the system may
have a timelag between the data
which has been input and the actu-
al date and driving distance.
INFORMATION ITEMS
Oil change
Replace oil filter
Rotate tires
Replace tires
Replace battery
Replace brake linings
Replace wiper blades
Replace engine coolant

4Runner_Navi_U (L/O 0308)
11 7
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
L00185
This system has a function which in-
forms you the memo you entered.
When the system begins operating af-
ter reaching the memo’s date, the In-
formation screen will be displayed.
The Information screen will not be dis-
played again by touching the
“Do not
display this message again”
switch.
L00153
Push the “INFO” button to display
the “Information Menu” screen. Touch
the
“Calendar” switch to display
the “Calendar” screen.
Today’s date is circled in green. If today’s
date is not displayed on the screen,
touch
“Today” switch to display a cal-
endar of this month.
L00153
Calendar with memo (a) Inputting a memo

4Runner_Navi_U (L/O 0308)
125
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
NZN065
Depending on the position of the head-
light switch, the screen changes to the
day mode or night mode.
To display the screen in the day mode
even with the headlight switch on, touch
“DAY MODE” on the adjustment screen
for brightness and contrast control.
However, if the instrument panel light
control is adjusted to full intensity, mode
switching cannot be done. It remains in
the day mode. In this case, “DAY MODE”
is not shown on the screen.
If the screen is set in the day mode with
the headlight switch turned to on, this
condition is memorized in the system
even with the engine turned off.
NZN044
You can select a function that enables
automatic return to the previous
screen from the audio screen.
1. Push the
“INFO” button to display the “Information Menu” screen. Touch “Screen Transition”.
Screen transition

4Runner_Navi_U (L/O 0308)
128
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
AUDIO SYSTEM
Audio system
Quick reference for your audio system129 . . . . . . . . . . . . . . . . . . . . . . .
Your audio system130 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using your audio system131 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio remote controls146 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Car audio system operating hints150 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SECTION V

4Runner_Navi_U (L/O 0308)
129
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
Function switch display screen
Touch the switches displayed on
the screen to control the radio,
cassette tape player and compact
disc player. For details, see page
132.“TUNE” knob
Turn this knob to move up or
down the station band. For
details, see page 135.
“AM” button
Push this button to choose an AM
station. For details, see pages
131 and 135.
“FM” button
Push this button to choose a FM
station. For details, see pages
131 and 135.
“DISC” button
Push this button to turn the
compact disc player on. For
details, see pages 131 and 142.
“TAPE” button
Push this button to turn the
cassette tape player on. For
details, see pages 131 and 139.
“TRAF” button
Push this button to seek a station
that broadcasts traffic information
regularly. For details, see page
138. “OPEN” button
Push this button to open the
display to access the slots for the
cassette tape player and compact
disc player. For details, see pages
130, 139 and 143.
“PWR·VOL” knob
Push this knob to turn the
audio system on and off, and
turn it to adjust the volume.
For details, see page 131.
“SEEK/TRACK” button
Push either side of this button
to seek up or down for a
station, or to access a desired
program or track. For details,
see pages 135, 142 and 144.
“SCAN” button
Push this button to scan radio
stations or scan the tracks on
a compact disc. For details,
see pages 136 and 145.
“AUDIO” button
Push this button to display the
audio control screen. For
details, see page 131.
“TILT” button
Push this button to tilt the
display. For details, see page
130.
Quick reference for your audio system

4Runner_Navi_U (L/O 0308)
130
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
L00004
You can adjust the angle of the dis-
play by pushing the “TILT” button.
Each push of the “TILT” button will tilt
the display to position 1, 2, 3 and then
back to 0 in that order.
If you turn the ignition switch off, the
display will automatically move back to
position 0. The display will automatically
resume the previous position you used
when the ignition switch is turned to the
“ACC” or “ON” position.
The slots for the cassette tape player
and compact disc player are behind
the display.
To lower the display, push the “OPEN”
button. After you inserting the cassette
tape or compact disc, push the button
again to close the display.
CAUTION
Do not place anything on the
opened display, as such items may
be thrown about in the compart-
ment and possibly injure people in
the vehicle during sudden braking
or in an accident.
To reduce the chance of injury in
case of an accident or sudden
stop while driving, keep the dis-
play closed.
Take care not to jam your hand
while the display is moving. Other-
wise, you could be injured.
NOTICE
Do not obstruct the display while it
is moving. It could damage your au-
dio system.
Your audio system

4Runner_Navi_U (L/O 0308)
131
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
This section describes some of the basic
features of the Toyota audio system.
Some information may not pertain to your
system.
Your audio system works when the igni-
tion switch is in the “ACC” or “ON” posi-
tion.
NOTICE
To prevent the battery from being
discharged, do not leave the car au-
dio on longer than necessary when
the engine is not running.
L00166
(a) Turning the system on and off
PWR·VOL: Push this knob to turn the
audio system on and off. Turn this knob
to adjust the volume. The system turns
on in the last mode used.
AUDIO: Push this button to display
switches for audio system (audio control
mode).
You can select the function that enables
automatic return to the previous screen
from the audio screen. See page 125 for
details.Push “AM”, “FM”, “DISC” or “TAPE”
button to turn on the desired mode.
The selected mode turns on immedi-
ately.
Push these buttons if you want to switch
from one mode to another.
If the tape or disc is not set, the cassette
player or compact disc player does not
turn on.
You can turn off the cassette player or
compact disc player by ejecting the cas-
sette tape or compact disc. If the audio
system was previously off, then the entire
audio system will be turned off when you
eject the cassette tape. If another func-
tion was previously playing, it will come
on again.
Using your audio system—
—Some basics

4Runner_Navi_U (L/O 0308)
132
2004 4RUNNER Navigation from Aug. ’03 Prod. (OM35813U)
The switches for radio, cassette tape
player, compact disc player operation
is displayed on the function switch
display screen when the audio control
mode is selected. Touch the switches
lightly and directly on the screen.
The selected switch is highlighted in
green.
INFORMATION
If the system does not respond to
a touch of a switch, move your fin-
ger away from the screen and then
touch it again.
You cannot operate dimmed
switches.
Wipe off fingerprints on the surface
of the display using a glass clean-
ing cloth.
