TOYOTA 4RUNNER 2020 Owners Manual (in English)

3615-3. Using the storage features
5
Interior features
4RUNNER (U)
■Adjusting the size of the cup holders
Front seats
Rear seats (without third row seats)
Remove the adapter.
Remove the adapter.
WARNING
■
Items unsuitable f or the cup holders
Do not place anything other than cups or aluminum cans in the c up holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury. If possible, cover hot drinks t o prevent
burns.
■ When not in use (second row seat cup holders only)
Keep the cup holders closed. In the event of sudden braking, an accident
may occur due to an occupant being struck by the open cup holde rs or the
items stored inside.
NOTICE
■ To prevent damage to the rear cup holders (second row seats onl y)
Stow the cup holders before stowing the armrest.

3625-3. Using the storage features
4RUNNER (U)
Push the lid.
Auxiliary box (if equipped)
WARNING
■Items unsuitable for storing
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the auxiliary box to open and the items insi de may fall
out, resulting in an accident.

3635-3. Using the storage features
5
Interior features
4RUNNER (U)
Lift the lid while pul ling up the knob to release the lock.
Coin holder
Tissue pocket
Pen holder
Coin holder/tissue pocket/pen holder
1
2
3

3645-3. Using the storage features
4RUNNER (U)
■When using the bottle holder
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
Front seatsRear seats (without third row
seats)/second row seats (with
third row seats)
WARNING
■Items unsuitable for the bottle holder
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
■ Items that should not be st owed in the bottle holders
Put the cap on before stowing a bottle. Do not place open bottl es in the bot-
tle holders, or glasses and paper cups containing liquid. The c ontents may
spill and glasses may break.

3655-3. Using the storage features
5
Interior features
4RUNNER (U)■
Cargo hooks
Vehicles with third seats
Fold down the third seats. (
P. 145)
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Vehicles with out third seats
Raise the hook to use.
The cargo hooks are provided
for securing loose items.
Luggage compartment features
1
2

3665-3. Using the storage features
4RUNNER (U)■
Cargo net hooks
The cargo net itself is not included as original equipment.
Vehicles with third seats (pattern 1)
Raise the rear cargo hook to
use.
Vehicles with third seats (pattern 2)
Fold down the third seats. ( P. 145)
Raise the cargo hook to use.
Vehicles without third seats (pattern 1)
Raise the rear cargo hook to
use.
1
2

3675-3. Using the storage features
5
Interior features
4RUNNER (U)
Vehicles without third seats (pattern 2)
Raise the cargo hook to use.
■Storage compartment
Open the storage co mpartment as shown.
Type A (if equipped)Type B (if equipped)

3685-3. Using the storage features
4RUNNER (U)■
Slide deck (if equipped)
Slide the deck while turning the
lock release lever, and then
release the lever after sliding
the deck to the
lock position.
Half-slide locked position
Full-slide locked position
■Grocery bag hooks
Type B only: To use the grocery bag hooks, slide the slide deck to
the full-slide locked position.
1
2
Ty p e AType B (if equipped)

3695-3. Using the storage features
5
Interior features
4RUNNER (U)
WARNING
■When the cargo hooks are not in use
To avoid injury, always return the cargo hooks to their stowed positions.
■ Slide deck operating precaution (if equipped)
● Be careful not to get hands or feet pinched by the slide deck.
● Be careful not to allow the slide deck to hit any persons or lu ggage while
sliding the deck.
● Do not operate the slide deck while someone is on it.
Doing so may cause an accident.
● If operating the slide deck when the vehicle is stopped on an i ncline, the
slide deck may move faster. Be careful not to allow the slide d eck to hit
you or pinch your fingers etc.
● After sliding the deck, make sure it is securely locked in position.
● Do not close the back door while any person is sitting on the s lide deck or
any person is between the slide deck and back door.
● Do not stow any objects into the space between the slide deck r ails.
NOTICE
■To prevent damage to the cargo net hooks
Avoid hanging things other than a cargo net on them.
■ Slide deck weight capacity (if equipped)
Do not load anything heavier than 440 lb. (200 kg) on the slidi ng deck.
■ Grocery bag hook weight capacity
Do not hang any object heavier than 8.8 lb. (4 kg) on the groce ry bag hooks.
■ When using the slide deck (if equipped)
● Do not close the back door while the slide deck is sliding out. Doing so
may cause the back door or slide deck to break.
● If operating the slide deck when the vehicle is stopped on an i ncline, the
slide deck may move faster. Be careful as luggage may become da maged
or fly out and damage the cabin.

370
4RUNNER (U)
5-4. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Slide the cover to open.
The light turns on when the cover
is opened.
Other interior features
Sun visors
1
2
3
Vanity mirrors
NOTICE
■ To prevent battery discharge
Do not leave the vanity lights on for extended periods while th e engine is off.
