TOYOTA 4RUNNER 2022 Owner's Manual

21Pictorial index
4RUNNER (U)USB port
*2
Seat heater/ventilator switches*1. . . . . . . . . . . . . . . . . . . . . P. 367
Power outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 390
Front-wheel drive control lever
*1. . . . . . . . . . . . . . . . . . . . . P. 305
Front-wheel drive control switch
*1 . . . . . . . . . . . . . . . . . . . P. 305
Four-wheel drive control switch
*1. . . . . . . . . . . . . . . . . . . . P. 309
USB charging ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 393
Power back window switch . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Seat heater switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 3 67
*1: If equipped
*2: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5
6
7
8

22Pictorial index
4RUNNER (U)Audio remote control switches
*
Talk switch*
Meter control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 93
Cruise control switch
Dynamic radar cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . P. 268
LDA (Lane Departure Alert) switch. . . . . . . . . . . . . . . . . . . . P. 260
Vehicle-to-vehicle distance switch . . . . . . . . . . . . . . . . . . . . P. 275
Telephone switches
*
1
2
3
4
5
6
7

23Pictorial index
4RUNNER (U)
■Interior
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 37
Floor mat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 28
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 135
Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 152
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 32
Console box/tissue pocket . . . . . . . . . . . . . . . . . . . . . . P. 373, 377
Inside lock buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 113
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 374
Bottle holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 378
Armrest/cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 374, 395
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
*: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5
6
7
8
9
10
11
12

24Pictorial index
4RUNNER (U)Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 157
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 384
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 384
Interior light
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370
Personal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 370
Moon roof switches
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 169
“SOS” button
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 72
Garage door opener switches
*1. . . . . . . . . . . . . . . . . . . . . . P. 396
Microphone
*3
Assist grips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 395
Active traction control switch
*1. . . . . . . . . . . . . . . . . . . . . . P. 313
VSC off switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 335
DAC switch
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 320
Rear differential lock switch
*1 . . . . . . . . . . . . . . . . . . . . . . . P. 317
Crawl Control switch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 3 23
Multi-terrain Select switch
*1. . . . . . . . . . . . . . . . . . . . . . . . . P. 326
Auxiliary box
*1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17

25Pictorial index
4RUNNER (U)Back door handles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131
Luggage compartment lights . . . . . . . . . . . . . . . . . . . . . . . . P. 132
Back door strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 131
Child restraint anchor brackets . . . . . . . . . . . . . . . . . . . . . . . P. 59
Power outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 390
Power outlets (120 V AC) . . . . . . . . . . . . . . . . . . .
. . . . . . . . P. 386
Slide deck
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 382
Storage compartment
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 502
Tool bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 502
Cargo net hooks/Grocery bag hooks . . . . . . . . . . . . . . P. 380, 382
*1: If equipped
*2: The illustration shows the front, but they are also equipped in the rear.
*3: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5
6
7
8
9
10
11

26Pictorial index
4RUNNER (U)

27
For safety and security1
4RUNNER (U)1-1. For safe use
Before driving ...................... 28
For safe driving ................... 30
Seat belts ............................ 32
SRS airbags ........................ 37
Front passenger occupant classification system ......... 48
Safety information for children ............................. 54
Child restraint systems........ 55
Installing child restraints...... 59
Exhaust gas precautions..... 71
1-2. Emergency assistance Safety Connect ................... 72
1-3. Theft deterrent system Engine immobilizer system .............................. 78
Alarm................................... 80

28
4RUNNER (U)
1-1. For safe use
Use only floor mats designed specifically for vehicles of the same
model and model year as your vehicle. Fix them securely in plac e
onto the carpet.
Insert the retaining hooks (clips)
into the floor mat eyelets.
Turn the upper knob of each
retaining hook (clip) to secure
the floor mats in place.
*: Always align the marks. The shape of the retaining hooks (clips) may differ from that s hown in the
illustration.
Before driving
Floor mat
1
*
O

291-1. For safe use
1
For safety and security
4RUNNER (U)
WARNING
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering
with the pedals while driving. An unexpectedly high speed may result or it may
become difficult to stop the vehicle. This could lead to an acc ident, resulting in
death or serious injury.
■ When installing the driver’s floor mat
● Do not use floor mats designed for other models or different model year
vehicles, even if they are Toyota Genuine floor mats.
● Only use floor mats designed for the driver’s seat.
● Always install the floor mat securely using the retaining hooks (clips) pro-
vided.
● Do not use two or more floor mats on top of each other.
● Do not place the floor mat bottom-side up or upside-down.
■ Before driving
● Check that the floor mat is securely
fixed in the correct place with all the
provided retaining hooks (clips). Be
especially careful to perform this check
after cleaning the floor.
● With the engine stopped and the shift
lever in P, fully depress each pedal to
the floor to make sure it does not inter-
fere with the floor mat.

301-1. For safe use
4RUNNER (U)
Adjust the angle of the seat-
back so that you are sitting
straight up and so that you do
not have to lean forward to
steer. (P. 1 3 5 )
Adjust the seat so that you can
depress the pedals fully and so
that your arms bend slightly at
the elbow when gripping the
steering wheel. ( P. 135)
Adjust the tilt and telescopic positions of the steering wheel down-
ward so the airbag is facing your chest. ( P. 155)
Lock the head restraint in place with the center of the head restraint
closest to the top of your ears. ( P. 1 5 2 )
Wear the seat belt correctly. ( P. 3 2 )
Make sure that all occupants are wearing their seat belts before driv-
ing the vehicle. ( P. 3 2 )
Use a child restraint system appropriate for the child until th e child
becomes large enough to properly wear the vehicle’s seat belt.
(  P. 55)
For safe driving
For safe driving, adjust the seat and mirror to an appropriate
position before driving.
Correct driving posture
1
2
Correct use of the seat belts
3
4
5
