Vehicle specifications
■Automatic light control system* (P. 235)
*: If equipped
■
Follow me home system (P. 237)
■LDA (Lane Departure Alert)* (P. 271)
*: If equipped
■
RSA (Road Sign Assist)* (P. 280)
*: If equipped
FunctionDefault settingCustomized set-
ting
Light sensor sensitivityStandard-2 to 2O—O
123
FunctionDefault settingCustomized set-
ting
Time elapsed before
headlights automatically
turn off
30 seconds
60 seconds
——O90 seconds
120 seconds
123
FunctionDefault settingCustomized set-
ting
LDA warning sensitivityHighStandard—O—
123
FunctionDefault settingCustomized set-
ting
RSA systemOnOff—O—
Notification method of
excessive speed Only display
Display and
buzzer
—O—
Off
Notification methods
other than excessive
speed
Only display
Display and
buzzer
—O—
Off
Notification level of
excessive speed 2 km/h (1 mph)10 km/h (5 mph)—O—5 km/h (3 mph)
123
AURIS Touring Sports_OM_Europe_OM12L13E.book 639 ページ ２０１６年６月２７日　月曜日　午後５時２１分

6409-2. Customization
AURIS Touring Sports_EE (12L13E)■
Stop & Start system* (P. 286)
*: If equipped
■
Toyota parking assist-sensor*1 (P. 308)
*1: If equipped
*2: Vehicles with a navigation/multimedia system
*3: When Toyota parking assist-sensor is operating.
■
Automatic air conditioning system* (P. 409)
*: If equipped
FunctionDefault settingCustomized set-
ting
Change the Stop & Start
system duration when the
A/C is on
NormalLong—O—
123
FunctionDefault settingCustomized set-
ting
Toyota parking assist-
sensor systemOnOff—O—
Detection distance of the
front center sensors
*2FarNearO—O
Detection distance of the
rear center sensors
*2FarNearO—O
Buzzer volume*251 to 4O—O
Display setting*2, 3All sensors dis-
playedDisplay offO—O
123
FunctionDefault settingCustomized set-
ting
Switching between out-
side air and recirculated
air mode linked to
“AUTO” switch operation
OnOffO—O
A/C auto switch operationOnOff——O
123
AURIS Touring Sports_OM_Europe_OM12L13E.book 640 ページ ２０１６年６月２７日　月曜日　午後５時２１分

647What to do if... (Troubleshooting)
AURIS Touring Sports_EE (12L13E)
●The seat belt reminder light is flashing
Are the driver and the front passenger wearing the seat belts? (P. 549)
●The brake system warning light is on
Is the parking brake released? (P. 234)
Depending on the situation, other types of warning buzzer may also sound.
(P. 545, 557)
●Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (P. 87)
Vehicles without a smart entry & start system
To stop the alarm, turn the engine switch to the “ON” position or start the
engine.
Vehicles with a smart entry & start system
To stop the alarm, turn the engine switch to IGNITION ON mode or start the
engine.
●Is the electronic key left inside the vehicle?
Vehicles with a 2-ring meter: Check the message on the multi-information
display. (P. 557)
●When a warning light turns on, refer to P. 545.
●When a warning light turns on or a warning message is displayed, refer to
P. 545, 557.
A warning buzzer sounds during driving
An alarm is activated and the horn sounds
(vehicles with an alarm)
A warning buzzer sounds when leaving the vehicle
(vehicles with a smart entry & start system)
A warning light turns on
(vehicles with a 3-ring meter)
A warning light turns on or a warning message is displayed
(vehicles with a 2-ring meter)
