TOYOTA AVALON 1996 User Guide

11
Wireless remote control transmitter:

Avoid knocking it hard against other
objects.

Avoid putting it in water.
Replacing transmitter batteries
The expected life of your transmitter bat-
teries is about one year. For replacement,
use DURACELL
[ DL2016 or equivalent.
a. Using a screwdriver, separate the two
halves of the transmitter with the transmit-
ter buttons facing down.
Take care not to damage the rubber gas-
ket during removal.
b. Remove and replace the transmitter
batteries.
If you touch a new battery with your fin-
gers, clean it with rubbing alcohol. Skin
oils may shorten the batteries' life.
c. Reassemble the transmitter case.
Make sure the gasket is properly installed.
After replacing batteries, check that the
transmitter operates properly. If the trans-
mitter still does not operate properly, con-
tact your Toyota dealer.
MODEL/FCC ID: GQ43VT7T
ISC: 1470 K1361
MADE IN U.S.A.
This device complies with part 15 of the
FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) This device must
accept any interference received, in-
cluding interference that may cause un-
desired operation.
The windows can be operated with the
switch on each door.
The power windows work when the igni-
tion switch is in the ONº position. Howev-
er, if both front doors are closed, they work
for 60 seconds even after the ignition
switch is turned off. They stop working
when either front side door is opened.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly push down the switch.
To close: Pull up the switch.
Power windows
ProCarManuals.com

12
Automatic operation (to open only):
Push the switch completely down and
then release it. The window will fully open.
To stop the window partway, lightly pull the
switch up and then release it.OPERATING THE PASSENGERS' WIN-
DOWS
Use the switches on the passengers'
doors. The driver's door also has
switches that control the passengers'
windows.
The window moves as long as you hold
the switch.
To open: Push down the switch.
To close: Pull up the switch.
If you push in the window lock button on
the driver's door, the passenger's win-
dows cannot be operated.
ProCarManuals.com

13
CAUTION!
To avoid serious personal injury, you
must do the following.

Always make sure the head, hands
and other parts of the body of all oc-
cupants are kept completely inside
the vehicle before you close the
power windows. If someone's
neck, head or hands gets caught in
a closing window, it could result in
a serious injury. When anyone
closes the power windows, be sure
that they operate the windows safe-
ly.

When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button
to prevent them from making unex-
pected use of the switches.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches
and get trapped in a window. Unat-
tended children can become in-
volved in serious accidents.
To open the trunk lid from the outside,
insert the master key and turn it clock-
wise.
See Luggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
To close the trunk lid, lower it and press
down on it. After closing the trunk lid, try
pulling it up to make sure it is securely
closed.
Keep the trunk lid closed while driv-
ing. This not only keeps the luggage
from being thrown out but also pre-
vents exhaust gases from entering
the vehicle.
CAUTION!
To open the trunk lid from the driver's
seat, pull up on the lock release lever.
ÐLock release lever
Trunk lid (type A)
ProCarManuals.com

14
This system deactivates the lock re-
lease lever so that things locked in the
trunk can be protected.
After closing the trunk lid, insert the
master key and turn it counterclockwise
to deactivate the lock release lever.
After closing the trunk lid, try pulling it up
to make sure it is securely locked.To open the trunk lid from the outside,
insert the master key and turn it clock-
wise.
See Luggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
To close the trunk lid, lower it and press
down on it. After closing the trunk lid, try
pulling it up to make sure it is securely
closed.
Keep the trunk lid closed while driv-
ing. This not only keeps the luggage
from being thrown out but also pre-
vents exhaust gases from entering
the vehicle.
CAUTION!
To open the trunk lid from the driver's
seat, push the lock release button.
To safeguard the lock release button from
unwanted access, lock the glovebox.
(See Gloveboxº in Chapter 1-8.)
ÐLuggage security system Trunk lid (type B)ÐLock release button
ProCarManuals.com

15
This system helps protect things
locked in the trunk by safeguarding
the lock release button from unwanted
access.
After closing the glovebox lid, insert
the master key into the glovebox lock
and turn it clockwise to safeguard the
lock release button.
After closing the trunk lid, try pulling it up
to make sure it is securely locked.To open the hood, do the following.
1. Pull the hood lock release lever.
The hood will spring up slightly.2. In front of the vehicle, pull up on the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that
you have not forgotten any tools, rags,
etc. Then lower the hood until make sure
it locks into place. If necessary, press
down gently on front edge to lock it.
Hood
ÐLuggage security system
ProCarManuals.com

16
To deter the vehicle theft, the system is
designed to give an alarm and keep the
engine from being started if any of the
doors, trunk or hood is forcibly un-
locked or the battery terminal is dis-
connected and then reconnected
when the vehicle is locked.
The alarm blows the horn intermittently
and flashes the headlights, tail lights and
other exterior lights. The engine cannot
be started because the starter circuit will
be cut.SETTING THE SYSTEM
1. Turn the ignition key to the LOCKº
position and remove it.
2. Have all passengers get out of the ve-
hicle.
3. Close and lock all the doors, trunk and
hood.
The indicator light will come on when all
the doors, trunk and hood are closed and
locked.
As the doors are locked, the system will
give you a preparation time of 30 seconds
before the setting, during which the doors,
trunk and hood may be opened to prepare
for the setting. Be careful not to use the key or wireless
remote control transmitter when opening
any door. This will cancel the system.
4. After making sure the indicator light
starts fl
ashing, you may leave the vehicle.
The system will automatically be set after
the preparation time passes. The indica-
tor light will flash to show the system is
set. If any of the doors, trunk or hood is
open at that time, the setting is interrupted
until it is closed and locked.
Never leave anyone in the vehicle when
you set the system, because unlocking
from the inside will activate the system.
WHEN THE SYSTEM IS SET
Activating the system
The system will give the alarm and cut the
starter circuit under the following condi-
tions:

If any of the doors, trunk or hood is un-
locked without using the key or wire-
less remote control transmitter

If the battery terminal is disconnected
and then reconnected
After one minute, the alarm will automati-
cally stop with the starter circuit cut kept
on.
Theft deterrent system
ProCarManuals.com

17
Reactivating the alarm
Once set, the system automatically resets
the alarm each time all the doors, trunk
and hood are closed after the alarm stops.
The alarm will be activated again under
the following conditions:

If any of the doors, trunk or hood is
opened

If the battery terminal is disconnected
and then reconnected
Stopping the alarm
Turn the ignition key from the LOCKº to
ACCº position. The alarm w ill be stopped
with the starter circuit kept on. Stopping
the alarm in this manner will keep the
alarm from being reactivated when any of
the doors, trunk or hood is opened.
Interrupting the setting
With the system set, the trunk can be
opened with the key or wireless remote
control transmitter without setting off the
system. While the truck is open, the set-
ting is interrupted and the doors and hood
may be opened in addition. However,
when the battery terminal is reconnected,
the system is activated. Close and lock the doors and hood, and
the system will automatically be reset af-
ter two seconds when the trunk is closed
with the key removed.
CANCELLING THE SYSTEM
Unlock either front door with the key or
wireless remote control transmitter. This
cancels the system completely and the
starter ci
rcuit cut will be cancelled at once.
INDICATOR LIGHT
The indicator light gives the following
three indications.
FLASHINGÐThe system is set. You
need the key or wireless remote control
transmitter to open the doors, trunk and
hood.
ONÐThe system will automatically be set
when the time comes. The doors, trunk
and hood may be opened without a key or
wireless remote control transmitter.
OFFÐThe system is inactive. You may
open any door, trunk and hood. TESTING THE SYSTEM
1. Open all the windows
2. Set the system as described above.
The doors should be locked with the key
or wireless remote control transmitter. Be
sure to wait until the indicator light starts
flashing.
3. Unlock any door from the inside. The
system should activate the alarm.
4. Cancel
the system by unlocking any of
the doors with the key or wireless remote
control transmitter.
5. Repeat this operation for the other
doors, trunk and hood. When testing on
the hood, also check that the system is ac-
tivated when the battery terminal is dis-
connected and then reconnected.
If the system does not work properly, have
it checked by your Toyota dealer.
ProCarManuals.com

18
1. To open the fuel filler door, pull the
lever up.
CAUTION!

Do not smoke, cause sparks or al-
low open flames when refuelling.
The fumes are flammable.

When opening the cap, do not re-
move the cap quickly. In hot
weather, fuel under pressure
could cause injury by spraying
out of the filler neck if the cap is
suddenly removed.
2. To remove the fuel tank cap, turn
the cap slowly counterclockwise, then
pause slightly before removing it. Af-
ter removing the cap, hang it on the
cap hanger.
It is not unusual to hear a slight swoosh
when the cap is opened. When installing,
turn the cap clockwise till you hear a click.
If the cap is not tightened securely, the
malfunction indicator lamp comes on.
Make sure the cap is tightened securely.
The indicator lamp goes off after driving
several times. If the indicator lamp does
not go off, contact your Toyota dealer as
soon as possible.
CAUTION!

Make sure the cap is tightened se-
curely to prevent fuel spillage in
case of an accident.

Use only a genuine Toyota fuel
tank cap for replacement. It has a
built in check valve to reduce fuel
tank vacuum.
Fuel tank cap
ProCarManuals.com

19
Sliding operation
Tilting operationTo operate the moon roof, use the
switches beside the interior light.
The moon roof works when the ignition
switch is in the ONº position. However, if
all the doors are closed, it works for 60
seconds even after the ignition switch is
turned off. It stops working when any of
the doors are opened.
Sun shade operationÐ
The sun shade can be opened or closed
by hand.
Sliding operationÐ
To open: Push the switch on the SLIDEº
side.
The sun shade will be opened together
with the roof.
To close: Push the switch on the opposite
side of the SLIDEº side.
As a precaution when closing, the roof
stops at the three-quarters closed posi-
tion before fully closing. Therefore, re-
lease the switch and then push it again to
close it completely.
Tilting operationÐ
To tilt up: Push the switch on the UPº
side.
To lower: Push the switch on the opposite
side of the UPº side.
You may stop the moon roof at any de-
sired
position. The roof will move while the
switch is being pushed and stop when re-
leased.
CAUTION!
To avoid serious personal injury, you
must do the following.

While the vehicle is moving, always
keep the head, hands and other
parts of the body of all occupants
away from the roof opening. Other-
wise, you could be seriously in-
jured if the vehicle stops suddenly
or if the vehicle is involved in an ac-
cident.

Always make sure nobody places
his/her head, hands and other parts
of the body in the roof opening be-
fore you close the roof. If some-
one's neck, head or hands gets
caught in the closing roof, it could
result in a seri ous injury. When any-
one closes the roof, first make sure
it is safe to do so.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the moon roof switches and get
trapped in the roof opening. Unat-
tended children can become in-
volved in serious accidents.

Never sit on top of the vehicle
around the roof opening.
Electric moon roof
ProCarManuals.com

20ProCarManuals.com
