TOYOTA AVALON 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 1161 of 1897
H01019H08392H08393
P/T Squib (RH)Airbag
Sensor
Assembly
(+)
(-)PR+
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-425
581 Author: Date:
2001 AVALON (RM808U)
DTC B0132/61 Short in P/T Squib (RH) Circuit (to
Ground)
CIRCUIT DESCRIPTION
The P/T squib (RH) circuit consists of the airbag sensor assembly and seat belt pretensioner (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0132/61 is recorded when a ground short is detected in the P/T squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0132/61
Short circuit in P/T squib (RH) wire harness (to ground)
P/T squib (RH) malfunction
Airbag sensor assembly malfunctionSeat belt pretensioner (RH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI-418.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-475).
2 Check P/T squib (RH) circuit.
CHECK:
For the connector (on the seat belt pretensioner side) between
the seat belt pretensioner (RH) and the airbag sensor assem-
bly, measure the resistance between PR+ and body ground.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween seat belt pretensioner (RH) and airbag
sensor assembly.
OK
DI4D2-02
Page 1162 of 1897
H01020H02139AB0118AB0119R13006H01079H02208
P/T Squib (RH)Airbag
Sensor
Assembly
PR+
PR-ACC
or
DTC B0132/61ON " u
E1
Tc DLC1
DI-426
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
582 Author: Date:
2001 AVALON (RM808U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect PR+ and PR- of the con-
nector (on the seat belt pretensioner side) between the
seat belt pretensioner (RH) and the airbag sensor assem-
bly.
(c) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least for
20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0132/61 is not output.
HINT:
Codes other than code B0132/61 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1163 of 1897
H01021AB0118AB0119R13006H01079H01208
"u
E1 TcACC ON
orAirbag
Sensor
Assembly P/T Squib (RH)
DTC B0132/61 DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-427
583 Author: Date:
2001 AVALON (RM808U)
4 Check P/T squib (RH).
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner (RH) connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0132/61 is not output.
HINT:
Codes other than code B0132/61 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1164 of 1897
H01019AB0119H08394H08268
P/T Squib (RH)Airbag
Sensor
Assembly
PR+
(+)
(-) ON
DI-428
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
584 Author: Date:
2001 AVALON (RM808U)
DTC B0132/62 Short in P/T Squib (RH) Circuit (to B+)
CIRCUIT DESCRIPTION
The P/T squib (RH) circuit consists of the airbag sensor assembly and seat belt pretensioner (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0133/62 is recorded when a B+ short is detected in the P/T squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0133/62
Short circuit in seat belt pretensioner (RH) wire harness
(to B+)
P/T squib (RH) malfunction
Airbag sensor assembly malfunctionSeat belt pretensioner (RH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
See page DI-418.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-475).
2 Check P/T squib (RH) circuit.
CHECK:
(a) Turn the ignition switch to ON.
(b) For the connector (on the seat belt pretensioner side) be-
tween the seat belt pretensioner (RH) and the airbag sen-
sor assembly, measure the voltage between PR+ and
body ground.
OK:
Voltage: 0 V
NG Repair or replace harness or connector be-
tween seat belt pretensioner (RH) and airbag
sensor assembly.
OK
DI4D3-02
Page 1165 of 1897
H01020H02139AB0118AB0119R13006H01081H02210
P/T Squib (RH)Airbag
Sensor
Assembly
PR+
PR-
ACC
or
DTC B0133/62ON " u
E1
Tc DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-429
585 Author: Date:
2001 AVALON (RM808U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect PR+ and PR- of the con-
nector (on the seat belt pretensioner side) between the
seat belt pretensioner (RH) and the airbag sensor assem-
bly.
(c) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least for
20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0133/62 is not output.
HINT:
Codes other than code B0133/62 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1166 of 1897
H01021AB0118AB0119R13006H01081H01211
"u
E1 TcACC ON
orAirbag
Sensor
Assembly P/T Squib (RH)
DTC B0133/62 DLC1
DI-430
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
586 Author: Date:
2001 AVALON (RM808U)
4 Check P/T squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner (RH) connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(b) Clear the DTC stored in memory
(See step 5 on page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0133/62 is not output.
HINT:
Codes other than code B0133/62 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1167 of 1897
H01454
P/T Squib (LH)
PL+
PL- 1
21 2
C5
C5 Y-B
YAirbag Sensor Assembly
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-431
587 Author: Date:
2001 AVALON (RM808U)
DTC B0135/73 Short in P/T Squib (LH) Circuit
CIRCUIT DESCRIPTION
The P/T squib (LH) circuit consists of the airbag sensor assembly and seat belt pretensioner (LH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0135/73 is recorded when a short is detected in the P/T squib (LH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0135/73
Short circuit between PL+ wire harness and PL- wire har-
ness of squib
P/T squib (LH) malfunction
Airbag sensor assembly malfunctionSeat belt pretensioner (LH)
Airbag sensor assembly
Wire harness
WIRING DIAGRAM
DI4D4-03
Page 1168 of 1897
H01016H02141H02211
P/T Squib (LH)Airbag
Sensor
Assembly
PL-
PL+
(+) (-)
DI-432
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
588 Author: Date:
2001 AVALON (RM808U)
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-475).
2 Check P/T squib (LH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the seat belt pretensioner (LH)
(See page DI-349).
CHECK:
For the connector (on the seat belt pretensioner side) between
the seat belt pretensioner (LH) and the airbag sensor assembly,
measure the resistance between PL+ and PL-.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween seat belt pretensioner (LH) and airbag
sensor assembly.
OK
Page 1169 of 1897
H01017AB0118AB0119R13006H01086H07487
P/T Squib (LH)
Airbag
Sensor
Assembly
ACC
or
DTC B0135/73ON
E1
Tc" u
DLC1
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-433
589 Author: Date:
2001 AVALON (RM808U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ACC or ON and wait at least for
20 seconds.
(b) Clear the DTC stored in memory (See page DI-349).
(c) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(d) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(e) Check the DTC (See page DI-349).
OK:
DTC B0135/73 is not output.
HINT:
Codes other than code B0135/73 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1170 of 1897
H01018AB0118AB0119R13006H01086H01229
"u
E1
Tc ACC ON
orAirbag
Sensor
Assembly P/T Squib (LH)
DTC B0135/73 DLC1
DI-434
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
590 Author: Date:
2001 AVALON (RM808U)
4 Check P/T squib (LH).
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect negative (-) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner (LH) connector.
(d) Connect negative (-) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to LOOK, and wait at least for 20
second.
(b) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(c) Clear the DTC stored in memory (See page DI-349).
(d) Turn the ignition switch to LOCK, and wait at least for 20
seconds.
(e) Turn the ignition switch to ACC or ON, and wait at least
for 20 seconds.
(f) Check the DTC (See page DI-349).
OK:
DTC B0135/73 is not output.
HINT:
Codes other than code B0135/73 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner (LH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
