TOYOTA AVALON 2001 Service Repair Manual

AX0KC-01
D07218
AX-22
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
1312 Author
: Date
:
2001 AVALON (RM808U)
REMOVAL
1. REMOVE UPPER REAR CONSOLE PANEL SUB-AS-
SEMBLY (See page BO-90)
2. REMOVE FRONT ASH RECEPTACLE ASSEMBLY
(See page BO-90)
3. REMOVE UPPER CONSOLE PANEL SUB- AS-
SEMBLY (See page BO-90)
4. REMOVE CONSOLE BOX PLATE (See page BO-90)
5. REMOVE REAR CONSOLE BOX ASSEMBLY
(See page BO-90)
6. REMOVE LH AND RH SCUFF PLATES
(See page BO-90)
7. REMOVE LH AND RH COWL SIDE TRIMS
(See page BO-90)
8. REMOVE LOWER NO.4 INSTRUMENT PANEL SUB-
ASSEMBLY (See page BO-90)
9. REMOVE NO.2 INSTRUMENT PANEL UNDER COVER
SUB-ASSEMBL Y (See page BO-90)
10. REMOVE LOWER INSTRUMENT PANEL SUB- AS-
SEMBLY (See page BO-90)
11. Taiwan Spec.:
REMOVE CENTER INSTRUMENT CLUSTER FINISH
PANEL SUB-ASSEMBLY (See page BO-90)
12. Taiwan Spec.:
REMOVE RADIO TUNER OPENING COVERS WITH
HEATER CONSOLE & ACCESSORY ASSEMBLY
(See page BO-90)
13. Except Taiwan spec.:
REMOVE RADIO ASSEMBLY WITH HEATER CON-
SOLE & ACCESSORY ASSEMBLY
(See page BO-90)
14. REMOVE FRONT CONSOLE BOX ASSEMBLY
(See page BO-90)
15. w/ Rear Heater:
REMOVE REAR CONSOLE NO.1 BOX ASSEMBLY
CONSOLE BOX DUCT
Remove the clip and duct.
16. REMOVE FLOOR SHIFT LEVER ASSEMBLY
(a) Remove the clip and disconnect the shift cable from the
floor shift assembly.
(b) Disconnect the wire harness from the wire harness clamp.

D07219
- AUTOMATIC TRANSAXLEFLOOR SHIFT ASSEMBLY
AX-23
1313 Author
: Date
:
2001 AVALON (RM808U)
(c) Remove the 2 bolts from the brace.
(d) Remove the 4 bolts and floor shift assembly.
Torque: 12 N´m (120kgf´cm, 9 ft´lbf)

Q00229
AX0CJ-02
Q06496
Q05727
Q04617
Q04687
AX-4
- AUTOMATIC TRANSAXLEPARK/NEUTRAL POSITION (PNP) SWITCH
1294 Author
: Date
:
2001 AVALON (RM808U)
PARK/NEUTRAL POSITION (PNP)
SWITCH
ON-VEHICLE REPAIR
1. REMOVE ENGINE UNDER COVER
2. DISCONNECT PARK/NEUTRAL POSITION SWITCH
CONNECTOR
3. REMOVE PARK/NEUTRAL POSITION SWITCH
(a) Remove the clip from the shift control cable.
(b) Remove the nut and disconnect the control cable.
(c) Remove the nut, washer and transaxle control shaft lever.
(d) Using a screwdriver, pry off the lock plate.
(e) Remove the nut and lock plate.
(f) Remove the 2 bolts and pull out the park/neutral position
switch.
4. INSTALL AND ADJUST PARK/NEUTRAL POSITION
SWITCH
(a) Install the park/neutral position switch with the 2 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
(b) Install a new lock plate and nut.
Torque: 6.9 N´m (70 kgf´cm, 61 in.´lbf)
(c) Bend the claws on the lock plate to stake the nut.
(d) Install the transaxle control shaft lever and washer.
(e) Install and torque the nut.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)

Q06496
- AUTOMATIC TRANSAXLEPARK/NEUTRAL POSITION (PNP) SWITCH
AX-5
1295 Author
: Date
:
2001 AVALON (RM808U)
(f) Install the control cable and nut.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
(g) Install the clip to the shift control cable.
5. CONNECT PARK/NEUTRAL POSITION SWITCH CON-
NECTOR
6. CHECK PARK/NEUTRAL POSITION SWITCH OPERA-
TION
Check that the engine can be started with the shift lever only in
the N or P position, but not in other positions.
If not as started above, carry out the adjustment procedure
(See page DI-160).
7. TEST DRIVE VEHICLE
8. INSTALL ENGINE UNDER COVER

AX05E-03
D02451D02452D02453D02455
ABC
IGP
P2 P1 ACC
STP KLS
+ESLS
-SLS+
Q06585
Q06584
AX-18
- AUTOMATIC TRANSAXLESHIFT LOCK SYSTEM (Column Shift)
1308 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY
Using a voltmeter, measure the voltage at each terminal.
HINT:
Do not disconnect the shift lock control unit assembly connec-
tor.
Terminal No. (Symbols)Measuring ConditionVoltage (V)
1 (ACC) - 5 (E)Ignition switch ACC10 - 14
3 (IG) - 5 (E)Ignition switch ON10 - 14
6 (STP) - 5 (E)Depressing brake pedal10 - 14
4 (KLS+) - 5 (E)
4. Ignition switch ACC and P position
5. Ignition switch ACC and except P position
6. Ignition switch ACC and except P position (After approx. 1 second)0
7.5 - 11
6 - 9
1. Ignition switch ACC and P position0
2 (SLS+) - 1 (SLS-)
1.Ignition switch ACC and P osition
2. Depress brake pedal
0
8.5 -13.52 (SLS) 1 (SLS)2.De ress brake edal
3. Except P position
8.5 13.5
0
4 (P1) 1 (P)1. Ignition switch ON, P position and depress brake pedal04 (P1) - 1 (P)1.Ignition switch ON, P osition and de ress brake edal
2. Shift except P position under condition above
0
9 - 13.5
3 (P2) 1 (P)1. Ignition switch ACC and P position9 - 13.53 (P2) - 1 (P)1.Ignition switch ACC and P osition
2. Shift except P position under condition above
9 13.5
0
2. INSPECT SHIFT LOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure resistance between termi-
nals.
Standard resistance: 29 - 35 W
If resistance value is not as specified, replace the solenoid.
(c) Supply battery positive voltage between terminals. Check
that an operation noise can be heard from the solenoid.
If the solenoid does not operate, replace the solenoid.

AT8748
D02459
21
D07236
P
P2
P1
- AUTOMATIC TRANSAXLESHIFT LOCK SYSTEM (Column Shift)
AX-19
1309 Author
: Date
:
2001 AVALON (RM808U)
3. INSPECT KEY INTERLOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure the resistance between ter-
minals.
Standard resistance: 12.5 -16.5 W
If resistance value is not as specified, replace the solenoid.
(c) Supply battery positive voltage between terminals.
If the solenoid does not operate, replace the solenoid.
4. INSPECT SHIFT LOCK CONTROL SWITCH
Inspect that continuity between at each terminal.
Shift positionTester connectionSpecified value
P position (Release button
is not pushed)3 (P1) - 1 (P)Continuity
P position (Release button
is pushed)3 (P1) - 1 (P)
4 (P2) - 1 (P)Continuity
R, N, D, 2, L position4 (P2) - 1 (P)Continuity
If continuity is not specified, replace the switch.

AX03T-04
D07231
Shift Lock Control Switch
Key Interlock Solenoid
Stop Light Switch Shift Lock Solenoid
Shift Lock Control ECU
- AUTOMATIC TRANSAXLESHIFT LOCK SYSTEM (Column Shift)
AX-17
1307 Author
: Date
:
2001 AVALON (RM808U)
SHIFT LOCK SYSTEM (Column Shift)
LOCATION

AX0CT-02
Q09455Wire harness side: 5 (IG)
4 (KLS
+)
3 (E)
2 (STP)1 (ACC)
Q09456
1 (KLS+)
2 (E)
Q09457(-) (+)1 (KLS
+)
2 (E) AX-16
- AUTOMATIC TRANSAXLESHIFT LOCK SYSTEM (Floor Shift)
1306 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
1. INSPECT SHIFT LOCK CONTROL UNIT ASSEMBLY
Using a voltmeter, measure the voltage at each terminal.
HINT:
Do not disconnect the shift lock control unit assembly connec-
tor.
Terminal (Symbol)Measuring ConditionVoltage (V)
1 (ACC) - 3 (E)Ignition switch ACC10 - 14
5 (IG) - 3 (E)Ignition switch ON10 - 14
2 (STP) - 3 (E)Depressing brake pedal10 - 14
4 (KLS+) - 3 (E)
(1) Ignition switch ACC and P position
(2) Ignition switch ACC and except P position
(3) Ignition switch ACC and except P position (After approx. 1 second)0
7.5 - 11
6 - 9.5
2. INSPECT KEY INTERLOCK SOLENOID
(a) Disconnect the solenoid connector.
(b) Using an ohmmeter, measure resistance between termi-
nals.
Standard resistance: 14.5 ± 1.5 W
If resistance value is not as specified, replace the solenoid.
(c) Apply battery positive voltage between terminals. Check
that an operation noise can be heard from the solenoid.
If the solenoid does not operated, replace the solenoid.

AX0CS-02
D07232
Key Interlock Solenoid
Stop Light Switch
Shift Lock Control
Unit Assembly
- AUTOMATIC TRANSAXLESHIFT LOCK SYSTEM (Floor Shift)
AX-15
1305 Author
: Date
:
2001 AVALON (RM808U)
SHIFT LOCK SYSTEM (Floor Shift)
LOCATION

AT0952
SST
AX040-04
AT0953
SST
AT3306
Hold
Lock
Free
Turn
AT2821
- AUTOMATIC TRANSAXLETORQUE CONVERTER CLUTCH AND DRIVE PLATE
AX-43
1333 Author
: Date
:
2001 AVALON (RM808U)
TORQUE CONVERTER CLUTCH
AND DRIVE PLATE
INSPECTION
1. INSPECT ONE-WAY CLUTCH
(a) Install SST into the inner race of the one-way clutch.
SST 09350-32014 (09351-32010)
(b) Install SST so that it fits in the notch of the converter clutch
hub and outer race of the one-way clutch.
SST 09350-32014 (09351-32020)
(c) With the torque converter clutch standing on its side, the
clutch locks when turned counterclockwise, and rotates
freely and smoothly clockwise.
If necessary, clean the converter and retest the clutch.
Replace the converter if the clutch still fails the test.
2. MEASURE DRIVE PLATE RUNOUT AND INSPECT
RING GEAR
(a) Set up a dial indicator, and measure the drive plate run-
out.
(b) Check the damage of the ring gear.
Maximum runout: 0.20 mm (0.0079 in.)
If the runout is not within the specification or ring gear is dam-
aged, replace the drive plate.
Torque: 83 N´m (850 kgf´cm, 61 ft´lbf)
