TOYOTA AVALON 2001 Service Repair Manual
Manufacturer: TOYOTA, Model Year: 2001, Model line: AVALON, Model: TOYOTA AVALON 2001Pages: 1897, PDF Size: 26.61 MB
Page 1701 of 1897
RS0LF-01
H11926
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
Seatback Frame Headrest
Headrest Support
Seatback Cover (w/ Pad)
Hog Ring
37 (375, 27)
43 (440, 32)
Front Seat Cushion Shield
Non-reusable partInner Front Seat Cushion Shield
Reclining adjuster
Release Handle
37 (375, 27)
Side Airbag
Assembly
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-55
1575 Author: Date:
2001 AVALON (RM808U)
SIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
COMPONENTS
Page 1702 of 1897
RS0LI-01
RS-58
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1578 Author: Date:
2001 AVALON (RM808U)
DISPOSAL
See page RS-45.
Page 1703 of 1897
RS0LH-01
H11979
Cross Section
H11978
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-57
1577 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. Vehicles not involved in collision:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-349).
(b) Do a visual check which includes the following item with
the seatback assembly installed in the vehicle.
Check that there are no cuts or frayed in seams and out-
side of seatback cover.
2. Vehicle involved in a collision and airbag is not
deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-349).
(b) Do a visual check which includes the following items with
the seatback assembly removed from the vehicle.
Check cuts, tears and cracks of the side airbag as-
sembly.
Check cuts and cracks in wire harness, and chip-
ping in connectors.
CAUTION:
For removal and installation of the seatback assembly, see
page RS-56 and RS-60. Be sure to follow the correct pro-
cedure.
3. Vehicle involved in a collision and airbag is deployed:
INSPECT SUPPLEMENTAL RESTRAINT SYSTEM
(a) Do a diagnostic system check (See page DI-349).
(b) Do a visual check which includes the following items with
the seatback assembly removed from the vehicle.
Check the seatback installation part of the seat ad-
juster.
Check the damage to the connector and wire har-
ness.
HINT:
If the seat adjuster is deformed, never repair it. Always replace
it with new one.
Page 1704 of 1897
RS0LK-01
H11929
H11928
H11930
RS-60
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1580 Author: Date:
2001 AVALON (RM808U)
INSTALLATION
NOTICE:
Never use airbag parts from another vehicle. When replac-
ing parts, replace them with new parts.
1. INSTALL SEATBACK ASSEMBLY
(a) Install the 4 bolts.
Torque: 43 N´m (440 kgf´cm, 32 ft´lbf)
NOTICE:
Make sure that the seatback assembly is installed
with the specified torque.
If the seatback assembly has been dropped, or there
are cracks, dents or other defects in the case or con-
nector, replace the seatback assembly with a new
one.
When installing the seatback assembly, take care it is
not pinched between other parts.
(b) Install 3 new hog rings as shown in the illustration.
HINT:
When installing the hog rings, take care to prevent wrinkles as
little as possible.
(c) Install the wire harness of the side airbag assembly to the
seat cushion assembly.
2. INSTALL INNER FRONT SEAT CUSHION SHIELD
Install the inner front seat cushion shield with the 2 screws.
3. INSTALL FRONT SEAT CUSHION SHIELD
Install the front seat cushion shield with the 2 screws.
4. INSTALL RECLINING ADJUSTER KNOBS
5. INSTALL HEADREST
Page 1705 of 1897
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-61
1581 Author: Date:
2001 AVALON (RM808U)
6. INSTALL FRONT SEAT
NOTICE:
When mounting the seat to the vehicle, take care not to
damage the airbag wire harness.
(a) Connect the side airbag connector.
(b) Slide the front seat to the most front position.
NOTICE:
Make sure that seat adjuster locks.
(c) Without holding the seat track handle, mount the seat to
the vehicle.
HINT:
If holding the seat track handle, the adjusted rearmost position
slip off.
(d) Tighten the bolts on the front side temporarily, from the
bolt on the inner side tighten them completely.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
(e) Slide the seat to the most front position to install the bolts
on the rear side.
Torque: 37 N´m (375 kgf´cm, 27 ft´lbf)
Page 1706 of 1897
RS0LG-01
H11931
H11927
H11928
H11929
RS-56
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
1576 Author: Date:
2001 AVALON (RM808U)
REMOVAL
NOTICE:
If the wiring connector of the SRS is disconnected
and the ignition switch is at ON or ACC position, DTCs
will be recorded.
Never use the airbag parts from another vehicle.
When replacing parts, replace them with new parts.
1. REMOVE FRONT SEAT
(a) Remove the 4 seat track covers and 4 bolts.
(b) Disconnect the side airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(c) Remove the front seat.
2. REMOVE HEADREST
3. REMOVE RECLINING ADJUSTER KNOB
4. REMOVE FRONT SEAT CUSHION SHIELD
Remove the 2 screws and front seat cushion shield.
5. REMOVE INNER FRONT SEAT CUSHION SHIELD
Remove the 2 scerws and front seat cushion inner shield.
6. REMOVE SEATBACK ASSEMBLY
(a) Remove the hog rings.
(b) Remove the wire harness of the side airbag assembly.
NOTICE:
When handling the airbag wire harness, take care not to
damage the airbag wire harness.
(c) Remove the 4 bolts and seatback assembly.
Page 1707 of 1897
RS0LJ-01
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Manual Adjuster Type)
RS-59
1579 Author: Date:
2001 AVALON (RM808U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the seatback assembly or seatback cover.
CaseReplacing part
If the side airbag has been deployed.Seatback assembly
If the side airbag assembly has been found to be faulty in troubleshooting.Seatback assembly
If the side airbag assembly has cuts during checking items
(See page RS-57).Seatback assembly
If the seatback cover has cuts and frayed seams during checking items
(See page RS-57).Seatback cover
If the side airbag assembly has been found to be faulty during checking items
(See page RS-57).Seatback assembly
If the seatback cover has been found to be faulty during checking items
(See page RS-57).Seatback cover
If the seatback assembly has been dropped.Seatback assembly
CAUTION:
For removal and installation of the seatback assembly, see page RS-56 and RS-60. Be sure to follow
the correct procedure.
Page 1708 of 1897
RS0L9-01
H11925
N´m (kgf´cm, ft´lbf): Specified torque
43 (440, 32)
19 (194, 14)
Driver's seat with bench type:
Driver's seat with bench type: No. 1 Seat Armrest CoverSeatback Frame
AssemblyHeadrest
Headrest Support
Seatback Board
Side Airbag Assembly
Seatback Cover (w/ Pad) Hog Ring Reclining Adjuster
Inside Cover
Front Seat Cushion
Inner Shield
Seat Cushion Assembly
Seat Cushion Assembly
19 (194, 14)
43 (440, 32)
42 (430, 31)
Seat Armrest Assembly
Front Seat Cushion Shield
Power Seat Switch Knob
Front Seat Inner Belt
Non-reusable part
37 (375, 27)
41 (420, 30)
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS-41
1561 Author: Date:
2001 AVALON (RM808U)
SIDE AIRBAG ASSEMBLY (Power Adjuster Type)
COMPONENTS
Page 1709 of 1897
RS0LC-01
AB0152
SST
AB0158
Battery
SST
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
RS-45
1565 Author: Date:
2001 AVALON (RM808U)
DISPOSAL
HINT:
When scrapping vehicles equipped with an SRS or disposing
of the side airbag assembly always first deploy the airbag in ac-
cordance with the procedure described below. If any abnormal-
ity occurs with the airbag deployment, contact the SERVICE
DEPT. of TOYOTA MOTOR SALES, U.S.A., INC.
CAUTION:
Never dispose of a side airbag assembly which has
an undeployed airbag.
The airbag produces a sizeable exploding sound
when it deploys, so perform the operation out-of-
doors and where it will not create a nuisance to
nearby residents.
When deploying the airbag, always use the specified
SST (SRS Airbag Deployment Tool), perform the op-
eration in a place away from electrical noise.
SST 09082-00700
When deploying an airbag, perform the operation at
least 10 m (33 ft) away from the airbag assembly.
The side airbag assembly is very hot when the airbag
is deployed, so leave it alone for at least 30 minutes
after deployment.
Use gloves and safety glasses when handling side
airbag assembly with the deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a side airbag assembly with
the deployed airbag.
1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE-
HICLE
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Check functioning of the SST (See step 1-(a) on page
RS-17).
SST 09082-00700
Page 1710 of 1897
H11931
H11932SST
R13455
10 m (33 ft) or more
SSTBattery
H11933
RS-46
- SUPPLEMENTAL RESTRAINT SYSTEMSIDE AIRBAG ASSEMBLY (Power Adjuster Type)
1566 Author: Date:
2001 AVALON (RM808U)
(b) Disconnect the side airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(c) Install the SST.
(1) Connect the connectors of the 2 SST to the airbag
connector.
SST 09082-00700, 09082-00750
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Move the SST at least 10 m (33 ft) away from the
front of the vehicle.
(3) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(4) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the battery negative
(-) terminal.
(d) Deploy the airbag.
(1) Check that no one is inside the vehicle or within 10
m (33 ft) area around the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
CAUTION:
The side airbag assembly is very hot when the airbag
is deployed, so leave it alone for at least 30 minutes
after deployment.
Use gloves and safety glasses when handling the
side airbag assembly with the deployed airbag.
Do not apply water, etc. to the side airbag assembly
with the deployed airbag.
Always wash your hands with water after completing
the operation.
When scrapping a vehicle, deploy the airbag and
scrap the vehicle with the side airbag assembly still
installed.
