Page 1681 of 1897
RS0LO-01
- SUPPLEMENTAL RESTRAINT SYSTEMAIRBAG SENSOR ASSEMBLY (Floor Shift)
RS-65
1585 Author: Date:
2001 AVALON (RM808U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the airbag sensor assembly.
If the SRS has been deployed in a collision.
If the airbag sensor assembly has been found to be faulty in troubleshooting.
If the airbag sensor assembly has been dropped.
CAUTION:
For removal and installation of the airbag sensor assembly, see page RS-63 and RS-66. Be sure to
follow the correct procedure.
Page 1682 of 1897
RS0ER-02
H11911
N´m (kgf´cm, ft´lbf): Specified torqueFront Airbag Sensor RH
Front Airbag Sensor LH
Head Light RH
Head Light LH
20 (205, 15)
20 (205, 15)
20 (205, 15)
20 (205, 15)
RS-72
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1592 Author: Date:
2001 AVALON (RM808U)
FRONT AIRBAG SENSOR
COMPONENTS
Page 1683 of 1897
RS01N-28
H11883
H11914
LH
RH RS-74
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1594 Author: Date:
2001 AVALON (RM808U)
INSPECTION
1. VEHICLES NOT INVOLVED IN COLLISION
Do a diagnostic system check (See page DI-349).
2. VEHICLES INVOLVED IN COLLISION
(a) Do a diagnostic system check (See page DI-349).
(b) If the front fender of the car or its periphery is damaged,
do a visual check for damage to the front airbag sensor,
which includes the following items even if the airbag was
not deployed:
Check the bracket deformation.
Check the paint peeling off the bracket.
Check the cracks, dents or chips in the case.
Check the cracks, dents, chipping and scratches in
the connector.
Check the peeling off of the label or damage to the
serial number.
Page 1684 of 1897
H11912H11913H11907
LH:
RH:
RS0LW-01
H11914
LH:
RH: RS-76
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
1596 Author: Date:
2001 AVALON (RM808U)
INSTALLATION
1. INSTALL FRONT AIRBAG SENSOR LH AND RH
(a) Install the front airbag sensors with the 4 bolts.
Torque: 20 N´m (205 kgf´cm, 15 ft´lbf)
NOTICE:
Connection of the connector is done after the sensor
assembly has been installed.
Make sure the sensor is installed with the specified
torque.
If the sensor has been dropped, or there are cracks,
dents or other defects in the case, brackets or con-
nector, replace the removed sensor with a new one.
The front sensor is equipped with an electrical con-
nection check mechanism. Be sure to lock this mech-
anism securely when connecting the connector. If the
connector is not securely locked, a malfunction code
will be detected by the diagnostic system.
HINT:
Install the front airbag sensor with the arrow on the sensor fac-
ing toward the front of the vehicle.
(b) Connect the front airbag sensor connector.
2. INSTALL HEAD LIGHT
Install head lights with the 4 bolts and 2 screws (See page
BE-23).
Page 1685 of 1897
RS0LV-01
H11912
H11913
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
RS-73
1593 Author: Date:
2001 AVALON (RM808U)
REMOVAL
NOTICE:
If the wiring connector of the SRS is disconnected
with the ignition switch at ON or ACC position, DTCs
will be recorded.
Never use SRS parts from another vehicle. When re-
placing parts, replace them with new parts.
Never reuse the sensor involved in a collision when
the SRS has deployed.
Never repair a sensor in order to reuse it.
1. LH:
REMOVE FRONT AIRBAG SENSOR
(a) Remove the 2 bolts, screw and head light LH.
(b) Disconnect the connector.
NOTICE:
Disconnect the connector with sensor assembly installed.
(c) Remove the 2 bolts and front airbag sensor LH.
2. RH:
REMOVE FRONT AIRBAG SENSOR
(a) Remove the 2 bolts, screw and head light RH.
(b) Disconnect the connector.
NOTICE:
Disconnect the connector with sensor assembly installed.
(c) Remove the 2 bolts and front airbag sensor RH.
Page 1686 of 1897
RS01O-16
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT AIRBAG SENSOR
RS-75
1595 Author: Date:
2001 AVALON (RM808U)
REPLACEMENT
REPLACEMENT REQUIREMENTS
In the following cases, replace the front airbag sensor.
If the SRS has been deployed in a collision. (Replace both the left and right airbag sensors.)
If the front airbag sensor has been found to be faulty in troubleshooting.
If the front airbag sensor has been found to be faulty during checking items (See page RS-74).
If the front airbag sensor has been dropped.
CAUTION:
For removal and installation of the front airbag sensor, see page RS-73 and RS-76. Be sure to follow
the correct procedure.
Page 1687 of 1897
RS014-32
H11896N´m (kgf´cm, ft´lbf) : Specified torqueInstrument Panel
No. 4 Heater To Resister Duct
Center BracketGlove Box Lamp
No. 5 Heater To Resister Duct
Front Passenger Airbag Assembly
No. 3 Resister
No. 1 Safety Pad
20 (205, 15)
20 (205, 15)
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS-27
1547 Author: Date:
2001 AVALON (RM808U)
FRONT PASSENGER AIRBAG ASSEMBLY
COMPONENTS
Page 1688 of 1897
RS0L7-01
AB0152
SST
AB0158
SSTBattery RS-32
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
1552 Author: Date:
2001 AVALON (RM808U)
DISPOSAL
HINT:
When scrapping vehicle equipped with an SRS or disposing of
a front passenger airbag assembly, always first deploy the air-
bag in accordance with the procedure described below. If any
abnormality occurs with the airbag deployment, contact the
SERVICE DEPT. of TOYOTA MOTOR SALES, U.S.A., INC.
CAUTION:
Never dispose of a front passenger airbag assembly
which has an undeployed airbag.
The airbag produces a sizeable exploding sound
when it deploys, so perform the operation out-of-
doors and where it will not create a nuisance to
nearby residents.
When deploying the airbag, always use the specified
SST (SRS Airbag Deployment Tool). Perform the op-
eration in a place away from electrical noise.
SST 09082-00700
When deploying an airbag, perform the operation at
least 10 m (33 ft) away from the front passenger air-
bag assembly.
The front passenger airbag assembly is very hot
when the airbag is deployed, so leave it alone for at
least 30 minutes after deployment.
Use gloves and safety glasses when handling a front
passenger airbag assembly with the deployed airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to a front passenger airbag
assembly with the deployed airbag.
1. AIRBAG DEPLOYMENT WHEN SCRAPPING VE-
HICLE
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Check functioning of the SST (See step 1-(a) on page
RS-17).
SST 09082-00700
Page 1689 of 1897
H11900
H11901SST
R13455
10 m (33 ft) or more
SSTBattery
H03286
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
RS-33
1553 Author: Date:
2001 AVALON (RM808U)
(b) Disconnect the airbag connector.
(1) Using a screwdriver, pry out the glove compartment
door finish plate inside the lower panel.
HINT:
Tape the screwdriver tip before use.
(2) Remove the connector from the glove compartment
door finish plate.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
(3) Disconnect the airbag connector.
(c) Install the SST.
(1) Connect the connectors of the 2 SST to the front
passenger airbag assembly connector.
SST 09082-00700, 09082-00760
NOTICE:
To avoid damaging the SST connector and wire harness,
do not lock the secondary lock of the twin lock.
(2) Move the SST to at least 10 m (33 ft) away from the
front of the vehicle.
(3) Close all the doors and windows of the vehicle.
NOTICE:
Take care not to damage the SST wire harness.
(4) Connect the SST red clip to the battery positive (+)
terminal and the black clip to the negative (-) termi-
nal.
(d) Deploy the airbag.
(1) Check that no one is inside the vehicle or within 10
m (33 ft) area around the vehicle.
(2) Press the SST activation switch and deploy the air-
bag.
Page 1690 of 1897
H11902
RS-34
- SUPPLEMENTAL RESTRAINT SYSTEMFRONT PASSENGER AIRBAG ASSEMBLY
1554 Author: Date:
2001 AVALON (RM808U)
CAUTION:
The front passenger airbag assembly is very hot
when the airbag is deployed, so leave it alone for at
least 30 minutes after deployment.
Use gloves and safety glasses when handling the
front passenger airbag assembly with the deployed
airbag.
Always wash your hands with water after completing
the operation.
Do not apply water, etc. to the front passenger airbag
assembly with the deployed airbag.
When scrapping a vehicle, deploy the airbag and
scrap the vehicle with the front passenger airbag as-
sembly still installed.
When moving a vehicle for scrapping which has the
front passenger airbag assembly with the deployed
airbag, use gloves and safety glasses.
HINT:
The airbag deploys simultaneously as the LED of the SST ac-
tivation switch lights up.
2. DEPLOYMENT WHEN DISPOSING OF FRONT PAS-
SENGER AIRBAG ASSEMBLY ONLY
NOTICE:
When disposing of the front passenger airbag assem-
bly only, never use the customer's vehicle to deploy
the airbag.
Be sure to follow the procedure given below when de-
ploying the airbag.
HINT:
Have a battery ready as the power source to deploy the airbag.
(a) Remove the front passenger airbag assembly (See page
RS-28).
CAUTION:
When removing the front passenger airbag assembly,
work must be started 90 seconds after the ignition
switch is turned to the ºLOCKº position and the nega-
tive (-) terminal cable is disconnected from the bat-
tery.
When storing the front passenger airbag assembly,
keep the upper surface of the airbag deployment side
facing upward.
