Page 501 of 1897

TOYOTA AVALON 2001  Service Repair Manual F09717
F09718
- BRAKEBRAKE MASTER CYLINDER
BR-17
1416 Author: Date:
2001 AVALON   (RM808U)
6. w/ VSC:
REMOVE 2 PISTONS AND SPRINGS
(a) Push in the piston with a screwdriver, and remove the
straight

Page 502 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR0KT-01
BR-18
- BRAKEBRAKE MASTER CYLINDER
1417 Author: Date:
2001 AVALON   (RM808U)
INSPECTION
HINT:
Clean the disassembled parts with compressed air.
1. INSPECT CYLINDER BORE FOR RUST OR SCORING

Page 503 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR0KV-05
BR-20
- BRAKEBRAKE MASTER CYLINDER
1419 Author: Date:
2001 AVALON   (RM808U)
INSTALLATION
Installation is in the reverse order of removal (See page BR-15).
HINT:
Before installation, adjus

Page 504 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR0KU-01
- BRAKEBRAKE MASTER CYLINDER
BR-19
1418 Author: Date:
2001 AVALON   (RM808U)
REASSEMBLY
Reassembly  is in the reverse order of disassembly (See-page BR-16).
NOTICE:
Apply lithium soap base

Page 505 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR0KR-02
F09713SST
F09714
- BRAKEBRAKE MASTER CYLINDER
BR-15
1414 Author: Date:
2001 AVALON   (RM808U)
REMOVAL
1. REMOVE AIR CLEANER COVER WITH AIR CLEANER
HOSE
2. TAKE OUT FLUID WITH SYRINGE
NOTICE

Page 506 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR14Z-01
F09707
F09708
F09709
R00699
BR-4
- BRAKEBRAKE FLUID
1403 Author: Date:
2001 AVALON   (RM808U)
BRAKE FLUID
BLEEDING
HINT:
If any work is done on the brake system or if air in the brake lines

Page 507 of 1897

TOYOTA AVALON 2001  Service Repair Manual F10182
SST
F07901
2 1
(-)(+)
- BRAKEBRAKE FLUID
BR-5
1404 Author: Date:
2001 AVALON   (RM808U)
(b) While an assistant depresses the pedal, loosen the
bleeder plug until fluid starts to run out. Then

Page 508 of 1897

TOYOTA AVALON 2001  Service Repair Manual BR150-01
F09720
Brake Pedal Bracket Lower LH Panel Insert
Lower No. 1 Instrument Panel
Stop Light Switch
Cruise Control ECU
Pedal Pad
Clip
Return Spring
Collar
Wave Washer
Clevis Pin
Cushion Plate
 B

Page 509 of 1897

TOYOTA AVALON 2001  Service Repair Manual R00954
Stop Light Switch
Push Rod
Pedal HeightBR0KI-04
R00935
Pedal Freeplay BR-6
- BRAKEBRAKE PEDAL
1405 Author: Date:
2001 AVALON   (RM808U)
BRAKE PEDAL
ON-VEHICLE  INSPECTION
1. CHECK PEDAL HEIGH

Page 510 of 1897

TOYOTA AVALON 2001  Service Repair Manual R00934
Pedal Reserve Distance
- BRAKEBRAKE PEDAL
BR-7
1406 Author: Date:
2001 AVALON   (RM808U)
4. CHECK PEDAL RESERVE DISTANCE
Release the parking brake.
With the engine running, depress the pedal
