Controller and buttons
“MAP/VOICE” buttonPush this button torepeat a guidance
voice, cancel the map scroll and start a
guidance. For details, see page 35.
“MENU” button
Push this button to display the menu
screen. This screen allows you to make adjustments or
correct settings of
various options and functions.
Zoom in/out button These buttons
magnify or reduce the map scale. For
details, see page 46.
“OFF” button
Push this button
when finishing the
navigation system.
“DISP” button
Push this button to
display screen. For
details, see page 113. “DEST” button
Push this button to display the destination
screen. For details, see page 9.
“ENT” button/select and scroll lever
In case of selecting the function and letters
or moving cursor, press down the lever to
one direction out of 8 directions. In case of
deciding the function after selecting it on the
screen, push down on the lever as a button.
Numeric keypad
Push these buttons to
input letters and numbers.
For details, see page 6.
“INFO” button
Push this button to
display the
maintenance screen.
For details, see page
97.
“PUSH” button
Push this button to
remove the controller.
For details, see page
2.
Signal output
portion
Transmit the signals
to signal reception
portion. For details.
see page 2.
Power plug
Bucket type front
seats only—The
vehicle battery power
is supplied when the
controller is fixed in
its original position.
Battery cover
To replace the
batteries, see page 2.
SURFACE
BACKSIDE
“BACK” button
Push this button when
to call out the screen
just before.

AVALON_Navi_U (L/O 0205)
52003 AVALON NAVI (OM41403U)
NOTICE
Make sure the positive side and
negative side of the battery should
be faced correctly.
 Do not replace the battery with wet
hands. Water may cause unexpected
rust.
To input letters and/or numbers, move
the select and scroll lever to the 8 di-
rections, and when the letter or number
you wish to input is lit up, push the
“ENT” button. A beep sound is heard,
and the letter or number is input. Re-
peat this procedure to input the name
or number, etc.
You can also input letters and numbers
with numeric keypad of the controller. For
details, see “—Inputting with numeric key-
pad” on page 6 in this section.
If you type a wrong letter, delete it with
the
switch. Selecting the switch
erases one letter. Selecting the
“List” switch on the
screen, the screen will be changed to dis-
play the database items that match the
name or address that you have entered
on the screen. The number of matching
items is shown to the right side of the
screen. If the matching item is more than
9,999, the system displays “ ” on
the screen.
Selecting the
“À” switch to display the diacritics input screen, the “09” switch to display the numeral
input screen.
Selecting the “AZ” switch changes the
screen back to the alphabet input screen.
Inputting letters and
numbers—

AVALON_Navi_U (L/O 0205)
62003 AVALON NAVI (OM41403U)
When a list is displayed, you can scroll
the list by using select and scroll lever.This expresses a displayed
screen position.
If a or a appears to the right
or left of the item name, the
complete name is too long for
the display. Select the or
switch, and the name will scroll
to the end or beginning of its
name.
1NO099
You can input letters and numbers or
select the displayed numbers with the
numeric keypad of the controller. To
use the numeric keypad, open the lid.
The keypad is linked with 3 types of
screen, and the inputting mode of the key-
pad changes as follows:
INPUTTING NUMBER MODE
When the above screen appears on the
display, the keypad will change to the in-
putting number mode.
—Inputting with numeric
keypad

AVALON_Navi_U (L/O 0205)
72003 AVALON NAVI (OM41403U)
Inputting numbers are assigned to each
button of the keypad as follows:Buttons
Inputting number
11
22
33
44
55
66
77
88
99
00
&−
To delete a previous input
number
INPUTTING LETTER MODE
When the above screen appears on the
display, the keypad will change to the in-
putting letter mode.
When you select the
“À” switch, the screen will change to the diacritics input screen and the inputting letters will also change to the diacritics. When
you select the
“09” switch, the screen
will change to the numeral input screen
and the inputting letters will also change
to the number.
Selecting the
“AZ” switch changes the
screen back to the alphabet input screen
and inputting letters back to the alphabet. Inputting letters change according to how
many times the button is pushed. For ex-
ample, if you want to input “B”, push the
“2” button two times. For details, see the
list below.
When the letter you wish to input is high-
lighted on the screen, push the
“ENT”
button.
INFORMATION
If you want to input the same letter
or assigned letters on the same but-
ton in continuation, input the first let-
ter, push the
“ENT” button, and
then input the second letter. For ex-
ample, if you want to input “NO”,
push the
“6” button two times, push
the
“ENT” button, and then push
the
“6” button three times.

AVALON_Navi_U (L/O 0205)
82003 AVALON NAVI (OM41403U)
SELECTING PRESET NUMBER MODE
When the above screen appears on the
display, you can select a number with the
“1” through “5” buttons.
Inputting letters are assigned to each button of the keypad as follows:
À Á Â Ã Ä Å ÆÇ
Ñ  Ò Ó Ô Õ Ö Ø
W  X Y Z
!  ”  #  $  &
 ’  (  )
∗  +
 ,  −  .  /  :
 <  ?
Buttons Inputting letters
Alphabet Diacritics Number
1
2
3
4
5
6
7
8
9
0 —
A  B C
D  E F
G  H I
J  K L
M  N O
P  Q R S
T  U V
— —
È  É Ê Ë
Ì  Í Î Ï
—
—
Ù  Ú Û Ü
— 1
3
4
5
7
8
9
0 2
6
&
——
 To delete the previous input letter

AVALON_Navi_U (L/O 0205)
112003 AVALON NAVI (OM41403U)
US8
Connecticut
Maine
Massachisetts
New Hampshire
New Jersey
New York
Rhode Island
Vermont
US9
Delaware
Maryland
New Jersey
Pennsylvania
Virginia
Washington, D.C.
West Virginia
US10
Florida
Georgia
North Carolina
South Carolina
CANADACAN
Alberta
British Columbia
Manitoba
New Brunswick
Newfoundland and Labrador
Nova Scotia
Ontario
Prince Edward Island
Québec
Saskatchewan
Yukon Territory
You can find your destination using vari-
ous methods. See pages 13 through 28
for the detailed steps.1. By Address: You can input the house
number and the street address by us-
ing the input keys. See page 13 for the
detailed steps. 2. By POI (Point of Interest):
You can
select one of the many points of inter-
est that have been already stored in
the system’s database. There are 54
categories to choose from including
restaurants, hotels and so on. See
page 16 for the detailed steps.
3. By Marked Points: You can select
your own favorite destinations as
“Marked points”. The system allows
you to store up 100 marked points.
See page 22 for the detailed steps.
4. By Previous Destination: You can se-
lect a destination from any of the last
20 previously set destinations. See
page 23 for the detailed steps.
5. By Emergency: You can select one of
the three points of emergency service
points that have been already stored in
the system’s database. See page 23
for the detailed steps.
6. By Intersection: You can enter the
names of two intersecting streets. This
is helpful if you do not know the spe-
cific street address of your destination
but know the general vicinity. See page
24 for the detailed steps.

AVALON_Navi_U (L/O 0205)
132003 AVALON NAVI (OM41403U)
There are 2 ways to input a destination
by address.Select the
“Address” switch on the
“Destination” screen. The “Address”
screen appears, and then you can input
a house number.
After inputting a house number, select the
“OK” switch which you can input a
street name.
It is possible to input a street name first.
Select the
“Street” switch on the dis-
play to display the screen which you can
input a street name.
After each letter is inputted, the system
searches the database for street names
that match. Alphabet keys are dimmed if
the database does not have a match for
the next letter in the remaining list of
matching street names.
Selecting the
“À” switch to display the diacritics input screen, the “09” switch to display the numeral
input screen.
Based on your input, the number of
matching sites appears at the top right of
the screen. After the number decreases to
some extent, select the
“List” switch to
display the street selection list. If the
number of matches decreases to 4 or
less, the screen changes automatically to
the selection list.
Destination input by
ADDRESS (a) Inputting a street name

AVALON_Navi_U (L/O 0205)
412003 AVALON NAVI (OM41403U)
When you are driving while the route
guidance is operating, you can change
the route to detour around a section of
the route where a delay is caused by
road repairs, an accident, etc.
Select the “Chg. route” switch on
the right side of the screen if you en-
counter a reason to divert from the se-
lected route.
EMV3065U
This picture shows an example of how the
system would route you around a delay
caused by a traffic jam.
1This part indicates the location where
traffic jam is occurring due to road
repairs or an accident.
2These show the detour route sug-
gested by the system.
When you select the “Chg. route”
switch, the screen changes to the
“Change route” screen that allows you to
select the distance you want to detour.
Select one of the numeral keys to start
the detour process. After detouring, the
system returns to the original gui dance
route.
Detour setting

AVALON_Navi_U (L/O 0205)
692003 AVALON NAVI (OM41403U)
3. Select the “Change” switch which
you want to edit. CHANGING THE ICON
Select your desired icon. CHANGING THE NAMESelect alphabet or numeral keys to in-
put the name.
After you finish your entry, select the
“OK” switch on the screen.
The previous screen will be displayed.

AVALON_Navi_U (L/O 0205)
702003 AVALON NAVI (OM41403U)
CHANGING THE PHONE NUMBER
Select numeral keys.
After you finish your entry, select the
“OK” switch on the screen.
The previous screen will be displayed. EDITING THE LOCATION
(position/map location)
Operate the select and scroll lever to
move the cursor
to the desired
point on the map.
Push the
“ENT” button on the naviga-
tion controller when the cursor
is your
desired point.
The previous screen will be displayed.
SHOW NAME
You can set the name of marked point
either to show or not on the screen.
To show the name, select the
“On”
switch. Not to show it, select the
“Off” switch. 1. Push the
“MENU” button on the
navigation controller to display the
“Menu” screen and select the
“Marked points” switch.
2. Select the “Delete” switch of the
“Marked points”.
(c) Deleting marked points
