phone TOYOTA AVALON 2007 XX30 / 3.G Navigation Manual
[x] Cancel search | Manufacturer: TOYOTA, Model Year: 2007, Model line: AVALON, Model: TOYOTA AVALON 2007 XX30 / 3.GPages: 138, PDF Size: 4.82 MB
Page 22 of 138
xxii
When you select the of your de-
sired item, the screen changes and dis-
plays the map location of the selected
destination and the route preference.
(See “Entering destination” on page
xxxi.)In case of having some POIs of the same
name, this screen appears.
“Name sort”: Select this switch to list the
categories in alphabetical order.
“Dist. sort”: Select this switch to list the
categories in order of nearest place from
your current location.
INFORMATION
The information on the desired point
of interest can be displayed on the
map screen.
Select the “Info.” switch to display the
selected destination name, address and
telephone number.
Page 26 of 138
xxvi
Select the “Previous destination”switch on the “Destination” screen.
The screen lists to 20 previously set des-
tinations.
Select your desired destination. The
screen changes and displays the map
location of the selected destination and
the route preference. (See “Entering
destination” on page xxxi.)
You can delete the list of previous des-
tinations while you stop your vehicle if
you no longer need them. (See page xciii
for details.)By selecting the
“Emergency”switch on the “Destination” screen, the
display changes to a screen to select
police stations, hospitals or dealers.
While driving, only nearby police sta-
tions, hospitals or dealers are shown.
The current position is shown with an
address, the latitude and the longitude
at the top of the screen.
When you select your desired emergency
category, the selected emergency category
list is displayed.
The distance from your current position up
to the destination is displayed on the right
of the name.
You can see the names of the emergency
destinations in alphabetical order by se-
lecting the
“Name sort” switch on the
screen.
Select the
of your desired item.
The screen changes and displays the
map location of the selected destination
and the route preference. (See
“Enter-
ing destination” on page xxxi.)
Select the
“INFO” switch to display the
selected emergency destination name, ad-
dress and telephone number.
Destination input by
PREVIOUS DESTINATIONDestination input by
EMERGENCY
Page 34 of 138
xxxiv
Split screen: Map and guidance screen
are shown in a screen mode like the
above. (For details about guidance screen,
see page xxxv.)
The two route guidance screens have a
number of indicators and switches with
which you should be familiar.Map screen with switch: When the
“ENTER” button on the navigation con-
troller is pushed while the map is dis-
played, the switch screen is displayed on
the right side of the screen.
“GPS”: Upon reception of signals from
the GPS (Global Positioning System), this
mark appears. (For details, see page
lii.)
“Map orient”: To switch the map orienta-
tion between North−up and Heading−up.
(For details, see page l.)
“POI”: Select this switch, and symbols of
points of interest are shown on the
screen. (For details, see page xlv.)
“Chg. route”: The “Change route” screen
appears and the following settings are
available.“Mark”: Select this switch for quick regis-
tration of the marked point. (For details,
see page lxxxiii.)
“Guide”: When POI icons are displayed
on the map, select this switch, and the
name of a POI icon near the cursor is
displayed. Move the select and scroll le-
ver to the right or left, and the name of
the next POI icon is displayed. If no POI
icons are displayed on the screen, “No
guidance information available” is dis-
played. Push the “ENTER” button while
the name of a POI icon is displayed to
see detailed information about that POI
(name, location, phone number, etc.) dis-
played on the screen.
“
”: Select this switch when you
have several destinations to go. The dis-
tance and time from the current position
to the destination can be displayed for
each destination. When you are not travel-
ing on the route, however, only the dis-
tance is displayed.
Page 56 of 138
lvi
TERMS AND CONDITIONS
Personal Use Only. You agree to use
this Data together with the navigation
system for the solely personal, non−
commercial purposes for which you
were licensed, and not for service bu-
reau, time−sharing or other similar
purposes. Accordingly, but subject to
the restrictions set forth in the follow-
ing paragraphs, you may copy this
Data only as necessary for your per-
sonal use to (i) view it, and (ii) save
it, provided that you do not remove
any copyright notices that appear and
do not modify the Data in any way.
You agree not to otherwise reproduce,
copy, modify, decompile, disassemble
or reverse engineer any portion of this
Data, and may not transfer or distrib-
ute it in any form, for any purpose,
except to the extent permitted by
mandatory laws. Data provided in
multi−disc sets may not be transferred
or sold on a divided or single disc
basis.Restrictions.
Except where you have
been specifically licensed to do so by
[CLIENT], and without limiting the pre-
ceding paragraph, you may not (a)
use this Data with any products, sys-
tems, or applications installed or
otherwise connected to or in commu-
nication with vehicles, capable of ve-
hicle navigation, positioning, dispatch,
real time route guidance, fleet man-
agement or similar applications; or (b)
with or in communication with any
positioning devices or any mobile or
wireless−connected electronic or com-
puter devices, including without limita-
tion cellular phones, palmtop and
handheld computers, pagers, and per-
sonal digital assistants or PDAs.
Warning
. The Data may contain inac-
curate or incomplete information due
to the passage of time, changing cir-
cumstances, sources used and the
nature of collecting comprehensive
geographic data, any of which may
lead to incorrect results.
No Warranty. This Data is provided
to you “as is,” and you agree to use
it at your own risk. [CLIENT] and its
licensors (and their licensors and sup-
pliers) make no guarantees, represen-
tations or warranties of any kind, ex-
press or implied, arising by law or
otherwise, including but not limited to,
content, quality, accuracy, complete-
ness, effectiveness, reliability, fitness
for a particular purpose, usefulness,
use or results to be obtained from
this Data, or that the Data or server
will be uninterrupted or error−free.
Disclaimer of Warranty:
[CLIENT] AND
ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS) DIS-
CLAIM ANY WARRANTIES, EXPRESS
OR IMPLIED, OF QUALITY, PER-
FORMANCE, MERCHANTABILITY, FIT-
NESS FOR A PARTICULAR PUR-
POSE OR NON−INFRINGEMENT.
Some States, Territories and Countries
do not allow certain warranty exclu-
sions, so to that extent the above
exclusion may not apply to you.
Page 61 of 138
lxi
WARNINGS
The DATABASE comprises facts and
information from government and other
sources reflecting circumstances in
existence before you received the DA-
TABASE, which may contain errors
and omissions. Accordingly, the DA-
TABASE may contain inaccurate or in-
complete information due to the pas-
sage of time, changing circumstances,
and due to the nature of the sources
used. The DATABASE does not in-
clude or reflect information relating to,
among other things, neighborhood
safety; law enforcement; emergency
assistance; construction work; road or
lane closures; vehicle or speed re-
strictions; road slope or grade; bridge
height, weight or other limits; road or
traffic conditions; special events; traf-
fic congestion; or travel time.U.S. GOVERNMENT RIGHTS
If you are an agency, department, or
other entity of the United States Gov-
ernment, or funded in whole or in part
by the United States Government,
then use, duplication, reproduction, re-
lease, modification, disclosure or
transfer of this commercial product
and accompanying documentation, is
restricted in accordance with the LIM-
ITED or RESTRICTED rights as de-
scribed in DFARS 252.227−7014(a)(1)
(JUN 1995) (DOD commercial comput-
er software definition), DFARS
227.7202−1 (DOD policy on commer-
cial computer software), FAR
52.227−19 (JUN 1987) (commercial
computer software clause for civilian
agencies), DFARS 252.227−7015
(NOV 1995) (DOD technical data −
commercial items clause); FAR
52.227−14 Alternates I, II, and III
(JUN 1987) (civilian agency technical
data and noncommercial computer
software clause); and/or FAR 12.211
and FAR 12.212 (commercial item ac-
quisitions), as applicable.In case of conflict between any of the
FAR and DFARS provisions listed
herein and this Agreement, the
construction that provides greater limi-
tations on the Government’s rights
shall control. Contractor/manufacturer
is Tele Atlas North America, Inc., 11
Lafayette Street, Lebanon, NH
03766−1445. Phone: 603.643. 0330.
The DATABASE is ©1984−2005 by
Tele Atlas North America, Inc. ALL
RIGHTS RESERVED. For purpose of
any public disclosure provision under
any federal, state or local law, it is
agreed that the DATABASE is a trade
secret and a proprietary commercial
product and not subject to disclosure.
Page 80 of 138
lxxx
Operate the select and scroll lever of
the navigation controller, so that the
direction is facing to your desired di-
rection.
Push the
“ENTER” button on the navi-
gation controller and the map screen re-
turns.Once a marked point is registered, you
can edit the icon, name or telephone
number.
1. Push the
“MENU” button on the
navigation controller to display the
“Menu” screen and select the
“Marked points” switch.
2. Select the “Edit” switch of the
“Marked points”.
The screen lists the marked points.
Sort by “Icon”: Select this switch to list
the marked points in order of the type of
icon.
Sort by “Date”: Select this switch to list
the marked points in order of the regis-
tered date.
Sort by “Name”: Select this switch to list
the marked points in alphabetical order.
Select
switch of the desired marked
point to display the edit marked point
screen.
(b) Editing marked points
Page 82 of 138
lxxxii
CHANGING THE PHONE NUMBER
Select numeral keys.
After you finish your entry, select the
“OK” switch on the screen.
The previous screen will be displayed.EDITING THE LOCATION
(position/map location)
Operate the select and scroll lever to
move the cursor
to the desired
point on the map.
Push the
“ENTER” button on the navi-
gation controller when the cursor
is at
your desired point.
The previous screen will be displayed.
SHOW NAME
You can set the name of marked point
either to show or not on the screen.
To show the name, select the
“On”
switch. Not to show it, select the
“Off” switch.1. Push the
“MENU” button on the
navigation controller to display the
“Menu” screen and select the
“Marked points” switch.
2. Select the “Delete” switch of the
“Marked points”.
(c) Deleting marked points
