Foreword
Welcome to the growing group of value−conscious people who drive Toyotas. We are proud of the advanced engineering and
quality construction of each vehicle we build.
This Owner ’s Manual explains the operation of your new Toyota. Please read it thoroughly and have all the occupants
follow the instructions carefully. Doing so will help you enjoy many years of safe and trouble free motoring. For
important information about this manual and your Toyota, read the following pages carefully.
When it comes to service, remember that your Toyota dealer knows your vehicle very well and is interested in your complete
satisfaction. Your Toyota dealer will provide quality maintenance and any other assistance you may require.
If there is not a Toyota dealer near you, please call the following number:
U.S. OWNERS:
When traveling in the U.S. mainland or Canada: Toyota Customer Experience Center Toll free:1 800 331 4331
Hawaii:
Servco Automotive Customer Services Toll free:1 888 272 5515
CANADIAN OWNERS:
When traveling in Canada or the U.S. mainland: Toyota Canada Customer Interaction Centre Toll free:1 888 TOYOTA 8 or 1 888 869 6828
Please leave this Owner ’s Manual in this vehicle at the time of resale. The next owner will need this information also.
All information and specifications in this manual are current at the time of printing. However, because of Toyota’s policy of
continual product improvement, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may
find some explanations for equipment not installed on your vehicle.
Please access our websites for further information.
The U.S. mainland www.toyota.com
Hawaiiwww.toyotahawaii.com
Canadawww.toyota.ca
©2006 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in part, without the written permission of Toyo ta
Motor Corporation.
Page 2 of 404
ii
Important information about this manual
Safety and vehicle damage warnings
Throughout this manual, you will see safety and vehicle dam-
age warnings. You must follow these warnings carefully to
avoid possible injury or damage.
The types of warnings, what they look like, and how they are
used in this manual are explained as follows:
CAUTION
This is a warning against anything which may cause
injury to people if the warning is ignored. You are
informed about what you must or must not do in
order to reduce the risk of injury to yourself and
others.
NOTICE
This is a warning against anything which may cause
damage to the vehicle or its equipment if the warning
is ignored. You are informed about what you must or
must not do in order to avoid or reduce the risk of
damage to your vehicle and its equipment.
Safety symbol
When you see the safety symbol
shown above, it means: “Do not...”;
“Do not do this”; or “Do not let this
happen”.
Page 3 of 404
iii
Important information about your Toyota
Occupant restraint systems
Toyota encourages you and your family to take the time to
read Section 1−3 of this Owner’s Manual carefully. In terms
of helping you understand how you can receive the maximum
benefit of the occupant restraint systems this vehicle pro-
vides, Section 1 −3 of this Owner’s Manual is the most impor-
tant Section for you and your family to read.
Section 1−3 describes the function and operation concerning
seats, seat belts, SRS airbags and child restraint systems of
this vehicle and some potential hazards you should be aware
of. These systems work together along with the overall struc-
ture of this vehicle in order to provide occupant restraint in
the event of a crash. The effect of each system is enhanced
when it is used properly and together with other systems. No
single occupant restraint system can, by itself, provide you or
your family with the equal level of restraint which these sys-
tems can provide when used together. That is why it is im-
portant for you and your family to understand the purpose
and proper use of each of these systems and how they re-
late to each other.
The purpose of all occupant restraint systems is to help re-
duce the possibility of death or serious injury in the event of
a collision. None of these systems, either individually or to-
gether, can ensure that there is no injury in the event of
collision. However, the more you know about these systems
and how to use them properly, the greater your chances be-
come of surviving an accident without death or serious injury.
Seat belts provide the primary restraint to all occupants of
the vehicle, and every occupant of the vehicle should wear
seat belts properly at all times. Children should always be
secured in child restraint systems that are appropriate for
their age and size. SRS (Supplemental Restraint System) air-
bags are, as their names imply, designed to work with, and
be supplemental to, seat belts and are not substitutes for
them. SRS airbags can be very effective in reducing the risk
of head, chest and knee injuries by preventing contact of the
head, chest and knee with interior portions of the vehicle.
Page 4 of 404
iv
In order to be effective, the SRS airbags must deploy with
tremendous speed. The rapid deployment of the SRS airbags
makes the SRS airbags themselves potential sources of
death or serious injury if an occupant is too close to an
airbag, or if an object or some part of his or her body has
been placed between the occupant and the airbag at the time
of deployment. This is just one example of how the instruc-
tions in Section 1−3 of this Owner’s Manual will help ensure
proper use of the occupant restraint systems, and increase
the safety they can provide to you and your family in the
event of an accident.
Toyota recommends you to read the provisions in Section
1−3 carefully and refer to them as needed during your time
of ownership of this vehicle.Event data recorder
Your vehicle has computers that monitor and control certain
aspects of your vehicle. These computers assist in driving
and maintaining optimal vehicle performance. Besides storing
data useful for troubleshooting, there is a system to record
data in a crash or a near car crash event. This is called an
Event Data Recorder (EDR).
The SRS airbag sensor assembly contains the EDR. In a
crash or a near car crash event, this device may record
some or all of the following information:
Engine speed
Whether the brake pedal was applied or not
Vehicle speed
To what extent the accelerator pedal was depressed
Position of the transmission selector lever
Whether the driver and front passenger wore the seat
belts or not
Driver’s seat position
Front passenger’s occupant classification
SRS airbag deployment data
Page 5 of 404
v
SRS airbag system diagnostic data
If your vehicle is equipped with a vehicle stability control
(VSC) system, its Electronic Control Unit (ECU) may contain
another EDR. There are a variety of driving situations which
include activating the VSC under which the VSC EDR will
record certain information. The VSC EDR may record some
or all of the following information: Behavior of the vehicle
Steering wheel angle
Vehicle speed
To what extent the accelerator pedal was depressed
To what extent the brake pedal was applied
To what extent the ECU controlled the condition of the
4 wheels
Vehicle stability control system diagnostic data
The information above is intended to be used for the purpose
of improving vehicle safety performance. Unlike general data
recorders, the EDR does not record sound data such as
conversation between passengers.Toyota will not disclose the data recorded in an EDR to a
third party except when: An agreement from the vehicle’s owner (or the leasing
company for a leased vehicle) is obtained
Officially requested by the police or other authorities
Used as a defense for Toyota in a law suit
Ordered by the court
However, if necessary Toyota will: Use the data for research on Toyota vehicle safety
performance
Disclose the data to a third party for research purposes
without disclosing details of the vehicle owner, and only
when it is deemed necessary
Disclose summarized data cleared of vehicle identifica-
tion information to a non −Toyota organization for re-
search purposes
Page 6 of 404
vi
New vehicle warranty
Your new vehicle is covered by the following Toyota limited
warranties: New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the “Owner’s Warranty
Information Booklet” or “Owner’s Manual Supplement”.
Your responsibility for maintenance
It is the owner ’s responsib ility to make sure that the speci-
fied maintenance is performed. Section 6 gives details of
these maintenance requirements. Also included in Section
6 is general maintenance. For scheduled maintenance in-
formation, please refer to the “Scheduled Maintenance
Guide” or “Owner ’s Manual Supplement”.
Important health and safety
information about your Toyota
CAUTION
WARNING: Engine exhaust, some of its constitu-
ents, and a wide variety of automobile compo-
nents contain or emit chemicals known to the
State of California to cause cancer and birth de-
fects and other reproductive harm. In addition,
oils, fuels and fluids contained in vehicles as well
as waste produced by component wear contain or
emit chemicals known to the State of California to
cause cancer and birth defects or other reproduc-
tive harm.
Battery posts, terminals and related accessories
contain lead and lead compounds. Wash your
hands after handling. Used engine oil contains
chemicals that have caused cancer in laboratory
animals. Always protect your skin by washing
thoroughly with soap and water.
Page 7 of 404
vii
Accessories, spare parts andmodification of your Toyota
A wide variety of non −genuine spare parts and accessories
for Toyota vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or replace-
ment, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non −genuine Toyota
products. Modification with non −genuine Toyota products
could affect its performance, safety or durability, and may
even violate governmental regulations. In addition, damage or
performance problems resulting from the modification may not
be covered under warranty.
Spark ignition system of your
To y o t a
The spark ignition system in your Toyota meets all require-
ments of the Canadian Interference −Causing Equipment Stan-
dard.
Installation of a mobile two way
radio system
As the installation of a mobile two −way radio system in your
vehicle could affect electronic systems such as multiport fuel
injection system/sequential multiport fuel injection system,
electronic throttle control system, cruise control system, dy-
namic laser cruise control system, anti −lock brake system,
traction control system, vehicle stability control system, SRS
airbag system and seat belt pretensioner system, be sure to
check with your Toyota dealer for precautionary measures or
special instructions regarding installation.
Perchlorate Material
Special handling and disposal restrictions may apply, See
www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate.
These components may include airbag, seat belt pretension-
ers, and wireless remote control batteries.
Page 8 of 404
viii
Smart key system
Users of any electrical medical devices such as implanted
pacemakers should consult the manufacturer of the device
for information about its operation under the influence of ra-
dio waves. Radio waves could have unexpected effects on
the operation of such medical devices. For details, see
“Keys” on page 14 and “Smart key system” on page 27 in
Section 1−2.
Tires and loading on yourTo y o t a
Underinflated or overinflated tire pressure and ex-
cess load may result in the deterioration of steering
ability and braking ability, leading to an accident.
Check the tire inflation pressure periodically and be
sure to stay with the load limits given in this Owner’s
Manual. For details about tire inflation pressure and
load limits, see pages 289 and 361.
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your
Toyota contain explosive chemicals. If the vehicle is scrapped
with the airbags and pretensioners left as they are, this may
cause an accident such as fire. Be sure to have the systems
of the SRS airbag and seat belt pretensioner removed and
disposed of by the qualified service shop or by your Toyota
dealer before you dispose of your vehicle.
Leak detection pump
This pump performs fuel evaporation leakage check. This
check is done approximately five hours after the engine is
turned off. So you may hear sound coming from underneath
the luggage compartment for several minutes. It does not
indicate a malfunction.
Page 9 of 404
1
OPERATION OF INSTRUMENTS AND
CONTROLS
Overview of instruments and controls
Instrument panel overview2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
Instrument cluster overview 7
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
Center cluster overview 8
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . \
. . .
Indicator symbols on the instrument panel 9
. . . . . . . . . . . . . . . . . . . . . . .
SECTION 1 1
Page 10 of 404
2
1. Side vents
2. Side defroster outlets
3. Instrument cluster
4. Center cluster
5. Garage door opener switches
6. Auxiliary boxes
7. Front personal lights, interior lightand/or electric moon roof switches
8. Center vents
9. Glove box
10. Power door lock switches
11. Power window switches
12. Trunk opener main switch
13. Rear console box
14. Rear vents
15. Power outlets
16. Seat ventilator/heater switches
17. Cup holder
18. Automatic transmission selector lever
19. Tire pressure warning reset switch (On bottom of the instrument panel)
20. Hood lock release lever
21. Parking brake pedal
22. Window lock switch
23. Driving position memory switches
Instrument panel overview
View A
