set clock TOYOTA AVALON 2007 XX30 / 3.G Quick Reference Guide

1
INDEX
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND
EMERGENCY FEATURES
Engine maintenance 8
Fuel tank door release and cap 6
Hood release 7
Indicator symbols 4-5
Instrument cluster 4
Instrument panel 2-3
Keyless entry17
Remote engine starter 8
Trunk release 6
Air Conditioning/Heating 15
Audio 16-17
Auto lock functions110
Automatic Transmission 11
Clock 10
Cruise control 19
Cup holders 21
Door locks 18
Dynamic Laser Cruise Control 20
Garage door opener (HomeLink®)211
Light control-Instrument panel 21
Lights & turn signals 14
Moonroof 19
Parking brake 10
Power outlets 21
Seat adjustments-Front 12
Seat adjustments-Rear 12
Seat ventilators/heaters 18
Seats-Head restraints 12
Smart Key19
Steering wheel switches 18
Sunshade-Rear 19
Tilt and telescopic steering wheel 10
Windows 13
Windshield wiper & washer 13
Doors-Child safety locks 22
Seat belt comfort guide 23
Seat belts 22
Seat belts-Shoulder belt anchor 22
Spare tire & tools 23
Tire Pressure Warning System reset 22
Trunk-Internal release 23
1Programmable by customer. Refer to the Owner’s Manual for instructions and
more information.
2HomeLink®is a registered trademark of Johnson Controls, Inc.

FEATURES/OPERATIONS
Auto lock functions
Parking brake
Automatic Transmission
11 10
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Automatic door locks can be programmed to operate in 4 different modes,
or turned OFF.
-Doors lock when shifting from “Park.”
-Doors lock when the vehicle speed goes above approximately 12 mph.
-Doors unlock when shifting into “Park.”
-Doors unlock when the ignition switch is set from ON to ACC or OFF and
driver’s door is opened.
Refer to the Owner’s Manualfor more details.
Set: Depress
Release: Depress again
Tilt and telescopic steering wheel
Clock
NOTE: Do not attempt to adjust while the vehicle is in motion.
Lock release lever
Length
H-Hour set
M-Minute set
:00-Round off minutesGarage door openers manufactured under license from HomeLink
®* can be
programmed to operate garage doors, estate gates, security lighting, etc.
Refer to the Owner’s Manualfor more details.
For programming assistance, contact the Toyota Customer Experience
Center at 1-800-331-4331, or visit http://www.homelink.com.
* HomeLink®
is a registered trademark of Johnson Controls, Inc.
Park1
Reverse
Neutral
Drive
P
“S”“D”
Garage door opener (HomeLink®)*
(if equipped)
Lock release lever
Angle
“S” position:
+: Upshift (Push and release)
-: Downshift (Pull and release)
“S” (Sequential) mode
Downshifting increases power going uphill, or provides engine braking
downhill. For best fuel economy during normal driving conditions, always
drive with the shift lever in the “D” position. Push shift lever to the left from “D” position.
1The ignition switch must be ON, and the brake
pedal depressed to shift from “Park.”
NOTE:In Navigation System-equipped vehicles, clock settings are in
navigation setup menu.

19 18
FEATURES/OPERATIONS
Steering wheel switches
Sunshade-Rear (if equipped)
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Seat ventilators/heaters (if equipped)
Moonroof (if equipped)
Volume control
“Mode” 2
“”1vv
A/C control Audio control
Temperature selector
Auto A/C ON/OFF
A/C OFF
1
“”
-In radio modePush to select a preset station; push and hold to seek the
next strong station.
-In tape mode
*Push to skip up or down to next/previous track; push
and hold to fast forward or reverse.
-In CD modePush to skip up or down to next/previous track.
2“MODE”
Push to turn audio ON and select an audio mode. Push and hold to turn
the audio system “OFF.”
*If equipped
Heater only
With ventilators
Push knob to pop the controller out. Turn clockwise for heater, counter
clockwise for ventilator.
Sliding operationTilting operation
NOTE:If battery is disconnected, the moonroof needs to be reinitialized.
Refer to the Owner’s Manualfor more details.
Open
CloseCloseTilt
Push
NOTE:Sunshade will automatically go down when vehicle is shifted into
reverse. To raise again, push the button.
Cruise control
Functions
System
ON/OFF
Set/Decrease
speed Resume
2/
Increase speed
Cancel1
1The set speed may also be cancelled by depressing the brake pedal.2If vehicle speed falls below 25 mph, the set speed will not be resumed.
Refer to the Owner’s Manualfor more details.
Turning system ON/OFF
vvRecommended
driving position
to minimize
wind noise.
Door locks
LockUnlock
PushTu r nPush Turn

2021
FEATURES/OPERATIONS
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Light control-Instrument panel
Distance control mode will cruise at a set speed, decelerate to maintain
selected distance from a slower vehicle in front of you, and accelerate
back up to the selected speed if the vehicle in front of you changes lanes
or speeds up.
To select distance control modePush the ON-OFF button. The
“READY” and “CRUISE” indicator lights will come on.
To set, cancel and resume a speed Refer to instructions for Cruise
Controlon the previous page.
Note:Once vehicle speed is set, pushing lever up toward “+ RES” will
increase speed to the nearest 5 mph, and then in 5 mph increments.
Pushing lever down toward “- SET” will reduce speed in the same way.
LONG
MIDDLE
SHORT
To change the vehicle-to-vehicle distance
Pull the distance switch briefly toward you; the setting changes
progressively from LONG to MIDDLE to SHORT.
With the knob turned fully
clockwise, instrument panel
lights will not dim when the
headlights are turned ON.
+Brightness
control
-
Auxiliary box (12V)Console box (12V)
Cup holders
Power outlets
RearRear with console box
NOTE: Designed for car accessories. Ignition/Engine switch must be in the
“ACC” or “ON” position to be used.
Front
Dynamic Laser Cruise Control (if equipped)
To select conventional/fixed speed controlPush the ON-OFF button.
Push the lever forward and hold until the “NORM.” indicator appears.
To set, cancel and resume a speed Refer to instructions for Cruise
Controlabove.
Fixed speed mode
Refer to the Owner’s Manualfor more details and complete safety
precautions before attempting to use “Dynamic Laser Cruise Control.”
Distance control mode
(1)
(1) (2)
(2)
(3)
