display TOYOTA AVALON 2009 XX30 / 3.G Navigation Manual

ADVANCED FUNCTIONS
103
To display the next destination
To preview the route to the
next destination
To preview the route to the
next destination fast
To stop previewing
To preview the route to the
previous departure position
To preview the route to the
previous departure position
To display the previous de-
parture position
3. Select the “Edit” switch. The “Edit
route preview” screen appears.
“To next POI”: To preview the next POI
“To next
”: To preview the next destina-
tion
If the points of interest you selected are on
the route, they are displayed on the
screen.
“Select POI”: To select the POI icon
“Delete”: To delete the POI icon
4. Select your desired category of
point of interest.
5. Select your desired icon from the
list and select the “OK” switch.

MORE ADVANCED FUNCTIONS
106
You can set the values shown on the
“Setup” screen.
1. Select the “MENU” button on the
navigation controller.
2. Select the “Setup” switch to dis-
play the “Setup” menu screen. Select
items you want to set. Selected items
will be highlighted in green.
3. Select the “OK” switch on the
screen and then the previous screen
will be displayed. “Default”:
Select the
“Default” switch
on the right side of the screen. All of the
settings can be defaulted.
“Map color” (day or night): You can se-
lect your desired map color.
“Auto reroute”: You can set the system
will or will not automatically search for a
new route to the destination.
“Estimated travel time”: You can set to
display the time required to reach the des-
tination on the route guidance screen.
“Adjust time zone”: You can select your
desired time zone.
“Distance”: You can change
“km” or“miles” to display your desired units.
“Notify seasonal restrict”: You can se-
lect to notify or not to notify a seasonal re-
strict.
“Voice guide in all modes”: You can set
the voice guide in all modes or not.
“Current street name”: You can select to
show or not to show a current street name
on the map screen.
“Operation guide on map”: Display or
non−display of the operation guide on the
display can be selected.
Setup

MORE ADVANCED FUNCTIONS
108
3. Select the “On” switch of “Auto re-
route”.
Selected switch is highlighted in green.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new
route may or may not take you back to
the previous route depending on how
far you are off the original guidance
route.
When the “Estimated travel time” fea-
ture is turned on, the time estimated to
reach the destination is displayed on
the route guidance screen.
To turn the “Estimated travel time”
mode on:
1. Push the “MENU” button on the
navigation controller.
Time to destination

MORE ADVANCED FUNCTIONS
109
2. Select the “Setup” switch.
3. Select the “Change speed”switch on the “Setup” screen.
4. You can set the speed as your desire
by operating the select and scroll lever
of the navigation controller. Select the
item by moving the lever vertically, and
move the lever horizontally to set the
speed.
If you select the
“Default” switch, the
default speed is set at each item.
5. After you finish setting the desired
speeds, select the
“OK” switch on the
right side of the screen.
6. The “Setup” screen will be dis-
played. Select the
“On” switch of “Es-
timated travel time”.
Selected switch is highlighted in green.
INFORMATION
 The displayed time to the destina-
tion is the approximate driving
time calculated based on the
speeds you selected and your ac-
tual position along the guidance
route.
 The time shown may vary greatly
depending on your progress along
the route (which may be affected
by road conditions such as traffic
jams, construction work, etc.).
 Up to 99 hours 59 minutes can be
displayed.

MORE ADVANCED FUNCTIONS
11 0
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
3. Select the “Adjust” switch. The
“Adjust time zone” screen appears on
the display.
4. Select your desired time zone.
Selected switch is highlighted in green.
“Daylight saving time”: Select the
“On” switch on the screen and then se-
lect
or to set the day light saving
time.
5. Select the
“OK” switch on the
screen and the “Setup” screen will be
displayed.
Adjust time zone

MORE ADVANCED FUNCTIONS
11 4
This system has a function which in-
forms you of the time to replace certain
parts or components as well as other
information shown on the screen. (See
“Information items” on page 116.)
When the system begins operating af-
ter reaching either the information
item’s date or driving distance, the “In-
formation” screen will be displayed.
The “Information” screen will not be dis-
played or start up by selecting the
“Do
not display this message again”
switch.
1. Push the “INFO” button on the
navigation controller.
2. Select the “Maintenance” switch
to display the “Maintenance” screen.
Maintenance information

MORE ADVANCED FUNCTIONS
11 5
3. Select your desired icon and input
the conditions.
“Date” of notice: Input the next mainte-
nance date.
“Distance” of notice: Input the driving
distance until the next maintenance check.
When you select the
! switch on the
“Maintenance” screen, the screen
changes to display the change name
screen. Select the keys to input your de-
sired name and then input the conditions. After you input that information, select the
“OK” switch. The screen then returns to
the “Maintenance” screen. The icon’s color
will change to green after the date or driv-
ing distance is inputted. The icon’s color
will change to orange when your Toyota
needs to be serviced. The following
switches appear on the screen.
“Delete all”: Cancel all conditions which
have been inputted.
“Reset all”: Reset all items which satisfy
either condition.
Select the
“Off” switch at the top of the
“Maintenance” screen, and the informa-
tion screen will no longer be displayed.
INFORMATION
 For scheduled maintenance infor-
mation, please refer to the “Own-
er’s Manual Supplement” or
“Scheduled Maintenance”.
 Depending on your driving or the
road conditions, the system may
have a timelag between the data
which has been inputted and the
actual date and driving distance.

MORE ADVANCED FUNCTIONS
11 7
1. Push the “INFO” button on the
navigation controller.
2. Select the “Maintenance” switch
to display the “Maintenance” screen. (a) Register dealer
You can register your dealer’s name,
staff, location and phone number.
1. Select
the “Set dealer” switch on
the “Maintenance” screen.
2. Enter your dealer’s location ad-
dress in the same way as you input any
destination. (See pages 22 through 38.)
After you enter your dealer, the screen
changes and displays the map location of
the dealer. If it is OK, select the
“Enter”switch at the right of the screen.
The current screen changes to the screen
when you can edit the data of your dealer.
(See “(b) Edit dealer” on page 118.)
Dealer setting

MORE ADVANCED FUNCTIONS
11 8
(b) Edit dealer
You can edit your dealer’s name, staff,
location and phone number if you al-
ready registered the dealer.
1. Select the
“Set dealer” switch on
the “Maintenance” screen. The “Edit
dealer” screen appears on the display.
2. Select the “Change” switch to
edit the item. EDITING THE NAME OF THE DEALER
OR CONTACT
Select alphabet, numeral or umlaut
keys directly to input the name.
After you finish your entry, select the
“OK” switch at the bottom right of the
screen. The previous screen will be dis-
played.

MORE ADVANCED FUNCTIONS
120
(c) Delete dealer
1. Select the “Set dealer” switch on the
“Maintenance” screen.
2. Select the “Delete dealer” switch
on the screen.
3. A selected point will appear. Also, a
message will appear on the bottom of
the screen. To delete, select the
“Yes”switch. To cancel deletion, select the“No” switch. (d) View map
1. Select
the “Set dealer” switch on the
“Maintenance” screen.
2. Select the “View map” switch on
“Edit dealer” screen. The screen
changes and displays the map location
of the registered dealer and the route
preference. (See “Entering destina-
tion” on page 39.)
