Page 21 of 28
19
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Center display
Without navigation system
Audio display
Air Conditioning display
Outside temperature
Trip information display
Pattern selector knob
Display item can be switched by pushing the knob: (1) Entire display
(2) Audio display and Air Conditioning display (3) OFF.
With navigation systemRefer to the “Navigation System Owner’s Manual.”
Steering wheel switches
Audio controlClimate control
vv
Volume controlTemperature
selector
Auto A/C ON
System OFF
“ ”
-In radio mode Push to select a preset station; push and hold to seek the
next strong station.
-In CD mode Push to skip up or down to next/previous track; push and
hold to select a disc.
“MODE” Push to turn audio ON and select an audio mode. Push and hold to turn
audio system OFF.
09_Avalon_i.qxd 7/22/08 3:29 PM Page 19
Page 22 of 28
20
FEATURES/OPERATIONS
Air Conditioning/Heating
Temperature selector (driver side)
Temperature selector (passenger side)
Climate control OFF
Air Conditioning ON/OFF
Fresh or recirculated cabin air
Automatic climate control ON
Outside rearview mirror*/Rear defogger
Airflow vent
In “ ” mode, use fresh air (“ ” indicator OFF) to reduce
window fogging.
Fan speed
“DUAL” button
Indicator ON:Separate temperature settings for driver and
passenger.
Indicator OFF: Synchronize temperature settings for driver and
passenger.
Windshield defogger (fresh air only)
* If equipped
Display
Control
Without navigation systemWith navigation system
09_Avalon_i.qxd 7/22/08 3:29 PM Page 20
Page 23 of 28
21
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Door locks
Lock
Unlock
Seat ventilators/Heaters (if equipped)
Push knob to pop the controller out. Turn clockwise for heater,
counter-clockwise for ventilator.
PushTurn
With ventilatorHeater only
Push
Tu r n
Heater
OFF
Ventilator
09_Avalon_i.qxd 7/22/08 3:29 PM Page 21
Page 24 of 28
22
FEATURES/OPERATIONS
Cup holders
Rear (type B)
FrontRear (type A)
Power outlets
Auxiliary box
Console box
The “ENGINE START STOP” switch/engine switch must be in the “ACC” or
“ON” position to be used.
Clock
H-Hour set
M-Minute set
:00-Round off minutes
Without navigation system
With navigation system Refer to the “Navigation System Owner’s Manual.”
412714M2_r1.qxd 7/23/08 5:12 PM Page 22
Page 25 of 28
23
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
SAFETY AND
EMERGENCY FEATURES
Moving the lever to “LOCK” will allow the door to be opened only f\
rom
the outside.
Rear door
Doors-Child safety locks
If belt is fully extended, then retracted even slightly, it cannot be
re-extended beyond that point, unless fully retracted again. This featur\
e
is used to help hold child restraint systems securely.
To find more information about seat belts, and how to install a child
restraint system, refer to the Owner's Manual.
Keep as low on
hips as possible
Take up slack
Too high
Seat belts
Push up, or
squeeze lock
release to lower
Seat belts-Shoulder belt anchor
09_Avalon_i.qxd 7/22/08 3:29 PM Page 23
Page 26 of 28
24
SAFETY AND EMERGENCY FEATURES
System reset initiali zation
1. Push and hold “ SET” button
until the indicator blinks
three times.
2. Wait a few minutes to allow
initialization to complete.
Seat belt comfort guide
Rear seat outside position guides provide added comfort for children who
have outgrown child restraints.
After adjusting tire pressures, or after tires have been rotated or
replaced, turn the ignition switch to “ON” and press and hold the
“ SET” button until indicator blinks three times. Let the vehicle sit for a
few minutes to allow initialization to complete.
Refer to the load label on the door jamb or the Owner
’s Manual for tire
inflation specifications.
If the tire pressure indicator flashes for more than 60 seconds and then
remains on, take the vehicle to your local To y o t a dealer.
Note :The warning light may come on due to temperature changes or
changes in tire pressure from natural air leakage. If the system has not
been initialized recently
, setting the tire pressures to factory
specifications should turn off the light.
Tire Pressure Monitoring (warning)
System
412714M2_r1.qxd 7/23/08 5:13 PM Page 24
Page 27 of 28
25
Spare tire & tools
Tool location
Removing the spare tire
(1) Remove the luggage cover.
(2) Loosen and remove the center fastener.
(3) Remove the spare tire cover.
Refer to the Owner’s Manual for tire changing and jack positioning
procedures.
Spare tire
Jack handle
Luggage floor cover
OVERVIEW
FEATURES/OPERATIONS
SAFETY AND EMERGENCY FEATURES
Jack
Spare tire cover
Wheel nut wrench
Trunk-Internal release
Pull
(1)(2)(3)
412714M1.qxd 7/22/08 3:33 PM Page 3
Page 28 of 28
MN 00505-QRG09-AVA
Printed in the USA 7/08
