TOYOTA AVALON 2010 XX30 / 3.G Navigation Manual

ADVANCED FUNCTIONS
99
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen. (a) Adding a preferred road
1. Select
the “Add” switch of the “Set
preferred road” and then the following
screen appears.
2. Move the cursor to your desired
location and push
“ENTER” button
on the navigation controller.
Messages appear to confirm your request
on the screen.
Select the
“Enter” switch to register the
road.
Select the
“Next” switch if you want to
change the road.
3. The “Add preferred road” screen
appears. Select the “Add” switch if
you want to add as preferred road.
Setting a preferred road

ADVANCED FUNCTIONS
100
(b) Modifying a preferred road
1. Select the “Modify” switch of the
“Set preferred road”. The “Modify pre-
ferred road” screen appears.
2. Select the preferred road which you
want to modify and select the
switch.
3. Do the same procedure as “(a) Add-
ing a preferred road”. (See page 99.) (c) Deleting a preferred road
1. Select the “Delete” switch of the
“Set preferred road”. The “Delete pre-
ferred road” screen appears.
2. Select the preferred road which you
want to delete.
Select the
“Del. all” switch if you want
to delete all the preferred roads.
3. Messages appear depending on the
type of deletion. If you want to delete,
select the
“Yes” switch. To cancel the
deletion, select the “No” switch.

ADVANCED FUNCTIONS
101
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen.
3. Select the “Search condition”switch of “Condition”. The “Search
condition” screen appears.
“Quick”: A route on which you can reach
the destination in the shortest time.
“Short”: A route on which you can reach
the destination in the shortest distance.
4. Select the
“Quick” or “Short”switch and select the “OK” switch.
Search condition

ADVANCED FUNCTIONS
102
You can see the entire route from the
starting point to the destination.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Route overview”switch on the screen. The route over-
view screen appears.
The entire route from the starting point to
the destination is displayed. You can preview the route from the
starting point to the destination.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Route preview”switch on the screen. The route preview
screen appears.
Route overviewRoute preview

ADVANCED FUNCTIONS
103
To display the next destination
To preview the route to the
next destination
To preview the route to the
next destination fast
To stop previewing
To preview the route to the
previous departure position
To preview the route to the
previous departure position
To display the previous de-
parture position
3. Select the “Edit” switch. The “Edit
route preview” screen appears.
“To next POI”: To preview the next POI
“To next
”: To preview the next destina-
tion
If the points of interest you selected are on
the route, they are displayed on the
screen.
“Select POI”: To select the POI icon
“Delete”: To delete the POI icon
4. Select your desired category of
point of interest.
5. Select your desired icon from the
list and select the “OK” switch.

ADVANCED FUNCTIONS
104

SECTION 3
MORE ADVANCED FUNCTIONS
105
MORE ADVANCED FUNCTIONS
Convenient features
Setup 106
 Map color 107
 Automatic rerouting 107
 Time to destination 108
 Adjust time zone 110
 Distance 111
 Notify seasonal restrict 111
 Voice guide in all modes 112
 Current street name 113
 Maintenance information 114
 Dealer setting 117
 Calendar with memo 121
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MORE ADVANCED FUNCTIONS
106
You can set the values shown on the
“Setup” screen.
1. Select the “MENU” button on the
navigation controller.
2. Select the “Setup” switch to dis-
play the “Setup” menu screen. Select
items you want to set. Selected items
will be highlighted in green.
3. Select the “OK” switch on the
screen and then the previous screen
will be displayed. “Default”:
Select the
“Default” switch
on the right side of the screen. All of the
settings can be defaulted.
“Map color” (day or night): You can se-
lect your desired map color.
“Auto reroute”: You can set the system
will or will not automatically search for a
new route to the destination.
“Estimated travel time”: You can set to
display the time required to reach the des-
tination on the route guidance screen.
“Adjust time zone”: You can select your
desired time zone.
“Distance”: You can change
“km” or“miles” to display your desired units.
“Notify seasonal restrict”: You can se-
lect to notify or not to notify a seasonal re-
strict.
“Voice guide in all modes”: You can set
the voice guide in all modes or not.
“Current street name”: You can select to
show or not to show a current street name
on the map screen.
“Operation guide on map”: Display or
non−display of the operation guide on the
display can be selected.
Setup

MORE ADVANCED FUNCTIONS
107
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
3. Select your desired day and/or night
map color and then select the
“OK”
switch to return the map screen.
Select the
“Normal” switch to default
the map color.
Select the
“Auto” switch to select the
map color automatically.
When you select the
“Auto” switch, the
map color is changed in every three
month. When the “Auto reroute” feature is
turned on, the
system will automatical-
ly search for a new route to the destina-
tion if you leave the guidance route.
This feature does not operate while you
are driving on roads where the guid-
ance is not available.
To turn the “Auto reroute” mode on:
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
Map colorAutomatic rerouting

MORE ADVANCED FUNCTIONS
108
3. Select the “On” switch of “Auto re-
route”.
Selected switch is highlighted in green.
INFORMATION
If your vehicle leaves the guidance
route, the system searches for a new
route to the destination. The new
route may or may not take you back to
the previous route depending on how
far you are off the original guidance
route.
When the “Estimated travel time” fea-
ture is turned on, the time estimated to
reach the destination is displayed on
the route guidance screen.
To turn the “Estimated travel time”
mode on:
1. Push the “MENU” button on the
navigation controller.
Time to destination
