TOYOTA AVALON 2010 XX30 / 3.G Navigation Manual

ADVANCED FUNCTIONS
89
(d) Quick marked point registration
You can register your current position
or any points (See “Screen scroll-
ing”on page 57.) from the map screen.
1. Move the cursor
to the desired
point, and if you wish to register that
point, push the
“ENTER” button on
the navigation controller.
2. Select the “Mark” switch.
When you select the “Mark” switch, the
above screen appears for a few seconds,
and then the map screen will be displayed.
To change the icon or name, etc., see “(b)
Editing marked points” on page 86.
You can register up to 100 marked points.
If you attempt to register more than 100, a
message appears for confirmation.
If you want to register a new point, push the
“MENU” button on the navigation con-
troller to display the menu screen and se-
lect the
“Marked points” switch. De-
lete several old points by following the “(c)
Deleting marked points” on page 88.

ADVANCED FUNCTIONS
90
You can set up to 5 destinations before-
hand.
Push the “MENU” button on the navi-
gation controller.
(a) Registering preset destinations
1. Select the
“Marked points”switch.
2. Select the “Register” switch of
“Preset dest.”.
3. Select the 15 switch to register
the preset destination you want.
If you have already registered the preset
destination, you can overwrite on the pres-
ent registered destination.
4. Input the preset destination in the
same way as the destination inputs.
(See pages 22 through 38.)
Preset destinations

ADVANCED FUNCTIONS
91
(b) Editing preset destinations
1. Select the
“Marked points”switch.
2. Select the “Edit” switch of “Preset
dest.”.
3. Select the switch that you want
to edit.
You can change the name, location and
phone No. of the preset destination.
Select the
“Change” switch. (See
page 86.) (c) Deleting preset destinations
1. Select the
“Marked points”switch.
2. Select the “Delete” switch of “Pre-
set dest.”.
3. Select the preset destination that
you want to delete and select the
switch.
Messages appear depending on the type
of deletion. If you want to delete, select the
“Yes” switch. To cancel the deletion, se-
lect the “No” switch.

ADVANCED FUNCTIONS
92
Any areas you want to avoid due to traf-
fic jams, construction work or other
reasons can be registered as avoid
areas.
Push the “MENU” button on the navi-
gation controller and then select the
“Marked points” switch to display
the following screen.
INFORMATION
 Some areas and freeways may not
be able to be set as an avoid point.
 If the route calculation cannot be
made without running through the
area to avoid, a route passing
through the area to avoid may be
shown.
(a) Registering area to avoid
1. Select the
“Register” switch of
the “Area to avoid”.
2. Enter the location in the same way
as you input any destination or display
the map of the area you want to avoid.
(See pages 22 through 38.)
INFORMATION
Only 10 points can be registered as
area to avoid. If there are 10 points al-
ready registered, the message “Un-
able to register additional points. Per-
form operation again after deleting
unnecessary points.” appears on the
screen.
Area to avoid

ADVANCED FUNCTIONS
93
3. When any of the “detour gauge” at
the left side of the screen is selected, a
box appears around the cursor
. This
is to determine the area to avoid. Select
the “detour gauge” you desire.
When you push the
“ENTER” button on
the navigation controller , the message ap-
pears.
INFORMATION
When the above screen is displayed,
if the map scale is larger than
1/80,000, the message “Position can-
not be specified in this scale. Switch
to more detailed map.” appears on
the screen. Set the map scale, so that
it is more detailed than 1/80,000.
(b) Editing area to avoid
1. Select the
“Edit” switch of the
“Area to avoid” to display the “Edit area
to avoid” screen.
2. Select the area to avoid switch
you want to edit.
3. Select the “Name”, “Location” or
“Change area size” on this screen.

ADVANCED FUNCTIONS
94
CHANGING THE NAME
Select alphabet or numeral keys to in-
put the name.
After you finish your entry, select the
“OK” switch on the screen.
The previous screen will be displayed.
CHANGING THE LOCATION
Move the cursor to your desired point,
and push the
“ENTER” button of the
navigation controller.
CHANGING THE AREA SIZE
Select one of the “detour gau ge” on the left
side of this screen if you want to change
the area size. (c) Deleting area to avoid
1. Select the
“Delete” switch of the
“Area to avoid” to display the “Delete
area to avoid” screen.
2. Select the area you want to delete
from the list.
“Delete all”: All registered areas to avoid
in the system are deleted.
3. Messages appear depending on the
type of deletion. If you want to delete,
select the
“Yes” switch. To cancel the
deletion, select the “No” switch.

ADVANCED FUNCTIONS
95
The current vehicle position mark will
be automatically corrected while driv-
ing on reception of GPS signals. If your
vehicle cannot receive GPS signals,
you can correct the current position
mark manually.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Setup” switch.
3. Select the “Calib.” switch on the
right side of the screen.
The next screen appears.
4. Select the “Position/Direction”switch.
INFORMATION
For additional information on current
position accuracy, see “Limitations
of the navigation system” on page 59.
Current position calibration

ADVANCED FUNCTIONS
96
POSITION/DIRECTION CALIBRATION
1. Move the cursor mark to your de-
sired point by operating the select and
scroll lever of the n avigation controller.
Push the
“ENTER” button on the navi-
gation controller.
2. Operate the select and scroll lever
of the navigation controller, so that the
screen direction is facing to your de-
sired direction.
Push the
“ENTER” button on the navi-
gation controller, and then the map screen
will be displayed. TIRE CHANGE CALIBRATION
The tire change calibration function
should be used when the tires are re-
placed.
This will adjust for any possible
change in tire circumference from the
old tires to the new ones. If this proce-
dure is not performed when tires are re-
placed, the current vehicle position
mark may become incorrect.
To execute the fast distance tire calibration
procedure, select the
“Tire change”switch on the “Calibration” screen.
The message appears and the fast dis-
tance calibration is automatically started.
A few seconds later, the map screen will be
displayed.

ADVANCED FUNCTIONS
97
1. Push the “MENU” button on the
navigation controller.
2. Select the “Edit route” switch on
the screen. (a) Adding a destination
1. Select the “Add” switch of “Des-
tination”.
2. Input an additional destination in
the same way as the destination input.
(See page 18.)
3. The “Add destination” screen ap-
pears. Select the “Add” switch on the
right side of the screen that you want to
add as destination.
Edit route

ADVANCED FUNCTIONS
98
(b) Reordering a destination
1. Select the “Reorder” switch of
“Destination”.
2. Choose the destinations in the or-
der of arrival by selecting the
switch
on the left side of the screen.
After you finished selecting the destina-
tions, select the
“OK” switch.
The previous screen will be displayed. (c) Deleting a destination
1. Select the “Delete” switch of
“Destination”.
2. Select the switch of the destina-
tion that you want to delete.
Select the
“Del. all” switch if you want
to delete all destinations.
3. Messages appear depending on the
type of deletion. If you want to delete,
select the
“Yes” switch. To cancel the
deletion, select the “No” switch.
To delete a previous destination:
1. Push the
“MENU” button to dis-
play the “Menu” screen and select the
“Marked points” switch on the
screen.
2. Select the
“Del. prev. dest.”switch.
3. Do the same procedure as deleting
a destination.
