TOYOTA AVALON 2010 XX30 / 3.G Navigation Manual

BASIC FUNCTIONS
49
The system announces your approach to
the final destination.
1“Your destination is ahead.”
2“You have arrived at your des-tination. The route guidance is
now finished.”
INFORMATION
 Voice guidance may be made early
or delayed.
 If the system cannot determine the
current position correctly, you
may not hear voice guidance or
may not see the magnified inter-
section on the screen.
 If you did not hear voice guidance
command, push the
“MAP/
VOICE” button to hear it again.
If you register your home address be-
forehand, you can easily set the route
back to your home.
1. Push the “MENU” button on the
navigation controller.
2. Select the “Marked points”switch.
Registration of your home

BASIC FUNCTIONS
50
3. Select the “Reg. home” switch
for registering your home address.
If your home is already registered, the
“Reg. home” switch changes to the
“Delete home” switch.
You may register the location of your
home by some different methods: cur-
rent position, address, map location,
etc. Select your desired method from
the menu on the screen.
Input your home in the same way as the
destination input. (See page 38.) DELETING YOUR HOME
1. Push the “MENU” button on the
navigation controller to display the
“Menu” screen and select the
“Marked points” switch.
2. Select the “Delete home” switch.
The screen changes and displays the map
location of the home and a message. If you
are sure, select the
“Yes” switch. If not,
select the “No” switch.

BASIC FUNCTIONS
51
When you are driving while the route
guidance is operating, you can change
the route to detour around a section of
the route where a delay is caused by
road repairs, an accident, etc.
Select the “Chg. route” switch on the
right side of the screen if you encounter
a reason to divert from the selected
route.
This picture shows an example of how the
system would route you around a delay
caused by a traffic jam.
1 This part indicates the location where
traffic jam is occurring due to road re-
pairs or an accident.
2 These show the detour route sug-
gested by the system.
When you select the “Chg. route”switch, the screen changes to the “Change
route” screen that allows you to select the
distance you want to detour. Select one of
the numeral keys to start the detour pro-
cess. After detouring, the system returns
to the original guidance route.
“Whole route”: If you select this switch,
the system will calculate an entire new
route to the destination.
INFORMATION
 When your vehicle is on a freeway,
the detour distance selections are
5, 15 and 25 miles.
 The system may not be able to cal-
culate a detour route depending on
the selected distance and sur-
rounding road conditions.
“Search condition”: To change the con-
ditions of the searching route. (See page
101.)
“Quick”: A route on which you can reach
the destination in the shortest time.
“Short”: A route on which you can reach
the destination in the shortest distance.
“Alternative”: Other route.
Detour setting

BASIC FUNCTIONS
52
Points of interest such as gas stations
and restaurants can be displayed on
the map screen. You can also set their
location as a destination and use them
for route guidance.
To display a particular type of point of
interest on the screen, select the
“POI” switch on the map right side of
the screen.
A window with a limited choice of points of
interest will be displayed. When you select
your desired type of point of interest, icons
will appear on the map screen indicating
where the POI addresses are located.
“More”: If you cannot find your desired
point of interest on the limited choice
screen, select this switch. The screen then
displays the more “Point of Interest” listing
screen.
You can show up to 5 types of icons on the
screen.
When you select the point of interest type
from more list, the screen will display the
complete “Point of Interest” listing screen.
Selecting the “Delete” switch will delete
the last selected icon.
When you select a point of interest type
from either the limited list or the complete
list, the screen will display icons at those
locations on the map screen.
Displaying points of interest

BASIC FUNCTIONS
53
“Local POI list”: Select this switch while
selecting some categories of POI. The “Lo-
cal POI list” screen will appear with a list of
the points within 20 miles (32 km).
Sort by “Icon”: Select this switch to list
the points of interest in order of the type of
symbol.
Sort by “Dist”: Select this switch to list the
points of interest in order of the distance.
Sort by “Name”: Select this switch to list
the points of interest in alphabetical order.
“Route”: Select this switch to list the
points of interest on the route in order of the
distance.
To turn off the icons of the points of in-
terest on the map screen, select the
“POI off” switch on the screen “Show
POI icons”. Setting a POI as a destination
You can select one of the points of in-
terest icons on the map screen as a
destination and use it for a route guid-
ance.
1. Select the icon of the point of inter-
est that you want to set as a destination.
Operate
the select and scroll lever to move
the cursor
to your desired POI icon.
Then the icon “POI” is centered in the
screen and it overlaps with the cursor
.
2. Push the
“ENTER” button on the
navigation controller, and then the
switch menu appears.
3. Select the “Guide” switch.

BASIC FUNCTIONS
54
The name of the point of interest is dis-
played at the top of the screen. You can se-
lect the other POI icon on the displayed
map.
When you push the
“ENTER” button on
the navigation controller, the information
such as the name and address, etc. are
displayed.
4. If you set the point of interest as a
destination, select the
“Enter ”switch. If not, push the “BACK” but-
ton on the navigation controller, then
the previous screen returns.
When there are 2 screens displayed, se-
lect “Right screen” switch. You can
display the “Edit right screen”.
Select “Show POI icons”. POI icon is
displayed when the indicator next to the
is highlighted, and if not, the POI icon
is not displayed.

BASIC FUNCTIONS
55
You can change from the map screen to
a “Turn list” screen that displays the list
of the roads up to your destination. This
list can be used for a route guidance.
1. Push the “MENU” button on the
navigation controller.
2. Screen and select the “Route
overview” switch.
3. The screen will change to the “En-
tire route map” screen, push the “EN-
TER” button on the navigation con-
troller to display the menu switches.
And then select the
“Turn list”switch.
You can scroll through the list of roads.
However, not all road names in the route
may appear on the list. If a road changes
its name without requiring a turn (such as
on a street that runs through two or more
cities), the name change will not appear on
the list. The street name closest to the
starting point will be displayed with a mile-
age to the next turn.
These marks indicate the
direction which you
should turn at an
intersection.
Select the “Map” switch on the “T urn list”
screen of your desired point. The point
which you choose is displayed on the map
screen.
Turn list

BASIC FUNCTIONS
56
INFORMATION
The current vehicle position mark
appears at the bottom of the
screen next to the name of the
street you are driving on. The mark
does not move.
 If you leave the guidance route, the
name of the street you are on is not
shown on the list next to the cur-
rent vehicle position mark.
 If the road type you are on changes
between a highway, a main street
or a residential street (at an inter-
change or fork), it will appear on
the turn list.
 If a long route has been selected, it
may take a long time to display the
turn list.
 Push the
“MAP/VOICE” button
on the navigation controller to re-
turn to the map display with route
guidance.
The map scale can be changed by pushing
the zoom in/out buttons of the navigation
controller to the
“+” (zoom in) side or to
the “” (zoom out) side while the map is
displayed and while guiding as well. The
scale runs from 1/32nd of a mile to 128
miles. Push and release the zoom in/out
buttons to the
“+” side or “” side to
change the scale one step at a time. Push
and hold either button to zoom in or out
smoothly.
The map scale is displayed under the
North−up symbol or Heading −up symbol
at the top left of the screen.
Map scale

BASIC FUNCTIONS
57
If you wish to look at a different point on the
map other than your current vehicle posi-
tion, you can bring the desired point to the
center of the screen by using the scroll fea-
ture.
Move the cursor mark
to the point you
desire by operating the select and scroll le-
ver of the navigation controller. Push the
“ENTER” button on the navigation con-
troller, and select the
“Enter ” switch.
If you continue to hold the lever by your fin-
ger on the navigation controller, the map
will continue scrolling in that direction until
you lift your finger.
After scrolling the screen, the map remains
centered at the selected location until you
push the
“MAP/VOICE” button. The
current vehicle position mark will continue
to move along your actual route and may
move off the screen. When you push the
“MAP/VOICE” button, the current ve-
hicle position mark returns to the center of
the screen and the map moves as you pro-
ceed on your route.
INFORMATION
If you enter a destination using the
screen scrolling function, the road
nearest to the point you selected is
set as the destination. At this time, if
the nearest road is over 4 miles from
destination point, the system may not
be able to calculate a guidance route.
You can change the orientation of the map
from North −up to Heading −up.
Select the
or switch.
Northup screen
Headingup screen
Northup symbol
Regardless of the direction of vehicle trav-
el, the north is always up.
Headingup symbol
The direction of the vehicle travel is always
up. A red arrow indicates the North.
Screen scrollingOrientation of the map

BASIC FUNCTIONS
58
1. Push the “ENTER” button while
the map screen is displayed.
2. When the “Map orient” at the
right side of the screen is selected, the
orientation of the map screen is
switched between the Northup and
the Headingup. When there are 2 map
screens displayed, the Northup and
the Headingup of the left side map
screen is switched by this operation.
3. When there are 2 map screens dis-
played to switch the Northup/Head-
ingup of the right screen map, select
the
“Right screen” switch.
4. Select the “Map orient.” of the
“Edit right screen”, and then the North
up/Headingup of the right screen is
switched.
When 2 map screens are displayed, you
can set one as the North −up and the other
one as the Heading −up.
