TOYOTA AVALON 2012 XX40 / 4.G User Guide

11
Compass P. 380
Garage door opener switches P. 372
Inside rear view mirror P. 80
Personal light P. 348
Moon roof switch P. 88
Interior light P. 348
Vanity mirror P. 358
Personal light P. 348
Sun visor P. 357
SRS curtain shield airbag P. 106
A
: If equipped

12
B
Door lock switch P. 48
Window lock switch P. 85
Power window switches P. 85
Pictorial indexInterior

13
C
Cup holders P. 355
Ashtray P. 360
Seat heater/ventilator switch P. 363
Shift lock override button P. 503
Shift lever P. 161
Storage compartment P. 354
: If equipped

14
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch P. 178
P. 166
P. 182
Gauges and meters P. 169
Windshield wipers and
washer switch
P. 189
Glove box P. 350
Telescopic lock release
lever
P. 78
Parking brake pedal
P. 167
Tilt lock release lever P. 78
Driving position
memory switches

P. 63
Tire pressure warning reset switch(hidden under panel)
P. 422
Horn P. 168

15
Audio remote control switches P. 286
Engine (ignition) switch
(vehicles without smart key
system)
P. 158
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
A
B
Telephone switch P. 293
Engine (ignition) switch
(vehicles with smart key system)
P. 154
Climate remote control
switches
P. 236
Talk switch* P. 293
“DISP” switch P. 175
Cruise control switch P. 194

16
C
Pictorial indexInstrument panel
Emergency flashers P. 472
Clock P. 359
Air conditioning
system
P. 228
Audio system
Navigation system
*
P. 239
Rear window and outside rear
view mirror defoggers
P. 237

17
D
Rear sunshade switchP. 366
Glass breakage sensorP. 99
Fuel filler door opener P. 92
Trunk openerP. 54
Outside rear view mirror switches P. 82
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
VSC off switch P. 208

18
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustration may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.

19
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.
Installation of a mobile two-way radio system
As the installation of a mobile two-way radio system in your vehicle could
affect electronic systems such as the multiport fuel injection system/sequen-
tial multiport fuel injection system, electronic throttle control system, cruise
control system, vehicle stability control system, SRS airbag system and seat
belt pretensioner system, be sure to check with your Toyota dealer for pre-
cautionary measures or special instructions regarding installation.

20
Scrapping of your Toyota
The SRS airbag and seat belt pretensioner devices in your Toyota contain
explosive chemicals. If the vehicle is scrapped with the airbags and seat belt
pretensioners left as they are, this may cause an accident such as fire. Be
sure to have the systems of the SRS airbag and seat belt pretensioner
removed and disposed of by a qualified service shop or by your Toyota
dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These compo-
nents may include airbag, seat belt pretensioners, and wireless remote con-
trol batteries.
