engine TOYOTA AVALON 2014 XX40 / 4.G Navigation Manual

290
1. TOYOTA PARKING ASSIST MONITOR
The parking assist monitor displays the last-used parking mode first.
Perpendicular parking Parallel parking
 When the shift lever is shifted to the “R” position and any mode button (such as
“DEST” ) is pressed
The parking assist monitor is canceled, and the screen is switched to the mode of
the button that was pressed
SCREEN DISPLAY
The parking assist monitor screen will be displayed if the shift lever is shifted to the
“R” position while the power switch is in ON mode.
No.DisplayFunction
Display mode switch screen but-
tonSwitches the display mode.
Parking mode switch screen but-
tonSwitches the parking mode (between perpendic-
ular parking and parallel parking assist screens)
Narrow mode screen on-off but-
tonSwitch the narrow mode on and off. ( P.293)
CANCELING TOYOTA PARKING ASSIST MONITOR
The parking assist monitor is canceled when the shift lever is shifted into any posi-
tion other than the “R” position.

303
1. TOYOTA PARKING ASSIST MONITOR
9
PERIPHERAL MONITORING SYSTEM
10When the vehicle is parallel with the
road or the shoulder, straighten the
steering wheel.
Check your surroundings visually and
with the mirrors, then back up using the
distance guide lines as a reference,
and stop.
When the vehicle is approximately in the
desired parking location, the parallel park-
ing assist is complete.
1Touch .
The steering wheel has been turned too
far, and the system cannot function.
Return the steering wheel to its original
position.
 If the message is displayed before the out-
line is positioned over the desired parking
space, it is likely that the vehicle is too far
away from the shoulder. Check that there
is a gap of approximately 3 ft. (1 m)
between your vehicle and the parked vehi-
cle.
 Normal mode
Narrow mode
If the engine switch is turned off when the
parking assist monitor is canceled with
narrow mode, the caution screen is dis-
played first when the parallel parking
assist is selected next time.
INFORMATION
● There is a possibility that parallel parking
guidance may not be given when back-
ing up at a very slow speed.
● If the trunk is opened, the parallel park-
ing assist will be discontinued halfway.
CANCELING PARALLEL
PARKING ASSIST
IF THE MESSAGE “Steering
wheel turned too far, please
return.” IS DISPLAYED
NARROW MODE
If the position the vehicle is to be
parked in is narrower than usual, nar-
row mode can be used.

327
Open source license
This product uses the following open
source software.
· T-Kernel
This Product uses the Source Code of
T-Kernel under T-License granted by
the T-Engine Forum
(www.t-engine.org
).
· C Library
This product includes software
developed by the University of
California, Berkeley and its
contributors. This product includes
software developed by the University
of California, Lawrence Berkeley
Laboratory.
Copyright © 1982, 1985, 1993 The
Regents of the University of California.
All rights reserved.
Copyright © 1982, 1986, 1993 The
Regents of the University of California.
All rights reserved.
Copyright © 1982, 1986, 1989, 1993
The Regents of the University of
California. All rights reserved.
© UNIX System Laboratories, Inc. All
or some portions of this file are derived
from material licensed to the
University of California by American
Telephone and Telegraph Co. or Unix
System Laboratories, Inc. and are
reproduced herein with the permission
of UNIX System Laboratories, Inc.
Copyright © 1982, 1986, 1991, 1993,
1994 The Regents of the University of
California. All rights reserved.
© UNIX System Laboratories, Inc. All
or some portions of this file are derived
from material licensed to the
University of California by American
Telephone and Telegraph Co. or Unix
System Laboratories, Inc. and are
reproduced herein with the permission
of UNIX System Laboratories, Inc.
Copyright © 1983, 1990, 1993 The
Regents of the University of California.
All rights reserved.
© UNIX System Laboratories, Inc. All
or some portions of this file are derived
from material licensed to the
University of California by American
Telephone and Telegraph Co. or Unix
System Laboratories, Inc. and are
reproduced herein with the permission
of UNIX System Laboratories, Inc.
Copyright © 1983, 1993 The Regents
of the University of California. All rights
reserved.
Copyright © 1987, 1991, 1993 The
Regents of the University of California.
All rights reserved.
Copyright © 1987, 1993 The Regents
of the University of California. All rights
reserved.
Copyright © 1988 Regents of the
University of California. All rights
reserved.
Copyright © 1988 University of Utah.
Copyright © 1992, 1993 The Regents
of the University of California. All rights
reserved. This code is derived from
software contributed to Berkeley by
the Systems Programming Group of
the University of Utah Computer
Science Department and Ralph
Campbell.

329
This software was developed by the
Computer Systems Engineering group
at Lawrence Berkeley Laboratory
under DARPA contract BG 91-66 and
contributed to Berkeley. All advertising
materials mentioning features or use of
this software must display the following
acknowledgement: This product
includes software developed by the
University of California, Lawrence
Berkeley Laboratory.
Copyright © 1992, 1993 The Regents
of the University of California. All rights
reserved.
This code is derived from software
contributed to Berkeley by Ralph
Campbell. This file is derived from the
MIPS RISC Architecture book by Gerry
Kane.
Copyright © 1993 The Regents of the
University of California. All rights
reserved.
Copyright © 1994 The Regents of the
University of California. All rights
reserved.
This code is derived from software
contributed to Berkeley by Andrew
Hume of AT&T Bell Laboratories.
Redistribution and use in source and
binary forms, with or without
modification, are permitted provided
that the following conditions are met:1. Redistributions of source code must
retain the above copyright notice, this
list of conditions and the following
disclaimer.
2. Redistributions in binary form must
reproduce the above copyright notice,
this list of conditio ns and the following
disclaimer in the documentation and/or
other materials provided with the
distribution.
3. All advertising materials mentioning
features or use of this software must
display the following
acknowledgement: This product
includes software developed by the
University of California, Berkeley and
its contributors.
4. Neither the name of the University
nor the names of its contributors may
be used to endorse or promote
products derived from this software
without specific prior written
permission.
