4977-2. Steps to take in an emergency
7
When trouble arises
After stopping the hybrid system and waiting for 5 minutes or
more, start the hybrid system again and check for the multi-infor-
mation display.
If the message does not disappear:
Stop the hybrid system and contact your Toyota dealer.
If the message is not displayed:
The hybrid system temperature has dropped and the vehicle
may be driven normally.
However, if the message appears again frequently, contact your To y o t a
dealer.
WARNING
■To prevent an accident or injury when inspecting under the hood of
your vehicle
Observe the following precautions.
<00290044004c004f005800550048000300570052000300470052000300560052000300500044005c00030055004800560058004f00570003004c00510003005600480055004c0052005800560003004c0051004d00580055005c0003005600580046004b00
03004400560003004500580055005100560011[
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot.
●After the hybrid system has been turned off, check that the “READY” indi-
cator is off. When the hybrid system is operating, the gasoline engine may
automatically start, or the cooling fan may suddenly operate even if the
gasoline engine stops. Do not touch or approach rotating parts such as the
fan, which may lead to fingers or clothing (especially a tie, a scarf or a muf-
fler) getting caught, resulting in serious injury.
●Do not loosen the radiator cap and the coolant reservoir cap while the
hybrid system and radiator are hot.
High temperature steam or coolant could spray out.
NOTICE
■When adding engine/power control unit coolant
Wait until the hybrid system has cooled down before adding engine/power
control unit coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot hybrid sys-
tem too quickly can cause damage to the hybrid system.
■To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
●Do not use any coolant additives.
6

5058-1. Specifications
8
Vehicle specifications
*: The engine oil capacity is a reference quantity to be used when changing
the engine oil. Warm up the engine and turn off the hybrid system, wait
more than 5 minutes, and check the oil level on the dipstick.
■
Engine oil selection
“Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use
Toyota approved “Toyota Genuine Motor Oil” or equivalent to sat-
isfy the following grade and viscosity.
Oil grade: API SN/RC multigrade engine oil
Recommended viscosity: SAE 0W-16
SAE 0W-16 is the best choice for
good fuel economy and good start-
ing in cold weather.
If SAE 0W-16 is not available, SAE
0W-20 oil may be used. However,
it must be replaced with SAE 0W-
16 at the next oil change.
Oil viscosity (0W-16 is explained here as an example):
• The 0W in 0W-16 indicates the characteristic of the oil which allows cold
startability. Oils with a lower value before the W allow for easier starting of
the engine in cold weather.
• The 16 in 0W-16 indicates the viscosity characteristic of the oil when the
oil is at high temperature. An oil with a higher viscosity (one with a higher
value) may be better suited if the vehicle is operated at high speeds, or
under extreme load conditions.
Lubrication system
Oil capacity
(Drain and refill ―
reference
*)
With filter
Without filter
4.8 qt. (4.5 L, 4.0 Imp. qt.)
4.4 qt. (4.2 L, 3.7 Imp. qt.)
Outside temperature

548Alphabetical index
Engine
ACCESSORY mode ............. 197
Compartment ........................ 403
Engine switch........................ 196
Hood ..................................... 401
How to start the hybrid
system ................................ 196
Identification number ............ 503
If your vehicle has to be
stopped in an
emergency.......................... 449
Ignition switch
(power switch) .................... 196
Overheating .......................... 494
Power switch......................... 196
Engine coolant
Capacity ................................ 506
Checking ............................... 407
Preparing and checking
before winter....................... 333
Engine coolant temperature
gauge........................................ 98
Engine oil
Capacity ................................ 505
Checking ............................... 404
Preparing and checking
before winter....................... 333
Engine switch .......................... 196
Enhanced VSC ......................... 323
EPS
(Electric Power Steering)...... 324
Warning light ......................... 457
EV drive mode.......................... 202
Event data recorder
(EDR) ........................................ 10
Exclusive jump starting
terminal .................................. 487Flat tire ..................................... 471
Floor mats .................................. 24
Fluid
Brake .................................... 507
Hybrid transmission .............. 507
Washer ................................. 410
Front interior light ................... 353
Front passenger occupant
classification system .............. 48
Front passenger’s seat belt
reminder light ........................ 458
Front personal lights............... 353
Front seat heaters ................... 349
Front seats ............................... 155
Adjustment............................ 155
Cleaning ............................... 389
Correct driving posture ........... 26
Driving position memory ....... 159
Head restraints ..................... 164
Power easy access
system ................................ 159
Seat heaters ......................... 349
Seat ventilators ..................... 349
Front side marker lights
Light switch ........................... 218
Replacing light bulbs ............ 445
Front turn signal lights
Replacing light bulbs ............ 445
Turn signal lever ................... 211
Fuel
Capacity................................ 504
Fuel gauge.............................. 98
Information............................ 510
Refueling .............................. 230
Type.............................. 504, 510
Warning light......................... 458
Fuel consumption ........... 106, 131
Fuel filler door ......................... 230
If the fuel filler door
cannot be opened .............. 234
Refueling .............................. 230
Fuses ........................................ 442F

552Alphabetical index
Navigation system*
Noise from under vehicle............ 6
Odometer.................................... 98
Oil
Engine oil .............................. 505
Opener
Fuel filler door ....................... 233
Hood ..................................... 401
Trunk..................................... 144
Outside rear view mirrors ....... 170
Adjusting and folding ............ 170
Blind spot monitor (BSM) ...... 276
Linked mirror function
when reversing ................... 171
Mirror position memory ......... 159
Outside rear view mirror
defoggers ........................... 343
Outside temperature
display ...................................... 98
Overheating, Hybrid
system .................................... 494Paddle shift switches .............. 208
Panic mode .............................. 135
Panoramic view monitor*
Parking brake........................... 212
Parking brake engaged
warning buzzer/
message............................. 215
Warning light......................... 456
Parking lights........................... 218
Light switch ........................... 218
Replacing light bulbs ............ 445
PCS (Pre-Collision
System) .................................. 242
Warning light......................... 457
Personal lights......................... 353
Power control unit ..................... 79
Power control unit coolant ..... 407
Capacity................................ 506
Checking............................... 407
Preparing and checking
before winter ...................... 333
Power outlet ............................. 363
Power steering
(Electric power steering
system) .................................. 324
Warning light......................... 457
Power switch ........................... 196
Power windows ....................... 173
Door lock linked window
operation ............................ 175
Jam protection function ........ 173
Operation .............................. 173
Window lock switch .............. 173
Pre-Collision System
(PCS) ...................................... 242
Warning light......................... 457
Premium Audio
*
N
O
P

559Alphabetical index
Warning lights............................ 93
ABS....................................... 456
Brake hold operated
indicator .............................. 457
Brake Override System......... 456
Brake system ........................ 455
Charging system ................... 455
Drive-Start Control ................ 456
Driver’s seat belt
reminder ............................. 458
Electric power steering ......... 457
Front passenger’s
seat belt reminder............... 458
High coolant temperature ..... 455
ICS OFF indicator ................. 457
LDA indicator ........................ 457
Low engine oil pressure ........ 455
Low fuel level ........................ 458
Malfunction indicator lamp .... 456
Master warning light.............. 458
Parking brake indicator ......... 456
PCS warning light ................. 457
Rear passengers’
seat belt reminder light ....... 458
Seat belt reminder light ......... 458
Slip indicator ......................... 458
SRS ...................................... 456
Tire pressure......................... 458
Warning messages .................. 465Washer ..................................... 226
Checking............................... 410
Preparing and checking
before winter ...................... 333
Switch ................................... 226
Washing and waxing ............... 386
Weight ...................................... 502
Cargo capacity...................... 193
Load limits ............................ 193
Vehicle capacity weight ........ 502
Wheels ...................................... 430
Replacing.............................. 430
Size....................................... 508
Window glasses ...................... 173
Window lock switch ................ 173
Windows................................... 173
Power windows..................... 173
Rear window defogger.......... 343
Washer ................................. 226
Windshield wipers ................... 226
Winter driving tips ................... 333
Wireless charger ..................... 366
Wireless remote control ......... 134
Battery-Saving Function ....... 150
Locking/Unlocking ........ 138, 145
Panic mode........................... 135
Replacing the battery............ 439
