TOYOTA BZ4X 2023 Owners Manual

4116-1. Using the air conditioning system and defogger
Owners Manual_USA_M42C01_en
6
Interior features
■Electronic key battery depletion
 P. 1 6 2
■When the electronic key bat-
tery is fully depleted
 P. 4 9 7
■Customization
Setting (e.g. Operation using “A/C”
on the wireless remote control) can
be changed. (Customizable fea-
tures: P.575)*: If equipped
WARNING
■Precautions for the Remote
Air Conditioning System
●Do not use the system if people
are in the vehicle.
Even when the system is in use,
the internal temperature may
still reach a high or low level
due to features such as the
automatic shut-off. Children and
pets left inside the vehicle may
suffer heatstroke dehydration or
hypothermia, or could result in
death or serious injury.
●Depending on the surrounding
environment, signals from the
wireless switch may transmit
further than expected. Pay
appropriate attention to the
vehicle’s surroundings and use
the switch only when necessary.
●Do not operate “A/C” if the hood
is open. The air conditioning
may operate unintentionally and
objects may be drawn into the
electrical cooling fan.
NOTICE
■To prevent the traction bat-
tery from being discharged
through incorrect operation
Use “A/C” only when necessary.
Heated steering
wheel*/seat heat-
ers*/seat ventila-
tors*/radiant heater*
 Heated steering wheel
Warms up the grip of the
steering wheel
 Seat heaters
Warm up the seat upholstery
 Seat ventilators
Maintain good airflow on the
seat upholstery by sucking air
into the seats
 Radiant heaters
Warm up the feet of the front
seats
WARNING
■To prevent minor burn inju-
ries
Care should be taken if anyone in
the following categories comes in
contact with the steering wheel or
seats when the heater is on:
●Babies, small children, the
elderly, the sick and the physi-
cally challenged
●Persons with sensitive skin
●Persons who are fatigued
●Persons who have taken alco-
hol or drugs that induce sleep
(sleeping drugs, cold remedies,
etc.)

4126-1. Using the air conditioning system and defogger
Owners Manual_USA_M42C01_en
Turns the heated steering wheel
on/off
Each time the switch is pressed,
the operation condition changes as
follows.
AUTO (lit)  Hi (2 segments lit) 
Lo (1 segment lit)  Off
The AUTO indicator and/or level
indicator illuminates during
operation.
■The heated steering wheel can
be used when
The power swit ch is in ON.
■Front
Turns the seat heaters on/off
Each time the switch is pressed,
the operation condition changes as
follows.
AUTO (lit)  Hi (3 segments lit) 
Mid (2 segments lit)  Lo (1 seg-
ment lit)  Off
The AUTO indicator and/or level
indicator illuminates during
operation.
■Rear (outboard rear seats)
Each time the switch is pressed,
the operation condition changes
as follows.
Hi (3 segments lit)  Mid (2
segments lit)  Lo (1 segment
lit)  Off
When not in use, put the switch
in the neutral position. The indi-
cator will turn off.
NOTICE
■To prevent damage to the
seat heaters and seat ventila-
tors
Do not put heavy objects that
have an uneven surface on the
seat and do not stick sharp
objects (needles, nails, etc.) into
the seat.
■To prevent 12-volt battery dis-
charge
Do not use the functions when the
EV system is off.
Heated steering wheel
Seat heaters

4136-1. Using the air conditioning system and defogger
Owners Manual_USA_M42C01_en
6
Interior features
■The seat heaters can be used
when
The power swit ch is in ON.
Turns the seat ventilators on/off
Each time the switch is pressed,
the operation condition changes as
follows.
AUTO (lit)  Hi (3 segments lit) 
Mid (2 segments lit)  Lo (1 seg-
ment lit)  Off
The AUTO indicator and/or level
indicator illuminates during
operation.
■The seat ventilators can be
used when
The power switch is in ON.
■Air conditioning system-linked
control mode
When the seat ventilator fan speed
level is Hi, the seat ventilator fan
speed becomes higher according to
the fan speed of the air conditioning
system.
Front passenger’s side radi-
ant heater
Driver’s side radiant heater
Turns the radiant heater on/off
Each time the switch is pressed,
the operation condition changes as
WARNING
■To prevent causes of over-
heating and minor burn inju-
ries
Observe the following precautions
when using a seat heater
●Do not cover the seat with a
blanket or cushion when using
the seat heater.
●Do not use seat heater more
than necessary.
Seat ventilators (front
seats)
Radiant heaters

4146-1. Using the air conditioning system and defogger
Owners Manual_USA_M42C01_enfollows.
Hi (3 segments lit) 
Mid (2 seg-
ments lit)  Lo (1 segment lit) 
Off
The level indicator illuminates
during operation.
■The radiant heater can be used
when
The power swit ch is in ON.
●The power may be turned off auto-
matically be continually touching
the heater section. In that case,
turn the radiant heater switch on
again.
●It may take some time for the
heater temperature to rise.
WARNING
■To prevent causes of over-
heating and minor burn inju-
ries
Observe the following precautions
when using a radiant heater
●Do not use radia nt heater more
than necessary.
●Do not let blank ets, cushions,
luggage, etc., to touch the radi-
ant heater. Do not use.
■Use while driving
Do not touch the radiant heater or
hold your hand or foot over it by
releasing a hand from the handle
or a foot from the pedal.
Doing so may cause the driver to
mishandle the vehicle and cause
an accident, resulting in death or
serious injury.
NOTICE
■To prevent damage to the
radiant heater
Do not pierce with uneven objects
or sharp objects such as wires or
needles.

4156-2. Using the interior lights
Owners Manual_USA_M42C01_en
6
Interior features
6-2.Using the interior lights
Outer foot lights (if equipped)
Inside door handle lights (if equipped)
Rear interior light ( P.416)
Footwell lights (if equipped)
Front interior lights/personal lights ( P.416, 417)
Shift lights
Auxiliary box lights (if equipped)/Wireless charger tray lights (if
equipped)
Center console light (if equipped)
Door trim ornament lights (if equipped)
■Personal lights/interior lights
automatic on/off
●Illuminated entry system: The
lights automatically turn on/off
according to power switch mode, the presence of the electronic key,
whether the doors are
locked/unlocked, and whether the
doors are opened/closed.
●If the interior
lights remain on
when the power switch is turned
Interior lights list
Location of the i nterior lights

4166-2. Using the interior lights
Owners Manual_USA_M42C01_enoff, the lights will go off automati-
cally after 20 minutes.
■The interior lights will turn on
automatically when
If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the interior lights will
turn on automatically. The interior
lights will turn off automatically after
approximately 20 minutes.
The interior lights can be turned off
manually. However, in order to help
prevent further collisions, it is rec-
ommended that they be left on until
safety can be ensured.
(The interior lights may not turn on
automatically depending on the
force of the impact and conditions of
the collision.)
■Customization
Setting (e.g. the time elapsed before
the lights turn off) can be changed.
(Customizable features: P.575)
■Front interior lights
1 Turns the door-linked func-
tion off
2 Turns the door-linked func-
tion on (door position)
The lights turn on/off according to
the opening/closing of the doors.
3Turns the lights on/off
Press the switch to turn on/off the
front interior lights/personal lights
and rear interior lights.
■Rear interior light
1 Turns the light on
2 Turns the door-linked func-
tion on (door position)
The light turns on/off according to
NOTICE
■To prevent 12-volt battery dis-
charge
Do not leave the lights on longer
than necessary when the EV sys-
tem is off.
Operating interior lights

4176-2. Using the interior lights
Owners Manual_USA_M42C01_en
6
Interior features
the opening/closing of the doors.
The rear interior light turn on/off
together the front interior light.
Turns the lights on/off
Operating personal lights

4186-3. Using the storage features
Owners Manual_USA_M42C01_en
6-3.Using the storage features
Bottle holders (P.420)
Card holders ( P.420)
Cup holders ( P.419)
Auxiliary box (if equipped) ( P.420)
Console box ( P.419)
Open tray ( P.420)
List of storage features
Location of the storage features
WARNING
■Items that should not be left
in the vehicle
Do not leave glasses, lighters or
spray cans in the storage spaces,
as this may cau se the following
when cabin temperature becomes
high:
●Glasses may be deformed by
heat or cracked if they come
into contact with other stored
items.
●Lighters or spray cans may
explode. If they come into con-
tact with other stored items, the
lighter may catch fire or the
spray can may release gas,
causing a fire hazard.

4196-3. Using the storage features
Owners Manual_USA_M42C01_en
6
Interior features
1 Slide the lid as backward.
2 Lift the lid while pulling the
lever to release the lock.
■Console box lid
The lid can be slide forward/back-
ward.
■Tray within console box
The tray can be removed by lifting
the tray it out.
■Front
Slide the lid as backward.
■Rear
Pull down the armrest.
Console box
WARNING
■Caution while driving
Keep the console box closed.
Injuries may result in the event of
an accident or sudden braking.
NOTICE
■To prevent damage to the
console box
Do not apply excessive force to
the armrest.
Cup holders
WARNING
■Items unsuitable for the cup
holders
Do not place anyth ing other than
cups or aluminum cans in the cup
holders.
Other items may be thrown out of
the holders in the event of an
accident or sudden braking, caus-
ing injury. If possible, cover hot
drinks to pre vent burns.

4206-3. Using the storage features
Owners Manual_USA_M42C01_en
■Front
■Rear
■Bottle holders
●When storing a bottle, close the
cap.
●The bottle may not be stored
depending on its size or shape.
Flip down the visor.Press the lid to open the auxil-
iary box.
Bottle holders
NOTICE
■Items that should be not
stowed in the bottle holders
Do not place open bottles or glass
and paper cups containing liquid
in the bottle holders. The contents
may spill and glasses may break.
Card holders
Auxiliary box (Vehicles
without wireless charger)
Open tray
