Page 4 of 516
TABLE OF CONTENTS4
C-HR_OM_USA_OM10526U5-1. Using the air conditioning
system and defogger
Air conditioning system ..... 290
Seat heaters ...................... 298
5-2. Using the interior lights Interior lights list ................ 300• Interior lights ................. 301
• Personal lights .............. 302
5-3. Using the storage features
List of storage features...... 303 • Glove box...................... 304
• Console box .................. 304
• Bottle holders ................ 305
• Cup holders .................. 306
Luggage compartment features ........................... 307
5-4. Using the other interior features
Other interior features ....... 313 • Sun visors ..................... 313
• Vanity mirrors................ 313
• Clock ............................. 314
• Power outlet .................. 315
• Assist grips ................... 316
• Steering wheel audio switches ........................ 317
• Using the
microphone ................... 318 6-1. Maintenance and care
Cleaning and protecting the vehicle exterior .......... 320
Cleaning and protecting the vehicle interior ........... 324
6-2. Maintenance Maintenance requirements ................... 327
General maintenance ........ 330
Emission inspection and maintenance (I/M)
programs ......................... 334
6-3. Do-it-yourself maintenance Do-it-yourself service precautions ...................... 335
Hood .................................. 338
Positioning a floor jack....... 340
Engine compartment ......... 341
Tires................................... 353
Tire inflation pressure ........ 363
Wheels............................... 367
Air conditioning filter .......... 370
Wireless remote control/electronic key
battery ............................. 373
Checking and replacing fuses ................................ 377
Light bulbs ......................... 381
5Interior features6Maintenance and care
Page 17 of 516
17Pictorial index
C-HR_OM_USA_OM10526UMeter control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
Vehicle-to-vehicle distance switch . . . . . . . . . . . . . . . . . . . . P. 236
LDA (Lane Departure Alert
with steering control) switch . . . . . . . . . . . . . . . . . . . . . . . . P. 229
Cruise control switch
Dynamic radar cruise control with full-speed range . . . . . . . . . P. 236
Talk switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 317
Telephone switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 317
Audio remote control switches . . . . . . . . . . . . . . . . . . . . . . P. 317
Page 104 of 516
1043-1. Key information
C-HR_OM_USA_OM10526U
NOTICE
■To prevent key damage
● Do not drop the keys, subject them to strong shocks, or bend them.
● Do not expose the keys to high temperatures for long periods of time.
● Do not get the keys wet or wash them in an ultrasonic washer, etc.
● Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.
● Do not disassemble the keys.
● Do not attach a sticker or anything else to the surface of the electronic key
and key (with a wireless remote control function).
● Vehicles with a smart key system: Do not place the keys near objects that
produce magnetic fields, such as TVs, audio systems and induction cook-
ers, or medical electrical equipment, such as low-frequency therapy equip-
ment.
■ Carrying the electronic key on your person (vehicles with a smart key
system)
Carry the electronic key 3.9 in. (10 cm) or more away from electric appli-
ances that are turned on. Radio waves emitted from electric appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.
■ In case of a smart key system malfunction or other key-related prob-
lems (vehicles with a smart key system)
Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.
■ When an electronic key is lost (vehicles with a smart key system)
If the electronic key remains lost, the risk of vehicle theft increases signifi-
cantly. Visit your Toyota dealer immediately with all remaining electronic
keys that was provided with your vehicle.
Page 121 of 516
1213-2. Opening, closing and locking the doors
3
Operation of each component
C-HR_OM_USA_OM10526U■
Conditions affecting operation
The smart key system uses weak radio waves. In the following situations, the
communication between the electronic key and the vehicle may be affected,
preventing the smart key system, wireless remote control and engine immobi-
lizer system from operating properly. (Ways of coping: →P. 436)
● When the electronic key battery is depleted
● Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise
● When carrying a portable radio, cellular phone, cordless phone or other
wireless communication device
● When the electronic key is in contact with, or is covered by the following
metallic objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
● When other wireless keys (that emit radio waves) are being used nearby
● When carrying the electronic key together with the following devices that
emit radio waves
• Portable radio, cellular phone, cordless phone or other wireless commu-
nication devices
• Another electronic key or a wireless key that emits radio waves
• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems
● If window tint with a metallic content or metallic objects are attached to the
rear window
● When the electronic key is placed near a battery charger or electronic
devices
● When parking at a meter
Page 166 of 516
1664-2. Driving procedures
C-HR_OM_USA_OM10526U
Stop the vehicle.
Set the parking brake (→P. 178), and shift the shift lever to P.
If the parking brake is in automatic mode, the parking brake is set automat-
ically when shifting the shift lever to P. ( →P. 177)
Press the engine switch.
Release the brake pedal and check that “ACCESSORY” on the
multi-information display is off.
Modes can be changed by pressing the engine switch with brake
pedal released. (The mode changes ea ch time the switch is pressed.)
Off
*
The emergency flashers can be
used.
The multi-information display will
not be displayed.
ACCESSORY mode
Some electrical components such
as the audio system can be used.
“ACCESSORY” will be displayed
on the multi-information display.
IGNITION ON mode
All electrical components can be
used.
“IGNITION ON” will be displayed on the multi-information display.
*: If the shift lever is in a position other than P when turning off the engine, the engine switch will be turned to ACCESSORY mode, not to off.
Stopping the engine
Changing engine switch modes
1
2
3
4
IGNITION ONACCESSORY
Page 232 of 516
2324-5. Using the driving support systems
C-HR_OM_USA_OM10526U■
Temporary cancellation of functions
When operation conditions are no longer met, a function may be temporarily\
canceled. However, when the operation conditions are met again, operation
of the function is automatically restored. (→P. 231)
■ Steering control function
Depending on the vehicle speed, lane departure situation, road conditions,
etc., the operation of the functions may not be recognized or the function may
not operate at all.
■ Lane departure alert function
The warning buzzer may be difficult to hear due to external noise, audio play-
back, etc.
■ Hands off steering wheel alert
When the system determines that the driver has removed their hands from
the steering wheel while the steering control function is operating, a warning
message is displayed on the multi-information display and the buzzer
sounds.
■ White (yellow) lines are only on one side of road
The LDA system will not operate for the side on which white (yellow) lines
could not be recognized.
■ Conditions in which functions may not operate properly
In the following situations, the camera sensor may not detect white (yellow)
lines and various functions may not operate normally.
●There are shadows on the road that run parallel with, or cover, the white
(yellow) lines.
● The vehicle is driven in an area without white (yellow) lines, such as in front
of a tollgate or checkpoint, or at an intersection, etc.
● The white (yellow) lines are cracked, “Botts’ dots”, “Raised pavement
marker” or stones are present.
● The white (yellow) lines cannot be seen or are difficult to see due to sand,
etc.
Page 255 of 516
2554-5. Using the driving support systems
4
Driving
C-HR_OM_USA_OM10526U
Press “<” or “>” of the meter contro l switches, select .
Press “ ∧” or “ ∨” of the meter control switches, select .
Press “ ∧” or “ ∨” of the meter control switches, select or
.
■ The outside rear view mirror indicators visibility
When under strong sunlight, the outside rear view mirror indicator may be dif-
ficult to see.
■ Hearing the RCTA buzzer
The RCTA buzzer may be difficult to hear over loud noises, such as if the
audio system volume is high.
■ When “Blind Spot Moni tor Unavailable.” is shown on the multi-informa-
tion display
Water, snow mud, etc., may be built up in the vicinity of the sensor area of
bumper ( →P. 257).
Removing the water, snow, mud, etc., from the vicinity of the sensor area
bumper should return it to normal.
Also, the sensor may not function normally when used in extremely hot or
cold weather.
■ When “Blind Spot Monitor System Ma lfunction Visit Your Dealer.” is
shown on the multi- information display
There may be a sensor malfunction or misaligned. Have the vehicle
inspected by your Toyota dealer.
Turning the BSM function/RCTA function on/off
1
2
3
Page 289 of 516
289
5Interior features
C-HR_OM_USA_OM10526U5-1. Using the air conditioning
system and defogger
Air conditioning system ..... 290
Seat heaters ...................... 298
5-2. Using the interior lights Interior lights list ................ 300• Interior lights ................. 301
• Personal lights .............. 302 5-3. Using the storage
features
List of storage features ..... 303 • Glove box...................... 304
• Console box .................. 304
• Bottle holders ................ 305
• Cup holders .................. 306
Luggage compartment features ........................... 307
5-4. Using the other interior features
Other interior features ....... 313 • Sun visors ..................... 313
• Vanity mirrors................ 313
• Clock ............................. 314
• Power outlet .................. 315
• Assist grips ................... 316
• Steering wheel
audio switches .............. 317
• Using the
microphone ................... 318
Page 317 of 516
3175-4. Using the other interior features
5
Interior features
C-HR_OM_USA_OM10526U
Some audio features (audio volume control, radio, CD player, etc.)
can be controlled using the swit ches on the steering wheel.
For more information, please re fer to the “TOYOTA Audio System
Owner’s Manual” or “TOYOTA Navigation System Owner’s Manual”.
Steering wheel audio switches
WARNING
To reduce the risk of an accident, exercise care when operating the audio
switches on the steering wheel.
Page 318 of 516
3185-4. Using the other interior features
C-HR_OM_USA_OM10526U
The microphone can be used for the voice command in the
Bluetooth® audio system or the hands-free phone system.
For more information, please re fer to the “TOYOTA Audio System
Owner’s Manual” or “TOYOTA Navigation System Owner’s Manual”.
Using the microphone
