C-HR_OM_USA_OM10526UFor your information....................... 6
Reading this manual .................... 10
How to search .............................. 11
Pictorial index .............................. 12
1-1. For safe use
Before driving ...................... 22
For safety drive ................... 24
Seat belts ............................ 26
SRS airbags ........................ 32
Front passenger occupant classification system ......... 46
Exhaust gas precautions ..... 53
1-2. Child safety Riding with children ............. 54
Child restraint systems ........ 55
1-3. Theft deterrent system Engine immobilizer system............................... 74
Theft prevention labels (U.S.A.) ............................. 76
2. Instrument cluster Warning lights and indicators........................... 78
Gauges and meters............. 86
Multi-information display ..... 89 3-1. Key information
Keys..................................... 98
3-2. Opening, closing and locking the doors
Side doors ......................... 105
Back door .......................... 112
Smart key system .............. 118
3-3. Adjusting the seats Front seats......................... 127
Rear seats ......................... 128
Head restraints .................. 130
3-4. Adjusting the steering wheel and mirrors
Steering wheel ................... 133
Inside rear view mirror ....... 135
Outside rear view mirrors ............................. 137
3-5. Opening and closing the windows
Power windows.................. 140
1For safety and security
2Instrument cluster
3Operation of each
component

3
1
8 7 5 4
3
2
9
C-HR_OM_USA_OM10526U
6
4-1. Before drivingDriving the vehicle ............. 146
Cargo and luggage............ 156
Vehicle load limits ............. 159
Trailer towing..................... 160
Dinghy towing.................... 161
4-2. Driving procedures Engine (ignition) switch (vehicles without
a smart key system) ........ 162
Engine (ignition) switch (vehicles with
a smart key system) ........ 165
Continuously variable transmission .................... 171
Turn signal lever................ 176
Parking brake .................... 177
Brake Hold ........................ 182
4-3. Operating the lights and wipers
Headlight switch ................ 185
Automatic High Beam ....... 190
Windshield wipers and washer ............................ 195
Rear window wiper and washer ............................ 198 4-4. Refueling
Opening the fuel tank cap................................... 200
4-5. Using the driving support systems
Toyota Safety Sense P ...... 204
PCS (Pre-Collision System) ........................... 211
LDA (Lane Departure Alert with steering
control) ............................ 226
Dynamic radar cruise control with full-speed
range ............................... 236
Driving mode select ........... 251
BSM (Blind Spot Monitor)......... 253
• BSM function ................. 258
• RCTA function ............... 263
Rear view monitor system ............................. 268
Driving assist systems ....... 279
4-6. Driving tips Winter driving tips .............. 285
4Driving

5
1
8 7 5 4
3
2
9
C-HR_OM_USA_OM10526U
6
7-1. Essential informationEmergency flashers .......... 396
If your vehicle has to be stopped in
an emergency ................. 397
7-2. Steps to take in an emergency
If your vehicle needs to be towed ..................... 399
If you think something is wrong .............................. 406
Fuel pump shut off system............................. 407
If a warning light turns on or a warning buzzer
sounds ............................ 408
If a warning message is displayed ......................... 418
If you have a flat tire .......... 423
If the engine will not start ................................. 434
If the electronic key does not operate
properly (vehicles with
a smart key system) ........ 436
If the vehicle battery is discharged ...................... 439
If your vehicle overheats ........................ 443
If the vehicle becomes stuck................................ 446 8-1. Specifications
Maintenance data (fuel, oil level, etc.) .......... 450
Fuel information ................. 458
Tire information.................. 461
8-2. Customization Customizable features ....... 474
8-3. Items to initialize Items to initialize ................ 482
Reporting safety defects for U.S. owners ........................ 484
Seat belt instructions for Canadian owners
(in French)................................ 485
SRS airbag instructions for Canadian owners
(in French)................................ 487
What to do if... (Troubleshooting) ..................... 498
Alphabetical index ...................... 502
7When trouble arises8Vehicle specifications
9For owners
Index

15Pictorial index
C-HR_OM_USA_OM10526UMulti-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 89
If a warning messages or indicator is displayed . . . . . . . . . . . P. 418
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 176
Headlight switch
Headlights/front parking lights/tail lights/
daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 185
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . P. 195
Rear window wiper and washer switch . . . . . . . . . . . . . . . . P. 198
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 195, 198
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 352
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 396
Hood lock release lever. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 338
Tilt and telescopic steering lock release lever . . . . . . . . . . P. 133
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 290
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 293
Seat heaters
*3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 298
*1: Vehicles without a smart key system
*2: Vehicles with a smart key system
*3: If equipped

381-1. For safe use
C-HR_OM_USA_OM10526U
WARNING
■SRS airbag precautions
● Do not attach anything to or lean any-
thing against areas such as the dash-
board, steering wheel pad and lower
portion of the instrument panel.
These items can become projectiles
when the SRS driver, front passenger
and driver’s knee airbag deploy.
● Do not attach anything to areas such as
the door, windshield, side window, front
or rear pillar, roof side rail and assist
grip.
● Vehicles without a smart key system:
Do not attach any heavy, sharp or hard
objects such as keys and accessories
to the key. The objects may restrict the
SRS driver’s knee airbag inflation or be
thrust into the driver's seat area by the
force of the deploying airbag, thus caus-
ing a danger.

741-3. Theft deterrent system
C-HR_OM_USA_OM10526U
Engine immobilizer system
Vehicles without a smart key sys-
tem:
The indicator light flashes after
the key has been removed from
the engine switch to indicate that
the system is operating.
The indicator light stops flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.
Vehicles with a smart key system:
The indicator light flashes after the engine switch has been turned off
to indicate that the system is operating.
The indicator light stops flashing after the engine switch has been
turned to ACCESSORY or IGNITION ON mode to indicate that the
system has been canceled.
The vehicle’s keys have built-in transponder chips that prevent
the engine from starting if a key has not been previously regis-
tered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehi-
cle.
This system is designed to help prevent vehicle theft but does
not guarantee absolute security against all vehicle thefts.

802. Instrument cluster
C-HR_OM_USA_OM10526U
*1: These lights turn on when the engine switch is turned to the “ON” position(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
*2: The light comes on to indicate a malfunction.
*3: The light flashes to indicate a malfunction.
*3Parking brake indicator (U.S.A.) P. 410
*3Parking brake indicator (Canada) P. 410
Low fuel level warning light P. 411
Driver’s and front passenger’s seat belt
reminder lightP. 4 1 1
Rear passengers’ seat belt reminder lights (on
the center panel)
P. 4 1 1
*1Tire pressure warning light
P. 411
*1Master warning lightP. 412
Warning lightsPages

822. Instrument cluster
C-HR_OM_USA_OM10526U
*1: These lights turn on when the engine switch is turned to the “ON” position(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
*2: In order to confirm operation, the BS M outside rear view mirror indicators
illuminate in the following situations:
• When the engine switch is turned to the “ON” position (vehicles without a smart key system) or IGNITION ON mode (vehicles with a smart key
system), the BSM function is enabled on the screen of the multi-
information display.
• When the BSM function is enabled on the screen of the multi- information display, the engine switch is turned to the “ON” position
(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system).
If the system is functioning correctly, the BSM outside rear view mirror indi-
cators will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not
turn off, there may be a malfunction in the system.
If this occurs, have the vehicle inspected by your Toyota dealer.
*3: The light flashes to indicate that the system is operating.
*4: The light turns on when the system is off.
*1VSC off indicator P. 280
*1, 4PCS warning light (if equipped) P. 215
*1“AIR BAG ON/OFF” indicator (on the center
panel) (if equipped) P. 4 6
IndicatorsPages

832. Instrument cluster
2
Instrument cluster
C-HR_OM_USA_OM10526U
*: These lights turn on when the engine switch is turned to the “ON” position(vehicles without a smart key system) or IGNITION ON mode (vehicles
with a smart key system) to indicate that a system check is being per-
formed. They will turn off after the engine is started, or after a few seconds.
There may be a malfunction in a system if a light does not come on, or if
the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
Indicators and symbols displaye d on the multi-information dis-
play
IndicatorsPages
*Brake hold operated indicator P. 182
*Brake hold standby indicatorP. 182
LDA indicator P. 230
Cruise control indicator P. 236
Cruise control “SET” indicator P. 236
Radar cruise control indicator P. 236
“SPORT” indicator P. 251
“ECO MODE” indicator P. 251
Eco Driving Indicator Light P. 85
Low outside temperature indicator P. 86

842. Instrument cluster
C-HR_OM_USA_OM10526U
Symbols on multi-information displayPages
Charging system warning light P. 408
Low engine oil pressure warning light P. 408
High engine coolant temperature warning light P. 411
Smart key system (if equipped) P. 165
Brake Override System/Drive-Start Control P. 412
