TOYOTA C-HR 2020 Owners Manual (in English)

3115-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10634U
List of storage features
Glove box ( P. 3 1 2 )
Bottle holders ( P. 3 1 3 ) Cup holders (
P. 314)
Console box ( P. 312)
WARNING
●Do not leave glasses, lighters or spray cans in the storage spa ces, as this
may cause the following when cabin temperature becomes high:
• Glasses may be deformed by heat or cracked if they come into c ontact
with other stored items.
• Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may r elease
gas, causing a fire hazard.
● When driving or when the storage compartments are not in use, k eep the
lids closed and trays clear.
In the event of sudden braking or sudden swerving, an accident may occur
due to an occupant being struck by an open lid or the items sto red inside.

3125-3. Using the storage features
C-HR_OM_USA_OM10634U
Press the button to open the glove
box.
The glove box light turns on when the tail lights are on.
Lift the lid while pulling up the
knob.
Glove box
Console box
When closing the lid, pass the wire of the
electronic device through the location
indicated in the illustration.
After closing the lid, check that the wiring
of the device does not interfere with the
lid.

3135-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10634U
●When storing a bottle, close the cap.
● The bottle may not be stored depending on its size or shape.
Bottle holders
FrontRear
WARNING
Do not place anything other than a bottle in the bottle holders .
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury.
NOTICE
Put the cap on before stowing a bottle. Do not place open bottl es in the bot-
tle holders, or glass or paper cups containing liquid. The cont ents may spill
and glass cups may break.

3145-3. Using the storage features
C-HR_OM_USA_OM10634U
Cup holders
The rear cup holder can have the partition
turned over, removed, and the depth
changed.
WARNING
●Do not place anything other than cups or aluminum cans in the cup hold-
ers.
Other items may be thrown out of the holders in the event of an accident or
sudden braking, causing injury.
● Observe the following precautions.
Failure to do so may result in serious injury such as burns.
• Close the lid on drinks that are hot.
• Check that the item can be sustained by the internal support.
• Take care to not let the cup height exceed armrest height.
• Do not use the partition in the front cup holder as it is only for use with
the rear cup holder.

3155-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10634U
Luggage compartment features
Cargo hooks are provided for
securing loose items.
Cargo hooks
WARNING
To avoid injury, always return the cargo hooks to their positio ns when they
are not in use.
Grocery bag hooks
NOTICE
Do not hang any object heavier than 4.4 lb. (2 kg) on the groce ry bag hook.

3165-3. Using the storage features
C-HR_OM_USA_OM10634U
Lift the deck mat tab and pull it
toward you to remove it.
Auxiliary boxes
Side auxiliary boxes

3175-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10634U
Hard type
Unhook the cords and return
the luggage cover to horizontal
position.
Ty p e A
Pull it toward you and then lift
the luggage cover to remove
it.
Installation position
Confirm that the cover has
been securely installed to the
original position when install-
ing.
Removal position
Ty p e B
Lift the luggage cover and
pull it toward you to remove
it.
Confirm that the cover has been
securely installed to the original
position when installing.
Luggage cover
1
2
2

3185-3. Using the storage features
C-HR_OM_USA_OM10634U
Soft type
■Removing the luggage cover
Unhook the cords.
Unhook the hook to the hook
brackets.
■Stowing the luggage cover
Hold the luggage cover with
both hands. Point your
thumbs in opposite direc-
tions.
1
2
1

3195-3. Using the storage features
5
Interior features
C-HR_OM_USA_OM10634U
Bend one side of the cover
towards you.
Twist the other side in the
opposite direction, as shown
in the illustration.
Make a small circle, then fold
it inward.
Make sure the three circles
are side by side.2
3
4
5

3205-3. Using the storage features
C-HR_OM_USA_OM10634U
Make sure the luggage cover
is properly folded.6
WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.
●Do not place anything on the luggage cover. In the event of sudden brak-
ing or turning, the item may go flying and strike an occupant.
● Do not allow children to climb on the luggage cover. Climbing o n the lug-
gage cover could result in damage to the luggage cover.
● Soft type luggage cover only: Be sure to properly fold the luggage cover.
Otherwise it could unexpectedly unfold.
● Soft type luggage cover only: Be sure to attach the cords correctly to pre-
vent the cover from flying off.
NOTICE
Soft type luggage cover only: Do not apply too much force when folding the
luggage cover. Doing so may damage the luggage cover.
