3626-3. Do-it-yourself maintenance
C-HR_OM_USA_OM10634U
Tires
Check if the treadwear indicators are showing on the tires. Also check
the tires for uneven wear, such as excessive wear on one side o f the
tread.
Check the spare tire condition and pressure if not rotated.
New tread
Worn tread
Treadwear indicator
The location of treadwear indicators is shown by a “TWI” or “” mark,
etc., molded into the s idewall of each tire.
Replace the tires if the treadwear indicators are showing on a tire.
Rotate the tires in the order
shown.
To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.
Replace or rotate tires in accordance with maintenance sched-
ules and treadwear.
Checking tires
Tire rotation
Front

4377-2. Steps to take in an emergency
7
When trouble arises
C-HR_OM_USA_OM10634U
Location of the spare tire, jack and tools
To w i n g e y e l e t
Wheel nut wrench
JackJack handle
Spare tire

4768-1. Specifications
C-HR_OM_USA_OM10634U
Tire size (P. 478)
DOT and Tire Identification Number (TIN) ( P. 4 7 7 )
Uniform tire quality grading
For details, see “Uniform Tire Q uality Grading” that follows.
Location of treadwear indicators ( P. 3 6 2 )
Tire ply composition and materials
Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the p lies in a tire.
Radial tires or bias-ply tires
A radial tire has “RADIAL” on the sidewall. A tire not marked “ RADIAL”
is a bias-ply tire.
TUBELESS or TUBE TYPE
A tubeless tire does not have a tube and air is directly put into the tire.
A tube type tire has a tube insi de the tire and the tube mainta ins the air
pressure.
Load limit at maximum cold tire inflation pressure ( P. 366)
Maximum cold tire in flation pressure (P. 470)
This means the press ure to which a tire may be inflated.
Summer tires or all season tires ( P. 3 6 6 )
An all season tire has “M+S” on the sidewall. A tire not marked “M+S”
is a summer tire.
“TEMPORARY USE ONLY”
A compact spare tire is identified by the phrase “TEMPORARY USE
ONLY” molded on its sidewall. This tire is designed for tempora ry
emergency use only.

531Alphabetical index
C-HR_OM_USA_OM10634U
Snow tires ................................ 292
Spare tire .................................. 436Inflation pressure .................. 470
Storage location .................... 437
Spark plug ................................ 468
Specifications .......................... 464
Speedometer .............................. 94
Sport mode............................... 267
Steering lock
Column lock release ..... 179, 184
Steering wheel ......................... 149
Adjustment ............................ 149
Audio switches
*
Meter control switches ............ 98
Telephone switches
*
“TRIP” switch .......................... 95
Stop lights ................................ 403
Storage feature ........................ 311
Stuck If the vehicle becomes
stuck ................................... 460
Sun visors ................................ 321 Switches
Audio remote control
switches
*
Automatic High Beam switch ................................. 207
Brake hold switch ................. 199
Cruise control switch ............ 252
Door lock switches................ 121
Emergency flashers switch ................................. 408
Engine switch ............... 178, 181
Fog light switch ..................... 212
Fuel filler door opener switch ................................. 220
Heated steering wheel .......... 306
Ignition switch ............... 178, 181
LDA (Lane Departure Alert) switch ................................. 245
Light switches ....................... 202
Meter control switches ............ 98
Outside rear view mirror switches ............................. 152
Parking brake switch ............ 194
Power door lock switch ......... 121
Power window switches........ 155
Rear window and outside rear view mirror
defoggers switch ................ 301
Seat heater switches ............ 306
Talk switch
*
Telephone switches*
“TRIP” switch .......................... 95
Vehicle-to-vehicle distance switch ................................. 252
VSC off switch ...................... 287
Window lock switch .............. 155
Windshield wiper and washer switch..................... 213
*: Refer to “MULTIMEDIA OWNER’S MANUAL”.
