1. AIR INLET CONTROL SERVO MOTOR OPERATION (FOR PUSH SW TYPE)
(SWITCHING FROM FRESH TO RECIRC)
WITH THE IGNITION SW ON, CURRENT FROM THE GAUGE FUSE FLOWS TO TERMINAL 1 OF THE SERVO MOTOR. WHEN THE
RECIRC SW IS TURNED ON, THE CURRENT FLOWS FROM SERVO MOTOR " TERMINAL 3 " TERMINAL 5 OF THE HEATER
CONTROL SW " TERMINAL 1 " GROUND, THE MOTOR ROTATES AND THE DAMPER MOVES TO THE RECIRC SIDE. WHEN IT IS IN
THE RECIRC POSITION, THE CIRCUIT IS CUT INSIDE THE SERVO MOTOR AND THE DAMPER STOPS IN THAT POSITION.
WHEN THE CIRCUIT FOR THE INDICATOR LIGHT, CURRENT FLOWS FROM THE GAUGE FUSE " TERMINAL 12 OF THE HEATER
CONTROL SW " INDICATOR LIGHT " TERMINAL 1 " GROUND AND THE INDICATOR LIGHT CONTINUES TO LIGHT UP WHILE THE
RECIRC SW IS ON.
(SWITCHING FROM RECIRC TO FRESH)
WHEN THE IGNITION IS ON AND THE FRESH SW IS TURNED ON, CURRENT FLOWS FROM TERMINAL 2 OF THE SERVO MOTOR "
TERMINAL 6 OF THE HEATER CONTROL SW " TERMINAL 1 " GROUND, THE MOTOR ROTATES AND THE DAMPER MOVES TO THE
FRESH SIDE. WHEN THE DAMPER IS IN THE FRESH POSITION, THE CIRCUIT IS CUT INSIDE THE SERVO MOTOR AND THE DAMPER
STOPS IN THAT POSITION.
2. OPERATION OF AIR VENT MODE CONTROL SERVO MOTOR
WHEN THE IGNITION SW ON, CURRENT FLOWS FROM THE GAUGE FUSE TO TERMINAL 12 OF THE HEATER CONTROL SW,
TERMINAL 6 OF THE AIR VENT MODE CONTROL SERVO MOTOR.
WHEN THE DAMPER IS IN FACE POSITION AND THE BI±LEVEL OF THE HEATER CONTROL SW IS THEN TURNED ON, CURRENT
FLOWS FROM TERMINAL 3 OF THE HEATER CONTROL SW " TERMINAL 4 OF THE AIR VENT MODE CONTROL SERVO MOTOR SO
THAT A SINGAL THAT THE GROUND CIRCUIT IS ACTIVATED IS INPUT TO TERMINAL ªBº OF THE CONTROL CIRCUIT INSIDE THE AIR
VENT MODE CONTROL SERVO MOTOR.
SIMULTANEOUSLY, A SIGNAL THAT THE GROUND CIRCUIT IS NOT ACTIVATED IS INPUT TO TERMINAL ªAº OF THE CONTROL
CIRCUIT INSIDE THE SERVO MOTOR. THESE TWO SIGNALS ACTIVATE THE CONTROL CIRCUIT SO THAT CURRENT FROM THE
GAUGE FUSE TO THE SERVO MOTOR, CAUSING THE SERVO MOTOR TO OPERATE AND THE DAMPER TO MOVE TO BI±LEVEL
POSITION. WHEN THE DAMPER REACHES BI±LEVEL POSITION, A GROUND CUT SIGNAL IS INPUT TO TERMINAL ªBº OF THE
CONTROL CIRCUIT, THE CONTROL CIRCUIT OPERATES, THE SERVO MOTOR STOPS ROTATING AND THE DAMPER STOPS AT
BI±LEVEL.
WHEN ANOTHER MODE POSITION IS SWITCHED TO, INPUT OF SIGNALS TO TERMINAL ªAº AND TERMINAL ªBº OF THE CONTROL
CIRCUIT THAT GROUND IS MADE OR GROUND IS NOT MADE (AS EXPLAINED ABOVE) ACTIAVTES THE CONTROL CIRCUIT AND
MOVES THE SERVO MOTOR TO THE DESIRED POSITION.
3. AIR CONDITIONING OPERATION
WHEN THE IGNITION SW ON, CURRENT FLOWS FROM GAUGE FUSE TO TERMINAL 12 OF THE HEATER CONTROL SW, TERMINAL 6
OF THE AIR VENT MODE CONTROL SERVO MOTOR.
WHEN THE BLOWER SW IS ON, CURRENT FLOWS FROM THE GAUGE FUSE " HEATER RELAY (COIL SIDE) " TERMINAL 7 OF THE
BLOWER SW " TERMINAL 5 " GROUND, ACTIVATING THE HEATER RELAY. THIS CAUSES CURRENT TO FLOW FROM THE HEATER
FUSE TO THE HEATER RELAY (POINT SIDE) " A/C FUSE " TERMINAL 7 OF THE HEATER CONTROL SW (A/C SW). IF THE HEATER
CONTROL (A/C SW) IS THEN TURNED ON AT THIS TIME, A SIGNAL IS INPUT TO THE A/C AMPLIFIRE. THIS ACTIVATES THE A/C
AMPLIFIER AND A/C MAGNETIC CLUTCH RELAY SO THAT CURRENT FLOWS FROM THE GAUGE FUSE TO THE A/C MAGNETIC
CLUTCH RELAY (POINT SIDE) " A/C MAGNETIC CLUTCH, CAUSING THE COMPRESSOR TO OPERATE. THE VSV (FOR A/C IDLE±UP)
IS TURNED ON SIMULTANEOUSLY TO PREVENT A DECREASE IN ENGINE SPEED DUE TO A/C OPERATION.
HEATER RELAY
(4)5± (4)4 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON
A/C MAGNETIC CLUTCH RELAY
(4)5± (4)3 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON AND A/C SW ON
A 2 A/C DUAL PRESSURE SW
1±4 : OPEN WITH PRESSURE 2.1 KG/CM (30 PSI, 206 KPA) OR ABOVE 27 KG/CM (384 PSI, 2646 KPA)
B 5 BLOWER RESISTOR
6±2 : APPROX. 1.12 W
2±3 : APPROX. 0.5 W
3±1 : APPROX. 0.2 W
SYSTEM OUTLINE
SERVICE HINTS

254
AIR CONDITIONING (LEVER CONTROL SW TYPE)
CURRENT ALWAYS FLOWS FROM THE HEATER FUSE TO TERMINAL 5 OF THE HEATER RELAY. WHEN THE IGNITION SW IS TURNED
ON, CURRENT FLOWS FROM GAUGE FUSE TO TERMINAL 2 OF THE AIR VENT MODE CONTROL SERVO MOTOR AND A/C MAGNETIC
CLUTCH RELAY (COIL SIDE) " TERMINAL 12 OF THE A/C AMPLIFIER, TERMINAL 1 OF THE A/C DUAL PRESSURE SW " TERMINAL 4
" TERMINAL 2 OF THE A/C AMPLIFIER, HEATER RELAY (COIL SIDE) " TERMINAL 3 OF THE BLOWER SW.
1. OPERATION OF AIR VENT MODE CONTROL SERVO MOTOR
WHEN THE DAMPER IS IN FACE POSITION AND THE BI±LEVEL OF THE AIR VENT MODE CONTROL SW IS THEN TURNED ON,
CURRENT FLOWS FROM TERMINAL 7 OF THE AIR VENT MODE CONTROL SW " TERMINAL 5 OF THE AIR VENT MODE CONTROL
SERVO MOTOR SO THAT A SIGNAL THAT THE GROUND CIRCUIT IS ACTIVATED IS INPUT TO TERMINAL ªBº OF THE CONTROL
CIRCUIT INSIDE THE AIR VENT MODE CONTROL SERVO MOTOR. SIMULTANEOUSLY, A SIGNAL THAT THE GROUND CIRCUIT IS NOT
ACTIVATED IS INPUT TO TERMINAL ªAº OF THE CONTROL CIRCUIT INSIDE THE SERVO MOTOR. THESE TWO SIGNALS ACTIVATE
THE CONTROL CIRCUIT SO THAT CURRENT FROM THE GAUGE FUSE TO THE SERVO MOTOR, CAUSING THE SERVO MOTOR TO
OPERATE AND THE DAMPER TO MOVE TO BI±LEVEL POSITION. WHEN THE DAMPER REACHES BI±LEVEL POSITION. A GROUND
CUT SIGNAL IS INPUT TO TERMINAL ªBº OF THE CONTROL CIRCUIT, THE CONTROL CIRCUIT OPERATES, THE SERVO MOTOR
STOPS ROTATING AND THE DAMPER STOPS AT BI±LEVEL.
WHEN ANOTHER MODE POSITION IS SWITCHED TO, INPUT OF SIGNALS TO TERMINAL ªAº AND TERMINAL ªBº OF THE CONTROL
CIRCUIT THAT GROUND IS NOT MADE (AS EXPLAINED ABOVE) ACTIVATES THE CONTROL CIRCUIT AND MOVES THE SERVO
MOTOR TO THE DESIRED POSITION.
2. AIR CONDITIONING OPERATION
WHEN THE BLOWER SW IS ON, CURRENT FLOWS THE GAUGE FUSE " HEATER RELAY (COIL SIDE) " TERMINAL 3 OF THE
BLOWER SW " TERMINAL 1 " GROUND, ACTIVATING THE HEATER RELAY. THIS CAUSES CURRENT TO FLOW FROM THE HEATER
FUSE TO THE HEATER RELAY (POINT SIDE) " A/C FUSE " TERMINAL 2 OF THE A/C SW. IF THE A/C SW IS THEN TURNED ON AT
THIS TIME. A SIGNAL IS INPUT TO THE A/C AMPLIFIER. THIS ACTIVATES THE A/C AMPLIFER AND A/C MAGNETIC CLUTCH RELAY SO
THAT CURRENT FLOWS FROM THE GAUGE FUSE TO THE A/C MAGNETIC CLUTCH RELAY (POINT SIDE) " A/C MAGNETIC CLUTCH.
CAUSING THE COMPRESSOR TO OPERATE. THE VSV (FOR A/C IDLE±UP) IS TURNED ON SIMULTANEOUSLY TO PREVENT A
DECREASE IN ENGINE SPEED DUE TO A/C OPERATION.
HEATER RELAY
(4)5± (4)4 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON
A/C MAGNETIC CLUTCH RELAY
(5)5± (5)3 : CLOSED WITH THE IGNITION SW ON AND BLOWER SW ON AND A/C SW ON
A 2 A/C DUAL PRESSURE SW
1±4 : OPEN WITH PRESSURE 2.1 KG/CM (30 PSI, 206 KPA) OR ABOVE 27 KG/CM (384 PSI, 2646 KPA)
B 5 BLOWER RESISTOR
6±1 : APPROX. 3.17 W
6±3 : APPROX. 1.38 W
2±6 : APPROX. 0.38 W
: PARTS LOCATION
CODESEE PAGECODESEE PAGECODESEE PAGE
A 228 (1MZ±FE), 30 (5S±FE)A1732H 833
A 328 (1MZ±FE), 30 (5S±FE)B 432I 230 (5S±FE)
A1032B 532J 133
A1132B 632
A1232C1432
: RELAY BLOCKS
CODESEE PAGERELAY BLOCKS (RELAY BLOCK LOCATION)
425R/B NO. 4 (RIGHT KICK PANEL)
526R/B NO. 5 (ENGINE COMPARTMENT LEFT)
: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODESEE PAGEJUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1B20COWL WIRE AND J/B NO 1 (INSTRUMENT PANEL LEFT)1D20COWL WIRE AND J/B NO. 1 (INSTRUMENT PANEL LEFT)
