throttle position sensor TOYOTA CAMRY 1994 XV10 / 4.G Wiring Diagrams Workshop Manual

29
Position of Parts in Engine Compartment
[1MZ±FE]
I 1 Idle Air Control Valve (ISC Valve) N 1 Noise Filter (for Ignition System)
I 2 Igniter
I 4 Injector No. 1 O 1 Oil Pressure SW
I 5 Injector No. 2 O 6 O/D Direct Clutch Speed Sensor
I 6 Injector No. 3
I 7 Injector No. 4 P 1 Park/Neutral Position SW (Neutral Start SW) (A/T)
I 8 Injector No. 5
I 9 Injector No. 6 S 1 Solenoid Valve (for Hydrauric Motor)
I 15 Igniter S 3 Starter
I 16 Ignition Coil No. 1 S 4Starter
I 17 Ignition Coil No. 2
I 18 Ignition Coil No. 3 T 1 Throttle Position Sensor
I 19 Ignition Coil No. 4
I 20 Ignition Coil No. 5 V 1 VSV (for A/C Idle±Up)
I 21 Ignition Coil No. 6 V 2 VSV (for EGR System)
V 3 VSV (for Fuel Pressure Up)
J 6 Junction Connector V 4 VSV (for Intake Air Control)
V 5 Vehicle Speed Sensor (Speed Sensor)
K 1 Knock Sensor 1
K 2 Knock Sensor 2 W 1 Washer Motor
W 2 Water Temp. Sender
M 6 Mass Air Flow (Air Flow Meter)

31
Position of Parts in Engine Compartment
[5S±FE]
H 1 Headlight Hi LH O 1 Oil Pressure SW
H 2 Headlight Hi RH O 2 Oxygen Sensor (Sub)
H 3 Headlight Lo LH O 3 Oxygen Sensor (Main)
H 4 Headlight Lo RH
H 5 Horn LH P 1 Park/Neutral Position SW (Neutral Start SW) (A/T)
H 6 Horn RH
R 1 Radiator Fan Motor
I 1 Idle Air Control Valve (ISC Valve)
I 2 Igniter S 3 Starter
I 3 Ignition Coil S 4Starter
I 4 Injector No. 1
I 5 Injector No. 2 T 1 Throttle Position Sensor
I 6 Injector No. 3
I 7 Injector No. 4 V 1 VSV (for A/C Idle±Up)
I 10 Intake Air Temp. Sensor (In±Air Temp. Sensor) V 2 VSV (for EGR System)
V 3 VSV (for Fuel Pressure Up)
K 1 Knock Sensor V 5 Vehicle Speed Sensor (Speed Sensor)
M 1 Manifold Absolute Pressure Sensor (Vacuum Sensor) W 1 Washer Motor
W 2 Water Temp. Sender
N 1 Noise Filter (for Ignition System)

78
ENGINE CONTROL (1MZ±FE)
THIS SYSTEM UTILIZES AN ENGINE CONTROL MODULE (ENGINE AND ELECTRONIC CONTROLLED TRANSMISSION ECU) AND
MAINTAINS OVERALL CONTROL OF THE ENGINE, TRANSMISSION AND SO ON. AN OUTLINE OF THE ENGINE CONTROL IS
EXPLAINED HERE.
1. INPUT SIGNALS
(1) ENGINE COOLANT TEMP. (WATER TEMP.) SIGNAL CIRCUIT
THE ENGINE COOLANT TEMP. SENSOR (WATER TEMP. SENSOR) DETECTS THE ENGINE COOLANT TEMP. AND HAS A
BUILT±IN THERMISTOR WITH A RESISTANCE WHICH VARIES ACCORDING TO THE WATER TEMP. IS INPUT INTO TERMINAL
THW OF ENGINE CONTROL MODULE (ECU) AS A CONTROL SIGNAL.
(2) INTAKE AIR TEMP. SIGNAL CIRCUIT
THE INTAKE AIR TEMP. SENSOR IS INSTALLED IN THE MASS AIR FLOW (AIR FLOW METER) AND DETECTS THE INTAKE AIR
TEMP., WHICH IS INPUT AS A CONTROL SIGNAL TO TERMINAL THA OF ENGINE CONTROL MODULE (ECU).
(3) OXYGEN SENSOR SIGNAL SYSTEM
THE OXYGEN DENSITY IN THE EXHAUST GASES IS DETECTED AND INPUT AS A CONTROL SIGNAL TO TERMINAL OXL, OXR
AND OXS OF THE ENGINE CONTROL MODULE (ECU). TO MAINTAIN STABLE DETECTION PERFORMANCE BY THE OXYGEN
SENSOR, A HEATER IS USED FOR WARMING THE SENSOR. THE HEATER IS ALSO CONTROLLED BY THE ENGINE CONTROL
MODULE (ECU) (HTL, HTR AND HTS).
(4) RPM SIGNAL SYSTEM
CAMSHAFT POSITION AND CRANKSHAFT POSITION ARE DETECTED BY THE CAMSHAFT POSITION SENSOR AND
CRANKSHAFT POSITION SENSOR. CRANKSHAFT POSITION IS INPUT AS A CONTROL SIGNAL TO TERMINAL G22+ OF THE
ENGINE CONTROL MODULE (ECU), AND ENGINE RPM IS INPUT TO TERMINAL NE+.
(5) THROTTLE SIGNAL CIRCUIT
THE THROTTLE POSITION SENSOR DETECTS THE THROTTLE VALVE OPENING ANGLE AS A CONTROL SIGNAL, WHICH IS
INPUT INTO TERMINAL VTA OF THE ENGINE CONTROL MODULE (ECU). WHEN THE VALVE IS COMPLETELY CLOSED, THE
CONTROL SIGNAL IS INPUT INTO TERMINAL IDL.
(6) VEHICLE SPEED SIGNAL SYSTEM
THE VEHICLE SPEED SENSOR (SPEED SENSOR), INSTALLED INSIDE THE COMBINATION METER, DETECTS THE VEHICLE
SPEED AND INPUTS A CONTROL SIGNAL TO TERMINAL SP1 OF THE ENGINE CONTROL MODULE (ECU).
(7) PARK/NEUTRAL POSITION SW (NEUTRAL START SW) SIGNAL SYSTEM
THE PARK/NEUTRAL POSITION SW (NEUTRAL START SW) DETECTS WHETHER THE SHIFT POSITION IS IN NEUTRAL OR
PARKING OR NOT, AND INPUTS A CONTROL SIGNAL TO TERMINAL NSW OF THE ENGINE CONTROL MODULE (ECU).
(8) A/C SW SIGNAL SYSTEM
THE A/C AMPLIFIER INPUTS THE A/C OPERATIONS TO TEMRINAL A/C OF THE ENGINE CONTROL MODULE (ECU) AS A
CONTROL SIGNAL.
(9) BATTERY SIGNAL CIRCUIT
VOLTAGE IS CONSTANTLY APPLIED TO TERMINAL BATT OF THE ENGINE CONTROL MODULE (ECU). WHEN THE IGNITION SW
TURNED ON, VOLTAGE FOR ENGINE CONTROL MODULE (ECU) START±UP POWER SUPPLY IS APPLIED TO TERMINALS +B
AND +B1 OF ENGINE CONTROL MODULE (ECU) VIA EFI MAIN RELAY.
(10) INTAKE AIR VOLUME SIGNAL CIRCUIT
INTAKE AIR VOLUME IS DETECTED BY THE MASS AIR FLOW (AIR FLOW METER) AND THE SIGNAL IS INPUT TO TERMINAL VG
OF THE ENGINE CONTROL MODULE (ECU). AS A CONTROL SIGNAL.
(11) STA SIGNAL CIRCUIT
TO CONFIRM WHETHER THE ENGINE IS CRANKING, THE VOLTAGE APPLIED TO THE STARTER MOTOR DURING CRANKING IS
DETECTED AND THE SIGNAL IS INPUT INTO TERMINAL STA OF THE ENGINE CONTROL MODULE (ECU) AS A CONTROL
SIGNAL.
(12) ENGINE KNOCK SIGNAL CIRCUIT
ENGINE KNOCKING IS DETECTED BY THE KNOCK SENSOR NO. 1 AND NO. 2 AND THE SIGNALS ARE INPUT INTO TERMINALS
KNKR AND KNKL AS A CONTROL SIGNAL.
SYSTEM OUTLINE

82
ENGINE CONTROL (1MZ±FE)
A A
I18 I18 I18
ED 1 2
4 53 1
1 432 7VG±
B 21THA
B 22E2
B 7VTA
A 32IDL
C 14THG
B 20THW
D 20A/C
A 34E02
A 28E03 B±O
B±OL±B
BR
G±R
BR BR
BRR±B
L±B
B±Y
L±W
B±Y
W±B
W±BG±B BR G±Y BR1B 15KNKR
EE1 3EE11
WWBR
ENGINE COOLANT TEMP. SENSOR
(
EFI WATER TEMP. SENSOR) E4 EGR GAS
TE MP. SE NSOR
THROTTLE
POSITION
SENSOR T1
MASS AIR FLOW
(
AIR FLOW METER) M6
FROM
A/C AMPLIFIER
KNOCK SENSOR 1 K1
D 5ACT
LG±R
TO
A/C AMPLIFIER E1
1 2D
ENGINE CONTROL MODULE(
ENGINE A ND E LE CTRONIC
CONTROLLED TRANSMISSION ECU) E7 ,E8 ,E9 , E10BC
(
SHIELDED) (
SHIELDED)
I18
L±W
W±BBR
BR
D 26
OXSD 25
HTS IQ1 4IQ15
II1 9 II110 II18
B±O
BR P±BB
P±B B
4 2
31+B E
OX HT
H9
HEATED OXYGEN SENSOR
(
BANK1 SENSOR2)
L±B
I18
B±O
BR (
SHIELDED)
(
SHIELDED)
(
SHIELDED)
+B VG± THA
E2 B 18FC
B 1VC
2
VGB 8VG
BR
B±O
L±RR G±R
L
FROM COOLING
FA N ECU
A 33E01
W±B
B±OR±L R±L 4 2
31+B E
OX HT
H12
HEATED OXYGEN SENSOR
(
BANK2 SENSOR1)
4 2
31+B E
OX HT
H11
HEATED OXYGEN SENSOR
(
BANK1 SENSOR1)
I18 I18
C 10 B 19 B 13 C11B±OB
I18 I18
A 7 B 7 B 6 B 5 B 4 B 3 B 2 B 1B8 E14 E14 E13
E13 E13 E12
A 29 A 30 A 26 A 15 A 16 A 24 A 12A 1 A 2 A 3 A 4 A 5 A 6 A 8 2 1
2 1
2 1
2 1
2 1
2 1
IGNITION
COIL NO. 1 I16
IGNITION
COIL NO. 2 I17
IGNITION
COIL NO. 3 I18
IGNITION
COIL NO. 4 I19
IGNITION
COIL NO. 5 I20
IGNITION
COIL NO. 6 I21
+B COIL1 COIL2 COIL3 COIL4
COIL5COIL6
TA CHGND
IGF IGT1 IGT2 IGT3 IGT4 IGT5 IGT6 IGF IGT1 IGT2 IGT3 IGT4 IGT5 IGT6
C IGNITER I2 , I15B
W±R
W±G
Y±R
GR±B
L±B
R±B
G±RL±B
GR
WB±O B±O
B±O
B±O
B±O
B
W±B G
LG±B
PB±O
B±O
B±O B±O B±O B±O B±O B±O
(
SHIELDED) (
SHIELDED)
(
SHIELDED) W W
L±B
R±LL±B
R±L
V±R
W±B
B±OBR B±OBR B±O
B±O B±O
R±L
OXR HTR OXL HTLW±BB±O

84
ENGINE CONTROL (1MZ±FE)
CIRCUIT OPENING RELAY2±1 : CLOSED WITH STARTER RUNNING OR MEASURING PLATE (VOLUME AIR FLOW (AIR FLOW METER)) OPEN
EFI MAIN RELAY2±4 : CLOSED WITH IGNITION SW AT ON OR ST POSITION
E 4
ENGINE COOLANT TEMP. SENSOR (EFI WATER TEMP. SENSOR) 1±2 : 10.0 ± 20.0 K (±20°C, ±4°F)
: 4.0 ± 7.0 K (0°C, 32°F)
: 2.0 ± 3.0 K (20°C, 68°F)
: 0.9 ± 1.3 K (40°C, 104°F)
: 0.4 ± 0.7 K (60°C, 140°F)
: 0.2 ± 0.4 K (80°C, 176°F)
E 7(A), E 8(B), E 9(C), E10(D)
ENGINE CONTROL MODULE (ENGINE AND ELECTRONIC CONTROLLED
TRANSMISSION ECU)
VOLTAGE AT ENGINE CONTROL MODULE (ECU) WIRING CONNECTOR
BATT ± E1: ALWAYS 9.0±14.0 VOLTS
+B ± E1:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
+B1 ± E1:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
IDL ± E1:9.0±14.0 VOLTS (IGNITION SW ON AND THROTTLE VALVE FULLY OPEN)
0±3.0 VOLTS (IGNITION SW ON AND THROTTLE VALVE FULLY CLOSED)
VC ± E1: ALWAYS 4.5±5.5 VOLTS (IGNITION SW AT ON POSITION)
VTA ± E1:0.3±0.8 VOLTS (IGNITION SW ON AND THROTTLE VALVE FULLY CLOSED)
3.2±4.9 VOLTS (IGNITION SW ON AND THROTTLE VALVE FULLY OPEN)
VG ± E1:4.0±5.5 VOLTS (IGNITION SW AT ON POSITION)
THA ± E1:0.5±3.4 VOLTS (IGNITION SW ON AND INTAKE AIR TEMP. 20°C, 68°F)
THW ± E1:0.2±1.0 VOLTS (ENGINE IDLING AND COOLANT TEMP. 80°C, 176°F)
#10, #20, #30, #40, #50, #60
± E01:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
PULSE GENERATION (ENGINE IDLING)
IGT1, IGT2, IGT3
IGT4, IGT5, IGT6 ± E1: PULSE GENERATION (ENGINE IDLING)
IGF ± E1:4.5±5.5 VOLTS (IGNITION SW AT ON POSITION)
PULSE GENERATION (ENGINE IDLING)
G22+ ± G±: PULSE GENERATION (ENGINE IDLING)
NE+ ± G±: PULSE GENERATION (ENGINE IDLING)
RSC, RSO ± E1: PULSE GENERATION (ENGINE IDLING AND A/C OPERATION)
OXS, OXL, OXR ± E1: PULSE GENERATION (MAINTAIN ENGINE SPEED AT 2500 RPM FOR TWO MINUTES AFTER WARMING UP)
HTS, HTL, HTR ± E01:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
0±3.0 VOLTS (ENGINE IDLING)
KNKL, KNLR ± E1: PULSE GENERATION (ENGINE IDLING)
NSW ± E1:9.0±14.0 VOLTS (IGNITION SW ON AND OTHER SHIFT POSITION IN P OR N POSITION)
BELOW 3.0 VOLTS (IGNITION SW ON AND SHIFT POSITION IN P OR N POSITION)
SP1 ± E1: PULSE GENERATION (IGNITION SW ON AND ROTATE DRIVING WHEEL SLOWLY)
TE1 ± E1:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
TE2 ± E1:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
W ± E1: BELOW 3.0 VOLTS (MULFUNCTION INDICATOR LAMP ON)
9.0±14.0 VOLTS (MULFUNCTION INDICATOR LAMP OFF AND ENGINE RUNNING)
A/C ± E1: BELOW 1.5 VOLTS (ENGINE IDLING AND A/C SW ON)
7.5±14.0 VOLTS (A/C SW OFF)
ACT ± E1:9.0±14.0 VOLTS (ENGINE IDLING AND A/C SW ON)
BELOW 1.5 VOLTS (A/C SW OFF)
ACIS ± E01:9.0±14.0 VOLTS (IGNITION SW AT ON POSITION)
STA ± E1:6.0 VOLTS OR MORE (ENGINE CRANKING)
I 4, I 5, I 6, I 7, I 8, I 9
INJECTOR1±2 : APPROX. 13.8
T 1
THROTTLE POSITION SENSOR3±1 :0.2±5.7 KWITH CLEARANCE BETWEEN LEVER AND STOP SCREW 0 MM (0 IN.)
2±1 : LESS THAN 2.3 KWITH CLEARANCE BETWEEN LEVER AND STOP SCREW 0.5 MM (0.020 IN.)
WITH CLEARANCE BETWEEN LEVER AND STOP SCREW 0.7 MM (0.0276 IN.)
3±1 :2.0±10.2 KWITH THROTTLE VALVE FULLY OPEN
SERVICE HINTS

88
ENGINE CONTROL (5S±FE)
THIS SYSTEM UTILIZES AN ENGINE CONTROL MODULE (ENGINE ECU (M/T), ENGINE AND ELECTRONIC CONTROLLED
TRANSMISSION ECU (A/T)) AND MAINTAINS OVERALL CONTROL OF THE ENGINE, TRANSMISSION AND SO ON. AN OUTLINE OF THE
ENGINE CONTROL IS EXPLAINED HERE.
1. INPUT SIGNALS
(1) ENGINE COOLANT TEMP. (WATER TEMP.) SIGNAL SYSTEM
THE ENGINE COOLANT TEMP. SENSOR (EFI WATER TEMP. SENSOR) DETECTS THE ENGINE COOLANT TEMP. AND HAS A
BUILT±IN THERMISTOR WITH A RESISTANCE WHICH VARIES ACCORDING TO THE ENGINE COOLANT TEMP. (WATER TEMP.)
THUS THE ENGINE COOLANT TEMP. (WATER TEMP.) IS INPUT IN THE FORM OF A CONTROL SIGNAL TO TERMINAL THW OF
THE ENGINE CONTROL MODULE (ECU).
(2) INTAKE AIR TEMP. SIGNAL SYSTEM
THE INTAKE AIR TEMP. SENSOR (IN±AIR TEMP. SENSOR) IS DETECTS THE INTAKE AIR TEMP., WHICH IS INPUT AS A
CONTROL SIGNAL TO TERMINAL THA OF THE ENGINE CONTROL MODULE (ECU).
(3) OXYGEN SENSOR SIGNAL SYSTEM
THE OXYGEN DENSITY IN THE EXHAUST GASES IS DETECTED AND INPUT AS A CONTROL SIGNAL TO TERMINAL OX1 AND
OX2 OF THE ENGINE CONTROL MODULE (ECU).
(4) RPM SIGNAL SYSTEM
CRANKSHAFT POSITION AND ENGINE RPM ARE DETECTED BY THE PICK±UP COIL INSTALLED INSIDE THE DISTRIBUTOR.
CRANKSHAFT POSITION IS INPUT AS A CONTROL SIGNAL TO TERMINALS G+ AND G2 (CALIFORNIA), OF THE ENGINE
CONTROL MODULE (ECU), AND RPM IS INPUT TO TERMINAL NE+.
(5) THROTTLE SIGNAL SYSTEM
THE THROTTLE POSITION SENSOR DETECTS THE THROTTLE VALVE OPENING ANGLE, WHICH IS INPUT AS A CONTROL
SIGNAL TO TERMINAL VTA OF THE ENGINE CONTROL MODULE (ECU), OR WHEN THE VALVE IS FULLY CLOSED, TO
TERMINAL IDL
(6) VEHICLE SPEED SIGNAL SYSTEM
THE VEHICLE SPEED SENSOR (SPEED SENSOR), INSTALLED INSIDE THE COMBINATION METER, DETECTS THE VEHICLE
SPEED AND INPUTS A CONTROL SIGNAL TO TERMINAL SPD OF THE ENGINE CONTROL MODULE (ECU).
(7) PARK/NEUTRAL POSITION SW (NEUTRAL START SW) SIGNAL SYSTEM (A/T)
THE PARK/NEUTRAL POSITION SW (NEUTRAL START SW) DETECTS WHETHER THE SHIFT POSITION ARE IN NEUTRAL AND
PARKING OR NOT, AND INPUTS A CONTROL SIGNAL TO TERMINAL NSW OF THE ENGINE CONTROL MODULE (ECU).
(8) A/C SW SIGNAL SYSTEM
THE A/C AMPLIFIER INPUTS THE A/C OPERATIONS TO TARMINAL ACA OF THE ENGINE CONTROL MODULE (ECU) AS A
CONTROL SIGNAL.
(9) BATTERY SIGNAL CIRCUIT
VOLTAGE IS CONSTANTLY APPLIED TO TERMINAL BATT OF THE ENGINE CONTROL MODULE (ECU). WHEN THE IGNITION SW
TURNED ON, THE VOLTAGE FOR ENGINE CONTROL MODULE (ECU) START±UP POWER SUPPLY IS APPLIED TO TERMINALS
+B AND +B1 OF ENGINE CONTROL MODULE (ECU) VIA EFI MAIN RELAY. THE CURRENT FLOWING THROUGH THE IGN FUSE
FLOWS TO TERMINAL IGSW OF THE ENGINE CONTROL MODULE (ECU).
(10) INTAKE AIR VOLUME SIGNAL SYSTEM
INTAKE AIR VOLUME IS DETECTED BY THE MANIFOLD ABSOLUTE PRESSURE SENSOR (VACUUM SENSOR) (FOR MANIFOLD
PRESSURE) AND IS INPUT AS A CONTROL SIGNAL TO TERMINAL PIM OF THE ENGINE CONTROL MODULE (ECU).
(11) STA SIGNAL CIRCUIT
TO CONFIRM WHETHER THE ENGINE IS CRANKING, THE VOLTAGE APPLIED TO THE STARTER MOTOR DURING CRANKING IS
DETECTED AND THE SIGNAL IS INPUT INTO TERMINAL STA OF THE ENGINE CONTROL MODULE (ECU) AS A CONTROL
SIGNAL.
(12) ENGINE KNOCK SIGNAL CIRCUIT
ENGINE KNOCKING IS DETECTED BY KNOCK SENSOR AND THE SIGNAL IS INPUT INTO TERMINAL KNK AS A CONTROL
SIGNAL.
(13) ELECTRICAL LOAD SIGNAL SYSTEM
THE SIGNAL WHEN SYSTEMS SUCH AS THE REAR WINDOW DEFOGGER, HEADLIGHTS, ETC. WHICH CAUSE A HIGH
ELECTRICAL BURDEN ARE ON IS INPUT TO TERMINAL ELS AS A CONTROL SIGNAL.
SYSTEM OUTLINE

91
*
2 : EX. CALIFORNIA
* 4 : FOR CANADA IN TMM MADE * 1 : CALIFORNIA
* 5 : EX. * 4
B C
I18B 11 B 1B12
R
B
L R
VC VTA IDL
THROTTLE POSITION
SENSOR T11 2
1 2
1 2 E20
E20
E18 E17 E17 1234
2 3
32 112
A 13 A2C 18 C 17 C 5 C 4
B 2 A
4B3B10 B16 B9 PIM THW THA THG E21 E2 NE NE±(
*2)
G± G+B B± O W±R W±R
B±O
B± O
BR BR BR
B±Y
BR BR
BR
BR
BR
BRGR L±BLGB±R G G
W± R W±R
R
L
B
Y
B±O
D6
I3
D2
E7 ,E8 , E10 +B1 ELSW± R
NE+ NE± G± G+(
*2)
VC E2PIM
(
*2)
M1
E4
I10
E1
MANIFOLD ABSOLUTE
PRESSURE SENSOR
(
VACUUM SENSOR)
ENGINE COOLANT TEMP. SENSOR
(
EFI WATER TEMP. SENSOR)
INTAKE AIR TEMP. SENSOR
(
IN±AIR TEMP. SENSOR)
EGR GAS TEMP.
SENSOR
ENGINE CONTROL MODULE(
ENGINE AND ELECTRONIC CONTROLLED TRANSMISSION ECU)(
A/T)
B
DIODE
(
FOR IDLE±UP)
IGNITION COIL
DISTRIBUTOR FROM
I18 E18
4321BR
BR I18
L
L FROM CRUISE
CONTROL ECU 1
P
E19
C 3C20 534
12
W± R
WBW±R
B
W±R
(
SHIELDED)
IGF IGT COIL± +B IG±
IGF IGTIGNITER I2
TO TACHOMETER
[COMB. METER]
C 8
FPU 1 2 B±O
(
*1)
B±O
(
*1) B±RV3
VSV
(
FOR PRESSURE UP)
1342G2(
*1)
(
*1)
(
*2)
NE G2 G± G1(
*1)
B E11 , E12CA,E14ENGINE CONTROL MODULE(
ENGINE ECU)(
M/T) ONE BODY ASSEMBLY
EX. CALIFORNIA
R
BRB±R
1D 1415A
TAIL
1A 1010A
MIR±HTR
3C 53D 5
POWER SOURCESYSTEM(
SEE PAGE 64)

98
ENGINE CONTROL (5S±FE M/T EX. CALIFORNIA)
B4 A
IG2
ACC
IG1 ST2AM2
AM1
ST1
9
1 2
1 2
1 2
1 2 E20
E20
E20I20
I18I23 E20 E17E17
I18
I18
EBC 2C 7
A 25 A12C A 1 A 9A10
B 10 B 11 B12 IP3 12
2 1 2D 2
2B 22C3
31 2 2C A4
W±B
WY
R
B
L RW±R
W±R
W±R
W±RW±R W±R W±R W±R B±O
W±G
B±O B±O
B±O B±OG±Y G±R
LG W±L W±B
BRRB±O B±O B±O W±R
B±O B±O B±O B±O
B±O
# 20 # 10 VC VTA IDLBATT ISCVISCC ISCO +B 15A
EFI
EFI MAIN
RELAY
VSV
(
FOR A/C IDLE±UP) IDLE AIR CONTROL
VALVE
(
ISC VALVE)
ENGINE CONTROL MODULE(
ENGINE ECU)
THROTTLE POSITION
SENSOR
INJECTOR NO. 1
INJECTOR NO. 3
INJECTOR NO. 2
INJECTOR NO. 4 I4
I6
I5
I7
T1 E11 , E12 , E1
V1I1
W±R
IGNITION SW I12
IP1 11
B±O
231 2
B±O G
EGR
VSV
(
FOR EGR)
A FROM POWER SOURCE SYST
25 13
4321
V2IP1 9
W±R
I18
L
L FROM CRUISE
CONTROL ECU
B±O
IP1 18
B±O
B±O
WE18 E18
Y Y W
W
7. 5A
IGN
1D 9
1A 61G 8
EM(
SEEPAGE64)

196
CRUISE CONTROL
CURRENT IS APPLIED AT ALL TIMES THROUGH STOP FUSE TO TERMINAL 1 OF THE CRUISE CONTROL ECU AND TERMINAL 2 OF
STOP LIGHT SW, AND ALSO THROUGH THE STOP FUSE TO TERMINAL 15 OF CRUISE CONTROL ECU.
WITH THE IGNITION SW TURNED TO ON, THE CURRENT FLOWS THROUGH GAUGE FUSE TO TERMINAL (A) 6 OF COMBINATION
METER AND THE CURRENT THROUGH ECU±IG FUSE FLOWS TO TERMINAL 14 OF CRUISE CONTROL ECU.
WHEN THE IGNITION SW IS ON AND THE CRUISE CONTROL MAIN SW IS TURNED ON, A SIGNAL IS INPUT FROM TERMINAL 15 OF
CRUISE CONTROL MAIN SW TO TERMINAL 4 OF CRUISE CONTROL ECU. AS A RESULT, THE CRUISE CONTROL ECU FUNCTIONS
AND THE CURRENT TO TERMINAL 14 OF CRUISE CONTROL ECU TO TERMINAL 13 OF CRUISE CONTROL ECU " GROUND, AND
THE CRUISE CONTROL SYSTEM IS IN A CONDITION READY FOR OPERATION.
AT THE SAME TIME, THE CURRENT THROUGH THE GAUGE FUSE FLOWS FROM TERMINAL (A) 6 OF CRUISE CONTROL INDICATOR
LIGHT " TERMINAL (B) 9 " TERMINAL 5 OF CRUISE CONTROL ECU " TERMINAL 13 " TO GROUND, CAUSING THE CRUISE
CONTROL INDICATOR LIGHT TO LIGHT UP, INDICATING THAT THE CRUISE CONTROL IS READY FOR OPERATION.
1. SET OPERATION
WHEN THE CRUISE CONTROL MAIN SW IS TURNED ON AND THE SET SW IS TURNED ON WITH THE VEHICLE SPEED WITHIN THE
SET LIMIT (APPROX. 40 KM/H, 25 MPH TO 200 KM/H, 124 MPH), A SIGNAL IS INPUT TO TERMINAL 18 OF THE CRUISE CONTROL ECU
AND THE VEHICLE SPEED AT THE TIME THE SET SW IS RELEASED IS MEMORIZED IN THE ECU AS THE SET SPEED.
2. SET SPEED CONTROL
DURING CRUISE CONTROL DRIVING, THE ECU COMPARES THE SET SPEED MEMORIZED IN THE ECU WITH THE ACTUAL VEHICLE
SPEED INPUT INTO TERMINAL 20 OF THE CRUISE CONTROL ECU FROM THE VEHICLE SPEED SENSOR (SPEED SENSOR), AND
CONTROLS THE CRUISE CONTROL ACTUATOR TO MAINTAIN THE SET SPEED.
WHEN THE ACTUAL SPEED IS LOWER THAN THE SET SPEED, THE ECU CAUSES THE CURRENT TO THE CRUISE CONTROL
ACTUATOR TO FLOW FROM TERMINAL 12" TERMINAL 6 OF CRUISE CONTROL ACTUATOR "TERMINAL 7 "TERMINAL 11 OF
CRUISE CONTROL ECU. AS A RESULT, THE MOTOR IN THE CRUISE CONTROL ACTUATOR IS ROTATED TO OPEN THE THROTTLE
VALVE AND THE THROTTLE CABLE IS PULLED TO INCREASE THE VEHICLE SPEED. WHEN THE ACTUAL DRIVING SPEED IS HIGHER
THAN THE SET SPEED, THE CURRENT TO CRUISE CONTROL ACTUATOR FLOWS FROM TERMINAL 11 OF ECU "TERMINAL 7 OF
CRUISE CONTROL ACTUATOR "TERMINAL 6 "TERMINAL 12 OF CRUISE CONTROL ECU.
THIS CAUSES THE MOTOR IN THE CRUISE CONTROL ACTUATOR TO ROTATE TO CLOSE THE THROTTLE VALVE AND RETURN THE
THROTTLE CABLE TO DECREASE THE VEHICLE SPEED.
3. COAST CONTROL
DURING THE CRUISE CONTROL DRIVING, WHILE THE COAST SW IS ON, THE CRUISE CONTROL ACTUATOR RETURNS THE
THROTTLE CABLE TO CLOSE THE THROTTLE VALVE AND DECREASE THE DRIVING SPEED. THE VEHICLE SPEED WHEN THE COAST
SW IS TURNED OFF IS MEMORIZED AND THE VEHICLE CONTINUES AT THE NEW SET SPEED.
4. ACCEL CONTROL
DURING CRUISE CONTROL DRIVING, WHILE THE ACCEL SW IS TURNED ON, THE CRUISE CONTROL ACTUATOR PULLS THE
THROTTLE CABLE TO OPEN THE THROTTLE VALVE AND INCREASE THE DRIVING SPEED.
THE VEHICLE SPEED WHEN THE ACCEL SW IS TURNED OFF IS MEMORIZED AND THE VEHICLE CONTINUES AT THE NEW SET
SPEED.
5. RESUME CONTROL
UNLESS THE VEHICLE SPEED FALLS BELOW THE MINIMUM SPEED LIMIT (APPROX. 40 KM/H, 25 MPH) AFTER CANCELING THE SET
SPEED BY THE CANCEL SW, PUSHING THE RESUME SW WILL CAUSE THE VEHICLE TO RESUME THE SPEED SET BEFORE
CANCELLATION.
6. MANUAL CANCEL MECHANISM
IF ANY OF THE FOLLOWING OPERATIONS OCCURS DURING CRUISE CONTROL OPERATION, CURRENT FLOW TO MAGNETIC
CLUTCH OF THE ACTUATOR IS CUT TURNS OFF AND THE MOTOR ROTATES TO CLOSE THE THROTTLE VALVE AND THE CRUISE
CONTROL IS RELEASED.
*PLACING THE SHIFT LEVER IN ªNº POSITION (PARK/NEUTRAL POSITION SW (NEUTRAL START SW ON). ªSIGNAL INPUT TO
TERMINAL 2 OF ECUº (A/T)
*DEPRESSING THE CLUTCH PEDAL (CLUCH SW ON). ªSIGNAL INPUT TO TERMINAL 2 OF THE ECUº (M/T)
*DEPRESSING THE BRAKE PEDAL (STOP LIGHT SW ON). ªSIGNAL INPUT TO TERMINAL 16 OF ECUº
*PUSH THE CANCEL SW (CANCEL SW ON). ªSIGNAL INPUT TO TERMINAL 18 OF ECUº
*DEPRESSING THE PARKING BRAKE PEDAL (PARKING BRAKE SW ON). ªSIGNAL INPUT TO TERMINAL 3 OF ECUº (3VZ±FE)
*PULLING THE PARKING BRAKE LEVER (PARKING BRAKE SW ON). ªSIGNAL INPUT TO TERMINAL 3 OF THE ECUº (5S±FE)
SYSTEM OUTLINE

199
3
3C
28D 6 C 1
234I6
I18 I18
C
D B 20 A32 B7B1B22
C 5D 6D 3
D 112 1
BRG±OR±L L±R R±L
L±R BR BR
GR±B G±W
G± OL±R B±Y L±WG
BR
BR
R±L R±L
L±R L±RL±R
G±O THW IDL VTA VCP E2
L±W
L±WII2 4
R±L ENGINE COOLANT TEMP.
SENSOR(
EFI WATER
TEMP. SENSOR)
FROM
CRUISE CONTROL ECU
THROTTLE POSITION
SENSORFROM POWER SOURCE SYSTEM(
SEE PAGE 64)
JUNCTION
CONNECTOR
POWER
NORMAL ELECTRONIC CONTROLLED
TRANSMISSION
PATTERN SELECT SW
TE 2 TE1OD2
E1 TE 2 TE1
DA TA LINK CONNECTOR 1
(
CHECK CONNECTOR)JUNCTION
CONNECTOR D 12
SPEED
IP3 11 IP314 5124
G±B
G
23
1 VEHICLE SPEED
SENSOR
(
SPEED SENSOR)
LGP
R±L SP1
COMBINATION
METER
V5C8 T1
J3
E6E4
J1
D1I18II1 6
L±R TO
COMBINATION
METERL±R
IN1 6IN13
R±L
B E7 ,E8
AC,E9
ENGINE CONTROL MODULE(
ENGINE AND ELECTRONIC CONTROLLED TRANSMISSION ECU)
FROM
COOLING FAN ECU
L
D ,E10
IP 1 1
G± W
V±Y V±Y
AA
JUNCTION
CONNECTOR J7
BR
1K 81D6
3D 223D 10
10A
GAUGE
