The SRS airbag devices in your Toyota contain explo-
sive chemicals. If the vehicle is scrapped with the air-
bags left as they are, it may cause an accident such
as a fire. Be sure to have the SRS airbag system re-
moved and disposed of by a qualified service shop or
by your Toyota dealer before you dispose of your ve-
hicle.
As the installation of a mobile two-way radio system
in your vehicle could affect electronic systems such
as multiport fuel injection system/sequential multiport
fuel injection system, cruise control system, anti-lock
brake system and SRS airbag system, be sure to
check with your Toyota dealer for precautionary mea-
sures or special instructions regarding installation.
Installation of a mobile
two-way radio system
Scrapping of your Toyota
ProCarManuals.com

Indicator symbols on the instrument panel
5
Brake system warning light*1
Seat belt reminder light*1
Discharge warning light*1
Malfunction indicator lamp*1
Low fuel level warning light*1
Low oil pressure warning light*1
Anit-lock brake system warning light*1
Open door warning light*1
Rear light failure warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Overdrive-of f indicator light
PWRº mode indicator light
Cruise control indicator light*
2
Automatic transmission indicator lights
*
1: For details, see Service reminder indicators and warn-
ing buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
ProCarManuals.com

Part 1Headlights and turn signals
55
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-4
Lights, Wipers and Defogger

Headlights and turn signals

Emergency flashers

Instrument panel light control

Interior light

Ignition switch light

Personal light

Luggage compartment light

Windshield wipers and washer

Rear window wipers and washer

Rear window defogger
To turn on the lights on, twist the knob
on end of the lever.
Daytime running light system (Canada
only)ÐThe headlights turn on when the
parking brake is released with the engine
started, even with the light switch in the
OFFº position. They will not go off until
the ignition switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
first clickstop.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the second clickstop
to turn to full intensity for driving at night.FIRST CLICKSTOP: Only the parking,
tail, license plate, side marker and instru-
ment panel lights turn on.
SECOND CLICKSTOP: The headlights
also turn on.
The lights automatically turn off when the
driver's door is opened with the ignition
turned off. To turn them on again, turn the
key to the ONº position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.NOTICE
To prevent the battery from being
discharged, do not leave the lights
on for a long period when the
engine is not running.
ProCarManuals.com

66(a) Brake System Warning Light
This light has the following functions:
Parking brake reminder
If this light is on, make sure the parking
brake is fully released. The light should go
off.
Low brake fluid level warning
If this light comes on and stays on while
you are driving, slow down and pull off the
road. Then stop the vehicle carefully.
There may be a problem somewhere in
the brake system. Check the fluid level of
the see-through reservoir.
To make sure the parking brake has not
caused the warning light to come on,
check to see that the parking brake is fully
released.
If the brake fluid level is low...
At a safe place, test your brakes by start-
ing and stopping.

If you judge that the brakes still work
adequately, drive cautiously to your
nearest dealer or shop for repairs.

If the brakes are not working, have the
vehicle towed in for repairs. (For tow-
ing information, see Part 4.)
It is dangerous to continue driving
normally when the brake fluid level
is low.CAUTION
!
If the brake fluid level is correct...
Have the warning system checked by
your Toyota dealer.
(b) Seat Belt Reminder Light and Buzzer
Once the ignition key is turned to ONº or
STARTº, the reminder light and buzzer
come on if the driver's seat belt is not fas-
tened. Unless the driver fastens the belt,
the light stays on and the buzzer stops af-
ter about 4 to 8 seconds.
(c) Discharge Warning Light
This light warns that the battery is being
discharged.
If it comes on while you are driving, there
is a problem somewhere in the charging
system.
The engine ignition will continue to oper-
ate, however, until the battery is dis-
charged. Turn off the air conditioning,
blower, radio, etc., and drive directly to the
nearest Toyota dealer or repair shop.
NOTICE
Do not continue driving if the
engine drive belt is broken or loose.
(d) Malfunction Indicator Lamp
This lamp comes on in the following
cases.
a. The fuel tank is completely empty.
(See Fuel gaugeº in Chapter 1-5 for in-
structions.)b. The fuel tank cap is not tightened se-
curely. (See Fuel tank capº in Chapter
1-2 for instructions.)
c. There is a problem somewhere in your
engine or automatic transmission electri-
cal system.
If it comes on while you are driving in case
c, have your vehicle checked/repaired by
your Toyota dealer as soon as possible.
(e) Low Fuel Level Warning Light
This light comes on when the fuel level in
the tank becomes nearly empty. Fill up the
tank as soon as possible.
(f) Low Oil Pressure Warning Light
This light warns that the engine oil pres-
sure is too low.
If it flickers or stays on while you are driv-
ing, pull off the road to a safe place and
stop the engine immediately. Call a Toyota
dealer or qualified repair shop for assis-
tance.
The light may occasionally flicker when
the engine is idling or it may come on brief-
ly after a hard stop. There is no cause for
concern if it then goes out when the en-
gine is accelerated slightly.
The light may come on when the oil level
is extremely low. It is not designed to indi-
cate low oil level, and the oil level must be
checked using the level dipstick.
ProCarManuals.com

67
NOTICE
Do not drive the vehicle with the
warning light onÐeven for one
block. It may ruin the engine.
(g) ABSº Warning Light
This light warns that there is a problem
somewhere in your anti-lock brake sys-
tem.
If the light comes on while you are driving,
have your vehicle checked by your Toyota
dealer as soon as possible.
The light will come on when the ignition
key is turned to the ONº position. After
about 3 seconds, the light will go off.
When the ABSº warning light is on (and
the brake system warning light is off), the
brake system operates conventionally but
without anti-lock function.
(h) Open Door Warning Light
This light remains on until all the doors
and back door are completely closed.
(i) Rear Light Failure Warning Light
If this light comes on when the headlight
switch is turned on (at the first or second
clickstop), it indicates that one or more of
the tail lights are burned out.
If it comes on when the brake pedal is de-
pressed, one or more stop lights are
burned out.Have defective bulbs replaced as soon as
possible.
(j) SRS Airbag Warning Light
This light will come on when the igni-
tion key is turned to the ACCº or ONº
position. After about 6 seconds, the
light will go off. This means the airbag
system is operating properly.
The warning light system monitors the
front airbag sensors, center airbag sensor
assembly, inflators, warning light, inter-
connecting wiring and power sources.
If either of the following conditions occurs,
this indicates a malfunction somewhere in
the parts monitored by the warning light
system. Contact your Toyota dealer as
soon as possible to service the vehicle.

The light does not come on when the
ignition key is turned to the ACCº or
ONº position or remains on.

The light comes on while driving.
(k) Key Reminder Buzzer
This buzzer reminds you to remove the
key when you open the driver's door with
the ignition key in the ACCº or LOCKº
position.CHECKING SERVICE REMINDER INDI-
CATORS (except the low fuel level
warning light)
1. Apply the parking brake.
2 . Open one of the side doors or back door.
The open door warning light should come
on.
3. Close the door.
The open door warning light should go off.
4. Turn the ignition key to ACCº.
The SRS airbag warning light should
come on. It goes off after about 6 sec-
onds.
5. Turn the ignition key to ONº, but do not
start the engine.
All the service reminder indicators except
the open door warning light and SRS air-
bag warning light should come on. The
ABSº warning light goes off after about 3
seconds.
If any service reminder indicator or warn-
ing buzzer does not function as described
above, either the bulb is burned out or the
circuit is in need of repair. Have it checked
by your Toyota dealer as soon as pos-
sible.
ProCarManuals.com

Part 1Ignition switch with steering lock
69
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-6
Ignition switch,
Transmission
and Parking brake

Ignition switch with steering lock

Automatic transmission

Manual transmission

Parking brake

Cruise control
STARTºÐStarter motor on. The key
will return to the ONº position when
released.
For starting tips, see Part 3.
ONºÐEngine on and all accessories
on.
This is the normal driving position.
ACCºÐAccessories such as the ra-
dio operate, but the engine is off.
If you leave the key in the ACCº or
LOCKº position and open the driver's
door, a buzzer will remind you to remove
the key.
LOCKºÐEngine is off and the steer-
ing wheel is locked. The key can be re-
moved only at this position.You must push in the key to turn the key
from ACCº to the LOCKº position. On
vehicles with an automatic transmission,
the selector lever must be put in the Pº
position before pushing the key.
When starting the engine, the key may
seem stuck at the LOCKº position. To
free it, first be sure the key is pushed all
the way in, and then rock the steering
wheel slightly while turning the key gently.For manual transmission:
Never remove the key when the ve-
hicle is moving, as this will lock the
steering wheel and result in loss of
steering control.CAUTION
!
NOTICE
Do not leave the key in the ONº
position if the engine is not running.
The battery will discharge and the
ignition could be damaged.
ProCarManuals.com

71 Your automatic transmission has a shift
lock system to minimize the possibility of
incorrect operation. This means you can
only shift out of Pº position when the
brake pedal is depressed (with the ignition
switch in ONº position and the lock re-
lease button depressed).
(a) Normal driving
1. Start the engine as instructed in How
to start the engineº in Part 3. The trans-
mission must be in Pº or Nº.
2. With your foot holding down the brake
pedal, shift the selector lever to Dº.
In Dº position, the automatic transmis-
sion system will select the most suitable
gear for the running conditions such as
normal cruising, hill climbing, hard towing,
etc.
Always turn the overdrive switch on for
better fuel economy and quieter driving. If
the engine coolant temperature is low, the
transmission will not shift into overdrive
gear even with the overdrive switch on.
Never put your foot on the accelera-
tor pedal while shifting.CAUTION
!
3. Release the parking brake and brake
pedal. Depress the accelerator pedal
slowly for smooth starting.
(b) Using engine braking
To use engine braking, you can downshift
the transmission as follows:

Turn off the overdrive switch. The O/D
OFFº indicator light will come on and
the transmission will downshift to the
third gear.

Shift into the 2º position. The trans-
mission will downshift to the second
gear when the vehicle speed drops
down to or lower than the maximum al-
lowable speed for second gear, and
more powerful engine braking will be
obtained.

Shift into the Lº position. The trans-
mission will downshift to the first gear
when the vehicle speed drops down to
or lower than the maximum allowable
speed for Lº position and maximum
engine braking will be applied.MAXIMUM ALLOWABLE SPEEDS
km/h (mph)
2º Lº
5S-FE engine 120 (75) 66 (41)
1MZ-FE engine 128 (80) 70 (44)
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.CAUTION
!
NOTICE
Be careful not to overrev the en-
gine. Watch the tachometer to
keep engine rpm from going into
the red zone. The maximum allow-
able speed (approximate) for each
position is given above for your
reference.
Do not continue hill climbing for a
long time in the 2º or Lº posi-
tion. This may cause severe auto-
matic transmission damage from
overheating. To prevent such
damage, use Dº position for hill
climbing or hard towing.
ProCarManuals.com

72(c) Backing up
1. Bring the vehicle to a complete stop.
2. With the brake pedal held down with
your foot, shift the selector lever to the Rº
position.
NOTICE
Never shift into reverse while the
vehicle is moving.
(d) Parking
1. Bring the vehicle to a complete stop.
2. Pull the parking brake lever up fully to
securely apply the parking brake.
3. With the brake pedal pressed down,
shift the selector lever to the Pº position.
While the vehicle is moving, never
attempt to move the selector lever
into Pº position under any circum-
stances. Serious mechanical dam-
age and loss of vehicle control may
result.CAUTION
!
(e) Good driving practice

If the transmission is repeatedly up-
shifted and downshifted between the
third gear and overdrive when climbing
a gentle slope, the overdrive switch
should be turned off. Be sure to turn
the switch on immediately afterward.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use overdrive.
Always keep your foot on the brake
pedal while stopped with the engine
running. This prevents the vehicle
from creeping.CAUTION
!
NOTICE
Do not hold the vehicle on an
upgrade with the accelerator pedal.
It can cause the transmission to
overheat. Always use the brake
pedal or parking brake.
(f) Driving in PWRº mode
In the PWRº mode, the transmission is
shifted up and down at a higher vehicle
speed than in the NORMº mode and a
more powerful acceleration is achieved.
To set the PWRº mode, push in the driv-
ing pattern selector button. The PWRº
mode indicator light comes on.
For ordinary driving, Toyota recommends
using the NORMº mode to improve fuel
economy.
(g) If you cannot shift the selector lever
out of Pº position
If you cannot shift the selector lever from
Pº position even though the brake pedal
is depressed, use the shift lock override
button. For instructions, see If you can-
not shift automatic transmission selector
leverº in Part 4.
ProCarManuals.com

73
The shift pattern is conventional as
shown above.
Press the clutch pedal down fully while
shifting, and then release it slowly. Do not
rest your foot on the pedal while driving,
because it will cause clutch trouble. And
do not use the clutch to hold the vehicle
when stopped on an uphill gradeÐuse the
parking brake.Recommended shifting speeds
The transmission is fully synchronized
and upshifting or downshifting is easy.
For the best compromise between fuel
economy and vehicle performance, you
should upshift or downshift at the follow-
ing speeds:
gear km/h (mph)
1 to 2 or 2 to 1 24 (15)
2 to 3 or 3 to 2 40 (25)
3 to 4 or 4 to 3 64 (40)
4 to 5 or 5 to 4 72 (45)
Downshift to the appropriate gear if accel-
eration is needed when you are cruising
below the above downshifting speeds.
Upshifting too soon or downshifting too
late will cause lugging, and possibly ping-
ing. Regularly revving the engine to maxi-
mum speed in each gear will cause exces-
sive engine wear and high fuel
consumption.Maximum allowable speeds
To get on a highway or to pass slower traf-
fic, maximum acceleration may be neces-
sary. Make sure you observe the following
maximum allowable speeds in each gear:
gear km/h (mph)
1 49 (30)
2 89 (55)
3 140 (87)
NOTICE
Do not downshift if you are going
faster than the maximum allowable
speed for the next lower gear.
Good driving practice

If it is difficult to shift into reverse, put
the transmission in neutral, release
the clutch pedal momentarily, and then
try again.

When towing a trailer, in order to main-
tain engine braking efficiency, do not
use the fifth gear.
Manual transmission
ProCarManuals.com

74
Be careful when downshifting on a
slippery surface. Abrupt shifting
could cause the vehicle to spin or
skid.CAUTION
!
NOTICE
Make sure the vehicle is completely
stopped before shifting into reverse.
To set: Pull up the lever.
To release: Pull up slightly, press the
thumb button, and lower.
Before leaving your vehicle, firmly apply
the parking brake.
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.CAUTION
!
To set: Fully depress the pedal.
To release: Pull the lever.
Before leaving your vehicle, firmly apply
the parking brake.
Before driving, be sure the parking
brake is fully released and the park-
ing brake reminder light is off.CAUTION
! Parking brake (pedal type) Parking brake (lever type)
ProCarManuals.com
