TOYOTA CAMRY 1996 Owners Manual
Manufacturer: TOYOTA, Model Year: 1996, Model line: CAMRY, Model: TOYOTA CAMRY 1996Pages: 226, PDF Size: 4.66 MB
Page 1 of 226
Foreword
Welcome to the growing group of value-conscious people who drive Toyotas. We
are proud of the advanced engineering and quality construction of each vehicle we
build.
This Owner 's Manual explains the features of your new Toyota. Please read it and
follow the instructions carefully so that you can enjoy many years of safe motoring.
When it comes to service, remember that your Toyota dealer knows your vehicle
best and is interested in your complete satisfaction. He will provide quality mainte-
nance and any other assistance you may require.
Please leave this Owner's Manual in this vehicle at the time of resale. The next
owner will need this information also.
All information and specifications in this manual are current at the time of
printing. However, because of Toyota's policy of continual product improve-
ment, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment,
including options. Therefore, you may find some explanations for equipment
not installed on your vehicle.
TOYOTA MOTOR CORPORATION
1996 TOYOTA MOTOR CORPORATION
All rights reserved. This material may not be reproduced or copied, in whole or in
part, without the written permission of Toyota Motor Corporation.
ProCarManuals.com
Page 2 of 226
New vehicle warranty
Your new vehicle is covered by the following Toyota
limited warranties:
For further information, please refer to the separate
Owner 's Guideº, Owner's Manual Supplementº or
Warranty Bookletº.New vehicle warranty
Emission control systems warranty
Others
It is the owner's responsibility to make sure that the
specified maintenance is performed. Part 6 gives de-
tails of these maintenance requirements. Also in-
cluded in Part 6 is general maintenance. For sched-
uled maintenance information, please refer to the
separate Owner's Manual Supplement/Mainte-
nance Scheduleº.A wide variety of non genuine spare parts and acces-
sories for Toyota vehicles are currently available in
the market. You should know that Toyota does not
warrant these products and is not responsible either
for their performance, repair or replacement, or for
any damage they may cause to, or adverse effect
they may have on, your Toyota vehicle.
This vehicle should not be modified with non genuine
Toyota products. Modification with non genuine Toyo-
ta products could affect its performance, safety or du-
rability, and may even violate governmental regula-
tions. In addition, damage or performance problems
resulting from the modification may not be covered
under warranty.
The spark ignition system of your Toyota meets all re-
quirements of the Canadian Interference-Causing
Equipment Standard.
Your responsibility for maintenance
Accessories, spare parts and
modification of your Toyota
Spark ignition system of your Toyota
ProCarManuals.com
Page 3 of 226
The SRS airbag devices in your Toyota contain explo-
sive chemicals. If the vehicle is scrapped with the air-
bags left as they are, it may cause an accident such
as a fire. Be sure to have the SRS airbag system re-
moved and disposed of by a qualified service shop or
by your Toyota dealer before you dispose of your ve-
hicle.
As the installation of a mobile two-way radio system
in your vehicle could affect electronic systems such
as multiport fuel injection system/sequential multiport
fuel injection system, cruise control system, anti-lock
brake system and SRS airbag system, be sure to
check with your Toyota dealer for precautionary mea-
sures or special instructions regarding installation.
Installation of a mobile
two-way radio system
Scrapping of your Toyota
ProCarManuals.com
Page 4 of 226
ProCarManuals.com
Page 5 of 226
Publication No. OM33447U
Part No. 01999-33447
Printed in Japan 29- 9810- 04
Quick index
If a service reminder indicator or warning buzzer comes on 65. . . . .
If your vehicle will not start 149. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your engine stalls while driving 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle overheats 152,153. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If you have a flat tire 153. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
If your vehicle needs to be towed 163. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips for driving during break- in period 129. . . . . . . . . . . . . . . . . . . . . . . . .
How to start the engine 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General maintenance 172. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Complete index 221. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gas station information
Fuel type:
5S- FE engine: UNLEADED gasoline, Research Octane Number 91 (Octane
Rating 87) or higher.
1MZ- FE engine: UNLEADED gasoline, Research Octane Number 91 (Octane
Rating 87) or higher. For improved vehicle performance, the use of premium
unleaded gasoline with a Research Octane Number of 96 (Octane Rating
91) or higher is recommended.
See page 129 for detailed information.
Fuel tank capacity: 70 L (18.5 gal., 15.4 lmp. gal.)
Engine oil:
API SH, 'Energy- Conserving II'' multigrade engine oil or ILSAC multigrade
engine oil is recommended.
See page 186 for detailed information.
Automatic transmission fluid:
Automatic transmission fluid DEXRON
[- II.
Tire information: See pages 189 through 193.
Tire pressure: See pages 214 and 215.
A7
I
ProCarManuals.com
Page 6 of 226
Part 1
1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-1
Overview of instruments
and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the
instrument panel
ProCarManuals.com
Page 7 of 226
2
Instrument panel overview
ProCarManuals.com
Page 8 of 226
3ProCarManuals.com
Page 9 of 226
4
Instrument cluster overview
ProCarManuals.com
Page 10 of 226
Indicator symbols on the instrument panel
5
Brake system warning light*1
Seat belt reminder light*1
Discharge warning light*1
Malfunction indicator lamp*1
Low fuel level warning light*1
Low oil pressure warning light*1
Anit-lock brake system warning light*1
Open door warning light*1
Rear light failure warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Overdrive-of f indicator light
PWRº mode indicator light
Cruise control indicator light*
2
Automatic transmission indicator lights
*
1: For details, see Service reminder indicators and warn-
ing buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
