TOYOTA CAMRY 1999 Service Repair Manual

± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
DI±579
814 Author: Date:
43*
(DI±601)Malfunction in ABS control system
ABS control system
44*
(DI±602)Open or short circuit in NE signal circuit

NEO circuit

ECM

ECU
49
(DI±604)Open circuit in stop light switch circuit

Stop light switch

Stop light switch circuit

ECU
51
(DI±606)Pump motor is locked
ABS pump motor
53*
(DI±608)Malfunction in ECM communication circuit

TRC+ or TRC ± circuit

EFI+ or EFI± circuit

ECM

ECU
61*
(DI±609)Malfunction in engine control system
Engine control system
Always ON
(DI±610)Malfunction in ECU
ECU
*: TRAC OFF indicator light blinking

DI04G±04
F01177
SLIP Indicator Light
TRAC OFF Indicator Light
ABS Warning Light
DLC1
DLC2
Rear Speed Sensor
Sensor Rotor ABS & TRAC ActuatorABS & TRAC ECU
TRAC OFF Switch
ABS & TRAC
Solenoid Relay
ABS & TRAC
Motor RelaySensor Rotor
Front Speed Sensor
Stop Light Switch Front Speed Sensor
DI±580
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
815 Author: Date:
PARTS LOCATION

DI1JO±03
R05698
A15 A16A17
1 2 3 4 5 6 7 8 9 10
21 11 12 13
14
15 16 17 18 19
20 22 23 24 25 261 2 3 4 5
4 6 7
8
9 10 11 12 13 14 16 151
2 3 5 6
7 8
9 10 11 12
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
DI±581
816 Author: Date:
TERMINALS OF ECU
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
IG1 (A16 ± 8) ± GND (A15 ±
15, A17 ± 9, 10)B±R e W±BIG switch ON10 ± 14
R+ (A15 ± 1) ± SR (A15 ± 11)GR±R e GRIG switch ON, ABS warning light OFF9 ± 14
R+ (A15 ± 1) ± MR (A15 ± 24)GR±R e GR±LIG switch ONBelow 1.0
SFRR (A15 ± 26) ± GND (A15
± 15, A17 ± 9, 10)W±R e W±BIG switch ON, ABS warning light OFF10 ± 14
SFRH (A15 ± 13) ± GND (A15
± 15, A17 ± 9, 10)R±B e W±BIG switch ON, ABS warning light OFF10 ± 14
SFLR (A17 ± 1) ± GND (A15 ±
15, A17 ± 9, 10)W±L e W±BIG switch ON, ABS warning light OFF10 ± 14
SFLH (A17 ± 2) ± GND (A15 ±
15, A17 ± 9, 10)L±B e W±BIG switch ON, ABS warning light OFF10 ± 14
SRRR (A17 ± 7) ± GND (A15 ±
15, A17 ± 9, 10)R±G e W±BIG switch ON, ABS warning light OFF10 ± 14
SRRH (A17 ± 8) ± GND (A15 ±
15, A17 ± 9, 10)W±R e W±BIG switch ON, ABS warning light OFF10 ± 14
SRLR (A15 ± 12) ± GND (A15 ±
15, A17 ± 9, 10)LG±B e W±BIG switch ON, ABS warning light OFF10 ± 14
SRLH (A15 ± 25) ± GND (A15 ±
15, A17 ± 9, 10)G±Y e W±BIG switch ON, ABS warning light OFF10 ± 14
AST (A15 ± 10) ± GND (A15 ±
15, A17 ± 9, 10)R e W±BIG switch ON, ABS warning light OFF10 ± 14
WA (A16 ± 4) ± GND (A15 ± 15,GBWBIG switch ON, ABS warning light ONBelow 2.0WA (A16 4) GND (A15 15,
A17 ± 9, 10)G±B e W±BIG switch ON, ABS warning light OFF10 ± 14
STP (A16 ± 16) ± GND (A15 ±GWWBStop light switch OFFBelow 1.5STP (A16 16) GND (A15
15, A17 ± 9, 10)G±W e W±BStop light switch ON8 ± 14
D/G (A15 ± 22) ± GND (A15 ±
15, A17 ± 9, 10)R±L e W±BIG switch ON, ABS warning light ON10 ± 14
Tc (A15 ± 9) ± GND (A15 ± 15,
A17 ± 9, 10)LG±R e W±BIG switch ON8 ± 14
Ts (A15 ± 23) ± GND (A15 ± 15,
A17 ± 9, 10)R±Y eW±BIG switch ON8 ± 14
FR+ (A15 ± 17) ± FR± (A15 ±
18)W e BIG switch ON, slowly turn right front wheelAC generation
FL+ (A15 ± 5) ± FL± (A15 ± 4)R e GIG switch ON, slowly turn left front wheelAC generation
RR+ (A16 ± 9) ± RR± (A16 ±
10)W e BIG switch ON, slowly turn right rear wheelAC generation
RL+ (A16 ± 2) ± RL± (A16 ± 1)R e GIG switch ON, slowly turn left rear wheelAC generation

DI±582
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
817 Author: Date:
MT (A15 ± 14) ± GND (A15 ±
15, A17 ± 9, 10)R±W e W±BIG switch ONBelow 1.5
SRC1 (A17 ± 5) ± GND (A15 ±
15, A17 ± 9, 10)B±R e W±BIG switch ON, TRAC OFF indicator light OFF10 ± 14
SRC2 (A17 ± 6) ± GND (A15 ±
15, A17 ± 9, 10)B±Y e W±BIG switch ON, TRAC OFF indicator light OFF10 ± 14
SMC1 (A17 ± 12) ± GND (A15
± 15, A17 ± 9, 10)Y±R e W±BIG switch ON, TRAC OFF indicator light OFF10 ± 14
SMC2 (A17 ± 6) ± GND (A15 ±
15, A17 ± 9, 10)Y±B e W±BIG switch ON, TRAC OFF indicator light OFF10 ± 14
NEO (A16 ± 15) ± GND (A15 ±
15, A17 ± 9, 10)BR±W e W±BIdlingPulse generation
EFI+ (A16 ± 6) ± GND (A15 ±
15, A17 ± 9, 10)W e W±BIG switch ONPulse generation
EFI± (A16 ± 14) ± GND (A15 ±
15, A17 ± 9, 10)B e W±BIG switch ONPulse generation
TRC+ (A16 ± 13) ± GND (A15 ±
15, A17 ± 9, 10)G e W±BTRAC control activePulse generation
TRC± (A16 ± 5) ± GND (A15 ±
15, A17 ± 9, 10)L e W±BTRAC control activePulse generation
IND (A16 ± 3) ± GND (A15 ±LGWBIG switch ON, SLIP indicator light ONBelow 2.0IND (A16 3) GND (A15
15, A17 ± 9, 10)LG e W±BIG switch ON, SLIP indicator light OFF10 ± 14
WT (A16 ± 12) ± GND (A15 ±LWBIG switch ON, TRAC OFF indicator light ONBelow 2.0WT (A16 12) GND (A15
15, A17 ± 9, 10)L e W±BIG switch ON, TRAC OFF indicator light OFF10 ± 14
CSW (A16 ± 11) ± GND (A15 ±LGWBIG switch ON, TRAC cut switch pushed inBelow 2.0CSW (A16 11 ) GND (A15
15, A17 ± 9, 10)LG e W±BIG switch ON, TRAC cut switch released8 ± 14

DI04I±04
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
DI±583
818 Author: Date:
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the DTC check but the problem still occurs, check the circuits for each
problem symptom in the order given in the table below and proceed to the relevant troubleshooting page.
SymptomSuspect AreaSee page
ABS does not operate.
Only when 1. to 4. are all normal and the problem is still
occurring, replace the
ABS & TRAC ECU.
1. Check the DTC reconfirming that the normal code is
output.
2. IG power source circuit
3. Speed sensor circuit
4. Check the ABS & TRAC actuator with a checker. If ab-
normal, check the hydraulic circuit for leakage
(See page DI±623).
DI±574
DI±598
DI±593
BR±61
ABS does not operate efficiently.
Only when 1. to 4. are all normal and the problem is still
occurring, replace the
ABS & TRAC ECU.
1. Check the DTC reconfirming that the normal code is
output.
2. Speed sensor circuit.
3. Stop light switch circuit.
4. Check the ABS & TRAC actuator with a checker. If ab-
normal, check the hydraulic circuit for leakage
(See page DI±623).
DI±574
DI±593
DI±604
BR±61
ABS warning light abnormal.1. ABS warning light circuit
2. ABS & TRAC ECUDI±612
DI±610
DTC check cannot be done.
Only when 1. and 2. are all normal and the problem is still
occurring, replace the ABS & TRAC ECU.
1. ABS warning light circuit
2. TRAC OFF indicator light circuit
3. Tc terminal circuit
DI±612
DI±617
DI±621
Speed sensor signal check cannot be done.1. Ts terminal circuit
2. ABS & TRAC ECUDI±615
DI±610
TRAC does not operate.
Only when inspection circuits for each problem symptom
are all normal and the problem is still occurring, replace the
ABS & TRAC ECU.
1. Check the DTC, reconfirming that the normal code is
output.
2. IG power source circuit
3. Check the hydraulic circuit for leakage
4. Speed sensor circuit
DI±574
DI±598
DI±623
DI±593
SLIP indicator light abnormal.SLIP indicator light circuitDI±620
TRAC OFF indicator light abnormal.
Only when inspection circuits for each problem symptom
are all normal and the problem is still occurring, replace the
ABS & TRAC ECU.
1. TRAC OFF indicator light circuit
2. TRAC cut switch circuit
DI±617
DI±617

DI04J±04
F03951
ABS & TRAC Solenoid Relay
Battery
MAINB±G1F4 ALT1F5 B±G
FL
BlockW±B
EA 3 ABS
12
3 Engine Room R/B No. 3
1
2
336
4
53
3
3
W±L
A8
4ABS & TRAC
Actuator
ABS & TRAC
ECU
5
A8R
A1510
AST GR
GR±RABS & TRAC
ECU
11
A15
1
A15SR
R+
DLC1 DI±584
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
819 Author: Date:
CIRCUIT INSPECTION
DTC 11, 12 ABS & TRAC Solenoid Relay Circuit
CIRCUIT DESCRIPTION
This relay supplies power to each ABS & TRAC solenoid. After the ignition switch is turned ON, if the initial
check is OK, the relay goes on.
DTC No.DTC Detecting ConditionTrouble Area
11
Condition 1. to 3. are detected:
1. Malfunction of solenoid relay monitor
2. Battery voltage will not exceed more than 17.0 V within
2.16 sec.
3. Battery voltage will not become less than 9.5 V within
2.16 sec., or after the solenoid relay is ON and AST
voltage of ECU terminal does not become 8.0 V or more.

ABS & TRAC solenoid relay

ABS & TRAC solenoid relay circuit

ECU
12
Solenoid relay is OFF in the midst of premain routine, and
AST voltage of ECU terminal is 8.0 V or more, which con-
tinues for 2.04 sec. or more.
Fail safe function:
If any trouble occurs in the ABS & TRAC solenoid relay circuit, the ECU cuts off current to the ABS & TRAC
solenoid relay and prohibits ABS control and TRAC control.
WIRING DIAGRAM

F00182
(+)(±)
(+)(±)
(+)(±)(+)(±)
123
456
Engine Room R/B No. 3
F00055
ABS & TRAC
Solenoid
Relay
A15
AST
4
5
ABS & TRAC
Actuator
ECU
ABS & TRAC
Solenoid
Relay
A15
AST
4
5
ABS & TRAC
Actuator
ECU
ABS & TRAC
Solenoid
Relay
A15
AST
4
5
ABS & TRAC
Actuator
ECU
ABS & TRAC
Solenoid
Relay3
A8
A8
A15
AST
4
5
ABS & TRAC
Actuator
ECUEngine Room R/B No. 3
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
DI±585
820 Author: Date:
INSPECTION PROCEDURE
1 Check voltage between terminals 1 and 2 of Engine Room R/B No. 3 (for ABS &
TRAC solenoid relay).
PREPARATION:
Remove ABS & TRAC solenoid relay from Engine Room R/B
No. 3.
CHECK:
Measure the voltage between terminals 1 and 2 of Engine
Room R/B No. 3 (for ABS & TRAC solenoid relay).
OK:
Voltage: 10 ± 14 V
NG Check and repair harness or connector.
OK
2 Check continuity between terminal 3 of ABS & TRAC solenoid relay and terminal
AST of ABS & TRAC ECU.
CHECK:
Check continuity between terminal 3 of Engine Room R/B No.
3 (for ABS solenoid relay) and terminal AST of ABS & TRAC
ECU.
OK:
Continuity
HINT:
There is a resistance of 4 ~ 6 W between terminals A8 ± 4 and
A8 ± 5 of ABS actuator.
NG Repair or replace harness or ABS & TRAC
actuator.
OK

F00042
1
2 3
4 5 6
1 2 3
4 5 6
1 2 3
4 5 6 Open
Continuity
Continuity
Open Continuity
(+) (±)
DI±586
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
821 Author: Date:
3 Check ABS & TRAC solenoid relay.
CHECK:
Check continuity between each terminal of ABS & TRAC sole-
noid relay.
OK:
Terminals 4 and 6Continuity (Reference value 80 W)
Terminals 2 and 3Continuity
Terminals 1 and 3Open
CHECK:
(a) Apply battery positive voltage between terminals 4 and 6.
(b) Check continuity between each terminal of ABS & TRAC
solenoid relay.
OK:
Terminals 2 and 3Open
Terminals 1 and 3Continuity
NG Replace ABS & TRAC solenoid relay.
OK
4 Check for open and short circuit in harness and connector between ABS &
TRAC solenoid relay and ABS & TRAC ECU (See page IN±31).
NG Repair or replace harness or connector.
OK
If the same code is still output after the DTC is deleted, check the contact condition of each con-
nection.
If the connections are normal, the ECU may be defective.

F03413
Battery2
Engine Room R/B No. 3
MAIN B±G F4F5
FL
BlockABS
12
3
1ALT1
31 B±GABS & TRAC
Motor Relay
4
33
3GR±L
GR±R24
A15
1
A15ABS & TRAC ECU
MR
R+
MT
A1514
R±W
A83 ABS & TRAC Actuator
W±R2
A8
1
A8
W±B
EA
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
DI±587
822 Author: Date:
DTC 13, 14 ABS & TRAC Motor Relay Circuit
CIRCUIT DESCRIPTION
The ABS & TRAC motor relay supplies power to the ABS & TRAC pump motor. While the ABS is activated,
the ECU switches the ABS & TRAC motor relay ON and operates the ABS & TRAC pump motor.
DTC No.DTC Detecting ConditionTrouble Area
13
Conditions 1. to 3. are detected:
1. Malfunction of motor relay monitor
2. Battery voltage will not exceed more than 17.0 V within
2.16 sec.
3. Battery voltage will not become less than 9.5 V within
2.16 sec., or after the motor relay is ON and motor relay
monitor does not ON.

ABS & TRAC motor relay

ABS & TRAC motor relay circuit

ECU
14Motor relay is OFF, and motor relay monitor is ON , which
continues for 20.16 sec. or more.
Fail safe function:
If any trouble occurs in the ABS & TRAC motor relay circuit, the ECU cuts off current to the ABS & TRAC
solenoid relay and prohibits ABS control and TRAC control.
WIRING DIAGRAM
DI04K±04

F00049
1
2
34 (+) (±)
Engine Room
R/B No. 31
2
34 (+) (±)
Engine Room
R/B No. 31
2
34 (+) (±)
Engine Room
R/B No. 31
2
34 (+) (±)
Engine Room
R/B No. 3
F00056
ABS & TRAC
Motor
Relay
M2
A15
MT
32
2
3
ABS & TRAC
Actuator
ECU
ABS & TRAC
Motor
Relay
M2
A15
MT
32
2
3
ABS & TRAC
Actuator
ECU
ABS & TRAC
Motor
Relay
M2
A15
MT
32
2
3
ABS & TRAC
Actuator
ECU
A8
ABS & TRAC
Motor
Relay
A8 M2
A15
MT
32
2
3
ABS & TRAC
Actuator
ECUEngine Room R/B
No. 3
DI±588
± DIAGNOSTICSABS & TRACTION CONTROL SYSTEM
823 Author: Date:
INSPECTION PROCEDURE
1 Check voltage between terminal 1 of Engine Room R/B No. 3 (for ABS & TRAC
motor relay) and body ground.
PREPARATION:
Remove ABS & TRAC motor relay from Engine Room R/B No.
3.
CHECK:
Measure voltage between terminal 1 of Engine Room R/B No.
3 (for ABS & TRAC motor relay) and body ground.
OK:
Voltage: 10 ± 14 V
NG Check and repair harness or connector.
OK
2 Check continuity between terminal 2 of ABS & TRAC motor relay and terminal
MT of ABS & TRAC ECU.
CHECK:
Check continuity between terminal 2 of Engine Room R/B No.
3 (for ABS & TRAC motor relay) and terminal MT of ABS &
TRAC ECU.
OK:
Continuity
HINT:
There is a resistance of 4 ~ 6 W between terminals A8 ± 2 and
A8 ± 3 of ABS & TRAC actuator.
NG Repair or replace harness or ABS & TRAC
actuator.
OK
