TOYOTA CAMRY 1999 Service Repair Manual

AB0118
R13006AB0118H01023
H01075 H02144H02255
P Squib
Airbag
Sensor
Assembly
P+
P±ACC
or
DLC1
ON " u
E1 TcDTC B0107/51
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±259
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect P+ and P± of the connector
(on the front passenger airbag assembly side) between
the front passenger airbag assembly and the airbag sen-
sor assembly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See step 5 on page
DI±223).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI±223).
OK:
DTC B0107/51 is not output.
HINT:
Codes other than code B0107/51 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118
R13006AB0119H01024
H01075H01196
"u
E1Tc ACC ON
or
DTC B0107/51 DLC1Airbag
Sensor
Assembly P Squib
DI±260
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
4 Check P squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the front passenger airbag assembly connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See step 5 on page
DI±223).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI±223).
OK:
DTC B0107/51 is not output.
HINT:
Codes other than code B0107/51 may be output at this time, but
they are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H01022H02146
AB0119
H08262
P SquibAirbag
Sensor
Assembly
(±) (+)P+ ON
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±261
DTC B0108/52 Short in P Squib Circuit (to B+)
CIRCUIT DESCRIPTION
The P squib circuit consists of the airbag sensor assembly and front passenger airbag assembly.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see Pub. No. RM654U on page RS±2.
DTC B0108/52 is recorded when a B+ short is detected in the P squib circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0108/52

Short circuit in P squib wire harness (to B+)

P squib malfunction

Airbag sensor assembly malfunction
Front passenger airbag assembly (P squib)

Airbag sensor assembly

Wire harness
WIRING DIAGRAM
See page DI±251.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI±305).
2 Check P squib circuit.
CHECK:
(a) Turn ignition switch to ON.
(b) For the connector (on the front passenger airbag assem-
bly side) between the front passenger airbag assembly
and the airbag sensor assembly, measure the voltage be-
tween the P+ and body ground.
OK:
Voltage: 0 V
NG Repair or replace harness or connector be-
tween front passenger airbag assembly and air-
bag sensor assembly.
OK
DI1B9±23

AB0118
R13006AB0118H01023
H01076 H02144H02257
P Squib
Airbag
Sensor
Assembly
P+
P±ACC
or
DTC B0108/52
DLC1
ON " u
E1
Tc
DI±262
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect P+ and P± of the connector
(on the front passenger airbag assembly side) between
the front passenger airbag assembly and the airbag sen-
sor assembly.
(c) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See step 5 on page
DI±223).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI±223).
OK:
DTC B0108/52 is not output.
HINT:
Codes other than code B0108/52 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

AB0118
R13006AB0119H01024
H01076H01199
"u
E1Tc ACC ON
or
DTC B0108/52 DLC1Airbag
Sensor
Assembly P Squib
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±263
4 Check P squib.
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the front passenger airbag assembly connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See page DI±223).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI±223).
OK:
DTC B0108/52 is not output.
HINT:
Codes other than code B0108/52 may be output at this time, but
they are not relevant to this check.
NG Replace front passenger airbag assembly.
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.

H01454
P/T Squib (RH)Airbag Sensor Assembly
PR+
PR± Y±B
Y 1
26 5
C6
C6 DI±264
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DTC B0130/63 Short in P/T Squib (RH) Circuit
CIRCUIT DESCRIPTION
The P/T squib (RH) circuit consists of the airbag sensor assembly and seat belt pretensioner (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see Pub. No. RM654U on page RS±2.
DTC B0130/63 is recorded when a short is detected in the P/T squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0130/63

Short circuit between PR+ wire harness and PR± wire
harness of squib

P/T squib (RH) malfunction

Airbag sensor assembly malfunction
Seat belt pretensioner (RH)

Airbag sensor assembly

Wire harness
WIRING DIAGRAM
DI16S±25

H01019H02141H02203
P/T Squib (RH)Airbag
Sensor
Assembly
PR+
PR±
(+) (±)
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±265
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI±305).
2 Check P/T squib (RH) circuit.
PREPARATION:
Release the airbag activation prevention mechanism of the
connector (on the airbag sensor assembly side) between the
airbag sensor assembly and the seat belt pretensioner (RH)
(See page DI±223).
CHECK:
For the connector (on the seat belt pretensioner side) between
the seat belt pretensioner (RH) and the airbag sensor assem-
bly, measure the resistance between PR+ and PR±.
OK:
Resistance: 1 MW or Higher
NG Repair or replace harness or connector be-
tween seat belt pretensioner (RH) and airbag
sensor assembly.
OK

H01020AB0118AB0119R13006H01082H07485
P/T Squib (RH)Airbag
Sensor
Assembly
ACC
or
DTC B0130/63ON " u
E1
Tc DLC1
DI±266
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to ACC or ON and wait at least for 20
seconds.
(b) Clear DTC stored in memory (See page DI±223).
(c) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(d) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(e) Check DTC (See page DI±223).
OK:
DTC B0130/63 is not output.
HINT:
Codes other than code B0130/63 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK

H01021AB0118AB0119R13006H01082H01214
"u
E1 TcACC ON
orAirbag
Sensor
Assembly P/T Squib (RH)
DTC B0130/63 DLC1
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI±267
4 Check P/T squib (RH).
PREPARATION:
(a) Turn ignition switch to LOCK.
(b) Disconnect negative (±) terminal cable from the battery,
and wait at least for 90 seconds.
(c) Connect the seat belt pretensioner (RH) connector.
(d) Connect negative (±) terminal cable to the battery, and
wait at least for 2 seconds.
CHECK:
(a) Turn ignition switch to LOOK, and wait at least for 20 se-
cond.
(b) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(c) Clear DTC stored in memory (See page DI±223).
(d) Turn ignition switch to LOCK, and wait at least for 20 se-
conds.
(e) Turn ignition switch to ACC or ON, and wait at least for 20
seconds.
(f) Check DTC (See page DI±223).
OK:
DTC B0130/63 is not output.
HINT:
Codes other than code B0130/63 may be output at this time, but
they are not relevant to this check.
NG Replace seat belt pretensioner (RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.

H01019H02141H02205
P/T Squib (RH)Airbag
Sensor
Assembly
PR±
(+) (±) PR+
DI±268
± DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DTC B0131/64 Open in P/T Squib (RH) Circuit
CIRCUIT DESCRIPTION
The P/T squib circuit (RH) consists of the airbag sensor assembly and seat belt pretensioner (RH).
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see Pub. No. RM654U on page RS±2.
DTC B0131/64 is recorded when an open is detected in the P/T squib (RH) circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0131/64

Open circuit in PR+ wire harness or PR± wire harness of
squib

P/T squib (RH) malfunction

Airbag sensor assembly malfunction
Seat belt pretensioner (RH)

Airbag sensor assembly

Wire harness
WIRING DIAGRAM
See page DI±264.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI±305).
2 Check P/T squib (RH) circuit.
CHECK:
For the connector (on the seat belt pretensioner side) between
the seat belt pretensioner (RH) and the airbag sensor assem-
bly, measure the resistance between PR+ and PR±.
OK:
Resistance: Below 1 W
NG Repair or replace harness or connector be-
tween seat belt pretensioner (RH) and airbag
sensor assembly.
OK
DI1BG±20
