± PREPARATIONENGINE MECHANICAL (5S±FE)
58 Author: Date:
EQUIPMENT
Abrasive compoundValve
Caliper gauge
CO/HC meter
Compression gauge
Connecting aligner
Cylinder gauge
Dial indicator
Dye penetrant
Engine tune±up tester
Groove cleaning toolPiston ring groove
Heater
Magnetic finger
Micrometer
OBDII scan tool
Pin hole grinderPiston pin hole of piston
Piston ring compressor
Piston ring expander
Plastigage
Precision straight edge
Press
Ridge reamerCylinder
Soft brush
Solvent
Spring testerValve spring
Steel squareValve spring
Thermometer
Torque wrench
Valve seat cutter
V±block
Vernier calipers
Wire brushValve

PP1WA±02
± PREPARATIONENGINE MECHANICAL (5S±FE)
PP±7
59 Author: Date:
SSM (Special Service Materials)
08826±00080Seal Packing Black or equivalent
(FIPG)Camshaft bearing cap
Cylinder head cover
Semi±circular plug
08833±00070Adhesive 1324,
THREE BOND 1324 or equivalentFlywheel or drive plate bolt
Torque converter clutch bolt
08833±00080Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalentOil pressure switch

PP0BR±03
PP±8
± PREPARATIONENGINE MECHANICAL (1MZ±FE)
60 Author: Date:
ENGINE MECHANICAL (1MZ±FE)
SST (Special Service Tools)
09201±01055Valve Guide Bushing Remover & Re
placer 5.5
09201±41020Valve Stem Oil Seal Replacer
09202±70020Valve Spring Compressor
(09202±00010)Attachment
09213±54015Crankshaft Pulley Holding Tool
(91651±60855)Bolt
09222±30010Connecting Rod Bushing Remover
& Replacer
09223±15030Oil Seal & Bearing ReplacerCrankshaft rear oil seal
09248±55040Valve Clearance Adjust Tool Set
(09248±05410)Valve Lifter Press
(09248±05420)Valve Lifter Stopper
09249±63010Torque Wrench AdaptorRH camshaft timing pulley

± PREPARATIONENGINE MECHANICAL (1MZ±FE)
PP±9
61 Author: Date:
09330±00021Companion Flange Holding ToolCrankshaft pulley
09608±03071ReplacerSpark plug tube gasket
09816±30010Oil Pressure Switch SocketKnock sensor
09843±18020Diagnosis Check Wire
09950±50012Puller C Set
(09951±05010)Hanger 150Crankshaft pulley
Crankshaft timing pulley
(09952±05010)Slide ArmCrankshaft pulley
Crankshaft timing pulley
(09953±05010)Center Bolt 100Crankshaft pulley
Crankshaft timing pulley
(09953±05020)Center Bolt 150Crankshaft pulley
Crankshaft timing pulley
(09954±05010)Claw No.1Crankshaft timing pulley
(09954±05020)Claw No.2Crankshaft pulley
09950±70010Handle Set
(09951±07100)Handle 100Valve guide bushing
Crankshaft rear oil seal

PP±10
± PREPARATIONENGINE MECHANICAL (1MZ±FE)
62 Author: Date:
09960±10010Variable Pin Wrench Set
(09962±01000)Variable Pin Wrench Arm AssyCamshaft timing pulley
Camshaft sub±gear
(09963±01000)Pin 10Camshaft timing pulley
(09963±00500)Pin 5Camshaft sub±gear

PP0BS±03
± PREPARATIONENGINE MECHANICAL (1MZ±FE)
PP±11
63 Author: Date:
RECOMMENDED TOOLS
09040±00010Hexagon Wrench Set .
09090±04020Engine Sling DeviceFor suspending engine
09200±00010Engine Adjust Kit .
09258±00030Hose Plug Set .Plug for the vacuum hose, fuel
hose etc.
09904±00010Expander Set .

PP0BT±03
PP±12
± PREPARATIONENGINE MECHANICAL (1MZ±FE)
64 Author: Date:
EQUIPMENT
Abrasive compound
Caliper gauge
CO/HC meter
Connecting rod aligner
Cylinder gauge
Dial indicator
Dye penetrant
Engine tune±up tester
Groove cleaning tool
Heater
Magnetic finger
Micrometer
OBDII scan tool
Pin hole grinderPiston pin hole
Piston ring compressor
Piston ring expander
Plastigage
Precision straight edge
Ridge reamer
Soft brush
Spring testerValve spring
Steel squareValve spring
Thermometer
Torque wrench
Valve seat cutter
Vernier calipers
Wire brushValve

PP1WT±01
± PREPARATIONENGINE MECHANICAL (1MZ±FE)
PP±13
65 Author: Date:
SSM (Special Service Materials)
08826±00080Seal Packing Black or equivalent
(FIPG)Camshaft bearing cap
Semi±circular plug
Cylinder head cover
Rear oil seal retainer
08826±00100Seal Packing 1282B,
THREE BOND 1282B or equivalent
(FIPG)Engine coolant drain union
Water seal plate
Water inlet housing
08833±00070Adhesive 1324,
THREE BOND 1324 or equivalentSpark plug tube
Drive plate bolt
08833±00080Adhesive 1344
THREE BOND 1344
LOCTITE 242 or equivalentNo.1 idler pulley pivot bolt

PP0JU±04
PP±14
± PREPARATIONEMISSION CONTROL (5S±FE)
66 Author: Date:
EMISSION CONTROL (5S±FE)
SST (Special Service Tools)
09843±18020Diagnosis Check Wire

PP0JV±04
± PREPARATIONEMISSION CONTROL (5S±FE)
PP±15
67 Author: Date:
EQUIPMENT
Torque wrench
Hose clipper
Pressure gauge
Vacuum gauge
