TOYOTA CAMRY 1999 Service Repair Manual

PP0KA±01
PP±46
± PREPARATIONSTARTING (5S±FE)
98 Author: Date:
STARTING(5S±FE)
SST (Special Service Tools)
09286±46011Injection Pump Spline Shaft
PullerArmature bearing
09810±38140Starter Magnet Switch Nut Wrench
14Terminal nut
09820±00030Alternator Rear Bearing ReplacerArmature front bearing

PP0KB±01
± PREPARATIONSTARTING (5S±FE)
PP±47
99 Author: Date:
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.

PP0KC±01
PP±48
± PREPARATIONSTARTING (5S±FE)
100 Author: Date:
EQUIPMENT
Dial indicatorCommutator
Magnetic fingerSteel ball
PressMagnetic switch terminal kit part
Pull scaleBrush spring
SandpaperCommutator
Torque wrench
V±blockCommutator
Vernier calipersCommutator, Brush

PP0C9±01
± PREPARATIONSTARTING (1MZ±FE)
PP±49
101 Author: Date:
STARTING (1MZ±FE)
SST (Special Service Tools)
09286±46011Injection Pump Spline Shaft
PullerArmature bearing
09810±38140Starter Magnet Switch Nut Wrench
14Terminal nut
09820±00030Alternator Rear Bearing ReplacerArmature front bearing

PP0CA±01
PP±50
± PREPARATIONSTARTING (1MZ±FE)
102 Author: Date:
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.

PP0CB±02
± PREPARATIONSTARTING (1MZ±FE)
PP±51
103 Author: Date:
EQUIPMENT
Dial indicatorCommutator
Magnetic fingerSteel ball
PressMagnetic switch terminal kit
Pull scaleBrush spring
SandpaperCommutator
Torque wrench
V±blockCommutator
Vernier calipersCommutator, Brush

PP0KD±01
PP±52
± PREPARATIONCHARGING (5S±FE)
104 Author: Date:
CHARGING(5S±FE)
SST (Special Service Tools)
09285±76010Injection Pump Camshaft Bearing
Cone ReplacerRotor rear bearing cover
09286±46011Injection Pump Spline Shaft
PullerRectifier end frame
09820±00021Alternator Rear Bearing Puller
09820±00030Alternator Rear Bearing ReplacerRotor rear bearing
09820±63010Alternator Pulley Set Nut Wrench
Set
09950±60010Replacer Set
(09951±00500)Replacer 50Rotor front bearing

PP0KE±01
± PREPARATIONCHARGING (5S±FE)
PP±53
105 Author: Date:
RECOMMENDED TOOLS
09082±00040TOYOTA Electrical Tester.

PP0KF±01
PP±54
± PREPARATIONCHARGING (5S±FE)
106 Author: Date:
EQUIPMENT
Battery specific gravity gaugeExcept maintenance free battery
Belt tension gauge
Torque wrench
Vernier calipersRotor (Slip ring), Brush

PP0CC±01
± PREPARATIONCHARGING (1MZ±FE)
PP±55
107 Author: Date:
CHARGING (1MZ±FE)
SST (Special Service Tools)
09285±76010Injection Pump Camshaft Bearing
Cone ReplacerRotor rear bearing cover
09286±46011Injection Pump Spline Shaft
PullerRectifier end frame
09820±00021Alternator Rear Bearing Puller
09820±00030Alternator Rear Bearing ReplacerRotor rear bearing
09820±63010Alternator Pulley Set Nut Wrench
Set
09950±60010Replacer Set
(09951±00500)Replacer 50Rotor front bearing
