O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 35 of 43
CHART 26:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P2198
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.55 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Response Monitor
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$31Time to change from Lean
(30.4 V) to Rich (.0.55 V)N/ASecondBetween 0 and
0.9 seconds
Time
$32Time to change from Rich
(.0.55 V) to Lean (30.4 V)N/ASecondBetween 0 and
0.9 seconds
If the time required to change is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Engine Idling
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$33Average Lean (30.4 V) time of
one waveform cycleN/ASecondBetween 0 and
2.8 seconds
Time
$34Average Rich (.0.55 V) time of
one waveform cycleN/ASecondBetween 0 and
2.8 seconds
If the sum of Time $33 and Time $34 is out of the standard value, the ECM interprets this as a
malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 36 of 43
CHART 26 (Continued):
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Vehicle Running
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$35Average Lean (30.4 V) time of
one waveform cycleN/ASecond
Between 0 and
0.75 seconds
(varies depending
on feedback
compensation factor)
Time
$36Average Rich (30.55 V) time of
one waveform cycleN/ASecond
Between 0 and
0.75 seconds
(varies depending
on feedback
compensation factor)
If the sum of Time $35 and Time $36 is out of the standard value, the ECM interprets this as a
malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05 V
Multiply 0.3906%Between 0 and 60%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 37 of 43
CHART 27:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P2198
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and
0.35 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.45 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Response Monitor
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$31Time to change from Lean
(30.35 V) to Rich (.0.45 V)N/ASecondBetween 0 and
0.6 seconds
Time
$32Time to change from Rich
(.0.45 V) to Lean (30.35 V)N/ASecondBetween 0 and
0.6 seconds
If the time required to change is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Engine Idling
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$33Average Lean (30.35 V) time of
one waveform cycleN/ASecondBetween 0 and
3 seconds
Time
$34Average Rich (.0.45 V) time of
one waveform cycleN/ASecondBetween 0 and
3 seconds
If the sum of Time $33 and Time $34 is out of the standard value, the ECM interprets this as a
malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 38 of 43
CHART 27 (Continued):
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Vehicle Running
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$35Average Lean (30.35 V) time of
one waveform cycleN/ASecond
Between 0 and 0.55
seconds
(varies depending
on feedback
compensation factor)
Time
$36Average Rich (30.45 V) time of
one waveform cycleN/ASecond
Between 0 and 0.55
seconds
(varies depending
on feedback
compensation factor)
If the sum of Time $35 and Time $36 is out of the standard value, the ECM interprets this as a
malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05 V
Multiply 0.3906%Between 0 and 60%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 39 of 43
CHART 28:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Voltage Monitor
Related DTCs: P0130, P0150, P2195, P2196, P2197 and P2198
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and
0.35 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.45 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Response Monitor
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$31Time to change from Lean
(30.35 V) to Rich (.0.45 V)N/ASecondBetween 0 and
0.6 seconds
Time
$32Time to change from Rich
(.0.45 V) to Lean (30.35 V)N/ASecondBetween 0 and
0.6 seconds
If the time required to change is out of the standard value, the ECM interprets this as a malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Engine Idling
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$33Average Lean (30.35 V) time of
one waveform cycleN/ASecondBetween 0 and
2 seconds
Time
$34Average Rich (.0.45 V) time of
one waveform cycleN/ASecondBetween 0 and
2 seconds
If the sum of Time $33 and Time $34 is out of the standard value, the ECM interprets this as a
malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 40 of 43
CHART 28 (Continued):
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Vehicle Running
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$35Average Lean (30.35 V) time of
one waveform cycleN/ASecond
Between 0 and 0.5
seconds
(varies depending
on feedback
compensation factor)
Time
$36Average Rich (30.45 V) time of
one waveform cycleN/ASecond
Between 0 and 0.5
seconds
(varies depending
on feedback
compensation factor)
If the sum of Time $35 and Time $36 is out of the standard value, the ECM interprets this as a
malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05 V
Multiply 0.3906%Between 0 and 60%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 41 of 43
CHART 29:
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Engine Idling
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$33Average Lean (30.4 V) time of
one waveform cycleN/ASecondBetween 0 and
4 seconds
Time
$34Average Rich (.0.55 V) time of
one waveform cycleN/ASecondBetween 0 and
4 seconds
If the sum of Time $33 and Time $34 is out of the standard value, the ECM interprets this as a
malfunction.
Front O2S (Bank 1 Sensor 1 and Bank 2 Sensor 1) Frequency Monitor During
Vehicle Running
Related DTCs: P0133 and P0153
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$35Average Lean (30.4 V) time of
one waveform cycleN/ASecond
Between 0 and 1.08
seconds
(varies depending
on feedback
compensation factor)
Time
$36Average Rich (.0.55 V) time of
one waveform cycleN/ASecond
Between 0 and 1.08
seconds
(varies depending
on feedback
compensation factor)
If the sum of Time $35 and Time $36 is out of the standard value, the ECM interprets this as a
malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 42 of 43
CHART 29 (Continued):
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and 0.4 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05 V
Multiply 0.3906%Between 0 and 60%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 43 of 43
CHART 30:
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Voltage Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$07The minimum voltage during
O2S monitoringN/AVBetween 0 and
0.45 V
Time
$08The maximum voltage during
O2S monitoringN/AVBetween 0.5 and
1.275 V
If the sensor voltage is out of the standard value, the ECM interprets this as a malfunction.
Rear O2S (Bank 1 Sensor 2 and Bank 2 Sensor 2) Element Monitor
Related DTCs: P0136 and P0156
TEST IDDESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05 V
Multiply 0.3906%Between 0 and 80%
Time
$84Percentage of monitoring time
where Oxygen Sensor voltage is
0.70 V or more
Multiply 0.3906%Between 20 and
100%
Time
$85Maximum Rich (.0.45 V) timeMultiply 0.2621SecondBetween 20 and
66.8 seconds
If all the values (Time $81, Time $84 and Time $85) are out of the standard values, the ECM
interprets this as a malfunction. O2S
Failure
Threshold
Charts
(Continued)

Toyota Supports ASE CertificationPage 1 of 2
AC003-04Title:
A/C COMPRESSOR INSTALLATION
PROCEDURE
Models:
Applicable Models
Technical Service
BULLETIN
March 1, 2004

Use the following tip when installing an A/C compressor on the AZ or ZZ series engine
to ensure proper belt alignment. Improper installation of the A/C compressor may result
in abnormal belt noise or wear.
1998 ± Current model year Corolla vehicles.
2000 ± Current model year Celica vehicles.
2000 ± Current model year MR2 Spyder vehicles.
2001 ± Current model year Highlander vehicles equipped with 4 cylinder engine.
2001 ± Current model year RAV4 vehicles.
2002 ± Current model year Camry vehicles equipped with 4 cylinder engine.
2002 ± Current model year Solara vehicles equipped with 4 cylinder engine.
2003 ± Current model year Matrix vehicles.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
Belt
Bolt
Clearance
A/C CompressorOKNG
Proper Installation Improper Installation
HEATING & AIR CONDITIONING
Introduction
Applicable
Vehicles
Warranty
Information
Installation
Procedure
