Toyota Supports ASE CertificationPage 1 of 1
TC003±99Title:
AUTOMATIC TRANSMISSION FLUIDS
Models:
All Models
Technical Service
BULLETIN
May 21, 1999

REVISION NOTICE:
The information contained in this TSB updates TC003±98 dated June 19, 1998.
Automatic Transmission Fluid Type T±IV now replaces Type T±II fluid. Use Type T±IV for
all applications that specify ATF Type T±II.
Please refer to the following table for the interchangeability between each ATF.
All vehicles produced after 1993 with Automatic Transmissions specified to use
ATF Type T, T±II and T±IV.
SPECIFIED ATFTYPE OF ATFSPECIFIED ATFDEXTRON) II OR IIITYPE TTYPE T±IITYPE T±IV
DEXTRON) II OR IIIOKXXX
TYPE TXOKXOK
TYPE T±IIXXOKOK
TYPE T±IVXXXOK
X = NOT USABLE
NOTICE:
With the exception of mixing ATF Type T with Type T±IV fluids, different types of fluids
must not
be mixed.
SIZENEW PART NUMBERPART NAME
4 Liter08886±01705ATF Type T±IV
OP CODEDESCRIPTIONTIMEOPNT1T2
N/ANot Applicable to Warranty ±±±±
TRANSMISSION & CLUTCH
Introduction
Affected
Vehicles
Parts
Information
Warranty
Information

Use the following tables to locate and read the original automatic transmission serial number.
Title: AUTOMATIC TRANSMISSION SERIAL NUMBERSPage 1 of 3
DECEMBER 20, 1996
TRANSMISSION &
CLUTCH
TC004-96
ALL MODELS
TRANSMISSION TRANSMISSION
LOCATION
MODEL SERIAL NUMBER
*See Model Code chart on Page 3.96 A E 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
96 A Y 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
96 A ZT 00001
5-Digit Serial No.
*Model Code
Manufacturing Month:
A thru M (ªIº not used)
Last 2 Digits of
Manufacturing Year:
1996
A4#D#
A34##
A131L
(AW Product)
A24##

AUTOMATIC TRANSMISSION SERIAL NUMBERSPage 2 of 3
* Exception: 1991 ± K, 1992 (January±March) ± M, 1992 (April±December) ± B
NOTE: Remanufactured transmissions also have an additional serial number.
TRANSMISSION TRANSMISSION
LOCATION
MODEL SERIAL NUMBER
6 A 00001
50001
5-Digit Serial No.
Manufacturing Month:
A thru M (ªIº not used)
Last Digit of
Manufacturing Year:
1996
D 01 00001
5-Digit Serial No.
Manufacturing Month:
Manufacturing Year:
A541E:
`93-A, `94-B, `95-C
A540E, A540H:
`90-A, `91-B, `92-C
6 A 00001
5-Digit Serial No.
Manufacturing Month:
A thru M (ªIº not used)
Last Digit of
Manufacturing Year:
1996
A140#
A130L
A131L
(TMC Product)
A132#
A54#E
A540H
A44##
F A 50001
5-Digit Serial No.
Manufacturing Month:
A thru M (ªIº not used)
*Manufacturing Year:
`93-C, `94-D, `95-E
6 01 00001
5-Digit Serial No.
Manufacturing Month:
Last 2 Digits of
Manufacturing Year:
1996

AUTOMATIC TRANSMISSION SERIAL NUMBERSPage 3 of 3
MODEL CODE CHART:
CODE MODEL CODE MODEL
A A40 N A45DF, A44D, A45D
w/o Lock-up
B A40D, A40DF P A44DL, A45DF, A45DL
w/Lock-up
C A42D Q A44DE, A45DF, A45DE
ECT, w/Lock-up
D A41 R A340E, A340F
w/lock-up
E A343F S A340H
w/Lock-up
F A43D T A340E
w/o Lock-up
H A43DL U A341H
K A42DL Y A131, A131L
Z A240L, A241L, A242L,
L A43DE, A46DE, A46DF A243L, A2444L, A240E,
A241E, A242E, A244E,
A244F, A241H
M A42DE ZT A245E, A246E

TC008±89 TECHNICAL ASSURANCE DEPARTMENT
TOYOTA
SERVICE BULLETIN
TOYOTA MOTOR SALES, U.S.A., INC.VOLUME
10
REFERENCE
NUMBER
DATE
MODEL
TRANSMISSION &
CLUTCH
008 (REVISED)
03±22±02
Page 1 of 2
A/TM NUMBER AND LOCATION INFORMATION
The purpose of this Service Bulletin is to provide information regarding the location of the A/TM
numbers.
NOTE:
The transmission numbers must be included on the AUTOMATIC TRANSMISSION CORE
INFORMATION/CREDIT REQUEST FORM when using the automatic transmission reman.
program.
AE, ST, SV, VV
(A131L) BR12E or BR18E
(A140E) BG, EG, CG, FG, DG
(A540e) ZF, GF19C

TECHNICAL ASSURANCE DEPARTMENT
TC008±89
Page 2 of 2
A/TM NUMBER AND LOCATION INFORMATION (CONT'D)

Toyota Supports ASE CertificationPage 1 of 43
SS002-03Title:
O2S TEST RESULTS (MODE 05)
Models:
All '96 ± '03, '04 Corolla, ECHO, Matrix, Sienna
& Scion xA & xBTechnical Service
BULLETIN
December 17, 2003
This Service Bulletin contains Oxygen Sensor (O2S) Monitor threshold values for all
models from 1996 to 2003 and some 2004 models. Starting in 2004, the O2S Monitor
threshold values can be found in the repair manual. These values are used when
analyzing the O2S test results to determine the O2S condition.
All 1996 ± 2003 model year Toyota vehicles.
2004 model year Corolla, ECHO, Matrix and Sienna vehicles.
2004 model year Scion xA and xB vehicles.
Checking O2S Test Results
To view O2S test results, the O2S Monitor must be completed and the test results must
be checked within the same key cycle. If the ignition key is cycled OFF, the O2S test
results will be set to the minimum or maximum limits, and all test results will be erased.
The O2S test results are stored in the ECU (SAE term: Powertrain Control Module/PCM)
when the monitor is completed. The test results are static and will not change once the
monitor is complete.
The process for checking O2S test results is described in the following three basic steps:
1. Completing the O2S Readiness Monitor (page 2).
2. Accessing O2S Test Results (page 3).
3. Comparing O2S Test Results to Failure Thresholds (page 4).
SPECIAL SERVICE TOOLS (SSTs)PART NUMBERQUANTITY
Toyota Diagnostic Tester Kit*
(or any OBDII Scantool)
010012711
12 Megabyte Diagnostic Tester Program Card
with version 10.1a Software (or later)*01002593-0051
* Essential SSTs.
NOTE:
Additional Diagnostic Tester Kits, Program Cards or other SSTs may be ordered by
calling SPX/OTC at 1-800-933-8335.
OP CODEDESCRIPTIONTIMEOFPT1T2
N/ANot Applicable to Warranty±±±±
SPECIAL SERVICE TOOLS
Introduction
Applicable
Vehicles
Function
Description
Required
SSTs
Warranty
Information

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 2 of 43
1. Clear any stored Diagnostic Trouble Codes (DTCs) using the Toyota
Diagnostic Tester.
2. Start the engine.
3. Perform the drive pattern below to run and complete the Oxygen Sensor (O2S) Monitor.
O2S Monitor Drive Pattern
ECT: 167
F (75
C) or more
Vehicle Speed
At Least 8 Times
48 km/h (30 mph)
IdlingAt Least Twice Accelerator Pedal
DepressingAccelerator Pedal
Releasing (Fuel±Cut)
6 mph
(10 km/h)
Time2 min.
or more40 sec
or more20 sec
or more10 sec
or more10 sec
or more
HINT:
The O2S Monitor is completed when the following conditions are met:
Two (2) minutes or more passed after the engine start.
The Engine Coolant Temperature (ECT) is 167
F (75
C) or more.
Cumulative running time at 30 mph (48 km/h) or more exceeds 6 minutes.
Vehicle is in closed loop.
The fuel±cut is operated for 8 seconds or more (for Rear O2S Monitor).
A. Allow the engine to idle for two minutes.
B. Warm up the engine until the Engine Coolant Temperature (ECT) reaches 167
F
(75
C).
C. Drive the vehicle over 30 mph (48 km/h) for more than 40 seconds.
D. Stop the vehicle and allow the engine to idle for more than 20 seconds.
E. Repeat steps C and D at least 8 times in one driving cycle.
(Do not cycle the ignition key.)
In addition, perform the following steps for the Rear O2S Readiness Monitor:
A. Select second gear.
B. Allow the vehicle to run at 30 mph (48 km/h) or more.
C. Keep the accelerator pedal ªoff±idleº for more than 10 seconds.
D. Immediately after step C, release the accelerator pedal for at least 10 seconds
without depressing the brake pedal (to execute the fuel±cut).
E. Decelerate the vehicle until the vehicle speed reaches less than 6 mph (10 km/h).
F. Repeat steps B ± E at least twice in one driving cycle.
Completing
O2S
Readiness
Monitor

O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 3 of 43
1. On the Diagnostic Tester* screen,
select the following menus:
DIAGNOSTICS
CARB OBD II
O2S TEST RESULTS
A list of the available oxygen sensors
will be displayed.
2. Select the desired oxygen sensor and
press Enter.
NOTE:
The monitor result of the A/F sensor will
not be displayed. If you select
ªBank 1±Sensor 1º or Bank 2±Sensor 1º
for a vehicle equipped with an A/F
sensor, the Diagnostic Tester will
display ªNo parameter to display.º
3. Compare the test results with the
values listed in the Failure
Threshold Chart.
* Although this procedure references the Toyota
Diagnostic Tester, the O2S test results can be
checked using a generic OBDII scantool.
Refer to your OBDII scantool operator's manual
for specific procedures.
Accessing
O2S Test
ResultsO2S TEST RESULT Screen
01 BANK 1 ± SENSOR 1
01 BANK 1 ± SENSOR 2
01 BANK 2 ± SENSOR 1
01 BANK 2 ± SENSOR 2
TEST DATA Screen
LOW SW V 0.400 V
HIGH SW V 0.550 V
MIN O2S V 0.100 V
MAX O2S V 0.900 V
TIME $81 17

NOTE:
Before the O2S Monitor completes or after the ignition switch is turned OFF, the
Diagnostic Tester displays the viewable upper limit or a lower limit of the test value
(example: 0 V, 1.275 V, 0 s [seconds], 10.2 s, 0 and 255).
O2S TEST RESULTS (MODE 05) ± SS002-03December 17, 2003
Page 4 of 43
1. Determine the correct O2S Failure Threshold Chart for your vehicle by looking in the
ªO2S Application Table,º pages 5 ± 9 in this bulletin.
2. Select appropriate year, model, and engine for specified O2S Failure
Threshold Chart.
3. Compare O2S test results with the specified O2S Failure Threshold Chart. It may be
necessary to convert O2S test results to a specific measurement unit using the
conversion factor that is supplied in the specified table. See example below:
Example:
A. The Diagnostic Tester displays
ª17º as a value of the ªTime $81º
(see illustration).
B. Find the Conversion Factor value
of ªTime $81º in the O2S Failure
Threshold chart below.
0.3906 is specified for Time $81
in this chart.
C. Multiply ª17º in step ªAº by 0.3906
(Conversion Factor) in step ªB.º
17 x 0.3906 = 6.6 %
D. If the answer is within the
Standard Value of TEST LIMIT,
the ªTime $81º can be confirmed
to be normal.
Example of O2S Failure Threshold Chart:
TEST ID
DESCRIPTION OF TEST DATACONVERSION
FACTORUNITSTANDARD VALUE
OF TEST LIMIT
Time
$81Percentage of monitoring time
where Oxygen Sensor voltage is
less than 0.05V
Multiply 0.3906%Within 60%
Comparing
O2S Test
Results to
Failure
Thresholds
Example
LOW SW V 0.400 V
HIGH SW V 0.550 V
MIN O2S V 0.035 V
MAX O2S V 0.835 V
Time $81 17
Time $84 84
Time $85 79
NOTE:
ªLOW SW Vº indicates the O2S
voltage when the O2S status changes
from rich to lean.
ªHIGH SW Vº indicates the O2S
voltage when the O2S status changes
from lean to rich.
If the O2S voltage is lower than
ªLOW SW V,º the O2S status is lean.
If the O2S voltage is higher than
ªHIGH SW V,º the O2S status is rich.
