TOYOTA CAMRY 1999 Service Repair Manual

L PART NUMBER OF CONNECTORS
Code Part Name Part NumberCodePart Name Part Number
Note : Not all of the above part numbers of the connector are established for the supply. In case of ordering
a connector or terminal with wire, please confirm in advance if there is supply for it using ªParts Catalog
Newsº (published by Parts Engineering Administration Dept.).
A 1A/C Condenser Fan Motor90980±10928
A 2A/C Magnetic Clutch and Lock Sensor90980±10942
A 3A/C Triple Pressure SW (A/C Dual and
Single Pressure SW)90980±10943
A 4ABS Actuator90980±11413
A 5ABS Actuator90980±10891
A 6ABS Speed Sensor Front LH90980±11075A 7ABS Speed Sensor Front RH90980±11 075
A 8Air Fuel Ratio Sensor90980±11178
A 9Airbag Sensor Front LH90980±11856A10Airbag Sensor Front RH90980±11 856
A11A/C Evaporator Temp. Sensor90980±10825
A12A/C SW90980±10631
A13ABS ECU90980±11424
A14ABS ECU90980±11390
A15Air Vent Mode Control Servo Motor90980±11165
A16Airbag Squib (Front Passenger Airbag
Assembly)90980±11884
A17Airbag Squib (Steering Wheel Pad)90980±10850
A18Ashtray Illumination81945±33010
A19ABS Speed Sensor Rear LH90980±11060A20ABS Speed Sensor Rear RH90980±11060
B 1Brake Fluid Level Warning SW90980±11207
B 2Blower Motor90980±10903
B 3Blower Resistor90980±10976
B 4Blower SW90980±10877
B 5Buckle SW LH90980±10825
C 1Camshaft Position Sensor90980±10947C 2Crankshaft Position Sensor90980±10947
C 3Cruise Control Actuator90980±11150
C 4Center Airbag Sensor Assembly90980±11869
C 5Center Airbag Sensor Assembly90980±11872
C 6Center Airbag Sensor Assembly90980±11867
C 7Cigarette Lighter90980±10760
C 8Cigarette Lighter Illumination90980±11148
C 9Clock90980±11013
C10Combination Meter90980±11114
C11Combination Meter90080±98046
C12Combination Meter90980±11115
C13Combination SW90980±11594
C14Combination SW90980±11616
C15Combination SW90980±11672
C16Cruise Control ECU90980±11391
C17Condenser90980±10860
D 1Data Link Connector 190980±11323
D 2Data Link Connector 290980±11417
D 3Data Link Connector 390980±11665
D 4Diode (Courtesy)90980±10962D 5Diode (Dome)90980±10962
D 6Diode (Idle±Up)90980±11071
D 7Door Courtesy SW Front LH
D 8Door Courtesy SW Front RH90980±10871D 9Door Courtesy SW Rear LH90980±10871
D10Door Courtesy SW Rear RH
D11Door Key Lock and Unlock SW Front LH90980±11490D12Door Key Lock and Unlock SW Front RH90980±11490
D13Door Lock Control SW RH90980±11326
D14Door Lock Motor and Door Unlock
Detection SW Front LH
D15Door Lock Motor and Door Unlock
Detection SW Front RH
90980±11150
D16Door Lock Motor and Door Unlock
Detection SW Rear LH90980±11 150
D17Door Lock Motor and Door Unlock
Detection SW Rear RH
E 1Electronically Controlled Transmission
Solenoid90980±11156
E 2Electronically Controlled Transmission
Solenoid90980±11143
E 3Engine Coolant Temp. Sensor90980±10737
E 4Engine Control Module90980±11392
E 5Engine Control Module90980±11391
E 6Engine Control Module90980±11390
E 7Engine Control Module90980±11408
F 1Front Turn Signal Light and Parking Light
LH
90980±11020
F 2Front Turn Signal Light and Parking Light
RH90980±11020
F 3Front Wiper Motor90980±11599
F 4Fuel Pressure Sensor (Delivery Pipe)90980±10845F 5Fuel Pressure Sensor (Fuel Pipe)90980±10845
F 6Fuel Shutoff Valve (Delivery Pipe)90980±11156
F 7Fuel Shutoff Valve (Fuel Pressure
Regulator)90980±11038
F 8Fuel Temp. Sensor (Delivery Pipe)90980±10737
F 9Fusible Link Block90980±09566
F10Fusible Link Block90980±09567
F11Fusible Link Block90980±09566
F12Fusible Link Block99141±13006
F13Fusible Link Block82620±06010
F14Fusible Link Block90980±11579
F15Front Door Speaker LH90980±10825F16Front Door Speaker RH90980±10825
F17Fuel Temp. Sensor and Fuel Shutoff Valve
(Fuel Tank)90980±10795
G 1Generator90980±09213

L
CodePart Name Part NumberCodePart Name Part Number
G 2Generator90980±11349
G 3Glove Box Light and SW90980±11098
H 1Headlight LH90980±11314H 2Headlight RH90980±11314
H 3Horn (High)90980±10619H 4Horn (Low)90980±10619
H 5Hazard SW90980±10801
H 6Heated Oxygen Sensor90980±11028
H 7Heater Control SW90980±10799
H 8High Mounted Stop Light90980±11148
I 1Idle Air Control Valve90980±11145
I 2Ignition Coil and Igniter No.190980±11150I 3Ignition Coil and Igniter No.290980±11 150
I 4Injector No.1
I 5Injector No.290980±11153I 6Injector No.390980±11 153
I 7Injector No.4
I 8Intake Air Temp. Sensor90980±11163
I 9Ignition Key Cylinder Light90980±10906
I10Ignition SW90980±11615
I11Integration Relay90980±11107
I12Integration Relay90980±11542
I13Interior Light90980±10121
J 1Junction Connector90980±10803
J 2Junction Connector90980±11542
J 3Junction Connector90980±10803
J 4Junction Connector90980±11542
J 5Junction Connector90980±11502
J 6Junction Connector90980±11661J 7Junction Connector90980±11661
J 8Junction Connector90980±11398
J 9Junction Connector90980±10976
J10Junction Connector90980±11661J11Junction Connector90980±11661
J12Junction Connector90980±10803
J13Junction Connector90980±11661J14Junction Connector90980±11661
J15Junction Connector90980±10803
J16Junction Connector90980±11661J17Junction Connector90980±11661
J18Junction Connector90980±11542J19Junction Connector90980±11542
J20Junction Connector90980±11539
J21Junction Connector90980±11529
J22Junction Connector90980±11502
J23Junction Connector
J24Junction Connector90980±11661J25Junction Connector90980±11661
J26Junction Connector
J27Junction Connector90980±11542
J28Junction Connector90980±11661J29Junction Connector90980±11661
J30Junction Connector90980±10803
J31Junction Connector90980±11661J32Junction Connector90980±11661
J33Junction Connector90980±10803
J34Junction Connector90980±10976
J35Junction Connector90980±10803
K 1Key Interlock Solenoid90980±10825
L 1License Plate Light LH90980±11148L 2License Plate Light RH90980±11148
L 3Light Failure Sensor90980±10803
L 4Luggage Compartment Light90980±11148
L 5Luggage Compartment Light SW90980±11097
M 1Manifold Absolute Pressure Sensor90980±10845
N 1Noise Filter (Ignition)90980±10843
N 2Noise Filter (Rear Window Defogger)90980±11259
O 1Oil Pressure SW90980±11363
O 2O/D Main SW and A/T Shift Lever
Illumination90980±10795
P 1Park/Neutral Position SW,A/T Indicator Light
SW and Back±Up Light SW90980±11332
P 2Power Steering Oil Pressure SW90980±11428
P 3Parking Brake SW90980±10871
P 4Power Outlet90980±10760
P 5Power Window Control SW Front RH90980±10789
P 6Power Window Control SW Rear LH90980±10631P 7Power Window Control SW Rear RH90980±10631
P 8Power Window Master SW and Door Lock
Control SW LH90980±10807
P 9Power Window Motor Front LH
P10Power Window Motor Front RH90980±10860P11Power Window Motor Rear LH90980±10860
P12Power Window Motor Rear RH
P13Pretensioner LH90980±11862P14Pretensioner RH90980±11862
R 1Radiator Fan Motor90980±10928
R 2Radio and Player90980±10996
R 3Radio and Player90980±10997
R 4Rear Window Defogger SW90980±11280
R 5Remote Control Mirror SW90980±11450

L PART NUMBER OF CONNECTORS
Code Part Name Part NumberCodePart Name Part Number
Note : Not all of the above part numbers of the connector are established for the supply. In case of ordering
a connector or terminal with wire, please confirm in advance if there is supply for it using ªParts Catalog
Newsº (published by Parts Engineering Administration Dept.).
R 6Rheostat90980±10908
R 7Rear Combination Light LH90980±10795
R 8Rear Combination Light LH90980±11001
R 9Rear Combination Light RH90980±10795
R10Rear Combination Light RH90980±11001
R11Rear Speaker LH90980±10860R12Rear Speaker RH90980±10860
Remote Control Mirror LH (w/ Mirror Heater)90980±10558
R13Remote Control Mirror LH (w/o Mirror
Heater)90980±10395
R14
Remote Control Mirror RH (w/ Mirror
Heater)90980±10558
R14Remote Control Mirror RH (w/o Mirror
Heater)90980±10395
S 1Starter90980±09689
S 2Starter90980±11400
S 3Shift Lock ECU90980±11488
S 4Stop Light SW90980±11118
T 1Throttle Position Sensor90980±11261
T 2Turn Signal Flasher82751±50010
U 1Unlock Warning SW90980±10860
V 1Vehicle Speed Sensor (Combination Meter)90980±11143
V 2VSV (EGR)90980±11156
W 1Washer Level Warning SW90980±11068
W 2Washer Motor90980±10981
W 3Water Temp. Sender90980±11428
W 4Water Temp. SW No.190980±11235

L
CodePart Name Part NumberCodePart Name Part Number

M OVERALL ELECTRICAL WIRING DIAGRAM

M
[A]: System Title
[B]: Indicates the wiring color.
Wire colors are indicated by an alphabetical code.
B = Black W = White BR = Brown
L = Blue V = Violet SB = Sky Blue
R = Red O = Orange LG = Light Green
P = Pink Y = Yellow GR = Gray
G = Green
The first letter indicates the basic wire color and the
second letter indicates the color of the stripe.
Example: L ± Y
L
(Blue)Y
(Yellow)
[C]: The position of the parts is the same as shown in
the wiring diagram and wire routing.
[D]: Indicates the pin number of the connector.
The numbering system is different for female
and male connectors.
Example :
Numbered in order
from upper left to
lower rightNumbered in order
from upper right to
lower left
Female Male
The numbering system for the overall wiring
diagram is the same as above
[E]: Indicates a Relay Block. No shading is used and
only the Relay Block No. is shown to distinguish
it from the J/B.
Example : Indicates Relay Block No.1
[F]: Junction Block (The number in the circle is the
J/B No. and the connector code is shown beside
it). Junction Blocks are shaded to clearly
separate them from other parts.
3C indicates
that it is inside
Junction Block
No.3 Example:

[G]: Indicates related system.
[H]: Indicates the wiring harness and wiring harness
connector. The wiring harness with male
terminal is shown with arrows (
).
Outside numerals are pin numbers.
Female Male ( )
[I]: ( ) is used to indicate different wiring and
connector, etc. when the vehicle model, engine
type, or specification is different.
[J]: Indicates a shielded cable.
[K]: Indicates and located on ground point.
[L]: The same code occuring on the next page
indicates that the wire harness is continuous.

SYSTEM INDEX
M OVERALL ELECTRICAL WIRING DIAGRAM
SYSTEMS LOCATION SYSTEMS LOCATION
ABS 15±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 19±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Back±Up Light 5±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging 1±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter and Clock 12±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Combination Meter 17±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruse Control 13±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Lock Control 11±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electronically Controlled Transmission and A/T Indicator 3±2. . . . . . . . . .
Engine Control 2±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight 4±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 16±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illumination 7±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Light 6±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Reminder and Seat Belt Warning 16±2. . . . . . . . . . . . . . . . . . . . . . . .
Light Auto Turn Off 6±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Power Outlet 12±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Source 1~19±1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Window 10±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Fan and Condenser Fan 18±3. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio and Player 11±7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Window Defogger and Mirror Heater 18±2. . . . . . . . . . . . . . . . . . . .
Remote Control Mirror 9±3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lock 12±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SRS 14±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting and Ignition 1±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stop Light 8±4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillight 8±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Hazard Warning Light 5±2. . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper and Washer 9±2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

M

1
234
1 CAMRY CNG ELECTRI CAL WI RI NG DI AGRAM
A 13 2ACC
IG1
IG2
ST2 AM1 4
6
8 7AM2
B
1B 54 1K 5
5A ALT±S
B
30A AM2 40A MAIN
S IGB
A A 2 1
3 5 2L 4
L A 1 2C 3
12A 2B32D52K92J11
1F 2F 1B
1AC 1
40A AM1
1K 2
11B
1B
1
A
IF5A
IGN 1K 41K3
1J 31C8
65
P
N
10 IG2
B±W
GR
B
I nst rument panel
brac e LH B±R1K 1
1J 2
IE2 4
EB1 6 8
4IJ2 1T B±R
R GRC
423 B±Y
324 W
CC W
1 1
B W± R
W± R
W
WB±RB±R
B±RB
B± GB±G B± R W± B B±W
GRY Y
BR
Y±R
W± R
W± R
B
BR B±R B±R
B±R B±R B±R B±Y
WR± L R± LB±G B±W
P 1
PARK/ NEUTRAL
POSITI ON SW I10
IGNI TION SW
ST REL AY
100A
ALTF1 0 , F 9
FUSI BL E L I NK
BL OCK
STARTER
BATTERYA
FL MAIN
3. 0WB
J 6 A
JUNCTION
CONNE CTORB J 7 , I 2
IGNITION
COI L AND
IGNITER
NO. 1J19
JUNCTION CONNECTOR
I 3
IGNITION
COIL AND
IGNITER
NO. 2
G 1 AG 2
GENERATOR
A 1 2
A
ABR
W±R
To Engine Contr ol
Module< 2±11>
BRJ18
JUNCTION
CONNECTOR ,
A
J 9
JUNCTION
CONNE CTOR
To Engine Control
Module< 2±11> 10A GAUGE
To B u lb Ch eck Re l ay
[Comb. Met er] < 17±6>
11 IG2
GR
B B
J22
JUNCTI ON
CONNECTOR
1
B±RC
N 1
NOI SE F I L TER
(
Ignition)
1
3 2 GND IGT IGF IGF IGT GND+B +B
Power Source Starting and Ignition Charging
To Engine Control
Module< 2±10>
B S 1 A , S 2 F1 1 FCF14,
B,
1 2
Y
EC Intake manifold
B±R B±RC B
B±W CHARGE WARNING
LIGHT[COMB. METER]B A C1 0 C1 1,
5A
ST ARTER
BA BA BA GR
12 IG3

M OVERALL ELECTRICAL WIRING DIAGRAM
1
234
(
Cont . next page)
2 CAMRY CNG
EFI RELAYCIR OPN RELAY
20A EFI
40A AM1 30A AM2
7. 5A OBD
2 1
3 5
2 1
3 5 1J 10 1K22L 41K 5
82J 2K7
11
1B 41B12A12C10 2J 22F4
11 1B 5
L±B
AM2 6
I10
IGNITION SW4 AM1
ST2IG2
2 IG1 ACC
7 2
11K 31K
5A
IGN
4EB1 5EB1
EB Left radiator
s ide s upport 1F 2F 1C
1A
B±G
BATTERY10A
GA UGE
71WB± Y B± Y
1D 2B± Y
FUSIBLE LINK BLOCK10 IF1
FL MAIN
3. 0WBA
100A
AL T
B±Y
1B±R
BB W±R
2
B±R
BR
IG3 9
BR
A
B±R
B±RB
Y
C
LG
Y
B±Y
LG±B
L±W
B±Y
B±Y B±Y
R± L G± R G± R
2
G± R
3
BB±Y W± B M 1
MANIFOLD ABSOLUTE
PRESSURE SENSORT 1
THROTTLE POSITI ON
SENSOR
B±RL±B L±B
L±B G±R
W± R
W
B
IG2 1
B± R F17
FUEL TEMP. SENSOR AND
FUEL SHUTOFF VALVE (
Fuel Tank)
B± R
1
A1 1
A/ C EVAPORATOR
TEMP. SENSOR
ON ML KJI H G
B±R
Y
LG
B± Y
LG±B
L±R
G±R
G±R
B± Y
B
C12
MALFUNCTION
I NDI CA TOR L AMP
[COMB. METER]
7
2 D D
J 3
JUNCTION
CONNECTOR
JUNCTION
CONNECTOR
B±Y
23 31 1
12
R± LB
PIM VCE2
B± R
Power SourceEngine Control
D
E
F
BR
4IB1 BR
3IG2
BR BR
7IB1
LG±B
EA
W±B
L±R
EA BAL±B
B±YB± Y
, F11 F 9 A C , F14 FB J23 J24A,
2C 5
W± B
B±Y L±B
2IG1
BKUnder the left
center pillar B±RB±R
B±Y
B±R
A
J34
JUNCTION
CONNECTOR
W± B
LG±BBR
B± R BR
2IB1
BR4BR
