4-3. Do-it-yourself maintenance
4
Maintenance and care
4 RR FOG
10 A No circuit
5 FR DEF 15 A No circuit
6 AM2 7.5 A Starting system
7 ALT-S 7.5 A Charging system
8 MAYDAY/TEL 7.5 A No circuit
9 E-ACM 10 A No circuit
10 ETCS 10 A Electronic throttle control system
11 HAZ 15 A Turn signal lights
12 IG2 20 AMultiport fuel injection system/
sequential multiport fuel injection
system, starting system, “GAUGE
NO.2” and “IGN” fuses
13 STR LOCK 20 A Steering lock system
14 DOME 10 AGauges and meters, vanity lights,
trunk light, engine switch light, door
courtesy lights, interior light, per-
sonal lights, clock, smart key sys-
tem
15 ECU-B NO.1 10 A Wireless remote control system,
front passenger occupant classifi-
cation system, main body ECU,
vehicle stability control system
16 RADIO NO.1 15 A Audio system, navigation system
17 DOOR NO.1 25 A Main body ECU
18 AMP 25 A Audio system
19 EFI MAIN 30 AMultiport fuel injection system/
sequential multiport fuel injection
system, electronic throttle control
system, “EFI NO.2”, and “EFI
NO.3” fuses
FuseAmpereCircuit

362 4-3. Do-it-yourself maintenance
20 EFI NO.310 AMultiport fuel injection system/
sequential multiport fuel injection
system
21 EFI NO.2 15 AMultiport fuel injection system/
sequential multiport fuel injection
system
22 S-HORN 7.5 A Horn
23 A/F 20 AMultiport fuel injection system/
sequential multiport fuel injection
system
24 MPX-B 10 A Gauges and meters
25 EFI NO.1 10 ATheft deterrent system, smart key
system, multiport fuel injection sys-
tem/sequential multiport fuel injec-
tion system, electronic throttle
control system
26 HORN 10 A Horns
27 H-LP(RL) 15 A Right-hand headlight (low beam)
28 H-LP(LL) 15 A Left-hand headlight (low beam)
29 H-LP(RH) 15 A Right-hand headlight (high beam)
30 H-LP(LH) 15 A Left-hand headlight (high beam)
31 HTR 50 A Air conditioning system
32 ABS NO.1 50 AAnti-lock brake system, vehicle sta-
bility control system, traction con-
trol system, brake assist system
33 FAN MAIN 50 A Electric cooling fans
34 ABS NO.2 30 AAnti-lock brake system, vehicle sta-
bility control system, traction con-
trol system, brake assist system
35 RR DEF 50 ARear window defogger, “MIR HTR”
fuse
36 RR PWR SEAT 30 A No circuit
FuseAmpereCircuit

363
4-3. Do-it-yourself maintenance
4
Maintenance and care
37 H-LP CLN
30 A No circuit
38 CDS FAN 40 A Electric cooling fans
39 RDI FAN 40 A Electric cooling fans
40 MSB 30 A No circuit
41 ALT 120 A“RR FOG”, “FR DEF”, “HTR”, “ABS
NO.1”, “FAN MAIN”, “ABS NO.2”,
“RR DEF”, “RR PWR SEAT”, “H-
LP CLN”, “CDS FAN”, “RDI FAN”
and “MSB” fuses
42 ST/AM2 30 A Starting system
FuseAmpereCircuit

364 4-3. Do-it-yourself maintenance
■Under the instrument panel
FuseAmpereCircuit
1 RR DOOR RH 25 A Rear right power window
2 RR DOOR LH 25 A Rear left power window
3 FUEL OPN 7.5 A No circuit
4 FR FOG 15 A Front fog lights
5 OBD 7.5 A On-board diagnosis system
6 ECU-B NO.2 7.5 A No circuit
7 STOP 10 A Stop lights, high mounted stop-
light, shift lock control system, mul-
tiport fuel injection system/
sequential multiport fuel injection
system, main body ECU, anti-lock
brake system, vehicle stability con-
trol system, traction control system,
brake assist system, electronic
throttle control system
8 TI&TE 30 A No circuit
9 AM1 7.5 A Starting system, multiport fuel
injection system/sequential multi-
port fuel injection system

365
4-3. Do-it-yourself maintenance
4
Maintenance and care
10 A/C
7.5 A Air conditioning system
11 PWR 25 A Power windows
12 DOOR NO.2 25 A Main body ECU
13 S/ROOF 30 A Electric moon roof
14 TAIL 15 AFront side marker lights, tail lights,
rear side marker lights, license
plate lights, front turn signal/park-
ing lights
15 PANEL 7.5 ANavigation system, seat heaters,
emergency flashers, air condition-
ing system, audio system, clock,
glove box light, instrument panel
lights, steering switches
16 ECU IG NO.1 10 A Main body ECU, electric moon
roof, tire pressure warning system,
electric cooling fans, auto anti-glare
inside rear view mirror
17 ECU IG NO.2 7.5 A Anti-lock brake system, vehicle sta-
bility control system, traction con-
trol system, brake assist system,
shift lock control system, auto-
matic transmission, cruise control
system
18 A/C NO.2 10 AAir conditioning system, rear win-
dow defogger
19 WASH 10 A Windshield wipers and washer
20 S-HTR 20 A Seat heaters
21 GAUGE NO.1 10 A Emergency flashers, back-up
lights, charging system
22 WIP 25 A Windshield wipers and washer
23 H-LP LVL 7.5 A No circuit
FuseAmpereCircuit

366 4-3. Do-it-yourself maintenance
24 INJ15 AMultiport fuel injection system/
sequential multiport fuel injection
system, starting system
25 IGN 10 AMultiport fuel injection system/
sequential multiport fuel injection
system, theft deterrent system,
SRS airbag system, steering lock
system, front passenger occupant
classification system, smart key
system, electronic throttle control
system
26 GAUGE NO.2 7.5 A Gauges and meters, multi-informa-
tion display, clock
27 ECU-ACC 7.5 A Clock, main body ECU, shift lock
control system, outside rear view
mirror, smart key system
28 CIG 20 A Power outlet
29 PWR OUTLET 20 A Power outlet
30 RADIO NO.2 7.5 A Audio system, navigation system
31 MIR HTR 10 A Outside rear view mirror defoggers
32 POWER 30 A Power windows
33 P/SEAT 30 A Power seats
■ After a fuse is replaced
●If the lights do not turn on even after the fuse has been replaced, a bulb
may need replacing. ( P. 368)
● If the replaced fuse blows again, have the vehicle inspected by your
Toyota dealer.
■ If there is an overload in the circuits
The fuses are designed to blow before the entire wiring harness is damaged.
FuseAmpereCircuit

367
4-3. Do-it-yourself maintenance
4
Maintenance and care
CAUTION
■
To prevent system breakdowns and vehicle fire
Observe the following precautions.
Failing to do so may cause damage, and possibly a fire or injury.
●Never use a fuse of a higher amperage rating than indicated, or use any
other object in place of a fuse.
● Always use a genuine Toyota fuse or equivalent.
Never replace a fuse with a wire, even as a temporary fix.
This can cause extensive damage or even fire.
● Do not modify the fuse or the fuse box.
NOTICE
■Before replacing fuses
Have the cause of electrical overload determined and repaired by your
Toyota dealer, as soon as possible.

368
4-3. Do-it-yourself maintenance
Light bulbs
You may replace the following bulbs yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb
replacement seems difficult to perfor m, contact your Toyota dealer.
For more information about replacing other light bulbs, contact your
Toyota dealer.
■ Prepare a replacement light bulb.
Check the wattage of the light bulb being replaced. ( P. 438)
■ Remove the engine compartment cover. (3.5 L V6 [2GR-FE]
engine only)
 P. 3 1 8
■ Bulb locations
Headlight high beam
Headlight low beam
Rear turn signal light
Stop/tail and rear side marker light

369
4-3. Do-it-yourself maintenance
4
Maintenance and care
Replacing light bulbs
■ Headlight
Turn the bulb base counterclock-
wise.
Headlight (low beam)
Headlight (high beam)
Unplug the connector while
depressing the lock release. Headlight (low beam)
Headlight (high beam)
■ Rear turn signal, stop/tail a nd rear side marker lights
Open the trunk lid and remove
the cover.
STEP1
STEP2
STEP1

370 4-3. Do-it-yourself maintenance
Turn the bulb bases counter-
clockwise and remove them.Rear turn signal light
Stop/tail and rear side marker
light
■ Lights other than the above
If any of the lights listed below has burnt out, have it replaced by
your Toyota dealer.
● Front fog lights
● Front turn signal/parking lights
● High mounted stoplight
● Front side marker lights
● Tail lights
● Back-up lights
● License plate lightsSTEP2
